ESD-SA824894NERugged handheld computer with integrated wireless

October 2000 APREL Project No.: Consulting * Research * Training * Certification Testing Since 1981 FCC ID: ESD-SA824894NE Exhibit 9 User’s Manual User’s Guide 0-15-15-0022 REVD Copyright 2000 Melard Technologies, Inc. All rights reserved. This document may not, in whole or part, be photocopied, reproduced, translated or reduced to any electronic medium or machine readable form without prior consent, in writing, from Melard Technologies, Inc. Notice: Melard Technologies reserves the right to make changes in the product described in this manual at any time and without notice. Sidearm All-Terrain Handheld PC is a trademark of Melard Technologies, Inc. Microsoft, Windows and Windows CE are registered trademarks of Microsoft Corp. Intel is a registered trademark of Intel Corp. This equipment conforms to FCC Parts 2 & 22 FCC Class A Part 15 This equipment has been tested and found to comply wi th the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Class B limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult your dealer or an experienced technician for help. Contents Getting started...............................................................................1 Unpacking................................................................................2 Power.............................................................................................4 Power options..........................................................................5 Installing the main battery........................................................6 Determining main battery condition..........................................6 Low power management..........................................................6 When the main battery becomes low.......................................7 Charging the main battery.................................................7 Swapping the main battery................................................8 When the backup battery becomes low....................................9 Replacing the backup battery............................................9 Using the Sidearm.......................................................................10 Turning the Sidearm on and off..............................................11 Setting automatic power-off time.....................................11 Understanding the indicators.................................................12 Using the stylus......................................................................13 Accessing the stylus.......................................................13 Calibrating the touchscreen............................................14 Managing the display panel...................................................14 Adjusting brightness........................................................14 Adjusting contrast...........................................................14 Controlling backlighting...................................................15 Setting audio volume..............................................................15 Wireless communications (optional).......................................16 Integrated wireless modems...........................................16 Sidearm’s wireless antenna............................................16 Landline communications (optional).......................................16 Resetting the Sidearm............................................................16 Performing a soft reset....................................................17 Performing a full reset.....................................................17 Restoring unit back to factory settings............................18 Maintaining the Sidearm.............................................................19 Cleaning the Sidearm.............................................................20 Disposing of batteries.............................................................20 Customer support...................................................................21 Availability.......................................................................21 Returning equipment for repair.......................................21 Sidearm specifications...............................................................23 Limited one-year warranty – hardware...................................25 Introduction Melard Technologies’ Sidearm All-Terrain Handheld PC™ is a rugged, Microsoft Windows CE-based handheld computer with integrated wireless communications. It provides a compact and lightweight mobile computing platform for field service operations. System Features n 640 x 240 touch-sensitive transflective display that supports navigation with stylus (included) or finger. n PC Card and CompactFlash slots. n Integrated half-wave dipole antenna (optional). n Internal V.90 56K modem (optional). n IrDA infrared port. n RS232 serial port with DB9 connector. n USB host port. n Power from rechargeable battery or AC adapte…

Text truncated - open the document above for the full version.

October 2000 APREL Project No.: Consulting * Research * Training * Certification Testing Since 1981 FCC ID: ESD-SA824894NE Exhibit 10 Attestation Statements FCC Part 15, Subpart B Certificate of Conformity FCC Part 2 & 22 Statement of Compliance October 2000 APREL Project No.: Consulting * Research * Training * Certification Testing Since 1981 FCC ID: ESD-SA824894NE PRODUCT: Rugged handheld computer with integrated wireless communications MODEL: Sidearm ALL-Terrain Handheld PC MANUFACTURER: Melard Technologies Inc. We certify that the pertinent tests have been performed on the above described equipment and that this equipment conforms FCC Parts 2 and 22. See Exhibit 2, Engineering Reports, of this application.

October 2000 APREL Project No.: Consulting * Research * Training * Certification Testing Since 1981 FCC ID: ESD-SA824894NE Table of Contents List of Exhibits Submitted E E X X H H I I B B I I T T 1 1 : : C C O O V V E E R R L L E E T T T T E E R R S S a)Application overview b)Equipment: Rugged handheld computer with integrated wireless communications(Using an approved radio modem FCC ID:NBZNRM-6832) c)Authorization Letter /Agent Designated (Jay Sarkar) d)Request for confidentiality e)Letter from Novatel Wireless Technologies. authorizing to use FCC approved (FCC ID NBZNRM-6832) radio modem in Melard Sidearm ALL- Terrain Handheld PC Exhibit 2:Engineering Reports (Test Reports) a)ERP (2.1046) b)Radiated Spurious Emissions (2.1053) c)Bandwidth (2.1049) Bandwidth Limitations (2.1047) d)Spurious Emissions, Antenna Terminal (2.1051) e)Frequency Stability (2.1055) Exhibit 3: Operational/Technical Description Exhibit 4: ID Label/Location Exhibit 5:External Photographs of the Equipment Internal Photographs of the equipment Exhibit 6:Block Diagram (Confidential) Exhibit 7: Schematic Diagram (Confidential) Exhibit 8:Parts List (Confidential), Tune–up Procedure Exhibit 9:User’s Manual Exhibit 10:a) Attestation Statement: FCC Part 15 Declaration of Conformance (DoC) certificate b)Attestation Statement: the equipment complies with Part 22 (see page 2 of Users’ Manual) Exhibit 11:RF Exposure Information: SAR Report (Includes Test Set-up Photographs)

October 2000 APREL Project No.: Consulting * Research * Training * Certification Testing Since 1981 FCC ID: ESD-SA824894NE Exhibit 1 a)Application overview b)Equipment: Rugged handheld computer with integrated wireless communications(Using an approved radio modem FCC ID:NBZNRM-6832) c)Authorization Letter /Agent Designated (Jay Sarkar) d)Request for confidentiality e)Letter from Novatel Wireless Technologies. authorizing to use FCC approved (FCC ID NBZNRM-6832) radio modem in Melard Sidearm ALL-Terrain Handheld PC Date: January 18 , 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Subject: FCC Part 22 Certification of Rugged handheld computer with integrated wireless communications using a radio modem (transmitter), Novatel CDPD, approved under FCC ID NBZ NRM-6832. Gentlemen: Enclosed herewith, please find an application for Part 22 Certification on behalf of Melard Technologies Inc., on their product/equipment: Rugged handheld computer with integrated wireless communications. This equipment (To be approved under FCC ID ESD-SA824894NE) uses a Novatel CDPD radio modem which is already approved by FCC under FCC ID NBZNRM-6832. FCC ID: ESD-SA824894NE PRODUCT: Rugged handheld computer with integrated wireless communications MODEL: Sidearm ALL-Terrain Handheld PC with a Novatel NRM6832Transmitter (FCC ID: NBZNRM6832) EUT TYPE: Licensed Non-Broadcast Station Transmitter (TNB) TX Frequency: 824-849 MHz MEASURED ERP:0.427 W Enclosed please find: Letter of Authorization, Request for Confidentiality Letter, Letter from Novatel Wireless to use CDPD modem in Melard Sidearm ALL-Terrain Handheld PC , ERP Report, Report for Field Strength for Spurious Radiation (Measurement Data, Test set-up photographs), and test data for Bandwidth/Bandwidth Limitation, Spurious Emissions for Antenna Terminal, Frequency Stability and SAR Report, FCC ID Label, internal and external photographs, block diagram (confidential),Schematic diagram (confidential), technical description, parts list and tune-up procedure(Confidential 1 ), user manual, and the letters for FCC Part 15 compliance and the attestation statement that the above equipment (Sidearm ALL-Terrain Handheld PC) complies with Part 22. Best Regards Jayanta (Jay) K. Sarkar Technical Director, Standards and Certification Telephone: (613) 820-2730 Fax: (613) 820-4161 e-mail: [email protected] APREL PROJ. NO.: SmartICE-Mobitex-3366 October 2000 APREL Project No.: Consulting * Research * Training * Certification Testing Since 1981 EQUIPMENT PRODUCT: Rugged handheld computer with integrated wireless communications MODEL: Sidearm ALL-Terrain Handheld PC MANUFACTURER: Melard Technologies Inc. FCC ID: ESD-SA824894NE PRODUCT: Rugged handheld computer with integrated wireless communications MODEL: Sidearm ALL-Terrain Handheld PC with a Novatel NRM6832Transmitter (FCC ID: NBZNRM6832) EUT TYPE: Licensed Non-Broadcast Station Transmitter (TNB) TX Frequency: 824-849 MHz MEASURED ERP:0.427 W NOVATEL WIRELESS, INC. SUITE 200, 6715 8 TH STREET N.E., CALGARY, ALBERTA, CANADA T2E 7H7 TELEPHONE (403) 295-4800 FACSIMILE (403) 295-4801 Novatel Wireless Inc. Suite 200, 6715 8 th St. NE Calgary, Alberta Canada T2E 7H7 Wednesday, November 08, 2000 REF: Expedite Modem Certification For : Dariush Shemtov Melard Technologies Inc. 28 Kaysal Court Armonk, New York USA 10504 To whom it may concern, Melard Technologies Inc, is our customer in good standing and will be producing a Windows CE product which incorporates the Novatel Wireless NRM6832 (Expedite) radio modem module (FCC ID NBZNRM – 6832, Industry Canada Certificate No. 10159A, Certification No. 3229182311A). Melard Technologies Inc. will be submitting their unit, incorporating the Expedite, for certification of the final integrated product with a unique FCC and Industry Canada ID using their own grantee code. Melard will also require SAR and ERP testing for the final integrated product. For more information about the radio modem module please refer to Novatel’s FCC ID or Industry Canada submission (attached). Should you have any questions, please do not hesitate to contact our Senior Certification Manager, Merv Coleman at (403) 295 4813 or by email at [email protected] For questions regarding Melard Technologies, please contact Dariush Shemtov at 914-273- 4488 x 333 or by email at [email protected] Yours truly, David S. McNab Product Manager Embedded Products Group Phone (403) 295 4823 [email protected] NOVATEL WIRELESS, INC. SUITE 200, 6715 8 TH STREET N.E., CALGARY, ALBERTA, CANADA T2E 7H7 TELEPHONE (403) 295-4800 FACSIMILE (403) 295-4801

February 6, 2001 Federal Communications Commission Equipment Authorization Division Applications Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To: Errol [email protected] From: Jay [email protected] Subject: Information requested RE: FCC ID ESD-SA824894NE Applicant: Melard Technologies Inc. Correspondence 17919 731 Confirmation No.EA99829 Date of Original e-mail: January 31, 2001 11:46 AM Dear Mr. Chang: Pursuant to your e-mail to me, dated January 31, 2001 , I am forwarding to you our response. The relevant portion of the e-mail from FCC follows with our response inserted in the appropriate place: The following information is based on a review of the RF exposure aspects alone. there may be the need for further clarifications when this application is reviewed again at a later date. 1. The second file uploaded to the Cover Letter Exhibit indicates this device has 427 mW ERP. The test data in Exhibit 6 is indicating 372 mW ERP; please clarify. Response: The correct ERP is 372 mW as indicated in the ERP test data. 2.Section 9 of the SAR report, Conclusions, indicates a warning will be used to alert users to provide at least 4 cm between the antenna and the body of persons. This info is not found in the manual submitted; please clarify and upload the relevant page(s) of the manual. Response: Relevant page is uploaded with this response. It reads: “In order to comply with the FCC RF Exposure requirements, this device must be operated with a minimum separation distance of 4 cm between the bystander, parts of the user other than the extremities, and the antenna in its intended upright vertical operating position”. 3.Please identify the peak SAR location measured for the device. The SAR distribution for Figure 2 is missing and a device outline has been shown on top of the measurement uncertainty table. Response: Data have been scrambled in transmission. We are re-transmitting entire SAR report with this response. 4.Table 2 indicates bystander exposure on the low channel is 4.13 W/kg, peak value. This does not appear to be consistent with the 4.13 W/kg 1-g surface SAR indicated in Section 8 (3); please clarify and revise all relevant info and numbers related to or derived from these numbers. Response: - The peak SAR values in table 2 are measured using area scans which take a measurement every 10 mm. The 1-g surface SAR is extrapolated by using zoom scans which take a measurement every 5 mm. At times, because of the higher resolution of the zoom scans, higher SAR values are used to measure the 1-g surface SAR than what was measured with the area scan. This would explain the similar numbers. The 4.13 W/kg 1-g surface SAR is an accurate measurement. 5.Please clarify the possible antenna operating positions and if the existing SAR results are sufficient for supporting all these possible antenna-operating positions. For example, when the antenna is not in its up-right position, whether SAR may change due to device performance or other operating issues. Response: The antenna is attached to the upper right edge of the display screen and should always be on the right side of the device and in upright position. The manual has a statement (page 16, revised uploaded with this response) describing the antenna position under the heading: “Positioning the wireless antenna”. It reads: “For the wireless systems, Sidearm uses a half-wave dipole antenna that is secured to the top right edge of the display screen. The antenna is strategically placed to optimize wireless coverage. For best coverage while using Sidearm, position the antenna in the upright position. Unauthorized antenna modifications could damage the Sidearm and may violate FCC regulations”. However, the SAR was measured in three antenna positions with the keyboard facing up as reference, the positions are: 1- The antenna pointing up directly away from the keyboard. 2- The antenna pointing up directly away from the top edge. 3- The antenna folded against the top edge. - The above antenna configuration has no effect on SAR results for this device. I trust that the above will answer your questions. If you have any questions, please feel free to contact the undersigned. Thanking you in advance for your kind cooperation. Best regards, Jayanta (Jay) K. Sarkar Technical Director, Standards and Certification

October 2000 APREL Project No.: Consulting * Research * Training * Certification Testing Since 1981 FCC ID: ESD-SA824894NE Exhibit 5 Photographs of the Equipment External Photos

October 2000 APREL Project No.: Consulting * Research * Training * Certification Testing Since 1981 FCC ID: ESD-SA824894NE Exhibit 4 FCC ID Label/Location Melard Technologies, Inc. SIDEARM PRODUCT FCC LABEL LOCATION Page 1 of 1 1/10/01 Bottom view of SIDEARM. FCC ID Label to be placed here. Melard Technologies, Inc. SIDEARM PRODUCT FCC LABEL LOCATION Page 2 of 2 1/10/01 Insert radio modem FCC ID labels in this area.

Consulting * Research * Training * Certification Testing Since 1981 January 23, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Subject: FCC ID Correction For: ESDSA824894NE EA99829 Filled January 22, 2001 Gentlemen: This application was filed yesterday afternoon. Please amend the FCC ID to include a hyphen between the grantee code and the ID proper. Presently it shows FCC ID:ESDSA824894NE, but the client actually wants: FCC ID:ESD-SA824894NE. Also all exhibits are marked FCC ID:ESD-SA824894NE, including the FCC ID Label information exhibit. Thank you, in advance for your cooperation. Art Brennan For Jay Sarkar APREL Laboratories

October 2000 APREL Project No.: Consulting * Research * Training * Certification Testing Since 1981 FCC ID: ESD-SA824894NE Exhibit 5 Photographs of the Equipment Internal Photos LTRECODESCRIPTIONDATE REVISION PROPRIETARY NOTICE INFORMATION DISCLOSED HEREIN IS THE PROPERTY OF MELARD TECHNOLOGIES, INC. IT IS FURNISHED FOR EVALUATION PURPOSES ONLY AND SHALL NOT BE DISCLOSED, COPIED OR USED FOR ANY OTHER PURPOSES, EXCEPT AS SPECIFIED BY WRITTEN CONTRACT BETWEEN THE RECIPIENT AND MELARD TECHNOLOGIES, INC. DUPLICATION OF ANY PORTION OF THIS DATA MUST INCLUDE THIS LEGEND MELARD TECHNOLOGIES, INC. 28 KAYSAL COURT ARMONK, N.Y. 10504 SCALE: NONE SHEET 1 OF 1 SIGNATURES ON FILE IF BOX CHECKED APPROVALSDATE 06/26/00 ENG DRW PAM ECC FINISH: MATERIAL: UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES. TOLERANCES ARE: FRACTIONS DECIMALS ANGLES +/- 1/64 .XX= +/- .010 +/- 1/2 O .XXX = +/- .005 SideArm Novatel Expedite personality - Primary Side LTRECODESCRIPTIONDATE REVISION PROPRIETARY NOTICE INFORMATION DISCLOSED HEREIN IS THE PROPERTY OF MELARD TECHNOLOGIES, INC. IT IS FURNISHED FOR EVALUATION PURPOSES ONLY AND SHALL NOT BE DISCLOSED, COPIED OR USED FOR ANY OTHER PURPOSES, EXCEPT AS SPECIFIED BY WRITTEN CONTRACT BETWEEN THE RECIPIENT AND MELARD TECHNOLOGIES, INC. DUPLICATION OF ANY PORTION OF THIS DATA MUST INCLUDE THIS LEGEND MELARD TECHNOLOGIES, INC. 28 KAYSAL COURT ARMONK, N.Y. 10504 SCALE: NONE SHEET 1 OF 1 SIGNATURES ON FILE IF BOX CHECKED APPROVALSDATE 06/26/00 ENG DRW PAM ECC FINISH: MATERIAL: UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES. TOLERANCES ARE: FRACTIONS DECIMALS ANGLES +/- 1/64 .XX= +/- .010 +/- 1/2 O .XXX = +/- .005 SideArm Novatel Expedite personality - Secondary Side LTRECODESCRIPTIONDATE REVISION PROPRIETARY NOTICE INFORMATION DISCLOSED HEREIN IS THE PROPERTY OF MELARD TECHNOLOGIES, INC. IT IS FURNISHED FOR EVALUATION PURPOSES ONLY AND SHALL NOT BE DISCLOSED, COPIED OR USED FOR ANY OTHER PURPOSES, EXCEPT AS SPECIFIED BY WRITTEN CONTRACT BETWEEN THE RECIPIENT AND MELARD TECHNOLOGIES, INC. DUPLICATION OF ANY PORTION OF THIS DATA MUST INCLUDE THIS LEGEND MELARD TECHNOLOGIES, INC. 28 KAYSAL COURT ARMONK, N.Y. 10504 SCALE: NONE SHEET 1 OF 1 SIGNATURES ON FILE IF BOX CHECKED APPROVALSDATE 06/26/00 ENG DRW PAM ECC FINISH: MATERIAL: UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES. TOLERANCES ARE: FRACTIONS DECIMALS ANGLES +/- 1/64 .XX= +/- .010 +/- 1/2 O .XXX = +/- .005 SideArm Main Board - Primary Side LTRECODESCRIPTIONDATE REVISION PROPRIETARY NOTICE INFORMATION DISCLOSED HEREIN IS THE PROPERTY OF MELARD TECHNOLOGIES, INC. IT IS FURNISHED FOR EVALUATION PURPOSES ONLY AND SHALL NOT BE DISCLOSED, COPIED OR USED FOR ANY OTHER PURPOSES, EXCEPT AS SPECIFIED BY WRITTEN CONTRACT BETWEEN THE RECIPIENT AND MELARD TECHNOLOGIES, INC. DUPLICATION OF ANY PORTION OF THIS DATA MUST INCLUDE THIS LEGEND MELARD TECHNOLOGIES, INC. 28 KAYSAL COURT ARMONK, N.Y. 10504 SCALE: NONE SHEET 1 OF 1 SIGNATURES ON FILE IF BOX CHECKED APPROVALSDATE 06/26/00 ENG DRW PAM ECC FINISH: MATERIAL: UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES. TOLERANCES ARE: FRACTIONS DECIMALS ANGLES +/- 1/64 .XX= +/- .010 +/- 1/2 O .XXX = +/- .005 SideArm Main Board - Secondary Side

October 2000 APREL Project No.: Consulting * Research * Training * Certification Testing Since 1981 FCC ID: ESD-SA824894NE Exhibit 11 RF Exposure Information Sar Report This report shall not be reproduced, except in full, without the express written permission of APREL Laboratories 51 Spectrum Way Nepean ON K2R 1E6 Tel: (613) 820-2730 Fax: (613) 820-4161 email: [email protected] Certification Report on Specific Absorption Rate (SAR) Experimental Analysis Melard Technologies Inc. Sidearm ALL-Terrain Handheld PC™ Rugged handheld computer with integrated wireless communication Test Date: October 16, 2000 MELB-Novatel Expedite CDPD Sidearm-3587 Page 2 of 20 Project #: MELB-Novatel Expedite CDPD Sidearm-3587 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6 Fax (613) 820 4161 e-mail: [email protected] © APREL 2000 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories. FCC ID:ESD-SA824894NE Applicant:Melard Technologies, Inc. Equipment:Rugged handheld computer with integrated wireless communication Model:Sidearm ALL-Terrain Handheld PC™ Standard:FCC 96 –326, Guidelines for Evaluating the Environmental Effects of Radio- Frequency Radiation ENGINEERING SUMMARY This report contains the results of the engineering evaluation performed on a Sidearm ALL- Terrain Handheld PC™ which incorporates a Novatel Expedite CDPD modem. The measurements were carried out in accordance with FCC 96-326. The Sidearm with a Novatel Expedite CDPD modem was evaluated for its maximum power level( 0.372 ERQ). The duty factor of the radio modem is 100%. The Sidearm with a Novatel Expedite CDPD modem was tested at low, middle and high channels for the keyboard up, keyboard down, right, and top sides. The maximum 10g SAR (1.75 W/kg) was found to coincide with the peak performance RF output power of channel 367 (middle, 836.01 MHz) for the right side of the device. (The hot spot is located on the antenna). Test data and graphs are presented in this report. At a separation distance of 4 cm from the antenna of the device, the maximum 1g SAR is 0.49 W/kg. The manual will have a warning to keep bystanders, and parts of the user’s body other than extremities, at least 4 cm away from the antenna. Based on the test results and on how the device will be marketed and used, it is certified that the product meets the requirements as set forth in the above specifications, for uncontrolled RF exposure environment. (The results presented in this report relate only to the sample tested.) Page 3 of 20 Project #: MELB-Novatel Expedite CDPD Sidearm-3587 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6 Fax (613) 820 4161 e-mail: [email protected] © APREL 2000 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories. TABLE OF CONTENTS 1.Introduction...................................................................................................................4 2.Applicable Documents..................................................................................................4 3.Device Under Investigation...........................................................................................4 4.Test Equipment..............................................................................................................5 5.Test Methodology..........................................................................................................5 6.Test Results....................................................................................................................6 6.1.Transmitter Characteristics............................................................................................6 6.2.SAR Measurements.......................................................................................................7 7.User’s Hand Exposure...................................................................................................8 8.Bystander Exposure......................................................................................................9 9.Conclusions.................................................................................................................12 APPENDIX A. Measurement Setup, Tissue Properties and SAR Graphs.............................13 APPENDIX B. Uncertainty Budget........................................................................................15 APPENDIX C. Validation Scan on a Flat Phantom...............................................................16 APPENDIX D. Probe Calibration...........................................................................................17 TABLES AND FIGURES Table 1. Sampled Conducted RF Power..................................................................................6 Table 2. SAR Measurements...................................................................................................8 Figure 1. Setup........................................................................................................................13 Table 3. Dielectric Properties of the Simulated Muscle Tissue at 835 MHz.........................13 Figure 2. Contour Plot of the Area Scan 2.5mm Above Phantom Surface............................14 Figure 3. Surface Plot of the Area Scan 2.5mm Above Phantom Surface.............................15 Figure 4. Peak Local SAR versus DUI Separation.................................................................14 Table 4. Uncertainty Budget..................................................................................................15 Figure 4. Contour Plot of the Reference Area Scan 2.5mm Above Phantom........................16 Figure 5. Surface Plot of the Reference Area Scan 2.5mm Above Phantom.........................16 Page 4 of 20 Project #: MELB-Novatel Expedite CDPD Sidearm-3587 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6 Fax (613) 820 4161 e-mail: [email protected] © APREL 2000…

Text truncated - open the document above for the full version.

16 Using the Sidearm User’s Guide Sidearm All-Terrain Handheld PC™ Wireless communications (optional) Using wireless modems The Sidearm supports fully integrated wireless modems for multiple data networks. It is not necessary to manually turn the wireless modem on or off; the appropriate application software will automatically activate the wireless modem when required. Positioning the wireless antenna For the wireless systems, Sidearm uses a half-wave dipole antenna that is secured to the top right edge of the display screen. The antenna is strategically placed to optimize wireless coverage. For best coverage while using Sidearm, position the antenna in the upright position. Unauthorized antenna modifications could damage the Sidearm and may violate FCC regulations. In order to comply with the FCC RF Exposure requirements, this device must be operated with a minimum separation distance of 4 cm between the bystanders, parts of the user other than the extremities, and the antenna in its intended upright vertical operating position. Landline communications (optional) The optional 56K v.90 landline modem is accessible via the standard sealed RJ-11 connector located on the top of the unit. A combination RJ-11 / RJ-45 connector is available. Ethernet connectivity (10BaseT/10Base2) is optional and supported via this connector. Resetting the Sidearm Certain conditions require that you reset the Sidearm: n After restoring data from a host PC. n After installing new software.

This report shall not be reproduced, except in full, without the express written permission of APREL Laboratories 51 Spectrum Way Nepean ON K2R 1E6 Tel: (613) 820-2730 Fax: (613) 820-4161 email: [email protected] Certification Report on Specific Absorption Rate (SAR) Experimental Analysis Melard Technologies Inc. Sidearm ALL-Terrain Handheld PC™ Rugged handheld computer with integrated wireless communication Test Date: October 16, 2000 MELB-Novatel Expedite CDPD Sidearm-3587 Page 2 of 18 Project #: MELB-Novatel Expedite CDPD Sidearm-3587 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6 Fax (613) 820 4161 e-mail: [email protected] © APREL 2000 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories. FCC ID:ESD-SA824894NE Applica…

Text truncated - open the document above for the full version.
