F4Z4K3FDM-M32-HRF Hand Track
Forward Electronics Co Ltd
Click to zoom
Application Details
- Equipment Class
- DXX - Part 15 Low Power Communication Device Transmitter
- Date of Grant
- Jan 23, 2003
- Application Purpose
- Original Equipment
- Date of Application
- Jan 23, 2003
- Equipment Note
- RF Hand Track
- Frequency Range
- 26.96000000 - 27.28000000
- Company
- Forward Electronics Co Ltd
- Country
- Taiwan
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
FCC ID: F4Z4K3FDM-M32-H Product Features: u 4D Laser RF Hand Track (Mouse) u Shield interface cable u NiMH Re-chargeable Battery (Any other type of battery is not suitable for this function.) u System Requirement: Available Computer’s USB-port, CD or DVD-ROM Drive, u Microsoft Windows 98 or higher, Macintosh OS 8.6 or higher etc. Product Specification: u Channel: one u Security ID: 8 Sets u Cordless Technology: Radio Frequency u Carry Frequency: 27.045MHZ u Modulation: FSK (Frequency Shift Key) u Transfer Rate: 2 kbps u Input Power: 3VDC u RF Power: 460uv/m at 3m u RF Out Power: 0.001mW u Buttons: 3-Button Type u Encoder Technology: Mechanical u Resolution: 200 DPI u Operation Switch: 1 Link Switch (Tact switch) u Effective Distance: 3 M u Battery Life: 6 Months FEDERAL COMMUNICATIONS COMMISSION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Block Diagram
FCC ID: F4Z4K3FDM-M32-H
External Photos
FCC ID : F4Z4K3FDM-M32-H FRONT SIDE OF EUT Number 1 FCC ID : F4Z4K3FDM-M32-H REAR SIDE OF EUT Number 2
ID Label/Location Info
FCC ID: F4Z4K3FDM-M32-H
Internal Photos
FCC ID : F4Z4K3FDM-M32-H Number 1 Mechanical Construction FCC ID : F4Z4K3FDM-M32-H Number 2 Mechanical Construction FCC ID : F4Z4K3FDM-M32-H Number 3 Mechanical Construction FCC ID : F4Z4K3FDM-M32-H Number 4 Mechanical Construction FCC ID : F4Z4K3FDM-M32-H Number 5 Front side of Main Board FCC ID : F4Z4K3FDM-M32-H Number 6 Rear side of Main Board
Operational Description
FCC ID: F4Z4K3FDM-M32-H FDM-M32-H Work Basis Mouse: 1.When the mouse were moved, the IRPD would detect the glide signal to also transmit signal to the MCU. 2.The MCU will convert the signal and modulate the signal. (Use FSK mode) 3.Through the 27MHZ frequency transmit the modulation signal. Receiver: 1.When the receiver receives the modulation signal will demodulate signal through RF circuit. And responds signal to MCU. 2.The MCU meeting converts the signal PC acceptable format.
Schematics
FCC ID: F4Z4K3FDM-M32-H FCC ID: F4Z4K3FDM-M32-H
Test Report
FCC TEST REPORT Report No. : F291202 FCC TEST REPORT for 47 CFR Part 15 Subpart C Equipment : RF Hand Track Model No. : FDM-M32-H FCC ID : F4Z4K3FDM-M32-H Filing Type : Certification Applicant : FORWARD ELECTRONICS CO., LTD 393 Chung Cheng Rd.Sec.1 San-Hsia Town, Taipei County. Taiwan, 237, R.O.C. The test result refers exclusively to the test presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. Certificate or Test Report must not be used by the applicant to claim the product in this test report endorsement by NVLAP or any agency of U.S. government. SPORTON International Inc. 6F, No.106, Sec. 1, Hsin Tai Wu Rd., Hsi Chih, Taipei Hsien, Taiwan, R.O.C. SPORTON International Inc. TEL : 886-2-2696-2468 FAX : 886-2-2696-2255 FCC TEST REPORT Report No. : F291202 TEL : 886-2-2696-2468 Page No. : i FAX : 886-2-2696-2255 Issued Date : Nov. 11, 2002 F4Z4K3FDM-M32-H 2.1. Test Manner....................................................................................................................................................................................3 Table of Contents History of this test report....................................................................................................................................ii CERTIFICATE OF COMPLIANCE........................................................................................................................1 1. General Description of Equipment under Test.............................................................................................2 1.1. Applicant..........................................................................................................................................................................................2 1.2. Manufacturer...................................................................................................................................................................................2 1.3. Basic Description of Equipment under Test....................................................................................................................................2 1.4. Feature of Equipment under Test...................................................................................................................................................2 2. Test Configuration of Equipment under Test...............................................................................................3 2.2. Description of Test System.............................................................................................................................................................3 2.3. Connection Diagram of Test System..............................................................................................................................................5 3. General Information of Test............................................................................................................................6 3.1. Test Facility.....................................................................................................................................................................................6 3.2. Standard for Methods of Measurement...........................................................................................................................................6 3.3. Test in Compliance with..................................................................................................................................................................6 3.4. Frequency Range Investigated.......................................................................................................................................................6 3.5. Test Distance..................................................................................................................................................................................6 4. Test of Conducted Emission..........................................................................................................................7 4.1. Major Measuring Instruments..........................................................................................................................................................7 4.2. Test Procedures..............................................................................................................................................................................7 4.3. Typical Test Setup Layout of Conducted Powerline.......................................................................................................................8 4.4. Test Result of Conducted Emission................................................................................................................................................9 4.5. Photographs of Conducted Powerline Test Configuration............................................................................................................11 5. Test of Radiated Emission............................................................................................................................13 5.1. Major Measuring Instruments........................................................................................................................................................13 5.2. Test Procedures............................................................................................................................................................................14 5.3. Typical Test Setup Layout of Radiated Emission..........................................................................................................................15 5.4. Test Result of Radiated Emission.................................................................................................................................................16 5.5. Photograph…
Text truncated - open the document above for the full version.
Test Setup Photos
FCC TEST REPORT Report No. : F291202 SPORTON International Inc. FCC ID : F4Z4K3FDM-M32-H TEL : 886-2-2696-2468 Page No. : 1 of 1 FAX : 886-2-2696-2255 Issued Date : Nov. 11, 2002 1.1. Photographs of Radiated Emission Test Configuration n The photographs show the configuration that generates the maximum emission. FRONT VIEW REAR VIEW
Contact Information
Applicant
Charlie Sung(Engineer)
Test Firm
SPORTON International IncKathy Lin
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 26.96 MHz - 27.28 MHz | - |
