EP9-TMXM061Fitness Watch with integrated Radios 1) WCDMA (850/1800/2100/R99+HSDPA) 2) BT (v3.0+EDR+LE) 3) GPS

Timex IRONMAN One GPS+ Watch Quick Start Cover <<TO BE CREATED BY TIMEX>> 2 CONTENTS To be Constructed Based on Final Outline ..................................................................................... x Thank you for purchasing the Timex IRONMAN One GPS+ watch! Read this Quick Start Guide and begin enjoying your watch right away. Be sure to visit www.OneGPS.Timex.com for the latest product information and other features. IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS 1. To prevent risk of fire, chemical burn, electrolyte leak, and/or injury from the unit's internal Lithium-polymer battery: a. Do not attempt to remove the case-back or exterior shell of the unit, or to remove its non-user-replaceable battery. b. Do not leave the unit exposed to a heat source or in a high-temperature location (such as in the sun or in an unattended vehicle). To prevent damage, store the unit out of direct sunlight. c. Do not puncture or incinerate the unit. d. When storing the unit for an extended time, keep it in the temperature range 32 to 77 F (0 to 25 C). e. Charge the unit only within the temperature range 32 to 113 F (0 to 45 C). f. Do not operate the unit outside the temperature range -4 to 131 F (-20 to 55 C). g. Contact your local waste disposal department to properly recycle or dispose of the unit or its battery. 2. Use only the charging cable supplied with the unit. 3. This unit is not a medical device and is not recommended for use by persons with serious heart conditions. Always consult your physician before beginning or modifying an exercise program. 4. Do not attempt to read the unit's display while moving: this is unsafe and distracting, and could result in an accident or collision. Read the display only when you can safely do so. See the instructions for details. WHAT’S INCLUDED  IRONMAN One GPS+ watch  Charging cable  Bluetooth® Heart Rate Sensor (for applicable style) GETTING STARTED Congratulations on your purchase of the Timex IRONMAN ONE GPS+ watch. Use this Quick Start Guide to get your watch set up to use right away. 3 INTRODUCING THE WATCH TOUCH SCREEN <<Full-color touch screen accesses the watch's apps......etc.>> [[if room allows, add bullet points for apps, non-obvious touch screen items]] FITNESS <<xxxxxx.>> MUSIC <<xxxxxx.>> CONTACTS <<xxxxxx.>> INBOX <<xxxxxx.>> CLOCK <<xxxxxx.>> SETTINGS <<xxxxxx.>> Combined with the touch-sensitive display, the four side-mounted buttons have specific functions. POWER  Long press: Turns the watch on or off.  Short press: Locks the touch screen. SETTINGS INBOX CONTACTS FITNESS BATTERY INDICATOR GPS, BLUETOOTH, 3G INDICATORS MUSIC TIME DISPLAY POWER SYMBOL MENU SYMBOL CONFIGURE SYMBOL TOUCH SCREEN ACTIVATION FITNESS SYMBOL SUNLGHT-READABLE, COLOR QUALCOMM® MIRASOL™ DISPLAY Will use product rendering 4 MENU  Long press: Turns on the front light  Short press: Opens the main menu from any mode CONFIGURATION  Long press: Sets the single function of the button: Split, Music Volume, or SOS Message  Short press: Performs the set function.. RUN  Long press: Starts or ends workout. Launches fitness workout countdown, if programmed.  Short press: Opens Run Preview screen. Starts, pauses, or resumes workout. Launches countdown for workout start, if programmed. CHARGING THE WATCH Before activating the watch, fully charge the battery using your computer as a power source. 1. Clip the contacts of the charging cable into the watch's case back. 2. Insert the free end of the charging cable into a powered USB port. NOTE: If using a USB adapter, plug the cable into the adapter, and then plug the adapter into a wall outlet. 3. Let the battery charge at least 4 hours until the watch indicates “100%”. FIRST-TIME SETUP ACTIVATE THE WATCH 1. Refer to the instructions on the watch display to activate your account and your watch. 2. Use an Internet-connected device to go to www.OneGPS.Timex.com. 3. Click on “New Account” to enter your information and to receive instructions for watch activation. WATCH SETTINGS Refer to Internet-connected device’s screen for settings to customize your ONE GPS+ watch. NOTE: You can make settings to the watch directly from the touch screen. Please refer to the full-length User Guide found at www.Timex.com/Manuals. NAVIGATING THE WATCH Use the touch screen to access the watch's modes and features.  Swipe to move through mode screens and settings.  Tap icons and fields to select options and enter settings.  The keyboard appears automatically as needed: o Swipe to see more characters. o Tap character group to open, then tap character. Or, press and hold key group to open, then slide to character. o Long-press to see special characters. o Tap in text field to enter a space. Double-tap text field to backspace (or use backspace key). o Press and hold text box for cursor control, scroll text to relocate cursor. TROUBLESHOOTING For detailed troubleshooting, consult the web site at www.OneGPS.Timex.com FULL INSTRUCTIONS 5 For detailed instructions, consult the full-length User Guide posted at: www.Timex.com/Manuals. For instructional videos, visit www.YouTube.com/TimexUSA. WATER RESISTANCE The watch is water-resistant to 50 m (164 ft). You can swim with the watch, but you cannot use GPS while swimming. Water-Resistance Depth Water Pressure Below Surface 50 m/164 ft 86 PSIA* *Pounds per square inch absolute WARNING: To maintain water resistance, do not press watch buttons under water.  The watch is water-resistant only while the lens, push buttons, and case remain intact.  Do not use the watch for diving.  Rinse the watch with fresh water after every exposure to perspiration or salt water. WARRANTY & SERVICE FCC/INDUSTRY CANADA This device complies with part 15 of the FCC rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that …

Text truncated - open the document above for the full version.

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: EP9-TMXM061 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Bill of Materials Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until Oct. 31, 2014. External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Sam Everett Quality Regulatory Engineer Timex Group USA Inc. Sept, 16, 2014

Qualcomm Connected Experiences, Inc. Confidential and Proprietary – Qualcomm Connected Experiences, Inc. NO PUBLIC DISCLOSURE PERMITTED: Please report postings of this document on public servers or websites to: [email protected]. Restricted Distribution: Not to be distributed to anyone who is not an employee of either Qualcomm or its subsidiaries without the express approval of Qualcomm’s Configuration Management. Not to be used, copied, reproduced, or modified in whole or in part, nor its contents revealed in any manner to others without the express written permission of Qualcomm Connected Experiences, Inc. Qualcomm is a trademark of QUALCOMM Incorporated, registered in the United States and other countries. All QUALCOMM Incorporated trademarks are used with permission. Other product and brand names may be trademarks or registered trademarks of their respective owners. This technical data may be subject to U.S. and international export, re-export or transfer (“export”) laws. Diversion contrary to U.S. and international law is strictly prohibited. Qualcomm Connected Experiences, Inc. 5775 Morehouse Drive San Diego, CA 92121 U.S.A. © 2014 Qualcomm Connected Experiences, Inc. All rights reserved. Geneva Exhibit Label 80-CA149-8 Rev. A August 19, 2014 80-CA149-8 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 2 Confidential and Proprietary – Qualcomm Connected Experiences, Inc. Revision history Revision Date Description A August 2014 Initial release 80-CA149-8 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 3 Confidential and Proprietary – Qualcomm Connected Experiences, Inc. Contents 1 Label Information ....................................................................................................... 4 Figures Figure 1-1 Label information ....................................................................................................................... 4 80-CA149-8 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 4 Confidential and Proprietary – Qualcomm Connected Experiences, Inc. 1 Label Information The label on the back of the sports watch contains the following information:  Model No.: M061  Federal Communications Commission (FCC) ID: EP9-TMXM061  Integrated Circuit (IC): 3348A-TMXM061 Figure 1-1 Label information

SAR EVALUATION REPORT FCC 47 CFR § 2.1093 IEEE Std 1528-2013 For WCDMA Band V, II and Bluetooth Smart Watch Model: M061 FCC ID: EP9-TMXM061 Report Number: 14U17447-S4A Issue Date: 9/23/2014 Prepared for TIMEX GROUP USA, INC. 555 CHRISTIAN ROAD MIDDLEBURY, CT 06762 Prepared by UL Verification Services Inc. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 Report No.: 14U17447-S4A Issue Date: 9/23/2014 FCC ID: EP9-TMXM061 Page 2 of 22 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. REVISION HISTORY Rev. Issue Date Revisions Revised By -- 9/18/2014 Initial Issue -- A 9/23/2014 Section 12.2 – Corrected ratio values to 1.2 Dave Weaver Report No.: 14U17447-S4A Issue Date: 9/23/2014 FCC ID: EP9-TMXM061 Page 3 of 22 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. Table of Contents 1. Attestation of Test Results ......................................................................................................... 5 2. Test Specification, Methods and Procedures ............................................................................ 6 3. Facilities and Accreditation ........................................................................................................ 6 4. SAR Measurement System & Test Equipment .......................................................................... 7 4.1. SAR Measurement System ........................................................................................................ 7 4.2. Test Equipment .......................................................................................................................... 8 5. Measurement Uncertainty ........................................................................................................... 9 6. Device Under Test (DUT) Information ...................................................................................... 10 6.1. DUT Description ...................................................................................................................... 10 6.2. Wireless Technologies ............................................................................................................. 10 6.3. Nominal and Maximum Output Power ...................................................................................... 10 6.4. Simultaneous Transmission Condition ..................................................................................... 10 6.5. Testing Rationale ..................................................................................................................... 10 7. RF Exposure Conditions (Test Configurations) ...................................................................... 11 7.1. Extremity (Wrist) ...................................................................................................................... 11 7.2. Additional Test Considerations ................................................................................................ 11 8. Conducted Output Power Measurements ................................................................................ 12 8.1. WCDMA Band V and II ............................................................................................................ 12 8.2. Bluetooth ................................................................................................................................. 13 9. Dielectric Property Measurements ........................................................................................... 14 9.1. Tissue Dielectric Parameters ................................................................................................... 14 9.2. Dielectric Property Measurements Results .............................................................................. 16 10. System Check ............................................................................................................................ 17 10.1. Reference Target SAR Values ............................................................................................. 17 10.2. System Check Results ......................................................................................................... 17 11. Measured and Reported (Scaled) SAR Results ....................................................................... 18 11.1. WCDMA Band V Measured SAR Results: Pre-Duty Cycle ................................................... 18 11.2. WCDMA Band V with Time Based Averaging Applied .......................................................... 18 11.3. WCDMA Band II Measured SAR Results: Pre-Duty cycle .................................................... 18 11.4. WCDMA Band II Results with Time Based Averaging Applied ............................................. 18 11.5. Bluetooth .............................................................................................................................. 19 11.5.1. Standalone SAR Test Exclusion Considerations ........................................................... 19 Report No.: 14U17447-S4A Issue Date: 9/23/2014 FCC ID: EP9-TMXM061 Page 4 of 22 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. 11.5.2. Estimated SAR .............................................................................................................. 19 12. SAR Measurement Variability ................................................................................................... 20 12.1. The Highest Measured SAR Configuration in Each Frequency Band ................................... 20 12.2. Repeated Measurement Results .......................................................................................... 20 13. Simultaneous Transmission SAR Analysis ............…

Text truncated - open the document above for the full version.

Report No.: 14U17447-S4 Issue Date: 9/18/2014 FCC ID: EP9-TMXM061 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. Appendix 14.7: Duty Cycle Calculation 1. Duty Cycle Calculation This section describes the approach to demonstrate RF Exposure compliance for the Ironman ONE GPS+ (FCC ID EP9-TMXM061) Model M061fitness watch with reference to FCC evaluation procedures for Low Transmission duty factor devices as defined in KDB 447498 D01 V05r02. The limited use cases of the M061 sports watch make it an ideal candidate for applying the duty factor procedures to adjust measured SAR levels to reflect the actual limited transmission characteristics of the device. The M061 enables software controls that limit the uplink transmissions to defined lengths of time as documented below. Additional information is contained within the confidential document “Ironman ONE GPS+ 3G Duty Factor Derivation” filed with this application. 1.1. Compliance Approach The Ironman ONE GPS+ Model M061 product functions such that the WCDMA radio transmits for a period of time in support of the limited data upload model as defined in section 1.2. Section 1.3.2 calculates duty factors for the M061 use cases based on conservatively slow 3G uplink data transmission rates supported by a WCDMA/HSDPA network. The conservative duty factors are derived from the parameters (e.g. use cases, data rates, uplink payload sizes) defined in Section 3. The duty factor is used to correct the measured SAR values that reflect the transmission characteristics of the device. A standalone SAR report will reference this document and include measured SAR data adjusted by the duty factor defined in this document to demonstrate compliance for the M061 based on the device transmission characteristics. 1.1.1. HSDPA uplink and downlink transmission rates The M061 supports WCDMA Release 99 and Release 5 Category 6 HSDPA with the uplink/downlink transmission rates show in Error! Reference source not found.. shows the 3GPP technology roadmap and associated data rates for reference. The M061 does not support HSUPA or HSPA+ supported after 3GPP Release 5. Table 1-1 3GPP uplink throughput data transmission rates Technology Uplink transmission rate Downlink transmission rate Standards reference WCDMA Release 99 9.6 to 384 kbps 9.6 to 384 kbps 3GPP 25.306 HSDPA Category 6 9.6 to 384 kbps 1.8 to 3.6 Mbps 3GPP 25.306 1.1 M061Use Case Definitions This section defines the M061 modes of operation that utilize the WCDMA modem. Future features made available with software updates will need to operate within the constraints defined in this document. Report No.: 14U17447-S4 Issue Date: 9/18/2014 FCC ID: EP9-TMXM061 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. The M061 does not have an open app store to add third-party applications features. All features must be provided by the device grantee. 1.1.1 Local tracking mode The user activates the device to record (internally to device) location and physical activity data. The data is stored locally on the device until the stored data size reaches approximately 132k upon which the device uploads the stored data to M061 server in background while continuing the user workout session. Upon completion of user workout session, the device initiates a data call to upload the workout data to the M061 server. The device will complete the request only after checking when the last upload event occurred and thus ensuring SAR compliance by enforcing transmission time duty factor. When this event occurs, the device will first check to see if the previous transmission start time is greater than 6mins. If not then the device will wait until that condition is met, but if yes, then the device will start a 150sec max allowed upload time timer and will start its upload attempts of the user data including retries if required. This total allowed upload timer of 150sec includes set up time/upload time/retry time. If the device is unable to upload all the user data within 150sec, then the device will store it until next upload attempt event is triggered (user data size reaches 132kB). The key points to ensure SAR compliance during Local Tracking use case are the following: - Maximum upload time bound by timer of 150sec (satisfies SAR compliance limits) followed by enforced upload not allowed time for 210sec (41.7% duty factor based on period of 6mins) - Default time between start of two transmissions is much greater than 6mins as device waits for 132kB of data to accumulate before attempting to upload. The maximum time the device is configured to upload continuously is set to be 150 sec followed by a minimum of a 210 sec no upload time duration (41.7% Duty Factor). 1.1.2 Live tracking mode The user may choose to initiate a live tracking fitness session which establishes a data call to upload location and physical activity data every 60 seconds. The device location and physical activity data can then be viewed by spectators via a website or mobile client application. The user cannot increase the frequency to provide updates faster than once per 60 seconds. The device will complete the live tracking upload only after checking when the last upload event occurred and thus ensuring SAR compliance by enforcing transmission time duty factor. Live tracking is similar to local tracking but the user data is a much smaller data payload and the M061 limits the periodicity of uploads to once per minute. The key points to ensure SAR compliance during Live Tracking use case are the following: - Maximum upload time bound by timer of 25sec (satisfies SAR compliance limits) followed by enforced upload not allowed time for 35sec (41.7% duty factor based on period of 6mins) - Default time between start of two transmissions is 1min during which approximately 6kB of data is accumulated…

Text truncated - open the document above for the full version.

Plot No. 1 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 9/11/2014 W-CDMA Band V Frequency: 836.6 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used (interpolated): f = 836.6 MHz; σ = 1.017 S/m; ε r = 53.013; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE3 Sn427; Calibrated: 1/21/2014 - Probe: EX3DV4 - SN3902; ConvF(9.86, 9.86, 9.86); Calibrated: 5/19/2014; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: SAM; Type: QD000P40CD; Serial: TP 1751 LHS 2/Rel. 99 RMC 12.2 kbps ch.4183/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 4.72 W/kg LHS 2/Rel. 99 RMC 12.2 kbps ch.4183/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 70.023 V/m; Power Drift = 0.10 dB Peak SAR (extrapolated) = 9.19 W/kg SAR(1 g) = 4.84 W/kg; SAR(10 g) = 2.83 W/kg Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 5.73 W/kg 0 dB = 5.73 W/kg = 7.58 dBW/kg Plot No. 2 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 9/11/2014 W-CDMA Band II Frequency: 1880 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used: f = 1880 MHz; σ = 1.564 S/m; ε r = 52.123; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE3 Sn427; Calibrated: 1/21/2014 - Probe: EX3DV4 - SN3902; ConvF(7.8, 7.8, 7.8); Calibrated: 5/19/2014; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: SAM; Type: QD000P40CD; Serial: TP 1751 LHS 2/Rel. 99 RMC 12.2 kbps ch.9400 2/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 7.93 W/kg LHS 2/Rel. 99 RMC 12.2 kbps ch.9400 2/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 74.172 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 17.4 W/kg SAR(1 g) = 9.24 W/kg; SAR(10 g) = 4.34 W/kg Maximum value of SAR (measured) = 13.1 W/kg 0 dB = 13.1 W/kg = 11.17 dBW/kg

Plot No. 1 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 9/9/2014 SystemPerformanceCheck-D835V2 SN 4d002 Frequency: 835 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used: f = 835 MHz; σ = 1.015 S/m; ε r = 53.03; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE3 Sn427; Calibrated: 1/21/2014 - Probe: EX3DV4 - SN3902; ConvF(9.86, 9.86, 9.86); Calibrated: 5/19/2014; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: SAM; Type: QD000P40CD; Serial: TP 1751 Body/Pin=100 mW/Area Scan (61x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Reference Value = 34.736 V/m; Power Drift = 0.02 dB Fast SAR: SAR(1 g) = 1.05 W/kg; SAR(10 g) = 0.699 W/kg Maximum value of SAR (interpolated) = 1.24 W/kg Body/Pin=100 mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 34.736 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 1.52 W/kg SAR(1 g) = 1.02 W/kg; SAR(10 g) = 0.671 W/kg Maximum value of SAR (measured) = 1.24 W/kg 0 dB = 1.24 W/kg = 0.93 dBW/kg Plot No. 2 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 9/9/2014 SystemPerformanceCheck-D835V2 SN 4d002 Frequency: 835 MHz; Duty Cycle: 1:1 Body/Pin=100 mW/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 1.20 W/kg Plot No. 3 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 9/10/2014 20140910_SystemPerformanceCheck-D1900V2 SN 5d043 Frequency: 1900 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used: f = 1900 MHz; σ = 1.581 S/m; ε r = 52.07; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Averaged Fast SAR: Polynomial fit - Electronics: DAE3 Sn427; Calibrated: 1/21/2014 - Probe: EX3DV4 - SN3902; ConvF(7.8, 7.8, 7.8); Calibrated: 5/19/2014; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: SAM; Type: QD000P40CD; Serial: TP 1751 Body/Pin=100 mW/Area Scan (61x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Reference Value = 53.529 V/m; Power Drift = 0.16 dB Fast SAR: SAR(1 g) = 3.85 W/kg; SAR(10 g) = 1.96 W/kg Maximum value of SAR (interpolated) = 5.19 W/kg Body/Pin=100 mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 53.529 V/m; Power Drift = 0.16 dB Peak SAR (extrapolated) = 7.15 W/kg SAR(1 g) = 3.9 W/kg; SAR(10 g) = 2.01 W/kg Maximum value of SAR (measured) = 5.27 W/kg 0 dB = 5.27 W/kg = 7.22 dBW/kg Plot No. 4 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 9/10/2014 20140910_SystemPerformanceCheck-D1900V2 SN 5d043 Frequency: 1900 MHz; Duty Cycle: 1:1 Body/Pin=100 mW/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 4.49 W/kg

FCC CFR47 PART 22 SUBPART H FCC CFR47 PART 24 SUBPART E INDUSTRY CANADA RSS-132 ISSUE 3 INDUSTRY CANADA RSS-133 ISSUE 6 CERTIFICATION TEST REPORT FOR Fitness Watch with integrated Radios 1) WCDMA (850/1800/2100/R99+HSDPA) 2) BT (v3.0+EDR+LE) 3) GPS MODEL NUMBER: M061 FCC ID: EP9-TMXM061 IC: 3348A-TMXM061 REPORT NUMBER: 14U17447-1 ISSUE DATE: AUGUST 4, 2014 Prepared for TIMEX GROUP USA, INC. 555 CHRISTIAN ROAD MIDDLEBURY , CT 06762 Prepared by UL VERIFICATION SERVICES 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 14U17447-1 DATE: August 4, 2014 FCC ID: EP9-TMXM061 IC: 3348A-TMXM061 UL VERFICATION SERVICES FORM ID: FCC_22_24_27_90 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 ULVS Confidential Revision History Rev. Issue Date Revisions Revised By - 08/04/14 Initial Issue REPORT NO: 14U17447-1 DATE: August 4, 2014 FCC ID: EP9-TMXM061 IC: 3348A-TMXM061 UL VERFICATION SERVICES FORM ID: FCC_22_24_27_90 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 ULVS Confidential TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ............................................................................. 5 2. TEST METHODOLOGY ................................................................................................. 6 3. FACILITIES AND ACCREDITATION ............................................................................. 6 4. CALIBRATION AND UNCERTAINTY ............................................................................ 6 4.1. MEASURING INSTRUMENT CALIBRATION .............................................................. 6 4.2. SAMPLE CALCULATION ............................................................................................ 6 4.3. MEASUREMENT UNCERTAINTY ............................................................................... 7 5. EQUIPMENT UNDER TEST .......................................................................................... 8 5.1. DESCRIPTION OF EUT .............................................................................................. 8 5.2. MAXIMUM OUTPUT POWER...................................................................................... 8 5.3. DESCRIPTION OF AVAILABLE ANTENNAS .............................................................. 9 5.4. DESCRIPTION OF TEST SETUP ...............................................................................10 6. TEST AND MEASUREMENT EQUIPMENT ..................................................................13 7. Summary Table ................................................................................................…

Text truncated - open the document above for the full version.
