FBITABLETOPTABLE TOP WIRELESS MICROPHONE

Digital Wireless Microphone Systems Quick Start Guide Setting Up Pre-Engineered ClearOne ® Systems for Optimal Performance Master Slave Terminators Headquarters: salt Lake City, ut usa 5225 Wiley Post Way suite 500 salt Lake City, ut 84116 tel: 801.975.7200 toll Free: 800.945.7730 Fax: 801.977.0087 e-mail: [email protected] eMea tel: 44 (0) 1189.036.053 e-mail: [email protected] aPaC tel: 852.3590.4526 e-mail: [email protected] L ataM tel: 801.974.3621 e-mail: [email protected] techsales tel: 800.707.6694 e-mail: [email protected] technical support tel: 800.283.5936 e-mail: [email protected] CLearOne LOCatIOns Open the Cartons: Confirm everything on the packing slip is enclosed. Set up the Docking Station: 1. ClearOne transmitters are shipped with rechargeable batteries. Plug in the charging dock, put the batteries in the transmitters, then place the transmitters in the dock while you set up the rest of the system. Mount the Receivers in the Rack 2. and connect them to power. Confirm the displays light up. Pre-engineered Antenna Design: 3. If you provided ClearOne with a floor plan, you will find a marked up version in the box (or, in your Email in-box) showing the antenna design along with the antennas and pre-made cables. Place the antennas according to the drawings. Your Own Design: A. If you did not request an antenna design, place the antennas according to the enclosed Antenna Applications Guide Improper antenna placement is the main cause of poor RF performance. Dipole Antennas: B. Dipole antennas mounted to the rack equipment can easily be locked away in a closet/rack cabinet. This results in poor RF performance because there is no line of sight between the transmitter and receiver antenna. Therefore, remote antennas are preferred. See the Antenna Application Guide for details. Connect the Antennas:4. The receiver that connects to the antennas should be set as the Antenna Master receiver. Master is the factory default. If your system daisy-chains antennas together, the downstream receivers should be set as Slaves. Terminators are used on the last system in the daisy-chain. Use ClearOne Remote’s Antenna Setup Wizard, which opens automatically the first time you connect. You can also find the wizard under the SETTINGS tab of the main page. If connecting ClearOne active remote antennas, make sure the red LED lights up. If not, check the receiver’s antenna phantom power setting using the ClearOne Remote Control Software. Connect the analog outputs to the mixer:5. The system is shipped with Euro block connectors. The default output level is set to +4 dBu. Note that factory default for the front panel headphone jack is set for mixed line-level out. Use ClearOne Remote>Settings>Headphone, to reset for headphones. CAUTION! Turn off phantom power from the mixer. Phantom power distorts the audio quality of your microphones. System Test:6. In most cases, the system is now ready to use. Confirm all channels pass audio perfectly. Modifications (FCC 15.21) Changes or modifications to this equipment not expressly approved by ClearOne may void the user’s authority to operate this equipment. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Applies to WS80-T: Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. This radio transmitter (WS80-T) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. Monopole antenna, 0dbi gain, 50 ohm impedance. Le présent émetteur radio (DS80-T) a été approuvé par Industrie Canada pour fonctionner avec les types d’antenne énumérés ci-dessous et ayant un gain admissible maximal et l’impédance requise pour chaque type d’antenne. Les types d’antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l’exploitation de l’émetteur. For Full Control Select the new parameter values and click OK to save changes to the receiver. Editing Transmitter Parameters: The easiest and most intuitive way to set the parameters of ClearOne transmitters and receivers is with ClearOne Remote software. Load ClearOne Remote from the disk provided onto a computer running Windows XP or Windows 7 (32 or 64-bit) and connect to the receiver via USB or RS232. Then open ClearOne Remote and select ONLINE. Open The Channel Edit Window: 1) The [Click to Edit] function opens the edit window of the channel you wish to edit. 2) Select the functions you want to edit and enter the parameter. (The various functions are described below.) Click [OK] to save the changes and close the Channel Edit window. 3) You will notice that the [Needs to Sync] alert is lit. This indicates that one or more parameters are in queue in the receiver ready to be downloaded and implemented with the next transmitter Sync of the channel. 1) 2) Digital Wireless Microphone Systems Using the ClearOne remote software: Click to Edit the channel’s parameters 3) The “Need To Sync” alert is lit. Sync the transmitter to apply the selected parameters. ClearOne Remote provides the following functions: File:1. Save a PDF image of the screen. Settings:2. Phantom Power:A. Turn antenna phantom …

Text truncated - open the document above for the full version.

APPLICANT: CLEARONE INC. FCC ID: FBITABLETOP IC: 1970A-TABLETOP TOP VIEW BOTTOM VIEW BACK VIEW

5225 Wiley Post Way, Suite 500 Salt Lake City, UT 84116 Phone: 801-975-7200 Fax: 801-303-5711 This document contains confidential information proprietary to ClearOne and may not be copied in whole or in part by any means without the prior authorization of ClearOne. SCALE N.T.S.DO NOT SCALESHEET 1 OF 1 REV SIZEPART # DESCRIPTION A ANGLES: 1 2 PLACE DIMS: 0.02 3 PLACE DIMS: 0.005 TOLERANCES DRAWN BY PLOT DATE DATE UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE IN INCHES NOTES: UNLESS OTHERWISE SPECIFIED 1. MATERIAL 9.4MIL, 40# LINER, 50# FACE PREMIUM COATED, SMOOTH THERMAL TRANSFER PAPER LABEL STOCK WITH GENERAL PURPOSE, ALL TEMPERATURE PERMANENT ACRYLIC ADHESIVE COLOR: WHITE MANUF REF: ZEBRA #Z 93675P (Z ULTIMATE 3000T) 2. PRINTING PDF DOCUMENT IS FOR REFERENCE ONLY PRINT COLOR: 5095 RESIN REVISION SPECIFICATION REV: NAME: DATE: DCN: 1.0 JPHELPS 14 NOV 2014 000539 INITIAL RELEASE JPHELPS LBL-0379-002 LABEL UNIT ASSY PROD ID WIRELESS TABLETOP CARDIOID TRANSMITTER/MIC (RF M500) COMPRESSED 1.0 04 NOV 2014 04 NOV 2014 CONTRACT MANUFACTURER ASCALADE EGI ICT INOVAR WELLEX CODE 02 05 03 01 04 FACTORY CODE TABLE FLEXTRONICS - U.S.A. 06 FLEXTRONICS - DG CHINA 07 FLEXTRONICS - FY CHINA 08 PTS 09 OPCOM 11 UNIKA 10 ARROW OEM 12 ACT 13 AV LEADER 14 COMFORTCOMMS 15 MINNRAY 16 EDCO 17 MSI 18 SUPERMICRO 19 EPIPHAN 20 CLEARONE C1 SABINE 21 LONGHAO 30 S/N: SSSS-YYWW-CMJJJ M/N: DS80-CC-C-M500 REV X.Y WIRELESS TABLETOP CARDIOID TRANSMITTER/MIC (RF M500) COMPRESSED ROHS www.clearone.com/patents FCC ID: FBITABLETOP IC: 1970A-TABLETOP REVIEW GROUP CHECKED BY DATE COMPLIANCE MARKETING DOCUMENT CONTROL QUALITY PLM C STEINER J OWSLEY J GALLEGOS D CLARK D RAMACHANDIRAN 14 NOV 2014 14 NOV 2014 14 NOV 2014 14 NOV 2014 14 NOV 2014 USE CURRENT REVISION OF DS80-CC-C-M500 0.50 1.50 BARCODE: 3 OF 9 (CODE 39) HEIGHT: 0.125 DENSITY: 0.003 BARCODE: CODE 93 HEIGHT: 0.125 DENSITY: 0.003 SSSS-YYWW-CMJJJ SEQUENCE # YEAR WEEK CONTRACT MANUFACTURE CODE JOB # OR LOT # (IF APPLICABLE) NOTE: USUALLY BLANK

5225 Wiley Post Way, Suite 500 Salt Lake City, UT 84116 Phone: 801-975-7200 Fax: 801-977-0087 This document contains confidential information proprietary to ClearOne and may not be copied in whole or in part by any means without the prior authorization of ClearOne. SCALE N.T.S.DO NOT SCALESHEET 1 OF 1 REV SIZEPART # DESCRIPTION A ANGLES: 1 2 PLACE DIMS: 0.02 3 PLACE DIMS: 0.005 TOLERANCES DRAWN BY PLOT DATE DATE UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE IN INCHES NOTES: UNLESS OTHERWISE SPECIFIED 1. MATERIAL 9.4MIL, 40# LINER, 50# FACE PREMIUM COATED, SMOOTH THERMAL TRANSFER PAPER LABEL STOCK WITH GENERAL PURPOSE, ALL TEMPERATURE PERMANENT ACRYLIC ADHESIVE COLOR: WHITE MANUF REF: ZEBRA #Z 93675P (Z ULTIMATE 3000T) 2. PRINTING PDF DOCUMENT IS FOR REFERENCE ONLY PRINT COLOR: 5095 RESIN REVISION SPECIFICATION REV: NAME: DATE: DCN: 1.0 JPHELPS 08 OCT 2014 000xxx INITIAL RELEASE JPHELPS LBL-0XXX-001 LABEL UNIT ASSY TABLETOP CARDIOID TRANSMITTER WITH M500 COMPRESSED 1.0 26 SEP 2014 30 SEP 2014 S/N: SSSS-YYWW-CMJJJ M/N: 910-6001-004-C REV X.Y TABLETOP CARDIOID TRANSMITTER WITH M500 COMPRESSION ROHS www.clearone.com/patents FCC ID: FBITABLETOP IC: 1970A-TABLETOP REVIEW GROUP CHECKED BY DATE COMPLIANCE MARKETING DOCUMENT CONTROL QUALITY PLM C STEINER J OWSLEY J GALLEGOS D CLARK D RAMACHANDIRAN 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 USE CURRENT REVISION OF 910-6001-004-C 0.50 1.50 BARCODE: 3 OF 9 (CODE 39) HEIGHT: 0.125 DENSITY: 0.003 BARCODE: CODE 93 HEIGHT: 0.125 DENSITY: 0.003 SSSS-YYWW-CMJJJ SEQUENCE # YEAR WEEK CONTRACT MANUFACTURE CODE JOB # OR LOT # (IF APPLICABLE) NOTE: USUALLY BLANK CONTRACT MANUFACTURER ASCALADE EGI ICT INOVAR WELLEX CODE 02 05 03 01 04 FACTORY CODE TABLE FLEXTRONICS - U.S.A. 06 FLEXTRONICS - DG CHINA 07 FLEXTRONICS - FY CHINA 08 PTS 09 OPCOM 11 UNIKA 10 ARROW OEM 12

5225 Wiley Post Way, Suite 500 Salt Lake City, UT 84116 Phone: 801-975-7200 Fax: 801-977-0087 This document contains confidential information proprietary to ClearOne and may not be copied in whole or in part by any means without the prior authorization of ClearOne. SCALE N.T.S.DO NOT SCALESHEET 1 OF 1 REV SIZEPART # DESCRIPTION A ANGLES: 1 2 PLACE DIMS: 0.02 3 PLACE DIMS: 0.005 TOLERANCES DRAWN BY PLOT DATE DATE UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE IN INCHES NOTES: UNLESS OTHERWISE SPECIFIED 1. MATERIAL 9.4MIL, 40# LINER, 50# FACE PREMIUM COATED, SMOOTH THERMAL TRANSFER PAPER LABEL STOCK WITH GENERAL PURPOSE, ALL TEMPERATURE PERMANENT ACRYLIC ADHESIVE COLOR: WHITE MANUF REF: ZEBRA #Z 93675P (Z ULTIMATE 3000T) 2. PRINTING PDF DOCUMENT IS FOR REFERENCE ONLY PRINT COLOR: 5095 RESIN REVISION SPECIFICATION REV: NAME: DATE: DCN: 1.0 JPHELPS 08 OCT 2014 000xxx INITIAL RELEASE JPHELPS LBL-0XXX-001 LABEL UNIT ASSY TABLETOP CARDIOID TRANSMITTER WITH M610 COMPRESSED 1.0 26 SEP 2014 30 SEP 2014 S/N: SSSS-YYWW-CMJJJ M/N: DS80-CC-C-M610 REV X.Y TABLETOP CARDIOID TRANSMITTER WITH M610 COMPRESSION ROHS www.clearone.com/patents FCC ID: FBITABLETOP IC: 1970A-TABLETOP REVIEW GROUP CHECKED BY DATE COMPLIANCE MARKETING DOCUMENT CONTROL QUALITY PLM C STEINER J OWSLEY J GALLEGOS D CLARK D RAMACHANDIRAN 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 USE CURRENT REVISION OF DS80-CC-C-M610 0.50 1.50 BARCODE: 3 OF 9 (CODE 39) HEIGHT: 0.125 DENSITY: 0.003 BARCODE: CODE 93 HEIGHT: 0.125 DENSITY: 0.003 SSSS-YYWW-CMJJJ SEQUENCE # YEAR WEEK CONTRACT MANUFACTURE CODE JOB # OR LOT # (IF APPLICABLE) NOTE: USUALLY BLANK CONTRACT MANUFACTURER ASCALADE EGI ICT INOVAR WELLEX CODE 02 05 03 01 04 FACTORY CODE TABLE FLEXTRONICS - U.S.A. 06 FLEXTRONICS - DG CHINA 07 FLEXTRONICS - FY CHINA 08 PTS 09 OPCOM 11 UNIKA 10 ARROW OEM 12

5225 Wiley Post Way, Suite 500 Salt Lake City, UT 84116 Phone: 801-975-7200 Fax: 801-977-0087 This document contains confidential information proprietary to ClearOne and may not be copied in whole or in part by any means without the prior authorization of ClearOne. SCALE N.T.S.DO NOT SCALESHEET 1 OF 1 REV SIZEPART # DESCRIPTION A ANGLES: 1 2 PLACE DIMS: 0.02 3 PLACE DIMS: 0.005 TOLERANCES DRAWN BY PLOT DATE DATE UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE IN INCHES NOTES: UNLESS OTHERWISE SPECIFIED 1. MATERIAL 9.4MIL, 40# LINER, 50# FACE PREMIUM COATED, SMOOTH THERMAL TRANSFER PAPER LABEL STOCK WITH GENERAL PURPOSE, ALL TEMPERATURE PERMANENT ACRYLIC ADHESIVE COLOR: WHITE MANUF REF: ZEBRA #Z 93675P (Z ULTIMATE 3000T) 2. PRINTING PDF DOCUMENT IS FOR REFERENCE ONLY PRINT COLOR: 5095 RESIN REVISION SPECIFICATION REV: NAME: DATE: DCN: 1.0 JPHELPS 08 OCT 2014 000xxx INITIAL RELEASE JPHELPS LBL-0XXX-001 LABEL UNIT ASSY TABLETOP CARDIOID TRANSMITTER WITH M610 COMPRESSED 1.0 26 SEP 2014 30 SEP 2014 S/N: SSSS-YYWW-CMJJJ M/N: 910-6001-003-C REV X.Y TABLETOP CARDIOID TRANSMITTER WITH M610 COMPRESSION ROHS www.clearone.com/patents FCC ID: FBITABLETOP IC: 1970A-TABLETOP REVIEW GROUP CHECKED BY DATE COMPLIANCE MARKETING DOCUMENT CONTROL QUALITY PLM C STEINER J OWSLEY J GALLEGOS D CLARK D RAMACHANDIRAN 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 USE CURRENT REVISION OF 910-6001-003-C 0.50 1.50 BARCODE: 3 OF 9 (CODE 39) HEIGHT: 0.125 DENSITY: 0.003 BARCODE: CODE 93 HEIGHT: 0.125 DENSITY: 0.003 SSSS-YYWW-CMJJJ SEQUENCE # YEAR WEEK CONTRACT MANUFACTURE CODE JOB # OR LOT # (IF APPLICABLE) NOTE: USUALLY BLANK CONTRACT MANUFACTURER ASCALADE EGI ICT INOVAR WELLEX CODE 02 05 03 01 04 FACTORY CODE TABLE FLEXTRONICS - U.S.A. 06 FLEXTRONICS - DG CHINA 07 FLEXTRONICS - FY CHINA 08 PTS 09 OPCOM 11 UNIKA 10 ARROW OEM 12

5225 Wiley Post Way, Suite 500 Salt Lake City, UT 84116 Phone: 801-975-7200 Fax: 801-977-0087 This document contains confidential information proprietary to ClearOne and may not be copied in whole or in part by any means without the prior authorization of ClearOne. SCALE N.T.S.DO NOT SCALESHEET 1 OF 1 REV SIZEPART # DESCRIPTION A ANGLES: 1 2 PLACE DIMS: 0.02 3 PLACE DIMS: 0.005 TOLERANCES DRAWN BY PLOT DATE DATE UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE IN INCHES NOTES: UNLESS OTHERWISE SPECIFIED 1. MATERIAL 9.4MIL, 40# LINER, 50# FACE PREMIUM COATED, SMOOTH THERMAL TRANSFER PAPER LABEL STOCK WITH GENERAL PURPOSE, ALL TEMPERATURE PERMANENT ACRYLIC ADHESIVE COLOR: WHITE MANUF REF: ZEBRA #Z 93675P (Z ULTIMATE 3000T) 2. PRINTING PDF DOCUMENT IS FOR REFERENCE ONLY PRINT COLOR: 5095 RESIN REVISION SPECIFICATION REV: NAME: DATE: DCN: 1.0 JPHELPS 08 OCT 2014 000xxx INITIAL RELEASE JPHELPS LBL-0XXX-001 LABEL UNIT ASSY TABLETOP OMNI TRANSMITTER WITH M500 COMPRESSED 1.0 26 SEP 2014 30 SEP 2014 S/N: SSSS-YYWW-CMJJJ M/N: 910-6001-014-C REV X.Y TABLETOP OMNI TRANSMITTER WITH M500 COMPRESSION ROHS www.clearone.com/patents FCC ID: FBITABLETOP IC: 1970A-TABLETOP REVIEW GROUP CHECKED BY DATE COMPLIANCE MARKETING DOCUMENT CONTROL QUALITY PLM C STEINER J OWSLEY J GALLEGOS D CLARK D RAMACHANDIRAN 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 USE CURRENT REVISION OF 910-6001-014-C 0.50 1.50 BARCODE: 3 OF 9 (CODE 39) HEIGHT: 0.125 DENSITY: 0.003 BARCODE: CODE 93 HEIGHT: 0.125 DENSITY: 0.003 SSSS-YYWW-CMJJJ SEQUENCE # YEAR WEEK CONTRACT MANUFACTURE CODE JOB # OR LOT # (IF APPLICABLE) NOTE: USUALLY BLANK CONTRACT MANUFACTURER ASCALADE EGI ICT INOVAR WELLEX CODE 02 05 03 01 04 FACTORY CODE TABLE FLEXTRONICS - U.S.A. 06 FLEXTRONICS - DG CHINA 07 FLEXTRONICS - FY CHINA 08 PTS 09 OPCOM 11 UNIKA 10 ARROW OEM 12

5225 Wiley Post Way, Suite 500 Salt Lake City, UT 84116 Phone: 801-975-7200 Fax: 801-977-0087 This document contains confidential information proprietary to ClearOne and may not be copied in whole or in part by any means without the prior authorization of ClearOne. SCALE N.T.S.DO NOT SCALESHEET 1 OF 1 REV SIZEPART # DESCRIPTION A ANGLES: 1 2 PLACE DIMS: 0.02 3 PLACE DIMS: 0.005 TOLERANCES DRAWN BY PLOT DATE DATE UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE IN INCHES NOTES: UNLESS OTHERWISE SPECIFIED 1. MATERIAL 9.4MIL, 40# LINER, 50# FACE PREMIUM COATED, SMOOTH THERMAL TRANSFER PAPER LABEL STOCK WITH GENERAL PURPOSE, ALL TEMPERATURE PERMANENT ACRYLIC ADHESIVE COLOR: WHITE MANUF REF: ZEBRA #Z 93675P (Z ULTIMATE 3000T) 2. PRINTING PDF DOCUMENT IS FOR REFERENCE ONLY PRINT COLOR: 5095 RESIN REVISION SPECIFICATION REV: NAME: DATE: DCN: 1.0 JPHELPS 08 OCT 2014 000xxx INITIAL RELEASE JPHELPS LBL-0XXX-001 LABEL UNIT ASSY TABLETOP OMNI TRANSMITTER WITH M610 COMPRESSED 1.0 26 SEP 2014 30 SEP 2014 S/N: SSSS-YYWW-CMJJJ M/N: DS80-CO-C-M610 REV X.Y TABLETOP OMNI TRANSMITTER WITH M610 COMPRESSION ROHS www.clearone.com/patents FCC ID: FBITABLETOP IC: 1970A-TABLETOP REVIEW GROUP CHECKED BY DATE COMPLIANCE MARKETING DOCUMENT CONTROL QUALITY PLM C STEINER J OWSLEY J GALLEGOS D CLARK D RAMACHANDIRAN 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 USE CURRENT REVISION OF DS80-CO-C-M610 0.50 1.50 BARCODE: 3 OF 9 (CODE 39) HEIGHT: 0.125 DENSITY: 0.003 BARCODE: CODE 93 HEIGHT: 0.125 DENSITY: 0.003 SSSS-YYWW-CMJJJ SEQUENCE # YEAR WEEK CONTRACT MANUFACTURE CODE JOB # OR LOT # (IF APPLICABLE) NOTE: USUALLY BLANK CONTRACT MANUFACTURER ASCALADE EGI ICT INOVAR WELLEX CODE 02 05 03 01 04 FACTORY CODE TABLE FLEXTRONICS - U.S.A. 06 FLEXTRONICS - DG CHINA 07 FLEXTRONICS - FY CHINA 08 PTS 09 OPCOM 11 UNIKA 10 ARROW OEM 12

5225 Wiley Post Way, Suite 500 Salt Lake City, UT 84116 Phone: 801-975-7200 Fax: 801-977-0087 This document contains confidential information proprietary to ClearOne and may not be copied in whole or in part by any means without the prior authorization of ClearOne. SCALE N.T.S.DO NOT SCALESHEET 1 OF 1 REV SIZEPART # DESCRIPTION A ANGLES: 1 2 PLACE DIMS: 0.02 3 PLACE DIMS: 0.005 TOLERANCES DRAWN BY PLOT DATE DATE UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE IN INCHES NOTES: UNLESS OTHERWISE SPECIFIED 1. MATERIAL 9.4MIL, 40# LINER, 50# FACE PREMIUM COATED, SMOOTH THERMAL TRANSFER PAPER LABEL STOCK WITH GENERAL PURPOSE, ALL TEMPERATURE PERMANENT ACRYLIC ADHESIVE COLOR: WHITE MANUF REF: ZEBRA #Z 93675P (Z ULTIMATE 3000T) 2. PRINTING PDF DOCUMENT IS FOR REFERENCE ONLY PRINT COLOR: 5095 RESIN REVISION SPECIFICATION REV: NAME: DATE: DCN: 1.0 JPHELPS 08 OCT 2014 000xxx INITIAL RELEASE JPHELPS LBL-0XXX-001 LABEL UNIT ASSY TABLETOP OMNI TRANSMITTER WITH M610 COMPRESSED 1.0 26 SEP 2014 30 SEP 2014 S/N: SSSS-YYWW-CMJJJ M/N: 910-6001-013-C REV X.Y TABLETOP OMNI TRANSMITTER WITH M610 COMPRESSION ROHS www.clearone.com/patents FCC ID: FBITABLETOP IC: 1970A-TABLETOP REVIEW GROUP CHECKED BY DATE COMPLIANCE MARKETING DOCUMENT CONTROL QUALITY PLM C STEINER J OWSLEY J GALLEGOS D CLARK D RAMACHANDIRAN 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 30 SEP 2014 USE CURRENT REVISION OF 910-6001-013-C 0.50 1.50 BARCODE: 3 OF 9 (CODE 39) HEIGHT: 0.125 DENSITY: 0.003 BARCODE: CODE 93 HEIGHT: 0.125 DENSITY: 0.003 SSSS-YYWW-CMJJJ SEQUENCE # YEAR WEEK CONTRACT MANUFACTURE CODE JOB # OR LOT # (IF APPLICABLE) NOTE: USUALLY BLANK CONTRACT MANUFACTURER ASCALADE EGI ICT INOVAR WELLEX CODE 02 05 03 01 04 FACTORY CODE TABLE FLEXTRONICS - U.S.A. 06 FLEXTRONICS - DG CHINA 07 FLEXTRONICS - FY CHINA 08 PTS 09 OPCOM 11 UNIKA 10 ARROW OEM 12

APPLICANT: CLEARONE INC. FCC ID: FBITABLETOP IC: 1970A-TABLETOP INTERNAL TOP VIEW INTERNAL BOTTOM VIEW

WS880 Tuning Procedure Editing Transmitter Parameters: The easiest and most intuitive way to set the parameters of ClearOne transmitters and receivers is with ClearOne Remote software. Load ClearOne Remote from the disk provided onto a computer running Windows XP or Windows 7 (32 or 64-bit) and connects to the receiver via USB or RS232. Then open ClearOne Remote and select ONLINE. Open The Channel Edit Window: 1) The [Click to Edit] function opens the edit window of the channel you wish to edit. 2) Select the functions you want to edit and enter the parameter. (The various functions are described below.) Click [OK] to save the changes and close the Channel Edit window. 3) You will notice that the [Needs to Sync] alert is lit. This indicates that one or more parameters are in queue in the receiver ready to be downloaded and implemented with the next transmitter Sync of the channel. (1) (2) (3) 1) Click to Edit the channel’s parameters 2) Select the new parameters values and click “OK” to save changes to the receiver 3) The “Need To Sync” alert will light up. Sync the transmitter to apply the selected parameters ClearOne Remote provides the following functions: File: 1. Save a PDF image of the screen. Settings: 2. Phantom Power: A. Turn antenna phantom power on or off. Default = ON. Redundancy: B. Set adjacent pairs of receivers to redundancy mode. Default = OFF. Headphone Mode: C. Toggles the mixed output jack from headphone mode to a balanced line output. Default = Balanced line output. Ethernet Settings: 3. If using Ethernet, assign the proper IP address to the ClearOne Receiver. RF Scan - RF Plot: 4. Shows the RF strength of each antenna in a ClearOne system and shows if there is outside interference. Presets: 5. Save or load preset system parameters configurations. Default = As Ordered. GPIO: 6. Assign contact closure functions and setup for RS232 control. Default = RS232 - Output mutes. Security: 7. Password to prevent unauthorized changes: (Under construction). Default = none. Alerts: 8. Send alerts to authorized personal when preventive maintenance is required of if there is a fault. Default = none. Update System: 9. Checks to see if the system has the most current firmware and provides a wizard for updating the firmware. Help: 10. Tutorials: A. Setting parameters, Antenna Application Guide, etc. About: B. Shows vital statistics for each component of the system Default Transmitter Preamp Gain Settings: Transmitter + Last 4 digits of serial Number Default Transmitter Preamp Gain BLT XXXX +10 dB HH XXXX H18 = 0dB, H13 & H18 = +20dB PDM XXXX +10dB BDM XXXX +20dB

FCC PART 74 LOW POWER LICENSED TRANSMITTER TEST REPORT APPLICANT CLEARONE INC. EDGEWATER CORPORATE PARK, SOUTH TOWER 5225 WILEY POST WAY, SUITE # 500 SALT LAKE CITY UTAH 84116 USA FCC ID FBITABLETOP MODEL NUMBER DS80-CC-C-M500, 910-6001-004-C, DS80-CC-C- M610, 910-6001-003-C, DS80-C0 -C-M500, 910- 6001-014-C, DS80-C0-C-M610,910-6001-013-C PRODUCT DESCRIPTION TABLE TOP WIRELESS MICROPHONE STANDARD APPLIED CFR 47 Part 74.801 & IC RSS-123 DATE SAMPLE RECEIVED 9/15/2014 DATE TESTED 9/22/2014 TESTED BY Sid Sanders APPROVED BY Cory Leverett TIMCO REPORT NO. 16 42 AUT14TestReport.docx TEST RESULTS PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP://WWW.TIMCOENGR.COM TABLE OF CONTENTS GENERAL REMARKS ............................................................................................................ 2 GENERAL INFORMATION ..................................................................................................... 3 EUT TECHNICAL DESCRIPTION ........................................................................... 3 GENERAL INFORMATION ..................................................................................................... 4 TEST PROCEDURES ............................................................................................................. 5 TEST REPORT SUMMARY ..................................................................................................... 6 RF POWER OUTPUT ............................................................................................................. 7 MODULATION CHARACTERISTICS ...................................................................................... 8 OCCUPIED BANDWIDTH ...................................................................................................... 8 MODULATION CHARACTERISTICS OCCUPIED BANDWIDTH .................................... 9 20 dB .............................................................................................................. 9 FIELD STRENGTH OF SPURIOUS EMISSIONS ................................................................... 10 FIELD STRENGTH OF SPURIOUS EMISSIONS TEST SETUP PHOTO ......................... 11 FIELD STRENGTH OF SPURIOUS EMISSIONS TEST DATA ..................................... 13 SPURIOUS EMISSIONS AT ANTENNA TERMINALS (CONDUCTED) .................................... 15 FREQUENCY STABILITY ..................................................................................................... 16 EMC EQUIPMENT LIST ....................................................................................................... 17 Applicant: CLEARONE INC. FCC ID: FBITABLETOP REPORT: W:\C\CLEARONE_FBI\1642AUT14\1642AUT14TESTREPORRREV1.DOCX Page 2 of 18 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. The test results relate only to the items tested. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Project Manager Name Engineering Project Manager Date: 9/26/14 Table of contents Applicant: CLEARONE INC. FCC ID: FBITABLETOP REPORT: W:\C\CLEARONE_FBI\1642AUT14\1642AUT14TESTREPORRREV1.DOCX Page 3 of 18 GENERAL INFORMATION RULES FCC PART 2.1033 & IC RSS - Gen EUT TECHNICAL DESCRIPTION EUT Description TABLE TOP WIRELESS MICROPHONE FCC ID FBITABLETOP Model Number DS80-CC-C-M500, 910-6001-004-C, DS80-CC-C- M610, 910-6001-003-C, DS80-C0-C-M500, 910- 6001-014-C, DS80-C0-C-M610,910-6001-013-C Modulation CQPSK Type of Emission 156K0G1D Frequency Range 499-608MHz & 614-618MHz Test Frequencies 499, 511.58, 605.40, 614.35, & 617.60MHz Maximum Output Power 9.2milliWatts EUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable Table of contents Applicant: CLEARONE INC. FCC ID: FBITABLETOP REPORT: W:\C\CLEARONE_FBI\1642AUT14\1642AUT14TESTREPORRREV1.DOCX Page 4 of 18 GENERAL INFORMATION Test Facility Timco Engineering, Inc. 849 NW State Road 45, Newberry, FL 32669 Test Condition The temperature was 24-26ºC with a relative humidity of 50-60%. Modifications None Test Exercise (e.g software description, test signal, etc.) The EUT was operated in its normal mode of operation. Applicable Standards ANSI/TIA 603-C:2010, FCC CFR 47 Parts 2 and 74, RSS- Gen, RSS-123 Issue 2, 2011 Table of contents Applicant: CLEARONE INC. FCC ID: FBITABLETOP REPORT: W:\C\CLEARONE_FBI\1642AUT14\1642AUT14TESTREPORRREV1.DOCX Page 5 of 18 TEST PROCEDURES Power Line Conducted Interference: The procedure used was ANSI/TIA 603-C:2004 using a 50uH LISN. Both lines were observed with the UUT transmitting. The bandwidth of the spectrum analyzer was 10 kHz with an appropriate sweep speed. Bandwidth 20 dB: The measurements were made with the spectrum analyzer's resolution bandwidth (RBW) = 1 MHz and the video bandwidth (VBW) = 3 MHz and the span set as shown on plot. Power Output: For a device with a fixed antenna, RF power is measured as ERP as the antenna is permanently attached. The substitution method was used as described in A…

Text truncated - open the document above for the full version.

APPLICANT: CLEARONE INC. FCC ID: FBITABLETOP IC: 1970A-TABLETOP TEST SET UP PHOTOS
