G2R-6022LeapPad Academy

This manual contains important information. Please keep it for future reference. Ce guide contient des informations importantes. Veuillez le conserver pour toute référence future. Need help? Visit: leapfrog.com/support/leappad-academy Vous avez besoin d’aide ? Visitez le site : leapfrog.com/support/leappad-academy Instruction Manual 1 Getting Started 1. Power Up the LeapPad ® Academy learning tablet with the included AC adapter. To save time, set up while charging. 2. Set up Wi-Fi by following onscreen prompts. It’s the easiest way to access the App Center. 3. Register your device by creating a parent account. It’s super quick and easy! 4. Download your included apps and sign-up for a 3-month free trial of LeapFrog Academy ® *. Wi-Fi, parent account and device set-up required to access all included apps. 5. Create & Play! You’re all set for an awesome experience that’s truly LeapPad ® Academy! * LeapFrog Academy ® is a subscription service. This 3-month free trial is a special offer for the LeapPad ® Academy tablet purchaser. Your 3-month free trial period begins when you sign-up. Cancel anytime during the first 3 months of your subscription and you will not be charged. After that you will be automatically charged, to the payment method you provide, until you cancel. No refunds or credits for partial months. Price subject to change. For details please read the LeapFrog Academy ® Subscription Terms of Use at leapfrog.com/terms-academy. 2 Microphone Headphone Jack Front & Rear Camera/Video Recorder Micro SD Slot Power Button Micro USB Connector/Charger Volume Button Speaker Stylus Stylus Tether Key Features 3 Parent Settings Control your child’s play with these interactive LeapPad ® Academy features: • Wireless Settings — Control connection setup and access to online experiences. • Child Profile — Easily manage permissions and profile information or add a new profile. • App Center — Kids can access the App Center, but only parents can purchase digital content directly from the tablet with a parent account password. • App Manager — Control your child’s access to included and downloaded apps. • Time Controls — Manage the amount of time your child spends on the tablet by total time, hours of the day and by app category. • LeapSearch ® Controls — Manage the web pages and websites your child explores in the LeapSearch ® Parent Portal. • Tablet Settings — Manage settings like language, time, date and more. Access to Parent Settings is protected by a 4-digit parent lock code that must be established during initial setup. Parent Settings can be accessed from the Sign-In screen by pressing the Parent Settings icon to log in with your parent lock. Alternatively, you can log in via the Parent Settings icon in the upper right-hand corner of the child’s Home Screen. Resetting Your Parent Lock If you have forgotten your 4-digit parent lock code you can look it up in the leapfrog.com parent account you created during device setup and registration. If you need to reset your parent lock, you can do it from the device or reference the FAQ section at leapfrog.com/support/leappad-academy for more information. 4 Operating Instructions WARNING: Please read all the Important Safety Instructions prior to using the LeapPad ® tablet. Failure to follow these safety instructions could result in fire, electric shock, or other injury or damage to the LeapPad ® tablet or other property. WARNING: Please read all safety instructions for any accessories or other products before using with the LeapPad ® tablet. LeapFrog is not responsible for the operation of third-party accessories or their compliance with safety and regulatory standards. Wi-Fi Connection Support—If you experience any difficulty with Wi-Fi connectivity, troubleshooting suggestions are available at leapfrog.com/support For Indoor, Dry-Location Use Only—Do not use the product near a sink or other wet locations. Take care not to spill food or any kind of liquid on this product as it may render it inoperable and not serviceable. In case the unit does get wet, unplug all cables and turn it Off. Allow to dry thoroughly before reusing. Do not attempt to dry with a hair dryer or other heat source. Do not re-connect to the AC outlet if wet or damaged. Handle With Care—To avoid injury, damage to this product or other property, avoid dropping and never disassemble, crush, puncture, microwave, incinerate, insert foreign objects or paint the product. Clean your hands before handling the product if they have been exposed to suntan lotions or other chemicals. Use the included bumper to help minimize damage from typical use and drops. Avoid Prolonged Exposure to Extreme Temperatures and Direct Sunlight —Operate in places with temperatures ranging from 5°C (40°F) to 38°C (100°F). Do not leave the product in your car as the temperatures in parked cars can exceed the acceptable storage temperature. Exposure to extreme temperatures can result in shortened battery life or cause the product to temporarily stop working. Battery Charging The LeapPad ® tablet is equipped with a rechargeable lithium-polymer battery. It will require about 5 hours of charging using the included AC power adapter prior to use. The tablet may also be charged via USB connection; however, this charging method will take much longer. If the battery is charging when the device is off, a battery meter icon will light up on the dark screen. When the battery meter icon is full, the battery is fully charged. If it is charging when the device is on, the battery meter at the top of the screen will show the charging status and the charge level. Charge the device in a well-ventilated area only. While charging the device do not cover it with anything such as a blanket, pillow or your child’s body. Never allow your child to sleep with or on the device while it is charging. For power or battery issues, please contact LeapFrog Consumer Support. 5 Cleaning—Disconnect all cords before cleaning. Clean the product with a sl…

Text truncated - open the document above for the full version.

Difference Declaration Original Model No.:6022 Adding Model No.: 602210, 80-602210 To whom it may concern, We, VTech Electronics Limited would like to declare those models 6022, 602210, 80-602210 are identical in electrical circuit design and PCB layout.The only difference are model name Sincerely yours, Applicant:VTech Electronics Limited Address: 23F Tai Ping Industrial Center, Block 1, 57 Ting Kok Road,Tai PoHong Kong Signature: Name and title:Antony Wong / Senior Manager Email:[email protected] Tel.:26801233

6022x0-3xx bottom cabinet I N T E R F E R E N C E , A N D ( 2 ) T H I S D E V I C E M U S T A C C E P T A N Y I N T E R F E R E N C E R E C E I V E D , I N C L U D I N G I N T E R F E R E N C E T H A T M A Y C A U S E U N D E S I R E D O P E R A T I O N . T H I S D E V I C E C O M P L I E S W I T H P A R T 1 5 O F T H E F C C R U L E S . O P E R A T I O N I S S U B J E C T T O T H E F O L L O W I N G T W O C O N D I T I O N S : ( 1 ) T H I S D E V I C E M A Y N O T C A U S E H A R M F U L Battery is not replaceable. / La batterie n’est pas remplaçable. MADE IN CHINA. FABRIQUÉ EN CHINE. TM & © 2015 LeapFrog Enterprises, Inc., Emeryville, CA, USA IC: 1135D-6022 leapfrog.com FCC ID: G2R-6022 Model: 6022 New 2021.07.09 59-602210-112-000

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN21DC76 002 Auftrags-Nr.: Order no.: 168323641 Seite 1 von 28 Page 1 of 28 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2021-06-08 Auftraggeber: Client: VTech Electronics Limited 23F Tai Ping Industrial Center, Block 1, 57 Ting Kok Road,Tai PoHong Kong Prüfgegenstand: Test item: LeapPad Academy Bezeichnung / Typ- Nr.: Identification / Type no.: 6022, 602210, 80-602210 (Trademark: LeapFrog) Auftrags-Inhalt: Order content: FCC & IC approval Prüfgrundlage: Test specification: CFR47 FCC Part 2: Section 2.1093 FCC KDB Publication 865664 D01 v01r04 FCC KDB Publication 865664 D02 v01r02 RSS-102 Issue 5 Amendment 1 (February 2, 2021) Wareneingangsdatum: Date of sample receipt: 2021-06-22 Please refer to Photo Document Prüfmuster-Nr.: Test sample no: A003074986-004 Prüfzeitraum: Testing period: 2021-07-05 – 2021-07-05 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X Signed by: Alex Lan genehmigt von: authorized by: X Signed by: Winnie Hou Datum: Date: 2021-07-25 Ausstellungsdatum: Issue date: 2021-07-25 Stellung / Position: Senior Project Engineer Stellung / Position: Technical Certifier Sonstiges / Other: FCC ID: G2R-6022 IC: 1135D-6022 HVIN: 6022 Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] · Web: www.tuv.com Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. CN21DC76 002 Seite 2 von 28 Page 2 of 28 Table of Contents 1. GENERAL INFORMATION .................................................................................................................4 1.1. STATEMENT OF COMPLIANCE..........................................................................................................4 1.2. EQUIPMENT UNDER TEST (EUT) INFORMATION.................................................................................5 1.2.1. General Information.............................................................................................................5 1.2.2. Wireless Technologies ........................................................................................................5 1.3. MAXIMUM CONDUCTED POWER .......................................................................................................5 2. TEST SITES ...................................................................................................................................6 2.1. TEST FACILITIES ............................................................................................................................6 2.2. AMBIENT CONDITION......................................................................................................................6 2.3. LIST OF TEST AND MEASUREMENT INSTRUMENTS .............................................................................6 3. MEASUREMENT UNCERTAINTY ........................................................................................................7 4. TEST SPECIFICATION, METHODS AND PROCEDURES..........................................................................8 5. SAR MEASUREMENT SYSTEM ........................................................................................................9 5.1. DEFINITION OF SPECIFIC ABSORPTION RATE (SAR) ..........................................................................9 5.2. SPEAG DASY SYSTEM ................................................................................................................9 5.2.1. Robot ................................................................................................................................ 10 5.2.2. Probes .............................................................................................................................. 11 5.2.3. Data Acquisition Electronics (DAE) .................................................................................... 11 5.2.4. Phantoms.......................................................................................................................... 12 5.2.5. Device Holder ................................................................................................................... 13 5.2.6. System Validation Dipoles ................................................................................................. 13 5.2.7. Tissue Simulating Liquids .................................................................................................. 14 5.2.8. SAR System Verification ................................................................................................... 17 6. SAR MEASUREMENT PROCEDURE ........................................…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN21DC76 001 Auftrags-Nr.: Order no.: 168323641 Seite 1 von 22 Page 1 of 22 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2021-06-08 Auftraggeber: Client: VTech Electronics Limited 23F Tai Ping Industrial Center, Block 1, 57 Ting Kok Road,Tai PoHong Kong Prüfgegenstand: Test item: LeapPad Academy Bezeichnung / Typ-Nr.: Identification / Type no.: 6022, 602210, 80-602210 (Trademark: LeapFrog) Auftrags-Inhalt: Order content: FCC & IC approval Prüfgrundlage: Test specification: CFR47 FCC Part 15: Subpart C Section 15.247 CFR47 FCC Part 15: Subpart C Section 15.207 CFR47 FCC Part 15: Subpart C Section 15.209 CFR47 FCC Part 15: Subpart B Section 15.107 CFR47 FCC Part 15: Subpart B Section 15.109 RSS-247 Issue 2 February 2017 RSS-Gen Issue 5 Amendment 2 (February 2021) ICES-003 Issue 7 October 2020 Wareneingangsdatum: Date of sample receipt: 2021-06-22 Please refer to Photo Document Prüfmuster-Nr.: Test sample no: A003074986-001 to 005 Prüfzeitraum: Testing period: 2021-06-25 – 2021-07-03 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X Signed by: Alex Lan genehmigt von: authorized by: X Signed by: Winnie Hou Datum: Date: 2021-07-25 Ausstellungsdatum: Issue date: 2021-07-25 Stellung / Position: Senior Project Engineer Stellung / Position: Technical Certifier Sonstiges / Other: FCC ID: G2R-6022 IC: 1135D-6022 HVIN: 6022 Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] · Web: www.tuv.com Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. CN21DC76 001 Seite 2 von 22 Page 2 of 22 Test Summary 5.1.1ANTENNA REQUIREMENT RESULT:Pass 5.1.2MAXIMUM PEAK CONDUCTED OUTPUT POWER RESULT:Pass 5.1.3CONDUCTED POWER SPECTRAL DENSITY RESULT:Pass 5.1.46DB BANDWIDTH RESULT:Pass 5.1.599% BANDWIDTH RESULT:Pass 5.1.6CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100 KHZ BANDWIDTH RESULT:Pass 5.1.7RADIATED SPURIOUS EMISSION RESULT:Pass 5.1.8CONDUCTED EMISSION ON AC MAINS RESULT:Pass 5.1.9RADIATED EMISSION RESULT:Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. CN21DC76 001 Seite 3 von 22 Page 3 of 22 Contents 1GENERAL REMARKS..........................................................................................................................4 1.1COMPLEMENTARY MATERIALS............................................................................................................4 2TEST SITES........................................................................................................................................5 2.1TEST FACILITIES................................................................................................................................5 2.2LIST OF TEST AND MEASUREMENT INSTRUMENTS................................................................................5 2.3TRACEABILITY...................................................................................................................................6 2.4CALIBRATION.....................................................................................................................................6 2.5MEASUREMENT UNCERTAINTY............................................................................................................7 2.6LOCATION OF ORIGINAL DATA............................................................................................................7 2.7STATUS OF FACILITY USED FOR TESTING............................................................................................7 3GENERAL PRODUCT INFORMATION.....................................................................................................8 3.1PRODUCT FUNCTION AND INTENDED USE............................................................................................8 3.2RATINGS AND SYSTEM DETAILS..........................................................................................................8 3.3INDEPENDENT OPERATION MODES......................................................................................................9 3.4NOISE GENERATING AND NOISE SUPPRESSING PARTS........................................................................9 3.5SUBMITTED DOCUMENTS....................................................................................................................9 4TEST SET-UP AND OPERATION MODES..............................................................................................10 4.1PRINCIPLE OF CONFIGURATION SELECTION.......................................................................................10 4.2TEST OPERATION AND TEST SOFT…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 24 of 58 Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 25 of 58 Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 26 of 58 Wi-Fi 802.11 b mode, Band Edge Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 27 of 58 Wi-Fi 802.11 g mode, Band Edge Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 28 of 58 Wi-Fi 802.11 n(HT20) mode, Band Edge Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 29 of 58 Note: Testing was carried out within frequency range 9kHz to the tenth harmonics. The measurement results below 30MHz and 18GHz - 26.5GHz were greater than 20dB below the limit, so only the radiated spurious emissions from 30MHz to 18GHz were reported. Appendix B.5: Test Results of Radiated Spurious Emissions 30MHz - 1GHz (Worst case) EUT Information EUT Name:LeapPad Academy Model:6022 Test Mode:WIFI 2.4G_11b_Low channel Test Voltage::Battery Remark:Temp 23 Humi:51% Test Standard:FCC 15.247 Tested By:Kei Zhang Reviewed By:Terry Yin 0 20 40 60 80 100 120 30M 5060 80100M200300400500 8001G L e v e l i n d B μ V / m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) PolAzimuth (deg) Corr. (dB/m) 55.02600036.5240.003.48100.0V127.0-18.4 167.98250030.3443.5013.16100.0V195.0-21.3 330.02100029.8446.0016.16100.0V185.0-15.5 832.62650036.3546.009.65100.0V152.0-5.8 Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 30 of 58 EUT Information EUT Name:LeapPad Academy Model:6022 Test Mode:WIFI 2.4G_11b_Low channel Test Voltage::Battery Remark:Temp 23 Humi:51% Test Standard:FCC 15.247 Tested By:Kei Zhang Reviewed By:Terry Yin 0 20 40 60 80 100 120 30M 5060 80100M200300400500 8001G L e v e l i n d B μ V / m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) PolAzimuth (deg) Corr. (dB/m) 55.89900033.1540.006.85100.0H188.0-18.5 168.03100040.9643.502.54100.0H161.0-21.3 263.28500037.3546.008.65100.0H213.0-17.0 723.55000027.6146.0018.39100.0H154.0-7.6 Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 31 of 58 EUT Information EUT Name:LeapPad Academy Model:6022 Test Mode:WIFI 2.4G_11b_High channel Test Voltage::Battery Remark:Temp 23 Humi:51% Test Standard:FCC 15.247 Tested By:Kei Zhang Reviewed By:Terry Yin 0 20 40 60 80 100 120 30M 5060 80100M200300400500 8001G L e v e l i n d B μ V / m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) PolAzimuth (deg) Corr. (dB/m) 55.22000033.9340.006.07100.0V97.0-18.5 122.24700025.2843.5018.22100.0V218.0-21.0 167.98250030.3943.5013.11100.0V201.0-21.3 328.85700029.9046.0016.10100.0V177.0-15.5 799.84050032.4446.0013.56100.0V116.0-6.4 Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 32 of 58 EUT Information EUT Name:LeapPad Academy Model:6022 Test Mode:WIFI 2.4G_11b_High channel Test Voltage::Battery Remark:Temp 23 Humi:51% Test Standard:FCC 15.247 Tested By:Kei Zhang Reviewed By:Terry Yin 0 20 40 60 80 100 120 30M 5060 80100M200300400500 8001G L e v e l i n d B μ V / m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) PolAzimuth (deg) Corr. (dB/m) 55.41400036.0540.003.95100.0H180.0-18.5 168.03100040.7743.502.73100.0H157.0-21.3 307.22600035.8146.0010.19100.0H133.0-16.1 665.59250028.9146.0017.09100.0H165.0-8.7 Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 33 of 58 1GHz - 18GHz Note: The highest waveform in the figure is Wi-Fi Fundamental. EUT Information EUT Name:LeapPad Academy Model:6022 Test Mode:WIFI 2.4G_11b_Low channel Test Voltage::Battery Remark:Temp 23 Humi:51% Test Standard:FCC 15.247 Tested By:Kei Zhang Reviewed By:Terry Yin 0 20 40 60 80 100 120 130 1G2G3G4G5G 6.2G L e v e l i n d B μ V / m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Average (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) PolAzimuth (deg) Corr. (dB/m) 1198.050000---39.9754.0014.03100.0V100.01.1 1198.22000048.45---74.0025.55100.0V100.01.1 1991.61000054.04---74.0019.96100.0V144.06.0 1991.610000---41.4854.0012.52100.0V144.06.0 4823.50000055.38---74.0018.62100.0V268.011.8 4823.500000---50.0954.003.91100.0V268.011.8 Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 34 of 58 EUT Information EUT Name:LeapPad Academy Model:6022 Test Mode:WIFI 2.4G_11b_Low channel Test Voltage::Battery Remark:Temp 23 Humi:51% Test Standard:FCC 15.247 Tested By:Kei Zhang Reviewed By:Terry Yin 0 20 40 60 80 100 120 130 1G2G3G4G5G 6.2G L e v e l i n d B μ V / m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Average (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) PolAzimuth (deg) Corr. (dB/m) 4823.50000056.90---74.0017.10100.0H232.011.8 Final_Result Frequency (MHz) Average (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) PolAzimuth (deg) Corr. (dB/m) 4823.80000043.6154.0010.39100.0H227.011.8 Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 35 of 58 EUT Information EUT Name:LeapPad Academy Model:6022 Test Mode:WIFI 2.4G_11b_Mid channel Test Voltage::Battery Remark:Temp 23 Humi:51% Test Standard:FCC 15.247 Tested By:Kei Zhang Reviewed By:Terry Yin 0 20 40 60 80 100 120 130 1G2G3G4G5G 6.2G L e v e l i n d B μ V / m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Average (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) PolAzimuth (deg) Corr. (dB/m) 4873.500000---50.7554.003.25100.0V271.011.8 4874.00000057.63---74.0016.37100.0V271.011.8 Prüfbericht - Produkte Test Report - Products Appendix B CN21DC76 001 Page 36 of 58 EUT Information EUT Name:LeapPad Academy Model:6022 Test Mode:WIFI 2.4G_11b_Mid channel Test Voltage::Battery Remark:Temp 23 Humi:51% Test Standard:FCC 15.247 Tested By:Kei Zhang Reviewed By:Terry Yin 0 20 40 60 80 100 1…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix A CN21DC76 001 Page 1 of 4 Appendix A: Photographs of the Test Set-Up APPENDIX A: PHOTOGRAPHS OF THE TEST SET-UP.......................................................................................................1 PHOTOGRAPH 1: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, 30MHZ - 1GHZ......................................................................2 PHOTOGRAPH 2: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, ABOVE 1GHZ...........................................................................2 PHOTOGRAPH 3: SET-UP PHOTO FOR RADIATED EMISSIONS BELOW 1GHZ.......................................................................................3 PHOTOGRAPH 4: SET-UP PHOTO FOR RADIATED EMISSIONS ABOVE 1GHZ........................................................................................3 PHOTOGRAPH 5: SET-UP PHOTO FOR CONDUCTED EMISSION ON AC MAINS.....................................................................................4 Prüfbericht - Produkte Test Report - Products Appendix A CN21DC76 001 Page 2 of 4 Photograph 1: Set-up photo for Radiated Spurious Emission, 30MHz - 1GHz Photograph 2: Set-up photo for Radiated Spurious Emission, above 1GHz Prüfbericht - Produkte Test Report - Products Appendix A CN21DC76 001 Page 3 of 4 Photograph 3: Set-up photo for Radiated Emissions Below 1GHz Photograph 4: Set-up photo for Radiated Emissions Above 1GHz Prüfbericht - Produkte Test Report - Products Appendix A CN21DC76 001 Page 4 of 4 Photograph 5: Set-up photo for Conducted Emission on AC Mains

Prüfbericht - Produkte Test Report - Products Appendix D CN21DC76 002 Page 1 of 2 Photographs of EUT> Prüfbericht - Produkte Test Report - Products Appendix D CN21DC76 002 Page 2 of 2 <Photographs of SAR Setup> Rear Face of EUT with 0 cm GapRight Side of EUT with 0 cm Gap
