FHO-LED2109G6Self-Ballasted LED Lamp

TRÅDFRI max 5 cm (max 2") > 10 s English 6 Français 16 Español 26 5English ADD LIGHT SOURCES TO YOUR STEERING DEVICE: Before you can use your light source you’ll need to pair it with a steering device. To add more light sources, just repeat the steps below: 1. Make sure that your light source is installed and the main power switch is turned on. 2. Hold the steering device close to the light source you want to add (no more than 5 cm away). 3. Press and hold the pairing button for at least 10 seconds. A red light will shine steadily on the 6 steering device. Your light source will begin to dim and finally flash one time to indicate that it has been successfully paired. Up to 10 light sources can be paired with 1 steering device. Make sure to pair them one at a time. If the light sources are close to each other, disconnect those that have already been paired from the main power switch. CAUTION: DO NOT USE WITH STANDARD DIMMERS. Only use the control 7 provided with or specified by these instructions to control this bulb. This bulb will not operate properly when connected to a standard (incandescent) dimmer or dimming control. Only controllable by IKEA Smart lighting products. RESET YOUR DEVICE Toggle the main switch 6 times. TECHNICAL DATA: Operating frequency: 2405 – 2480 MHz Output power: 10 dBm 8 Manufacturer: IKEA of Sweden AB Address: Box 702 SE-343 81 Älmhult SWEDEN This device complies with Part 15 of the FCC Rules. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation Science and Economic Development Canada's licence-exempt RSS standard(s). Operation is subject to the following two conditions: 9 (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device. WARNING: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 10 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. 11 However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the quipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from 12 that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. RF EXPOSURE INFORMATION According to RF exposure regulations, under normal operations the end user shall refrain from being closer than 20 cm from the device. 13 License rights and limitations NO RIGHTS OR LICENSES, EXPRESS OR IMPLIED, ARE GRANTED TO USE THIRD-PARTY DEVICES IN COMBINATION WITH THESE PRODUCTS IN A WIRELESS MESH NETWORK, OR TO USE THIRD-PARTY SERVICES TO ACCESS, MONITOR OR CONTROL THESE PRODUCTS IN A WIRELESS MESH NEWORK VIA THE INTERNET OR ANOTHER EXTERNAL WIDE AREA NETWORK. For use pursuant to U.S. Patent Nos.: US 6,914,893 US 7,697,492 US 8,964,708 14 The crossed-out wheeled bin symbol indicates that the item should be disposed of separately from household waste. The item should be handed in for recycling in accordance with local environmental regulations for waste disposal. By separating a marked item from household waste, you will help reduce the volume of waste sent to incinerators or land-fill and minimize any potential negative impact on human health and the environment. For more information, please contact your IKEA store. 15Français AJOUT SOURCES LUMINEUSES AU DISPOSITIF DE COMMANDE Avant d’utiliser votre source lumineuse, elle doit être couplée avec un dispositif de commande. Pour ajouter d’autres sources lumineuses, il suffit de répéter les étapes ci-dessous : 1. S’assurer que la source lumineuse est installée et allumée. 2. Maintenir le dispositif de commande à proximité (pas plus de 5 cm) de la source lumineuse à ajouter. 3. Appuyer sur le bouton de couplage et le maintenir 16 enfoncé au moins 10 secondes. Un voyant à LED rouge s’allume de manière continue sur le dispositif de commande. La source lumineuse baissera en intensité et clignotera une fois pour indiquer que le couplage est réussi. Il est possible de coupler jusqu’à 10 sources lumineuses à 1 dispositif de commande. Veiller à les coupler l’une après l’autre. Si les sources lumineuses sont proches les unes des autres, débrancher de l’alimentation générale celles qui ont déjà été couplées. 17 MISE EN GARDE: NE PAS UTILISER AVEC DES VARIATEURS D'INTENSITÉ STANDARD. Pour régler l'intensité lumineuse de cette ampoule, utiliser uniquement le dispositif de réglage fourni avec le produit ou mentionné dans les présentes instructions. Cette ampoule ne peut fonctionner correctement si elle est connectée à un variateur d'intensité standard (à incandescence). Cette ampoule ne peut fonctionner qu'avec les produits de la gamme éclairage connecté IKEA. 18 RÉINITIALISER L’APPAREIL Actionner l’interrupteur principal 6 fois. CARACTÉRISTIQUES TECHNIQUES Fréquence de fonctionnement : 2405 – 2480 MHz Puissance de sortie : 10 dBm Fabricant : IKEA of Sweden AB Adresse : Box 702, SE-343 81 Älmhult, SUÈDE 19 Ce dispositif est conforme à la section 15 des règlements de la FCC. Ce dispositif contient un ou plusieurs émetteurs/récepteurs sans licence qui sont conformes à la ou aux no…

Text truncated - open the document above for the full version.

Internal IKEA of Sweden AB Attestation Statements Not Covered Entity Applicant To: Federal Communications Commission Date: 2023.6.28 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(ii) filing FCC ID: FHO-LED2109G6 IKEA of Sweden AB (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely yours, Applicant Signature Printed Name: Ivan Susak Title: Engineering Manager Address: Box 702 SE-343 81, Almhult, Sweden Tel.: +4647681000 Email: [email protected] Ivan Susak (Jul 17, 2023 10:28 GMT+2) Ivan Susak

Internal IKEA of Sweden AB Attestation Statements Not Covered Equipment To: Federal Communications Commission Date: 2023.6.28 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) filing FCC ID: FHO-LED2109G6 IKEA of Sweden AB (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Ivan Susak Title: Engineering Manager Address: Box 702 SE-343 81, Almhult, Sweden Tel.: +4647681000 Email: [email protected] Ivan Susak (Jul 17, 2023 10:28 GMT+2) Ivan Susak

Internal Company Name (Applicant) U.S. Agent Designation for Service of Process ATTENTION: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA REGARDING: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Go Global Compliance, Inc. Contact Name: Peter Merguerian Street Address: 4454 Crabapple Ct. City/Province/Zip: Tracy, CA 95377 Telephone No: (408) 931-3303 Email: [email protected] FRN #: 0033672916 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: Signed by (Printed Name/Title): Peter Merguerian, President & CEO *This letter must be dated within 1-year (update if other terms apply) of the date the application is submitted to the TCB for device certification The Applicant confirms its explicit consent and acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: IKEA of Sweden AB FCC ID: FHO-LED2109G6 Contact Name: Ivan Susak Street Address: Box 702, SE-343 81, City/Province/Zip: Älmhult, Sweden Telephone No: +46766190914 Email: [email protected] Applicant Signature: Date: Signed by (Printed Name/Title): I van Susak (Jun 29, 2023 08:06 GMT+2) I van Susak Jun 29, 2023 I van Susak Range Engineering Manager Jun 29, 2023

IKEA of Sweden AB Page 1 of 1 Authority to Act as Agent Date: 2023.6.21 TUV Rheinland of North America, Inc. 1279 Quarry Lane., Suite. A Pleasanton, CA 94566 To Whom It May Concern: I appoint Jessie Xu of TÜV Rheinland (Shanghai) Co., Ltd. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the FCC or Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUV Rheinland Group, still resides with IKEA of Sweden AB (address: Box 702 SE-343 81, Almhult, Sweden). For TCB applications, We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Date: 2023.6.21 Agreement is valid for 12 months from the above date. By: __________________________ Ivan Susak (Signature) (Print name) BA Product Engineering Manager +4647681000 (Title) (Telephone) On behalf of: IKEA of Sweden AB (Company Name) Ivan Susak (Jun 29, 2023 08:10 GMT+2) Ivan Susak

IKEA of Sweden AB MS-0044715 Page 1 of 1 Revision 1 Internal Date: 2023.6.28 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Confidentiality Request for FHO-LED2109G6 Pursuant to FCC 47 CRF 0.457(d), the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term n/a External Photo Short Term Permanent Internal Photos *** Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Schematics Short Term Permanent Test Setup*** Short Term Permanent Tune-Up Procedure Short Term Permanent User’s Manual*** Short Term Permanent Part List/ Antenna Construction IKEA of Sweden AB has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. (*** Exceptional case for Permanent Confidentiality for these Exhibits by PAG only) Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: __________________ Engineering Manager __ ____ Ivan Susak _________________ (Signature/Title) (Print name) Tel: +4647681000 Email: [email protected] Ivan Susak (Jul 17, 2023 10:28 GMT+2) Ivan Susak

Revision Comment Approved by Approved date Description ♦ ♦ ______________________________________________ Name Replaces document No. of Pages 1 (1) Doc number Version Measurements according to the SI systems. This drawing is IKEA` prop erty and is covered by industrial and in- tellectual property rights and should, without written consent from IKEA, in no way be copied, re-produced or communicated or otherwise used for any other purpose other than that which has been agreed. A4 Template Version: 3.0 DRAWING IKEA of Sweden AB Marking_LED2109G6 E26_NA/MX Remark: CWS should be bold Marking position

Report Number: Attachment 2 of CN23KA4K 001 Model: LED2109G6 - Page 1 of 4 - Internal Photos Report Number: Attachment 2 of CN23KA4K 001 Model: LED2109G6 - Page 2 of 4 - Report Number: Attachment 2 of CN23KA4K 001 Model: LED2109G6 - Page 3 of 4 - Report Number: Attachment 2 of CN23KA4K 001 Model: LED2109G6 - Page 4 of 4 -

Prüfbericht - Produkte Test Report - Products Certificate #4301.01 Prüfbericht-Nr.: Test report no.: CN23KA4K 001 Auftrags-Nr.: Order no.: 244467986 Seite 1 von 21 Page 1 of 21 Kunden-Referenz-Nr.: Client reference no.: 1288983 Auftragsdatum: Order date: 2022-12-08 Auftraggeber: Client: IKEA of Sweden AB Box 702, SE-343 81 Älmhult, Sweden Prüfgegenstand: Test item: Self-Ballasted LED Lamp Bezeichnung / Typ-Nr.: Identification / Type no.: LED2109G6 Auftrags-Inhalt: Order content: TÜV Rheinland EMC service Prüfgrundlage: Test specification: FCC 47 CFR Part 15, Subpart B:2021 Class B ICES-005:2018 Wareneingangsdatum: Date of sample receipt: 2023-03-30 Refer to the EUT photos file Prüfmuster-Nr.: Test sample no: A003446434-003 Prüfzeitraum: Testing period: Refer to test report Ort der Prüfung: Place of testing: Refer to clause 1.1 Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shanghai) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: genehmigt von: authorized by: Datum: Date: 2023-07-28 Ausstellungsdatum: Issue date: 2023-07-28 Stellung / Position: Sachverständige(r)/Expert Stellung / Position: Sachverständige(r)/Expert Sonstiges / Other: FCC ID: FHO-LED2109G6 Test Firm Registration Number: 958801 Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the above mentioned test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TUV Rheinland (Shanghai) Co., Ltd. No.177, 178, Lane 777 West Guangzhong Road, Jing'an District,Shanghai, China Mail: [email protected] · Web: www.tuv.com Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: CN23KA4K 001 Test report no.: Seite 2 von 21 Page 2 of 21 Anmerkungen Remarks 1 Alle eingesetzten Prüfmittel waren zum angegebenen Prüfzeitraum gemäß eines festgelegten Kalibrierungsprogramms unseres Prüfhauses kalibriert. Sie entsprechen den in den Prüfprogrammen hinterlegten Anforderungen. Die Rückverfolgbarkeit der eingesetzten Prüfmittel ist durch die Einhaltung der Regelungen unseres Managementsystems gegeben. Detaillierte Informationen bezüglich Prüfkonditionen, Prüfequipment und Messunsicherheiten sind im Prüflabor vorhanden und können auf Wunsch bereitgestellt werden. The equipment used during the specified testing period was calibrated according to our test laboratory calibration program. The equipment fulfils the requirements included in the relevant standards. The traceability of the test equipment used is ensured by compliance with the regulations of our management system. Detailed information regarding test conditions, equipment and measurement uncertainty is available in the test laboratory and could be provided on request. 2 Wie vertraglich vereinbart, wurde dieses Dokument nur digital unterzeichnet. Der TÜV Rheinland hat nicht überprüft, welche rechtlichen oder sonstigen diesbezüglichen Anforderungen für dieses Dokument gelten. Diese Überprüfung liegt in der Verantwortung des Benutzers dieses Dokuments. Auf Verlangen des Kunden kann der TÜV Rheinland die Gültigkeit der digitalen Signatur durch ein gesondertes Dokument bestätigen. Diese Anfrage ist an unseren Vertrieb zu richten. Eine Umweltgebühr für einen solchen zusätzlichen Service wird erhoben. As contractually agreed, this document has been signed digitally only. TUV Rheinland has not verified and unable to verify which legal or other pertaining requirements are applicable for this document. Such verification is within the responsibility of the user of this document. Upon request by its client, TUV Rheinland can confirm the validity of the digital signature by a separate document. Such request shall be addressed to our Sales department. An environmental fee for such additional service will be charged. 3 Prüfklausel mit der Note * wurden an qualifizierte Unterauftragnehmer vergeben und sind unter der jeweiligen Prüfklausel des Berichts beschrieben. Abweichungen von Prüfspezifikation(en) oder Kundenanforderungen sind in der jeweiligen Prüfklausel im Bericht aufgeführt. Test clauses with remark of * are subcontracted to qualified subcontractors and descripted under the respective test clause in the report. Deviations of testing specification(s) or customer requirements are listed in specific test clause in the report. 4 Die Entscheidungsregel für Konformitätserklärungen basierend auf numerischen Messergebnisen in diesem Prüfbericht basiert auf der "Null-Grenzwert-Regel" und der "Einfachen Akzeptanz" gemäß ILAC G8:2019 und IEC Guide 115:2021, es sei denn, in der auf Seite 1 dieses Berichts genannten angewandten Norm ist etwas anderes festgelegt oder vom Kunden gewünscht. Dies bedeutet, dass die Messunsicherheit nicht berücksichtigt wird und daher auch nicht im Prüfbericht angegeben wird. Zu weiteren Informationen bezueglich des Risikos durch diese Entscheidungsregel siehe ILAC G8:2019. The decision rule for statements of conformity, based on numerical measurement results, in this test report is based on the “Zero Guard Band Rule” and “Simple Acceptance” in accordance with ILAC G8:2019 and IEC Guide 115:2021, unless otherwise specified in the applied standard mentioned on Page 1 of this report or requested by the customer. This means that measurement uncertainty is not taken in account and hence also not declared in the test report. For…

Text truncated - open the document above for the full version.

Report Number: Attachment 3 of CN23KA4K 001 Model: LED2109G6 - Page 1 of 2 - Test Set-up Photos Photograph 1: Set-up for measurement of conducted emission Photograph 2: Set-up for measurement of radiated emission (30-1000 MHz) Report Number: Attachment 3 of CN23KA4K 001 Model: LED2109G6 - Page 2 of 2 - (1-18 GHz)
