FM500 Instruction Manual. Introduction. FM500 Radio Frequency wireless mouse is a 3-button wheel mouse that will not cause any cord tangle. It uses digital radio technology to communicate flawlessly, without the need of pointing directly to your computer. Enjoy the enhanced features like no cord for unlimited movements and auto turn off to maximize battery life. Please read carefully the information and instructions contained in this manual and you are sure to obtain a higher level of computing enjoyment. Features & specifications: - Single channel(with ID Code)/dual channels. - 5ft range. - 2 x AAA batteries for mouse, approx. 3 months battery life(please only use alkali batteries) - Compatible with Windows 95, NT, 98, 2000. - Energy saving management. - Full Plug and Play. This package includes the following: (mouse, receiver ) Installation. 1. Turn off your computer. Plug the receiver cable into the PS/2 mouse or USB connectors of your computer. The green PS/2 connector on the main board is for the mouse port. 2. Open the battery compartment cover under the mouse and place the enclosed batteries inside the compartment. Close the battery compartment cover. (mouse ) 3. a) ID Code adjustment for single channel version: Once the receiver is connected, press the ID Code switch under the mouse and at the side of the receiver. Test the mouse for function and if the mouse is not moving, press the ID Code switches again. b) Channel adjustment for dual channel version. The channel adjustment switch is under the mouse and the receiver. Make sure they are adjusted at the same channel. Should you encounter interference, please adjust the channel on both the mouse and the receiver. (mouse & receiver channel ) 4. Turn on the computer to operate the mouse. If the mouse is functional, when the mouse moves the LED on the receiver will flash. The Receiver. (receiver ) RF signal LED(flashes when the mouse is being used). Trouble shooting. If you mouse does not work, please try the following: 1. Make sure the cables are connected into the system correctly. 2. The mouse have an optimal range of 2 meter from the receiver. Please keep at least 20cm of distance between the receiver and other electrical devices(such as speakers, monitors) 3. Make sure the channels underneath the mouse and the receiver are adjusted to the same one. 4. Working on metallic surfaces reduces RF performance. Avoid placing receiver on metallic surfaces. Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.

FCC ID LABEL FORMAT AND LOCATION Applicant: FOCUS ELECTRONIC CO., LTD. FCC ID: FSQ011113MSTX5 FCC ID: FSQ011113MSTX5 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 27 MHZ WIRELESS MOUSE MODEL: FM500 FCC ID NO: FSQ011113MSTX5 REPORT NO: 01E9841 ISSUE DATE: February 07, 2002 Prepared for FOCUS ELECTRONIC CO., LTD. 5F., NO. 306, SEC. 4, CHENGTEH RD., TAIPEI, TAIWAN, R. O. C. Prepared by COMPLIANCE ENGINE ERING SERVICES, INC. NO. 199, CHUNG SHENG ROAD, HSIN TIEN CITY, TAIPEI, TAIWAN, R. O. C. d.b.a. COMPLIANCE CERTIFICATION SERVICES REPORT NO: 01E9841 FCC ID: FSQ011113MSTX5 DATE: February 07, 2002 COMPLIANCE ENGINEERING SERVICES, INC. TEL: (02) 2217-0894 FAX: (02) 2217-1254 NO. 199, CHUNG SHENG ROAD, HSIN TIEN CITY, TAIPEI, TAIWAN, R. O. C. This report shall not be reproduced except in full, without the written approval of CES. This document may be altered or revised by Compliance Engineering Services personnel only, and shall be noted in the revision section of the document. (CCS DOCUMENT NO: CCSUP4002B) TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE........................................................................................1 2. PRODUCT DESCRIPTION........................................................................................................2 3. TEST FACILITY.........................................................................................................................2 4. MEASUREMENT STANDARDS..............................................................................................2 5. TEST METHODOLOGY............................................................................................................2 6. MEASUREMENT EQUIPMENT USED....................................................................................2 7. POWERLINE RFI LIMIT...........................................................................................................2 8. RADIATED EMISSION LIMITS...............................................................................................3 9. SYSTEM TEST CONFIGURATION.........................................................................................4 10. SYSTEM TEST CONFIGURATION.......................................................................................5 11. TEST PROCEDURE AND RESULT.......................................................................................5 11. 1 RADIATED EMISSION TEST PROCEDURE And RESULT.............................................5 l TEST DATA l EXTERNAL & INTERNAL PHOTOS l SCHEMATICS l BLOCK DIAGRAM l USER MANUAL REPORT NO: 01E9841 FCC ID: FSQ011113MSTX5 DATE: February 07, 2002 PAGE NO: 1 COMPLIANCE ENGINEERING SERVICES, INC. TEL: (02)2217-0894 FAX: (02)2217-1254 NO. 199, CHUNG SHENG ROAD, HSIN TIEN CITY, TAIPEI, TAIWAN, R. O. C. This report shall not be reproduced except in full, without the written approval of CES. This document may be altered or revised by Compliance Engineering Services personnel only, and shall be noted in the revision section of the document. (CCS DOCUMENT NO: CCSTP4005) 1. VERIFICATION OF COMPLIANCE COMPANY NAME: FOCUS ELECTRONIC CO., LTD. 5F., NO. 306, SEC. 4, CHENGTEH RD., TAIPEI, TAIWAN, R. O. C. CONTACT PERSON: Magic Hwa / Manager TELEPHONE NO.: 886-2-2880-5512 EUT DESCRIPTION: 27 MHZ WIRELESS MOUSE MODEL NAME/NUMBER: FM500 FCC ID: FSQ011113MSTX5 DATE TESTED: January 23, 2001 REPORT NUMBER: 01E9841 TYPE OF EQUIPMENT REMOTE CONTROL EQUIPMENT TYPE 27 MHz WIRELESS MOUSE MEASUREMENT PROCEDURE ANSI C63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Warning : This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Engineering Services, Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Engineering Services, Inc. will constitute fraud and shall nullify the document. RICK YEO / EMC MANAGER COMPLIANCE ENGINEERING SERVICES, INC. REPORT NO: 01E9841 FCC ID: FSQ011113MSTX5 DATE: February 07, 2002 PAGE NO: 2 COMPLIANCE ENGINEERING SERVICES, INC. TEL: (02)2217-0894 FAX: (02)2217-1254 NO. 199, CHUNG SHENG ROAD, HSIN TIEN CITY, TAIPEI, TAIWAN, R. O. C. This report shall not be reproduced except in full, without the written approval of CES. This document may be altered or revised by Compliance Engineering Services personnel only, and shall be noted in the revision section of the document. (CCS DOCUMENT NO: CCSTP4005) 2. PRODUCT DESCRIPTION CHASSIS TYPE Plastic Fundamental Frequency 27.045MHz ; 27.195MHz Power source 3.0V Battery Transmitting Time Continuous Local Oscillators N/A 3. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at No. 199, Chung Sheng Road, Hsin Tien City, Taipei, Taiwan R.O.C. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 4. MEASUREMENT STANDARDS The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5. TEST METHODOLOGY For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) 6. MEASUREMENT EQUIPMENT USED Manufacturer Model Number Description Cal Due Date R & S DSAI-D 804.8932.52 EMI Test Display (20Hz – 5GHz) 10/2002 R & S ESBI- RF/1005.4300.52 EMI Test RF Unit (20Hz – 5GHz) 10/2002 EMCO 6502 Antenna (9KHz – 30MHz) 04/2…

Text truncated - open the document above for the full version.

REPORT NO: 01E9841 FCC ID: FSQ011113MSTX5 DATE: February 07, 2002 PAGE NO: 4 COMPLIANCE ENGINEERING SERVICES, INC. TEL: (02)2217-0894 FAX: (02)2217-1254 NO. 199, CHUNG SHENG ROAD, HSIN TIEN CITY, TAIPEI, TAIWAN, R. O. C. This report shall not be reproduced except in full, without the written approval of CES. This document may be altered or revised by Compliance Engineering Services personnel only, and shall be noted in the revision section of the document. (CCS DOCUMENT NO: CCSTP4005) 9. SYSTEM TEST CONFIGURATION The EUT was configured for testing in a typical fashion ( as a customer would normally use it). Radiated Open Site Test Set-up
