EMWBBGC900PH900 MHz Cordless Telephone

1 IMPORTANT SAFETY INSTRUCTIONS BEFORE USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETYPRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THERISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSONS,INCLUDING THE FOLLOWING: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the wall telephone jack and power outlet before cleaning. Do not use LIQUID CLEANERS OR AEROSOL CLEANERS. Use a damp cloth for cleaning. 4. Do not use this product near water; for example, near a bathtub, wash bowl, kitchen sink, laundry tub, swimming pool, or in a damp basement. 5. Do not place this product on an unstable cart, stand or table. The product may fall, causing serious damage to the product. 6. This product should never be placed near or over a radiator or heater. This product should not be placed in a built-in installation unless proper ventilation is provided. 7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company. 8. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be damaged by persons walking on it. 9. Do not overload wall outlets or extension cords, as this can result in fire or electric shock. 10. Never push objects of any kind into this product through cabinet slots, as they may touch dangerous voltage points or short out parts, which could result in fire or electric shock. Never spill liquid of any kind on this product. 11. To reduce the risk of electric shock, do not disassemble this product. Instead, if repair work is required, take the unit to a qualified technician. Opening or removing covers may expose you to dangerous voltages or other risks. Incorrect reassembly can cause electric shock when the appliance is subsequently used. 12. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:a. When the power supply cord or plug is damaged or frayed. b. If liquid has been spilled into the product. c. If the product has been exposed to rain or water. d. If the product does not operate normally and proper operating instructions have been followed, adjust only those controls that are covered by the operating instructions. Improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal operation. e. If the product has been dropped. f. If the product exhibits a distinct change in performance. 13. Avoid using telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electrical shock from lightning. 14. Do not use the telephone to report a gas leak in the vicinity of the leak. Goofy Cordless Animated Talking Telep hone Instruction Manual DM-515-A01 3 2 15. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions. IMPORTANTES MESURES DE SÉCURITÉ Certaines mesures de sécurité doivent être prises pendatn I'utilisation de matérial téléphonique afin de réduire risques d'incendie, de choc électrique et de blessures. En voici quelquesunes: 1. Ne pas utiliser I’appareil près de I’eau, p.ex., près d’une baignoire, d’un lavabo, d’un évier de cuisine, d’un bac à laver, dans un sous-sol humide ou près d’une piscine. 2. Éviter d’utiliser le téléphone (sauf s’il s’agit d’un appareil sans fil) pendant un orage électrique. Ceci peut présenter un risque de choc électrique causé par la foudre. 3. Ne pas utiliser I’appareil téléphonique pour signaler une fuite de gaz s’il est situé près de la fuite. 4. Utiliser seulement le cordon d’alimentation et le type de piles indiqués dans ce manuel. Ne pas jeter les piles dans le feu: elles peuvent exploser. Se conformer aux règlements pertinents quant à I'élimination des piles. CONSERVER CES INSTRUCTIONS SAVE THESE INSTRUCTIONSBATTERY PACK SAFETY INSTRUCTIONSCAUTION: To reduce the risk of fire or personal injury, read and follow these instructions:1. Use only the battery pack bundled in package box of your cordless telephone. FOR HANDSET:3.6V 600mAH Ni-Cd rechar g able batter y : 2. Do not open or mutilate battery pack because released electrolyte is corrosive and may cause damage to the eyes and skin. It may be toxic if swallowed. 3. Exercise care in handing battery pack in order not to short a battery with conducting materials such as rings, bracelets and keys. The battery or conductive material may overheat and cause burns. 4. Charge the battery pack provided with or identified for use with this product only in accordance with the instructions and limitations specified in this manual. 5. Observe proper polarity orientation between the battery pack and battery charger.FCC RULESThis device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone.NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.This equipment complies with part 68 of the FCC rules. On the bottom of the Base of this equipment is a label that contains, among other information, the FCC Registration Number, Ringer Equivalence Number (REN) and the Universal Service Order Code (USOC), which is RJ-11C, for this equipment. You must, upon request, provide this information to your telephone company. In most, but not all areas, the sum of the R EN’S of al l de vices connected to one line should not exceed five (5 .0).…

Text truncated - open the document above for the full version.

1 2 3 4 5 6 78 ABCD 8 7 6 5 4 3 2 1 D CBA Title Number Revision Size A3 Date: 3-Apr-2002 Sheet of File: D:\Doc\ bunny .ddb Drawn By: MCU CIRCUIT KS57C5308 CHARGE CIRCUIT EEPROM RESET CIRCUIT RF 900MHZ CORDLESS UAA3515 DUPLEXER TXVCO RXVCO ANT SCL SDA P3.0P3.1 CHGLED 24C02 Q2, D3-D5 Q11,D9, R59, C91 B4018 RXTX CHG+CHG- CHGDETRESET +5V RF VCC X3 3.58MHz C8930pF C9030pF X1 10.25MHz C4912pF C5015pF BATLOWPLLENPLLDATAPLLCLKTXDATARXDATA LED3INUSE LED DRIVE INUSE Q8 +5V LL3, LL4C18, C19, C20 C64, C65 LL1, LL2 BLOCK DIAGRAM FOR BUGS BUNNY CORDLESS BASE 0.0 2 0F 2ST HUANG LED DRIVE Q13 LED2CHGLED +5V POLARITYPROTECTIONCIRCUIT SURGE ARRESTER RING DET AUDIO CIRCUIT W583S 4 0 MOTORDRIVERSPEAKDRIVER Q17 Q3,Q4,Q5 A + - FUSE RELAY RL1 TEL-LINE ADJUSTMENT DC RETURN LOSS ADJUSTMENT AMPLIFIERANDSIDE TONENETWORKQ10 +5V RXAUDIOTXAUDIO RINGDET U5, Z3, Z4,R80, C72, D7 D1-D4 PAGE DEMO MOTOR POSITION VOLTAGE REGULATOR Q8, Z5 VCC1 REGULATOR U3, D6, D8 +9V +5V RF VCC +5V +5V BUZZOUT AUDIOVOLTAGETG5 TG6TG1 TG3TG2 LOOP RELAY DRIVER Q7 LOOP 1 2 3 4 5 6 78 ABCD 8 7 6 5 4 3 2 1 D CBA Title Number Revision Size A3 Date: 3-Apr-2002 Sheet of File: D:\Doc\ bunny .ddb Drawn By: MCU CIRCUIT KS57C5308 KEY BOARD CHARGE CIRCUITBUZZER CIRCUIT EEPROM RESET CIRCUIT RF 900MHZ CORDLESS UAA3515 MIC CIRCUIT DUPLEXER TXVCO RXVCO ANT KR1-KR7KC1-KC3 SCL SDA P3.0P3.1 BUZZ Q5, C68, D2 24C02 Q2, D3-D5 Q3,Q4,Q6,D1 Q7 B4040 RXTX RECEIVERMIC RX-AUDIO TX-AUDIO CHG+CHG- CHGDETRESET BATTERY3.6V VBAT VBAT VBAT VBAT VBAT VBAT VBAT X2 3.58MHz C7030pF C7130pF X1 10.25MHz C4912pF C5015pF BATLOWPLLENPLLDATAPLLCLKTXDATARXDATA LED1LED LED DRIVE INUSE Q1 VBAT LL3, LL4C18, C19, C20 C64, C65 LL1, LL2 BLOCK DIAGRAM FOR BUGS BUNNY CORDLESS HANDSET 0.0 1 0F 2ST HUANG

goofy31 (640x480x16M jpeg) goofy21 (640x480x16M jpeg) goofy11 (640x480x16M jpeg) 2 (640x480x16M tiff) 1 (640x480x16M tiff) 4 (640x480x16M tiff) handset3 (640x480x16M jpeg) handset2 (640x480x16M jpeg)

KCL TECHNOLOGY LTD. TITLE: FCC PART 68 LABELP/N: ML-872-B01ALL DIM IN: mmDRAWN: LYQ MODEL:MATERIAL: CHK: SCALE: 2:1 REV: 3 TOL: +-0.1 SHEET: 1 OF 1 APR: DATE: 2002. 9. 12 DATE: DATE: SCALE: 2:1 BUGS BUNNY CORDLESS NOTES:1. MATERIAL: COMMON PAPER STICKER LABEL;2. TEXT COLOR: BLACK;3. FINISHING: VARNISH;4. SIZE: 50.0 x 30.0 mm. 50.0mm 30.0mm R3.0TYP.4 TM TELEMANIAMODEL: BUGS BUNNY CORDLESS ANIMATED TALKING TELEPHONE COMPLIES WITH 47 CFR PART 68 REQUIREMENTS REGISTRATION # : EMWW907BBBGC900PH RINGER EQUIVALENCE : 0.7B KCL TECHNOLOGY LTD. MADE IN CHINA U.S.O.C: RJ11C HAC FCC ID: EMWBBGC900PH NOTES: 2. BOTTOM COLOR: BLACK;3. WHITE PRINTING;4. FINISHING: VARNISH. 1. MATERIAL: COMMON PAPER; KCL TECHNOLOGY LTD. REV : 2 TOL: +-0.1 TITLE: FCC HANDSET LABELP/N: ML-937-B01ALL DIM IN: mmDRAWN: LYQDATE: 2002. 9. 12 MODEL: Bugs Bunny & Goofy Cordless Telephone MATERIAL:CHK:DATE: SHEET: 1 OF 1 APR:DATE: SCALE: 2 : 1 SCALE: 2 : 1 24.0mm 9.0mm R0.5 TYP4. FCC ID:EMWBBGC900PH

CIRCUIT DESCPITION A. Audio transmit The handset microphone’s signal passed through C43, R19 to UAA3515 IC pin27. After amplifier, then output at pin28, then pass through C45 to VCO circuit, and TXPOWER amplifier inside UAA3515, and pass through C15 to DUPLEXER F1, then transmit by the ANTENNA. The base unit antenna receives the carrier wave, then pass through to DUPLEXER, then pass through the filter which consisted by C2, L2 C3, L1, L5, C5, C4 to UAA3515, And UAA3515 have a single architecture with integrated image rejection mixer, the signal pass thought it, then output at pin 63, and filtered by external two IF (10.7MHz F3, F4) filters and amplified by internal two amplifiers. Then have demodulator and AMP at IC internal. Then transmit pass through to pin46 input, then pass through pin42 to C79, C99, R49, R50, Q10, then to TRANSFORMER T1, then pass through Q9, C95, C96 to POLARITY PROTECTION D1, D2, D3, D4, then pass through R99, RL1, Z1 to TELEPHONE LINE. B. Audio receive TELEPHONE LINE receives audio signal, pass through R99, RL1, Z1 to POLARITY PROTECTIO CIRCUIT D1, D2, D3, D4, then pass through Q9, C95, C96 to TRANSFORMER T1, then pass through Q10, R90, C108, C102, R100, R51, C100 and C43, R19 to UAA3515 IC pin27 input, pin28 output, then pass through C45 pin29 to compressor and hard limiter, then pass through C42, R18 to TXPOWER AMPLIFIER, then pass through C15 to DUPLEXER F1, then pass through the base ANTENNA to transmit. The handset antenna receives the carrier wave, then pass through to DUPLEXER, then pass through the filter which consisted by C2, L2 C3, L1, L5, C5, C4 to UAA3515, And UAA3515 have a single architecture with integrated image rejection mixer, the signal pass thought it, then output at pin 63, and filtered by external two IF (10.7MHz F3, F4) filters and amplified by internal two amplifiers. Then have demodulator and AMP at IC internal. Then transmit pass through to pin46 input to earpiece amplifier. Then pass through REC1. C. Data transmit and receive The handset TX data from MCU U2 pin 14 output, then pass through C17, R8 to UAA3515 VCO circuit, then pass to TXPOWER amplifier, then pass through C15 to DUPLEXER F1, then pass to ANTENNA to transmit. The base unit antenna receives the carrier wave, then pass through to DUPLEXER, then pass through the filter which consisted by C2, L2 C3, L1, L5, C5, C4 to UAA3515, And UAA3515 have a single architecture with integrated image rejection mixer, the signal pass thought it, then output at pin 63, and filtered by external two IF (10.7MHz F3, F4) filters and amplified by internal two amplifiers. Then have demodulator and AMP at IC internal. Then transmit pass through to pin40 input, then pass through pin39 to MCU U4 pin25. The handset TX data from MCU U4 pin 14 output, then pass through C17, R8 to UAA3515 VCO circuit, then pass to TXPOWER amplifier, then pass through C15 to DUPLEXER F1, then pass to ANTENNA to transmit. The base unit antenna receives the carrier wave, then pass through to DUPLEXER, then pass through the filter which consisted by C2, L2 C3, L1, L5, C5, C4 to UAA3515, And UAA3515 have a single architecture with integrated image rejection mixer, the signal pass thought it, then output at pin 63, and filtered by external two IF (10.7MHz F3, F4) filters and amplified by internal two amplifiers. Then have demodulator and AMP at IC internal. Then transmit pass through to pin40 input, then pass through pin39 to MCU pin25.

Applicant: KCL Technology Ltd. FCC ID: EMWBBGC900PH Report #: K\KCLEMW\710BHT2\710BHT2TestReport.doc Page #: Table of Contents TABLE OF CONTENTS APPLICANT: KCL TECHNOLOGY LTD. FCC ID: EMWBBGC900PH TEST REPORT CONTAINING: PAGE 1-5...........TEST EQUIPMENT LIST PAGE 6.............TEST PROCEDURE PAGE 7-8...........RADIATION INTERFERENCE TEST DATA PAGE 9.............OCCUPIED BANDWIDTH PAGE 10-11.........OCCUPIED BANDWIDTH PLOTS PAGE 12............POWERLINE CONDUCTED PAGE 13-16.........POWERLINE CONDUCTED PLOTS EXHIBIT ATTACHMENTS: EXHIBIT 1...........FCC ID LABEL SAMPLE EXHIBIT 2...........SKETCH OF FCC ID LABEL LOCATION EXHIBIT 3...........BLOCK DIAGRAMS EXHIBIT 4...........SCHEMATICS EXHIBIT 5...........CIRCUIT DESCRIPTION EXHIBIT 6...........USERS MANUAL EXHIBIT 7...........EXTERNAL PHOTOGRAPHS EXHIBIT 8...........INTERNAL PHOTOGRAPH – BASE COMPONENT VIEW EXHIBIT 9...........INTERNAL PHOTOGRAPH – BASE COPPER VIEW EXHIBIT 10..........INTERNAL PHOTOGRAPH – HANDSET COMPONENT VIEW EXHIBIT 11..........INTERNAL PHOTOGRAPH – HANDSET COPPER VIEW EXHIBIT 12..........RADIATED TEST SETUP PHOTOGRAPH – BASE EXHIBIT 13..........RADIATED TEST SETUP PHOTOGRAPH – HANDSET EXHIBIT 14..........CONDUCTED TEST SETUP PHOTOGRAPH Applicant: KCL Technology Ltd. FCC ID: EMWBBGC900PH Report #: K\KCLEMW\710BHT2\710BHT2TestReport.doc Page #: 1 of 16 Equipment List DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS X 3-Meter OATS TEI N/A N/A Listed 12/22/99 12/22/02 3/10-Meter OATS TEI N/A N/A Listed 3/26/01 3/26/04 X Receiver, Beige Tower X Spectrum Analyzer (Tan) HP 8566B Opt 462 3138A07786 3144A20661 CAL 8/31/01 8/31/02 X RF Preselector (Tan) HP 85685A 3221A01400 CAL 8/31/01 8/31/02 X Quasi-Peak Adapter (Tan) HP 85650A 3303A01690 CAL 8/31/01 8/31/02 Receiver, Blue Tower Spectrum Analyzer (Blue) HP 8568B 2928A04729 2848A18049 CHAR 10/22/01 10/22/02 RF Preselector (Blue) HP 85685A 2926A00983 CHAR 10/22/01 10/22/02 Quasi-Peak Adapter (Blue) HP 85650A 2811A01279 CHAR 10/22/01 10/22/02 Biconnical Antenna Electro-Metrics BIA-25 1171 CAL 4/26/01 4/26/03 X Biconnical Antenna Eaton 94455-1 1096 CAL 10/1/01 10/1/02 Biconnical Antenna Eaton 94455-1 1057 CHAR 3/15/00 3/15/01 BiconiLog Antenna EMCO 3143 9409-1043 X Log-Periodic Antenna Electro-Metrics LPA-25 1122 CAL 10/2/01 10/2/02 Log-Periodic Antenna Electro-Metrics EM-6950 632 CHAR 10/15/01 10/15/02 Applicant: KCL Technology Ltd. FCC ID: EMWBBGC900PH Report #: K\KCLEMW\710BHT2\710BHT2TestReport.doc Page #: 2 of 16 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Log-Periodic Antenna Electro-Metrics LPA-30 409 CHAR 10/16/01 10/16/02 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 152 CAL 3/21/01 3/21/02 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 153 CHAR 11/24/00 11/24/01 Double-Ridged Horn Antenna Electro-Metrics RGA-180 2319 CAL 12/19/01 12/19/02 Horn Antenna Electro-Metrics EM-6961 6246 CAL 3/21/01 3/21/02 Horn Antenna ATM 19-443-6R None No Cal Required Passive Loop Antenna EMC Test Systems EMCO 6512 9706-1211 CHAR 7/10/01 7/10/02 Line Impedance Stabilization . . . Electro-Metrics ANS-25/2 2604 CAL 10/9/01 10/9/02 Line Impedance Stabilization . . . Electro-Metrics EM-7820 2682 CAL 3/16/01 3/16/02 Termaline Wattmeter Bird Electronic Corporation 611 16405 CAL 5/25/99 (5/25/00) Termaline Wattmeter Bird Electronic Corporation 6104 1926 CAL 12/12/01 12/12/02 Oscilloscope Tektronix 2230 300572 CHAR 2/1/01 2/1/02 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 1/22/02 1/22/03 AC Voltmeter HP 400FL 2213A14499 CAL 10/9/01 10/9/02 AC Voltmeter HP 400FL 2213A14261 CHAR 10/15/01 10/15/02 AC Voltmeter HP 400FL 2213A14728 CHAR 10/15/01 10/15/02 X Digital Multimeter Fluke 77 35053830 CHAR 1/8/02 1/8/03 Applicant: KCL Technology Ltd. FCC ID: EMWBBGC900PH Report #: K\KCLEMW\710BHT2\710BHT2TestReport.doc Page #: 3 of 16 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Digital Multimeter Fluke 77 43850817 CHAR 1/8/02 1/8/03 Digital Multimeter HP E2377A 2927J05849 CHAR 1/8/02 1/8/03 Multimeter Fluke FLUKE-77-3 79510405 CAL 9/26/01 9/26/02 Peak Power Meter HP 8900C 2131A00545 CHAR 1/26/01 1/26/02 Digital Thermometer Fluke 2166A 42032 CAL 1/16/02 1/16/03 Thermometer Traulsen SK-128 CHAR 1/22/02 1/22/03 X Temp/Humidity gauge EXTech 44577F E000901 CHAR 1/22/02 1/22/03 Frequency Counter HP 5352B 2632A00165 CAL 11/28/01 11/28/02 Power Sensor Agilent Technologies 84811A 2551A02705 CAL 1/26/01 1/26/02 Injection Probe Fischer Custom Communications F-120-9A 270 CAL 6/1/01 6/1/02 Service Monitor IFR FM/AM 500A 5182 CAL 11/22/00 11/22/01 Comm. Serv. Monitor IFR FM/AM 1200S 6593 CAL 11/12/99 11/12/00 Signal Generator HP 8640B 2308A21464 CAL 11/15/01 11/15/02 Modulation Analyzer HP 8901A 3435A06868 CAL 9/5/01 9/5/02 Power Line Coupling/ Decoupling Network Fischer Custom Communications FCC-801- M2-16A 01048 CAL 8/29/01 8/29/02 Power Line Coupling/ Decoupling Network Fischer Custom Communications FCC-801- M3-16A 01060 CAL 8/29/01 8/29/02 Applicant: KCL Technology Ltd. FCC ID: EMWBBGC900PH Report #: K\KCLEMW\710BHT2\710BHT2TestReport.doc Page #: 4 of 16 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS VHF/UHF Current Probe Fischer Custom Communications F-52 130 CAL 8/30/01 8/30/02 Passive Impedance Adapter Fischer Custom Communications FCC-801- 150-50-CDN 01117 & 01118 CAL 8/29/01 8/29/02 Radiating Field Coil Fischer Custom Communications F-1000-4- 8/9/10-L-1M 9859 CAL 10/15/98 10/15/99 Near Field Probe HP HP11940A 2650A02748 CHAR 2/1/01 2/1/02 BandReject Filter Lorch Microwave 5BR4-2400/ 60-N Z1 CHAR 3/2/01 3/2/02 BandReject Filter Lorch Microwave 6BR6-2442/ 300-N Z1 CHAR 3/2/01 3/2/02 BandReject Filter Lorch Microwave 5BR4-10525/ 900-S Z1 CHAR 3/2/01 3/2/02 High Pas Filter Microlab HA-10N CHAR 10/4/01 10/4/02 Audio Oscillator HP 653A 832-00260 CHAR 3/1/01 3/1/02 Frequency Counter HP 5382A 1620A03535 CHAR 3/2/01 3/2/02 Frequency Counter HP 5385A 3242A07460 CHAR 12/11/01 12/11/02 Preamplifier HP 8449B-H02 3008A00372 CHAR 3/4/01 3/4/02 Amplifier HP 11975A 2738A01969 CHAR…
