ACCESS gAtEwAy FGA2230TCH Dual Band Wireless Integrated GPON Gateway Features at a Glance „Integrated 2.5/1.25 Gbps GPON port, compliant to ITU-T G.984.2 Class B+ „Integrated 1310/1490 nm diplexer transceiver „4 GE LAN ports „Dual band concurrent Wi-Fi interfaces IEEE 802.11n 2.4 GHz (3x3) IEEE 802.11ac 5 GHz (4x4) „2 FXS ports for phone or fax „1 superspeed USB 3.0 master port „1 highspeed USB 2.0 master port „Seamless media sharing (UPnP A/ V™ and DLNA®) „Future-proof full service platform „Extensive remote management „Non-service-affecting platform software upgrades (dual bank memory) „IPv4 & IPv6 enabled „Designed according to the latest ECO standards Seamless Video over Next-Gen Wi-Fi With its support of dual band concurrent Wi-Fi (IEEE 802.11n 2.4 GHz and the next-generation IEEE 802.11ac wave 2 standard for the 5 GHz band), the FGA2230TCH is a powerful and future-proof smart gateway enabling high-speed wireless HD video streaming inside the home. Thanks to its integrated wireless video bridge featuring a robust chipset and 4x4 antennas, it can support multiple UHD TV channels over the clean 5 GHz radio. Furthermore, its advanced architecture guarantees a very low packet error rate on the wireless link. Simultaneously, it guarantees uninterrupted transmission of data services over IEEE 802.11n using the 2.4 GHz band. OLT Agnostic GPON Gateway Built upon Technicolor’s extensive experience in xDSL gateway development and deployment, the FGA2230TCH interoperates seamlessly with different Optical Line Terminations (OLTs) in the field. By keeping a flexible software track on the FGA2230TCH, we can detect the OLT and reconfigure the gateway dynamically to ensure full compatibility between both. As such, there is no need for any firmware upgrades or restart in order to be able to cover deployments with multiple OLTs, even if from different vendors. Moreover, the FGA2230TCH supports standard G.984.4 and G.988 ONU Management and Control Interface (OMCI) features and implements some proprietary vendor specific Management Information Base (MIB), Managed Entities (MEs) and Alarms (MAs). Furthermore, the device can be maintained and upgraded using the TR-069 protocol. The FGA2230TCH is a high-speed Gigabit Passive Optical Network (GPON) gateway taking advantage of the latest developments in Fiber To The Home (FTTH), while at the same time guaranteeing the highest quality of service. AV ACCESS gAtEwAy FGA2230TCH High Speed Network Connectivity By integrating the ONT in the gateway and by using an integrated GPON interface, the FGA2230TCH can reach lightning fast speeds, allowing operators to respond to the increasing end-user demand for higher bandwidths. To benefit from these extreme WAN speeds the gateway implements a Gigabit Ethernet (GE) router, providing very high speed connectivity between LAN devices and the network. It also includes a dual band concurrent Wi-Fi base station with IEEE 802.11n and IEEE 802.11ac capabilities to stream data, including rich media content, anywhere in the home. The integration of the GPON ONT in a service gateway guarantees a lower installation and operation cost. Thanks to its innovative mechanical solution, the installation becomes as easy as any other fixed line service gateway installation. Easy to Manage The FGA2230TCH is completely designed according to the TR-069’s TR-098 IGD data model and the OMCI standard protocols through which the device can be configured remotely by the operator without interrupting the end user’s experience. In addition, the TR-181i2 Device:2 data model is made available to further increase the remote management capabilities towards life cycle management, diagnostics and application management. Voice over IP The FGA2230TCH offers VoIP functions for residential and business users. POTS phone connectors are provided to accommodate regular phones and faxes. Once the gateway is registered with a VoIP service, regular phone calls can be conducted over the Internet with all the benefits of IP telephony. On top of a wide range of advanced voice services like caller ID, CLIR, call waiting, call forwarding, three-way conference and message waiting notification, the FGA2230TCH is completely interoperable with the main IMS cores in the market. Easy to Use Like all Technicolor modems and gateways, the FGA2230TCH is an easy to use, easy to install device. For convenience of the end user, the easy-to-access LEDs provide a clear indication of start-up sequence, operational status, and connectivity status. Multiple integrated web pages also allow direct access to the status and settings, including privacy and security information. IPv6 Enabled With the approaching IPv4 address pool depletion, gateway products need to be ready for IPv6. Technicolor is a frontrunner in the support of IPv6 on its devices, with the FGA2230TCH enabled for multiple IPv6 field scenarios. Internet Protocol version 6 is the next generation of Internet technologies aiming to effectively support the ever-expanding Internet usage and functionality, and to address security concerns that exist in an IPv4 environment. Highest Security The FGA2230TCH Stateful Packet Inspection (SPI) firewall guarantees users the ultimate network security level. Through integration with Network Address & Port Translation (NAPT), the firewall leverages all the Application Level Gateways (ALGs) provided in the NAT context to minimize undesired service impacts. Advanced smart parental controls, security audit services, access logging and monitoring are optionally available for home, hotspot and mobile data network users to create a fully personalized and time-based access control environment, based on individual user profiles and web usage behaviour. The FGA2230TCH also supports powerful wireless security mechanisms, such as Wi-Fi Protected Access (WPA, WPA2) together with the secure and user friendly Wi-Fi Protected Setup (WPS) connection and configuration mechanism for connecting wireless clients…
