FHO-K2202Decoration lamp with LED

IKEA of Sweden AB

Click to zoom

Application Details

Equipment Class: JAB - Part 15 Class B Digital Device
Date of Grant: Jul 10, 2022
Application Purpose: Original Equipment
Date of Application: Jul 10, 2022
Equipment Note: Decoration lamp with LED
Company: IKEA of Sweden AB
Country: Sweden

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 STÄNKREGN 2AA-2332539-1 English IMPORTANT SAFETY INSTRUCTIONS For indoor use only. Regularly check the cord, the transformer and all other parts for damage. If any part is damaged the product should not be used. Important information! Keep these instructions for future use. CAUTION! The light source of this product is non- changeable light diodes (LED). Do not disassemble the product, as the light diodes can cause damage to the eyes. Do not immerse in water. Cleaning Use a damp cloth, never a strong cleaning agent. English WARNING Deviation from the assembly instructions may result in a risk of fire or electric shock. English CAUTION! Strangulation hazard. Hang out of reach of young children. 3 English This device complies with part 15 of the FCC Rules. Operation is subjected to the following two conditions: 1. This device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause undesired operation. WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. English Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. SAVE THESE INSTRUCTIONS 4AA-2332539-1 Français CONSIGNES DE SÉCURITÉ IMPORTANTES Uniquement pour une utilisation en intérieur. Vérifier régulièrement que le câble, le transformateur et les autres parties ne sont pas endommagés. Si l'une de ces pièces est endommagée, ne pas utiliser le produit. Information importante. Conserver la notice pour tout utilisation ultérieure. MISE EN GARDE La source lumineuse du produit est composée de diodes (LED) qui ne se remplacent pas. Ne jamais démonter le produit, les diodes peuvent causer des blessures aux yeux. Ne jamais immerger dans de l'eau. Entretien Nettoyer à l’aide d’un chiffon humide, éviter les détergents puissants. Français ATTENTION Tout écart par rapport aux instructions d'assemblage peut entraîner un risque d'incendie ou de choc électrique. Français ATTENTION! Risque d'étranglement. Accrocher hors de portée des jeunes enfants. 5 Français Cet appareil est conforme à la partie 15 des règles de la FCC. Son fonctionnement est soumis aux deux conditions suivantes: 1. Cet appareil ne doit pas provoquer de brouillage préjudiciable et 2. il doit accepter tout brouillage reçu, y compris le brouillage pouvant entraîner un mauvais fonctionnement. ATTENTION: Tout changement apporté à cet appareil non expressément approuvé par la partie responsable de la conformité est susceptible d'annuler le droit de l'utilisateur à se servir de cet équipement. Français Note : Cet équipement a été testé et déclaré conforme aux limites imposées aux appareils numériques de la classe B, en vertu de la partie 15 des règles de la FCC. Ces limites sont conçues pour assurer une protection suffisante contre les interférences nuisibles dans les installations résidentielles. Cet équipement génère, utilise et peut dégager de l'énergie de radiofréquence et, s'il n'est pas installé et utilisé conformément aux instructions du fabricant, provoquer un brouillage préjudiciable aux communications radio. Il n'existe toutefois aucune garantie qu'un équipement particulier ne sera pas victime de brouillage. Si cet équipement entraîne un brouillage préjudiciable à la réception des émissions radio ou de télévision, identifiable en mettant le terminal hors puis sous tension, il est recommandé à l'utilisateur de tenter de résoudre ce problème au moyen d'une ou plusieurs des mesures suivantes: - Orienter l'antenne réceptrice différemment ou la changer de place. - Augmenter la distance séparant l'équipement du récepteur. - Connecter l’appareil à une prise sur un circuit différent de celui auquel est branché le récepteur. - Obtenir de l'aide auprès du revendeur ou d'un technicien radio/TV expérimenté. CONSERVER CES MESURES DE SÉCURITÉ 6AA-2332539-1 Español INSTRUCCIONES IMPORTANTES DE SEGURIDAD Sólo para uso en interiores. Comprobar el cable, el transformador y los demás componentes con regularidad para cerciorarte de que no se hayan dañado. Si el producto tiene algún componente dañado, no se debe usar. ¡Información importante! Guardar estas instrucciones para su uso futuro. ¡ADVERTENCIA! La fuente de luz de este producto se compone de diodos luminosos (LED) que no pueden reemplazarse. Este producto no se debe desmontar, ya que los diodos luminosos pueden cuasar daños a los ojos. No se debe sumergir en agua. Limpieza Utiliza un paño húmedo. Evita utilizar detergentes fuertes. Español ADVERTENCIA No seguir las instrucciones de montaje puede resultar en incendio o descarga eléctrica. Español ¡PRECAUCIÓN! Riesgo de estrangulamiento. Colgar fuera del alcance de los niños. 7 Español Este aparato cumple la parte 15 de las normas FCC. Su funcionamiento está sujeto a las dos condiciones siguientes: 1. Este aparato no debe provocar interferencias perjudiciales. 2. Debe aceptar cualquier interferencia que reciba, incl…

Text truncated - open the document above for the full version.

Cover Letter(s)

© Inter IKEA Systems B.V. 2014 May 17, 2022 Federal Communications Commission 44 5 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement IKEA of Sweden AB FCC ID: FHO-K2202 To Whom It May Concern: We, IKEA of Sweden AB, hereby authorized Intertek Semko AB, Sweden to act as our Agent for the purpose of preparing application for FCC ID number FHO-K2202 under all applicable parts of the FCC regulations. The effective date of this limited agency agreement May 17th 2022. The Limited Agency Agreement expires on Nov 16th, 2022, unless sooner terminated or extended by written notice to Intertek Semko AB, Sweden and the Federal Communications Commission. This is to advise that we are in fu ll compliance with the Anti-Drug Abuse Act. The applicant i s not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Ivan Susak Team Manager, Laws&Standards IKEA of Sweden AB [email protected] +4647681000

Cover Letter(s)

© Inter IKEA Systems B.V. 2014 May 17, 2022 Attention: Application Examiner RE: Request for Confidentiality Applicant: IKEA of Sweden AB FCC ID: FHO-K2202 To Whom It May Concern: Permanent Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: Schematics Detailed Operational/Functional Description Block diagram Parts list Short-term Confidentiality Request is hereby submitted by IKEA of Sweden AB to withhold from public review for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 180 days from the date of Authorization: Test setup photos External photos Internal photos User manual Rationale for request for confidentiality: IKEA of Sweden AB has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would © Inter IKEA Systems B.V. 2014 also disclose successful implementation of unpublished, leading edge technology developed by us.] [Short term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] Sincerely, Ivan Susak Team Manager –Laws & standards IKEA of Sweden AB [email protected] +4647681000

External Photos

TEST REPORT Intertek Report: No: 211216128GZU-001 Amendment 1 Annex Version: 22-February-2019 Page 1 of 4 ICES-005:2018 (Issue 5)-a 1. ANNEX - PHOTOS OF TEST SETUP Conducted Emission Radiated Emission (30 MHz–1000 MHz) TEST REPORT Intertek Report: No: 211216128GZU-001 Amendment 1 Annex Version: 22-February-2019 Page 1 of 4 ICES-005:2018 (Issue 5)-a 2. APPENDIX II – PHOTOS OF EUT Overall view Back view TEST REPORT Intertek Report: No: 211216128GZU-001 Amendment 1 Annex Version: 22-February-2019 Page 1 of 4 ICES-005:2018 (Issue 5)-a Internal view Internal view TEST REPORT Intertek Report: No: 211216128GZU-001 Amendment 1 Annex Version: 22-February-2019 Page 1 of 4 ICES-005:2018 (Issue 5)-a PCB View *****************************End of Report***************************

ID Label/Location Info

Label loca�on for K2202

Internal Photos

Test Report

IKEA of Sweden AB TEST REPORT SCOPE OF WORK EMC TESTING–K2202 STÄ NKREGN REPORT NUMBER 211216128GZU-001 ISSUE DATE [REVISED DATE] 25-January-2022 [28-June-2022] PAGES 17 DOCUMENT CONTROL NUMBER FCC Part 15:2019-e © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 02-April-2020 Page 2 of 17 FCC Part 15:2019-e Applicant Name & Address : IKEA of Sweden AB Box 702, SE-343 81 Ä lmhult, Sweden Manufacturing Site : Zhejiang Haoting Lighting Co., Ltd. Feng Ming Industrial Zone TONG XIANG CITY Zhejiang Province 314505, China Intertek Report No : 211216128GZU-001 Amendment 1 Test standards CFR 47, FCC Part 15, Subpart B: 2019 ICES-005: 2018 (Issue 5) Sample Description Product : LED Portable luminaires Model No. : K2202 STÄ NKREGN Electrical Rating : 5VDC, Max 0.9W; Serial No. Not Labeled Date Received : -- Date Test Conducted : -- Prepared and Checked By Jackson Zhang Sr. Project Engineer Approved By: Sky Zhu Team Leader TEST REPORT Intertek Report No.: 211216128GZU-001 Amendment 1 Version: 02-April-2020 Page 3 of 17 FCC Part 15:2019-e CONTENT CONTENT ......................................................................................................................... 3 1. TEST RESULTS SUMMARY ......................................................................................... 4 2. EMC RESULTS CONCLUSION...................................................................................... 5 3. LABORATORY MEASUREMENTS ................................................................................ 6 4. EQUIPMENT USED DURING TEST .............................................................................. 7 5. EMI TEST .................................................................................................................. 9 5.1 CONDUCTED DISTURBANCE VOLTAGE AT MAINS PORTS ......................................................... 9 5.1.1 Block Diagram of Test Setup ............................................................................... 9 5.1.2 Test Setup and Procedure ................................................................................... 9 5.1.3 Limit .................................................................................................................. 10 5.1.4 Test Data and curve .......................................................................................... 11 5.2 RADIATED EMISSION 30 MHZ -1000 MHZ ...................................................................... 13 5.2.1 Block Diagram of Test Setup ............................................................................. 13 5.2.2 Test Setup and Procedure ................................................................................. 13 5.2.3 Limit .................................................................................................................. 14 5.2.4 Test Data and Curve ......................................................................................... 15 5.3 RADIATED EMISSION ABOVE 1 GHZ ................................................................................. 17 6. PHOTO OF TEST SETUP AND EUT ............................................................................ 17 TEST REPORT Intertek Report No.: 211216128GZU-001 Amendment 1 Version: 02-April-2020 Page 4 of 17 FCC Part 15:2019-e 1. TEST RESULTS SUMMARY Classification of EUT: Class B Test Item Standard Result Conducted disturbance voltage at mains ports CFR 47, FCC Part 15, Subpart B Pass Radiated emission (30 MHz–1 GHz) CFR 47, FCC Part 15, Subpart B Pass Radiated emission (Above 1 GHz) CFR 47, FCC Part 15, Subpart B N/A Remark: Reference publication is used for methods of measurement: ANSI C63.4:2014 Remark: 1. The symbol “N/A” in above table means Not Applicable. 2. When determining the test results, measurement uncertainty of tests has been considered. TEST REPORT Intertek Report No.: 211216128GZU-001 Amendment 1 Version: 02-April-2020 Page 5 of 17 FCC Part 15:2019-e 2. EMC RESULTS CONCLUSION RE: EMC Testing Pursuant to FCC part 15 performed on the LED Portable luminaires, Models: K2202 STÄ NKREGN. We tested the LED Portable luminaires, Model: K2202 STÄ NKREGN to determine if it was in compliance with the relevant standards as marked on the Test Results Summary. We found that the unit met the requirement of FCC part 15 standard when tested as received. The worst case’s test data was presented in this test report. Report revision reason: Amendment 1: This report is the revision of the previous test report 211216128GZU-001 dated 25-January- 2022 and shall be replace. 1. APPENDIX I - PHOTOS OF TEST SETUP and APPENDIX II – PHOTOS OF EUT remove this report. Create a new associated document 211216128G…
