FHO-J2143Decoration lamp with LED

DRAFT STRÅLA DRAFT English J2143 IMPORTANT SAFETY INSTRUCTIONS For indoor use only. Regularly check the cord, the transformer and all other parts for damage. If any part is damaged the product should not be used. Important information! Keep these instructions for future use. CAUTION! The light source of this product is non-changeable light diodes (LED). Do not disassemble the product, as the light diodes can cause damage to the eyes. Do not immerse in water. Cleaning Use a damp cloth, never a strong cleaning agent. English This device complies with part 15 of the FCC Rules. Operation is subjected to the following two conditions: 1. This device may not cause harmful interference, and DRAFT 2. this device must accept any interference received, including interference that may cause undesired opera- tion. WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfe- rence in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. DRAFT -Consult the dealer or an experienced radio/TV technici- an for help. English CAUTION! Strangulation hazard. Hang out of reach of young children. English WARNING Deviation from the assembly instructions may result in a risk of fire or electric shock. English IMPORTANT SAFETY INSTRUCTIONS When using electrical products, basic precautions should always be followed including the following: DRAFT READ AND FOLLOW ALL SAFETY INSTRUCTIONS Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use. When products are used in outdoor applications, connect the product to a Ground Fault Circuit Interrupting (GFCI) outlet. If one is not provided, contact a qualified electrician for proper installation. This seasonal use product is not intended for permanent installation or use. Do not mount or place near gas or electric heaters, fireplaces, candles or other similar sources of heat. Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails. Do not let lamps rest on the supply cord or on any wire. Unplug the product when leaving the house, when retiring for the night, or if left unattended. This is an electric product - not a toy! To avoid risk of fire, burns, personal injury and electric shock it should not be played with or placed where small children can reach it. Do not use this product for other than its intended use. Do not hang ornaments or other objects from cord, wire, or light string. Do not close doors or windows on the product or extension cords as this may damage the wire insulation. Do not cover the product with cloth, paper or any material not part of the product when in use. Read and follow all instructions that are on the product or provided with the product. DRAFT English USE AND CARE INSTRUCTIONS When the product is placed on a live tree, the tree should be well maintained and fresh. Do not place on live trees in which the needles are brown or break off easily. Keep the tree holder filled with water. If the product is placed on a tree, the tree should be well secured and stable. Before using or reusing, inspect product carefully. Discard any products that have cut, damaged, or frayed wire insulation or cords, cracks in the lampholders or enclosures, loose connections, or exposed copper wire. When storing the product, carefully remove the product from wherever it is placed, including trees, branches, or bushes, to avoid any undue strain or stress on the product conductors, connections, and wires. When not in use, store neatly in a cool, dry location protected from sunlight. English SEASONAL AND HOLIDAY LIGHTS INTRODUCTION This leaflet provides guidance on the purchase, inspec- tion, installation and use of Seasonal and Holiday lighting sets. Modern Seasonal and Holiday lighting sets DRAFT are safe to use if simple checks are taken. It is obvious but necessary to say, only use outdoor lights outdoors. If young children are around use Extra low voltage lights (24 or 12 Volts). Outdoors also use Extra low voltage lights unless you are going to make sure they are installed well out of reach of everyone. If you are going to put mains voltage lights outdoors protect them and everyone else by using a plug-in RCD. These are the devices you need when using a lawnmower or hedge trimmer. Electric lamps are much much safer than candles, go electric, no candles on your tree or anywhere near it. You may know they are just for show but someo- ne else during the festivities might think lighting the candles is a great idea. Go electric. Have you got young people in the house? Have you a working smoke alarm? Have you tested it? Go-on, do it now, you know it makes sense. Then go and buy a battery, it is so very necessary for a happy Holiday. First the smoke alarm, then the fancy decorations! Visual inspections New Seasonal and Holiday lighting sets should be checked and inspected in accordance with the manufacturer's instructions provided with the set. Don't throw away the box, keep it to store …

Text truncated - open the document above for the full version.

© Inter IKEA Systems B.V. 2014 Jan 25, 2022 Federal Communications Commission 44 5 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement IKEA of Sweden AB FCC ID: FHO-J2143 To Whom It May Concern: We, IKEA of Sweden AB, hereby authorized Intertek Semko AB, Swedens to act as our Agent for the purpose of preparing application for FCC ID number FHO-J2112 under all applicable parts of the FCC rules 12 regulations. The effective date of this limited agency agreement Jan 25th 2022. The Limited Agency Agreement expires on July 25th, 2022, unless sooner terminated or extended by written notice to Intertek Semko AB, Sweden and the Federal Communications Commission. This is to advise that we are in fu ll compliance with the Anti-Drug Abuse Act. The applicant i s not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Ivan Susak Team Manager, Laws&Standards IKEA of Sweden AB [email protected] +4647681000

© Inter IKEA Systems B.V. 2014 Jan 25, 2022 Attention: Application Examiner RE: Request for Confidentiality Applicant: IKEA of Sweden AB FCC ID: FHO-J2143 To Whom It May Concern: Permanent Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: Schematics Detailed Operational/Functional Description Block diagram Parts list Short-term Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold from public review for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 180 days from the date of Authorization: Test setup photos External photos Internal photos User manual Rationale for request for confidentiality: IKEA of Sweden AB has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would © Inter IKEA Systems B.V. 2014 also disclose successful implementation of unpublished, leading edge technology developed by us.] [Short term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] Sincerely, Ivan Susak Team Manager –Laws & standards IKEA of Sweden AB [email protected] +4647681000

TEST REPORT Intertek Report No.: 211021039GZU-001 Annex 1. ANNEX - PHOTOS OF TEST SETUP Conducted Emission Radiated Emission (30 MHz–1000 MHz) TEST REPORT Intertek Report No.: 211021039GZU-001 Annex 2. APPENDIX II – PHOTOS OF EUT External view Power unit view TEST REPORT Intertek Report No.: 211021039GZU-001 Annex Input connector view Controller view TEST REPORT Intertek Report No.: 211021039GZU-001 Annex Controller internal view Controller PCB view TEST REPORT Intertek Report No.: 211021039GZU-001 Annex LED view LED lighting string view *****************************End of Report***************************

Internal J2143 label position

Internal J2143 label

Internal Photos J2143 Stråla

IKEA of Sweden AB TEST REPORT SCOPE OF WORK EMC TESTING–J2143 STRÅLA REPORT NUMBER 211021039GZU-001 ISSUE DATE [REVISED DATE] 01-December-2021 [---------------------] PAGES 17 DOCUMENT CONTROL NUMBER FCC Part 15:2019-e © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 02-April-2020 Page 2 of 17 FCC Part 15:2019-e Applicant Name & Address : IKEA of Sweden AB Box 702, 343 81 Älmhult, SWEDEN Manufacturing Site : ZheJiang Hao Ting Lighting Co. Ltd Feng Ming Industrial Zone TONG XIANG CITY Zhejiang Province 314505 Intertek Report No : 211021039GZU-001 Test standards CFR 47, FCC Part 15, Subpart B: 2019 Sample Description Product : Low Voltage LED decorative lighting string Model No. : J2143 Stråla Electrical Rating : Input to power unit: 230 Vac, 50Hz; Input to string: 5Vdc, 0.32A, 1.6W, 200pcs non-replaceable LEDs Serial No. : Not Labeled Date Received : 02 November 2021 Date Test Conducted : 02 November 2021-01 December 2021 Prepared and Checked By Eric Chen Engineer Approved By: Jackson Zhang Sr. Project Engineer TEST REPORT Intertek Report No.: 211021039GZU-001 Version: 02-April-2020 Page 3 of 17 FCC Part 15:2019-e CONTENT TEST REPORT ....................................................................................................................... 1 CONTENT ......................................................................................................................... 3 1. TEST RESULTS SUMMARY ......................................................................................... 4 2. EMC RESULTS CONCLUSION...................................................................................... 5 3. LABORATORY MEASUREMENTS ................................................................................ 6 4. EQUIPMENT USED DURING TEST .............................................................................. 7 5. EMI TEST .................................................................................................................. 9 5.1 CONDUCTED DISTURBANCE VOLTAGE AT MAINS PORTS ......................................................... 9 5.1.1 Block Diagram of Test Setup ............................................................................... 9 5.1.2 Test Setup and Procedure ................................................................................... 9 5.1.3 Limit .................................................................................................................. 10 5.1.4 Test Data and curve .......................................................................................... 11 5.2 RADIATED EMISSION 30 MHZ -1000 MHZ ...................................................................... 13 5.2.1 Block Diagram of Test Setup ............................................................................. 13 5.2.2 Test Setup and Procedure ................................................................................. 13 5.2.3 Limit .................................................................................................................. 14 5.2.4 Test Data and Curve ......................................................................................... 15 5.3 RADIATED EMISSION ABOVE 1 GHZ ................................................................................. 17 TEST REPORT Intertek Report No.: 211021039GZU-001 Version: 02-April-2020 Page 4 of 17 FCC Part 15:2019-e 1. TEST RESULTS SUMMARY Classification of EUT: Class B Test Item Standard Result Conducted disturbance voltage at mains ports CFR 47, FCC Part 15, Subpart B Pass Radiated emission (30 MHz–1 GHz) CFR 47, FCC Part 15, Subpart B Pass Radiated emission (Above 1 GHz) CFR 47, FCC Part 15, Subpart B N/A Remark: Reference publication is used for methods of measurement: ANSI C63.4:2014 Remark: 1. The symbol “N/A” in above table means Not Applicable. 2. When determining the test results, measurement uncertainty of tests has been considered. TEST REPORT Intertek Report No.: 211021039GZU-001 Version: 02-April-2020 Page 5 of 17 FCC Part 15:2019-e 2. EMC RESULTS CONCLUSION RE: EMC Testing Pursuant to FCC part 15 performed on the Low Voltage LED decorative lighting string, Models: J2143 Stråla. We tested the Low Voltage LED decorative lighting string, Model: J2143 Stråla to determine if it was in compliance with the relevant standards as marked on the Test Results Summary. We found that the unit met the requirement of FCC part 15 standard when tested as received. The worst case’s test data was presented in this test report. The production units are required to conform to the initial sample as received when the units are placed on the market. TEST REPORT Intertek Report No.: 211021039GZU-00…
