FYLWVR100Wireless AV Transmitter

User’s Guide 506100-02-01-W-E-012506-01 Copyright © 2006, NewSoft Technology Corp. All Rights Reserved. No portion of this document may be copied or reproduced in any manner without prior written permission from NewSoft Technology Corp. (NewSoft) NewSoft has no warranties to this documentation and disclaims any implied warranty of merchantability or fitness for a particular purpose. All information contained herein is subject to change without notice. All sample images and electronic files included in the documentation and distribution materials are copyrighted by their respective photographers and are not to be copied or reproduced in any manner. Trademarks Windows 2000 and Windows XP are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. All other trademarks are the properties of their respective owners. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices). ii FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. U-NII device that operates in the band 5.15－5.25GHz band will be restricted to indoor operations to reduce any potential for harmful interference to co-channel MSS operation. www.newsoftinc.com www.newsoft.com.tw www.newsoft.co.jp www.newsoft.eu.com www.newsoft.com.cn iii Contents Chapter 1 Introducing WVR 100A 1 Features..........................................................................................2 System Requirements...................................................................2 Important Safety Instructions.......................................................3 Package Contents..........................................................................4 Front Panel.....................................................................................5 Rear Panel......................................................................................6 Chapter 2 Setting Up and Connecting a WVR System 8 Examples of Ways to Use Presto! WVR.......................................8 Setup to Watch TV.......................................................................8 Setup to Watch Video ................................................................ 10 Troubleshooting a Wireless Connection...................................11 Installing Presto! WVR................................................................11 Uninstalling Presto! WVR............................................................14 Using the Uninstall Presto! WVR Wizard...................................14 Using the Windows to Uninstall Presto! WVR............................14 Programming the Firmware on the WVR 100A Device.............14 Initializing the WVR 100A Device................................................15 Using the Settings Wizard...........................................................15 Refreshing the Program List.......................................................17 Chapter 3 Using Presto! WVR 20 Starting Presto! WVR...................................................................21 Getting to Know the Screen........................................................23 Control Panel................................................................................23 Choosing a Program to Watch....................................................24 iv Channel Surfing ...........................................................................25 Recording a Program..................................................................25 Time Shifting................................................................................26 Adjusting the Volume..................................................................27 Taking Snapshots........................................................................27 Using MTS....................................................................................27 Chap…

Text truncated - open the document above for the full version.

ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd. External Photos ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd. ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd. ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd. ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd. ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd. ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd. ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd. ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd. ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd. ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd. ETS DR.GENZ TAIWAN PS CO., LTD. Registration number: W6M20602-6599-E-54 FCC ID: FYLWVR100 ETS Dr.Genz Taiwan PS Co., Ltd.

Sampo Corporation Digital Products R&D Center Mobile TV R&D Division 55 Chung-Cheng Rd., Tu-Cheng City,Taipei Hsien 236, Taiwan Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Applicant’s declaration concerning RF Radiation Exposure We hereby indicate that the product Product description: Wireless Access Point Model No: WVR 100A TX is considered to be a digital transceiver. The internal / external antennas used for this mobile transmitter must provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. A safety statement concerning minimum separation distances from enclosure of the Product: WVR 100A TX will be integrated in the user’s manual to provide end-users with transmitter operating conditions for satisfying RF exposure compliance. The appropriate information can be drawn from the test report no.: W6M20602-6599-C-1, W6M20602-6599-E-54, W6M20602-6599-C-2 and the accompanying calculations. Company: Sampo Corporation Digital Products R&D Center Mobile TV R&D Division Address: 55 Chung-Cheng Rd., Tu-Cheng City City: Taipei Hsien ZIP / Postal code: 236 Country: Taiwan Place: Taiwan Date: March 13, 2006 Signature

MPE Prediction FCC Rule: 15.247(b)(5) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See §1.1307(b)(1) of this Chapter. LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average time (minutes) (A)Limits For Occupational / Control Exposures 30-300 61.4 0.613 1.0 6 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 PG S = -------------- 4πR² where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 19.13 (dBm) Maximum peak output power at antenna input terminal: 81.84648 (mW) Antenna gain(maximal): 2.0 (dBi) Prediction distance: 20 (cm) Prediction frequency: 2462 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.0 (mW/cm²) Power density at prediction frequency: 0.026052 (mW/cm²) The manual instruct the user to install and operate the device in a minimum distance of 20 cm between antenna and the users body.
