FHO-E2038Self-ballasted LED lamp

VARMFRONT 1 2 4 3 Max 300 mm (max 1') English 6 Français 16 Español 28 6 English Functions 1. POWER button 2. LED indicators 3. USB-C (charging and supply power) 4. USB-A (only supply power) Charging power bank • Connect the USB-C cable to the USB-C port of the power bank first and then connect the USB cable to a USB-charger or USB-outlet that can provide sufficient power to charge the power bank. The LED indicators will display the charging status. Supply power to devices • Connect the USB cable to USB-C or USB-A port of the power bank first and then connect the USB-cable to your device that you want to charge. • The power bank will detect a connected device and start charging automatically. 7 • The LED indicators will display the remaining charge in the power bank during discharging. Check power status • Click once on the POWER button and the LED indicators will light up and indicate the remaining power status. • If the USB cable is not disconnected while the charging process finishes, push the POWER button first to restart the charging. Small current supply mode • Press the POWER button for 8 seconds when your device is being charged. • The function is mainly used to charge certain wearable electronic devices. When charging a device that needs a charging current less than 100mA via a USB-A port, this mode should be activated. You can press the button for 3 seconds to exit this mode, it also automatically closes after 2 hours. 8 Power button function (E2038) Supply power modeNo actionStop supplying powerSwitch to the small current supply mode or back to normal supply power mode Charging modeUSB-A is ready to use.No actionNo action Sleeping modeShows via LED the remaining charge and that USB-A is ready to use.No actionTurn off after restart Current modeSingle pressDouble pressLong press 9 Good to know • You can charge up to 3 devices at the same time since the charger has 2 USB-A ports and 1 USB-C port. (Power Delivery and Quick Charge) • The USB-C port is compatible with the Power Delivery (PD) 3.0 standard and Quick Charge (QC) 3.0 standard. • The USB-A ports are compatible with the Quick Charge (QC) 3.0 standard. • USB cable length and quality influences charging speed and performance. • Devices may get warm during charging; this is completely normal and they will gradually cool down again after they are fully charged. • Charging time may vary based on the device’s battery capacity, charge level, the age of the battery and the temperature in the surrounding area. • Storage temperature: -10°C to 25°C (14 °F to 77 °F ). • Power bank operating temperature: 0°C to 40°C (32 °F to 104 °F ). 10 • Unplug the power bank from the power source before cleaning and when it is not in use. • Power bank should not be left discharged for a longer period. • Power bank should not be charged while in contact with flammable materials like textiles. WARNING • Do not modify, disassemble, open, drop, crush, puncture or shred product. • Only use in dry locations. • Risk of fires and burns. Do not open, crush, heat above 60°C (140°F) or incinerate. • Do not subject the product to wet, moist or excessively dusty environments since this can cause damage to the unit. • Keep the product away from open flames or sunlight to prevent heat buildup. • Keep the product away from high voltage devices. 11 • Children should be supervised to ensure they do not play with the product. • Do not short-circuit the product or its cells. • In the event of a cell leaking, do not allow the liquid to come in contact with the skin or eyes. Product servicing Do not attempt to repair this product yourself. If you open or remove parts, you may expose yourself to dangerous voltage points or other risks. Care instruction To clean the unit, wipe with a soft cloth moistened with a little mild detergent. Use another soft dry cloth to wipe dry. 12 Technical data Type: E2038 Capacity: 10400mAh/37.44Wh Input: 5.0Vdc, 3.0A/ 9.0Vdc, 2.0A/ 12.0Vdc, 1.5A (USB-C QC&PD) Output: 5.0Vdc, 3.0A, 15.0W/ 9.0Vdc, 2.0A, 18.0W/ 12.0Vdc, 1.5A, 18.0W (USB-C QC&PD, USB-A QC) When two or three ports output at the same time, they share 5.0V/3.0A. For indoor use only Rechargeable Li-Ion battery cell inside. Manufacturer: IKEA of Sweden AB Address: Box 702 SE-343 81 Älmhult SWEDEN 13 This device complies with Part 15 of the FCC Rules/Innovation Science and Economic Development Canada's licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device. WARNING: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC 14 Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the quipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 15 • Consult the dealer or an experienced radio/ TV technician for help. The crossed-out wheeled bin symbol indicates that the item should be disposed of sepa…

Text truncated - open the document above for the full version.

12 January 2023 1 (1) Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and Report & Order 22-84 located at htt ps://docs.fcc. gov/public/attachments/DOC-389524A1.pdf Applicant: I KEA of Sweden AB F CC ID: FHO-E2038 To whom it may concern, Pursuant to FCC Report & Order 22-84 section IV. Interim Freeze Order, paragraphs 264, 265, and 266, as an authorized representative of IKEA of Sweden AB, I attest that the equipment for which we are seeking equipment authorization through certification is not prohibited from receiving an equipment authorization; and IKEA of Sweden AB is not an entity identified on the Covered List or an affiliate or subsidiary of an entity identified on the Covered List, established pursuant to 47 CFR §1.50002. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the company and agree to immediately notify lntertek if there is any change in the status identified above. � � Ivan S usak Engineering manager IKEA of Sweden AB

© Inter IKEA Systems B.V. 2014 December 5 th , 2022 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement IKEA of Sweden AB FCC ID: FHO-E203 8 To Whom It May Concern: We, IKEA of Sweden AB, hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number FHO- E2038 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is December 5 th , 2022. The Limited Agency Agreement expires on March 5 th , 2023, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of f ederal benefits pursuant to Section 5301 of t he Anti -Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of f ederal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, I van Susak Team Manager, Laws&Standards IKEA of Sweden AB [email protected] +4647681000

Date: July 27, 2021 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality (Long and Short Term) FCC ID: FHO-E2038 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting, the Commission withhold the following submissions documents as confidential documents from public disclosure indefinitely. • Block Diagram(s) • Operational description • Schematics Those documents contain detailed system and equipment description and related information about the product which we consider to be confidential, proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis from which future technological products will evolve, we consider that this information would be of benefit to our competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request of 180 days for: • External Photos • Internal Photos • Test Setup Photos • User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Best regards, Ivan Susak Team Manager, Laws&Standards IKEA of Sweden AB [email protected] +4647681000

External view External view External view Internal view PCB view PCB view

YYWW YearWeek 2021---21 2022---22 2023---23 ...... 1st---01 2nd---02 3rd---03 ...... YYWW IKEA of Sweden AB SE-343 81 Älmhult 23159 CAUTION: SEE OPERATING INSTRUCTIONS ATTENTION: VOIR MODE DÉMPLOI Model: E2038 VARMFRONT Battery capacity: 3.6V, 10400mAh, 37.44Wh Input: 5V 3A Max, 9V 2A Max, 12V 1.5A Max (Type-C) Output: 5V 3A Max, 9V 2A Max, 12V 1.5A Max (Type-C) 5V 3A Max, 9V 2A Max, 12V 1.5A Max (USB A1) 5V 3A Max, 9V 2A Max, 12V 1.5A Max (USB A2) Total Output: 5V 3A Max Li-ion1INR19/65-4 CAN ICES-003 (B) / NMB-003 (B) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: FHO-E2038 5018762 CONFORMS TO UL Std.62368-1 CERTIFIED TO CSA Std. C22.2 No.62368-1 定格容量: 5V 6900mAh 9V 3800mAh 12V 2800mAh Made in China / Hecho en China 111mm 87mm

External view External view External view Internal view PCB view PCB view

IKEA OF SWEDEN AB TEST REPORT SCOPE OF WORK EMC TESTING–E2038 VARMFRONT REPORT NUMBER 220614245GZU-001 ISSUE DATE [REVISED DATE] 05-December-2022 [--------------------] PAGES 29 DOCUMENT CONTROL NUMBER FCC Part 15:2020-f © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 19-September-2021 Page 2 of 29 FCC Part 15:2020-f Applicant Name & Address : IKEA OF SWEDEN AB Box 702, 343 81 Ä LMHULT, SWEDEN Manufacturing Site : NanChang Innotech Homesmart Co., Ltd 1st to 5th floor, 2-1#, Nanchang Small and Medium-sized Enterprises Entrepreneurship Incubation Base (Phase II), Guowei Industrial Park, No. 669 Huangtang E Rd, Linkong Economic Zone, Nanchang, Jiangxi, China Intertek Report No: 220614245GZU-001 FCC ID: FHO-E2038 Test standards CFR 47, FCC Part 15, Subpart B:2020 Sample Description Product : Power bank Model No. : E2038 VARMFRONT Electrical Rating : Input: 5VDC 3A Max, 9VDC 2A Max, 12VDC 1.5A Max (TYPE-C) Output: 5VDC 3A Max, 9VDC 2A Max, 12VDC 1.5A Max (TYPE-C) 5VDC 3A Max, 9VDC 2A Max, 12VDC 1.5A Max (USB A1) 5VDC 3A Max, 9VDC 2A Max, 12VDC 1.5A Max (USB A2) Total Output: 5VDC 3A Max Battery Capacity: 3.6V, 10400mAh, 37.44Wh Serial No. Not Labeled Date Received : 14 June 2022 Date Test Conducted : 14 June 2022-29 June 2022 Prepared and Checked By Jackson Zhang Sr. Project Engineer Approved By: Sky Zhu Team Leader TEST REPORT Intertek Report No.: 220614245GZU-001 Version: 19-September-2021 Page 3 of 29 FCC Part 15:2020-f CONTENT TEST REPORT ....................................................................................................................... 1 CONTENT ......................................................................................................................... 3 1. TEST RESULTS SUMMARY ......................................................................................... 4 2. EMC RESULTS CONCLUSION...................................................................................... 5 3. LABORATORY MEASUREMENTS ................................................................................ 6 4. EQUIPMENT USED DURING TEST .............................................................................. 8 5. EMI TEST ................................................................................................................ 10 5.1 CONDUCTED DISTURBANCE VOLTAGE AT MAINS PORTS ....................................................... 10 5.1.1 Block Diagram of Test Setup ............................................................................. 10 5.1.2 Test Setup and Procedure ................................................................................. 10 5.1.3 Limit .................................................................................................................. 11 5.1.4 Test Data and curve .......................................................................................... 12 5.2 RADIATED EMISSION 30 MHZ -1000 MHZ ...................................................................... 20 5.2.1 Block Diagram of Test Setup ............................................................................. 20 5.2.2 Test Setup and Procedure ................................................................................. 20 5.2.3 Limit .................................................................................................................. 21 5.2.4 Test Data and Curve ......................................................................................... 22 5.3 RADIATED EMISSION ABOVE 1 GHZ ................................................................................. 29 TEST REPORT Intertek Report No.: 220614245GZU-001 Version: 19-September-2021 Page 4 of 29 FCC Part 15:2020-f 1. TEST RESULTS SUMMARY Classification of EUT: Class B Test Item Standard Result Conducted disturbance voltage at mains ports CFR 47, FCC Part 15, Subpart B Pass Radiated emission (30 MHz–1 GHz) CFR 47, FCC Part 15, Subpart B Pass Radiated emission (Above 1 GHz) CFR 47, FCC Part 15, Subpart B N/A Remark: Reference publication is used for methods of measurement: ANSI C63.4:2014 Remark: 1. The symbol “N/A” in above table means Not Applicable. 2. When determining the test results, measurement uncertainty of tests has been considered. TEST REPORT Intertek Report No.: 220614245GZU-001 Version: 19-September-2021 Page 5 of 29 FCC Part 15:2020-f 2. EMC RESULTS CONCLUSION RE: EMC Testing Pursuant to FCC part 15 performed on the Power bank Model: E2038 VARMFRONT. We tested the Power bank Model: E2038 VARMFRONT, to determine if it was in compliance with the relevant standards as marked on the Test Results Summary. We found that the unit met the requirement of FCC part 15 standard…

Text truncated - open the document above for the full version.

Conducted disturbance voltage at mains ports Radiated emission (30 MHz–1000 MHz)
