GSO300082Remote Control,433MHz

Owner’s Manual Model DF2690 DFP6854 DF2618 6904410100 7208680200R06 IMPORTANT SAFETY INFORMATION: Always read this manual first before attempting to install or use this fireplace. For your safety, always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage. To view the full line of Dimplex products, please visit www.dimplex.com 2 www.dimplex.com Table of Contents Always use a qualified technician or service agency to repair this fireplace. ! NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the equipment. WARNINg: Procedures and techniques which, if not carefully followed, will expose the user to the risk of fire, serious injury, or death. Welcome & Congratulations ................3 ImPorTAnT InsTruCTIons ...............4 Quick reference Guide . . . . . . . . . . . . . . . . . . . .7 site selection and Preparation ..............7 Fireplace Installation ......................8 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Warranty ...............................17 replacement Parts . . . . . . . . . . . . . . . . . . . . . . .21 3 Welcome & Congratulations Thank you and congratulations for choosing to purchase an electric fireplace from Dimplex, the world leader in electric fireplaces. Please carefully read and save these instructions. CAUTION: read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible electric shock, fire hazard and will void the warranty. Please record your model and serial numbers below for future reference: model and serial numbers can be found on the model and serial number Label of your fireplace. NO NEED TO RETURN TO THE STORE Questions with operation or assembly? Require Parts Information? Product under manufacturer’s Warranty? Contact us at:  www.dimplex.com/customer_support For Troubleshooting and Technical support OR  Toll-Free 1-888-DIMPLEX (1-888-346-7539) monday to Friday 8:00 a.m. to 4:30 p.m. EsT Please have your model number and product serial number ready. (see above) Serial Number Model Number 4 www.dimplex.com When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: ① read all instructions before using this appliance. ② The heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. The trim around the heater outlet becomes hot during heater operation. ③ Extreme caution is necessary when any heater is used by or near children or invalids and whenever the unit is left operating and unattended. ④ Young children should be supervised to ensure that they do not play with the appliance. ⑤ The appliance is not intended for use by young children or infirmed persons without supervision. ⑥ The appliance must be positioned so that the plug is accessible. ⑦ Always unplug the fireplace when not in use. ⑧ If the supply cord is damaged, it must be replaced by the IMPORTANT INSTRUCTIONS manufacturer, or its service agent, or a qualified person in order to avoid a hazard. ⑨ Do not operate any unit with a damaged cord or plug, or if the heater has malfunctioned, or if the fireplace has been dropped or damaged in any manner. return heater to authorized service facility for examination, electrical or mechanical adjustment or repair. ⑩ Do not use outdoors. ⑪ never locate fireplace where it may fall into a bathtub or other water container. ⑫ Do not install the fireplace directly on carpet or a similar surface which may restrict air circulation beneath the unit. ⑬ Do not run the cord under carpeting. Do not cover cord with throw rugs, runners or the like. Arrange cord away from traffic area and where it will not be tripped over. ⑭ Do not locate the heater immediately below a fixed socket- outlet. ⑮ To disconnect the unit, turn the controls off, then remove the plug from the outlet. 5 SAVE THESE INSTRUCTIONS ⑯ Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage to the heater. ⑰ To prevent a possible fire, do not block air intake or exhaust in any manner. Do not use on soft surfaces, like a bed, where openings may become blocked. ⑱ All electrical heaters have hot and arcing or sparking parts inside. Do not use in areas where gasoline, paint, or flammable liquids are used or stored or where the unit will be exposed to flammable vapours. ⑲ Do not modify the fireplace. use it only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock or injury to persons. ⑳ Avoid the use of an extension cord. Extension cords may overheat and cause a risk of fire. If you must use an extension cord, the cord shall be no. 14 AWG minimum size and rated not less then 1875 Watts. ㉑ Do not burn wood or other materials in the fireplace. ㉒ Do not strike the fireplace glass. ㉓ Always use a certified electrician should new circuits or outlets be required. ㉔ Always use properly grounded, fused and polarized outlets. ㉕ Disconnect all power supply before performing any cleaning, maintenance or relocation of the unit. ㉖ When transporting or storing the unit and cord, keep in a dry place, free from excessive vibration and store so as to avoid damage. IMPORTANT INSTRUCTIONS CAUTION rIsK oF ELECTrIC sHoCK Do noT oPEn no usEr-sErVICEABLE PArTs InsIDE 6 www.dimplex.com ! NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio freq…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 Shenzhen Yitoa Intelligent Control Co., Ltd. 2012-4-01 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Shenzhen Yitoa Intelligent Control Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Remote Control, 433MHz ; DF2690-R We affirm that between SIEMIC and Shenzhen Yitoa Intelligent Control Co., Ltd. , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature : ZelongLuo/ Engineer E-mail: [email protected] Phone: 86755-29833324 Fax: 86755-81785369 Address : A1 Building, Longma Industry Estate, Shiyan Town, Baoan District, Shenzhen, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Shenzhen Yitoa Intelligent Control Co., Ltd. (2012-4-01) To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality Request for FCC ID: GSO300082 We hereby request confidential treatment of information accompanying this application as outlined below: - Block diagram - Operation description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Zelong Luo/ Engineer E-mail: : [email protected] Phone: 86755-29833324 Fax: 86755-81785369 Address : A1 Building, Longma Industry Estate, Shiyan Town, Baoan District, Shenzhen, China

External of EUT

RECEIVER FCC LABEL 20mm x 12mm FCC ID Label DIMPLEX FCC ID: GSO300082 Model No.: DF2690-R Remote Control, 433MHz Input: AC 120V~60Hz Output: AC 120V~60Hz Made in China CAN RSS-Gen/CNR-Gen

Lable location

Internal of EUT

FCC ID: GSO300082 SHENZHEN EMTEK CO., LTD. Report No.: ES120419075F Page 1 of 20 TEST REPORT For Shenzhen Yitoa Intelligent Control Co., Ltd. Remote Control, 433MHz Model No.: DF2690-R FCC ID: GSO300082 Report Number : ES120419075F Date of Test : March 20, 2012 to March 23, 2012 Date of Report : March 27, 2012 Prepared for : Shenzhen Yitoa Intelligent Control Co., Ltd. Address : A1 Building, Longma Industry Estate, Shiyan Town, Baoan District, Shenzhen, China Prepared by : SHENZHEN EMTEK CO., LTD. Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 FCC ID: GSO300082 SHENZHEN EMTEK CO., LTD. Report No.: ES120419075F Page 2 of 20 TABLE OF CONTENT Test Report Description Page 1. SUMMARY OF TEST RESULT ..................................................................................................... 4 2. GENERAL INFORMATION........................................................................................................... 5 2.1. Description of Device (EUT) ....................................................................................................... 5 2.2. Description of Test Facility .......................................................................................................... 5 2.3. Measurement Uncertainty ............................................................................................................ 6 3. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 7 3.1. For Power Line Conducted Emission Measurement.................................................................... 7 3.2. For Radiated Emission Measurement ..........................................................................................7 4. POWER LINE CONDUCTED EMISSION MEASUREMENT .................................................. 8 4.1. Block Diagram of Test Setup ....................................................................................................... 8 4.2. Measuring Standard ..................................................................................................................... 8 4.3. Power Line Conducted Emission Limits (Class B) ..................................................................... 8 4.4. EUT Configuration on Measurement...........................................................................................8 4.5. Operating Condition of EUT........................................................................................................ 8 4.6. Test Procedure.............................................................................................................................. 9 4.7. Measuring Results........................................................................................................................ 9 5. RADIATED EMISSION MEASUREMENT................................................................................ 12 5.1. Block Diagram of Test Setup ..................................................................................................... 12 5.2. Measuring Standard ................................................................................................................... 12 5.3. Radiated Emission Limits (Class B) .......................................................................................... 13 5.4. EUT Configuration on Measurement......................................................................................... 13 5.5. Operating Condition of EUT...................................................................................................... 13 5.6. Test Procedure............................................................................................................................ 13 5.7. Measuring Results...................................................................................................................... 14 6. PHOTOGRAPHS............................................................................................................................ 19 6.1. Photos of Conducted Emission Measurement ........................................................................... 19 6.2. Photos of Radiation Emission Measurement ............................................................................. 20 FCC ID: GSO300082 SHENZHEN EMTEK CO., LTD. Report No.: ES120419075F Page 3 of 20 TEST REPORT DESCRIPTION Applicant : Shenzhen Yitoa Intelligent Control Co., Ltd. Manufacturer : Shenzhen Yitoa Intelligent Control Co., Ltd. Trade Mark : Dimplex EUT : Remote Control, 433MHz Model No. : DF2690-R Type of device : Superregenerative Receiver Power Supply : AC 120V, 60HZ Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart B Class B & FCC / ANSI C63.4-2009 The device described above is tested by SHENZHEN EMTEK CO., LTD. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and SHENZHEN EMTEK CO., LTD. is assumed full of responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of SHENZHEN EMTEK CO., LTD. Date of Test : March 20, 2012 to March 23, 2012 Prepared by : (Engineer) Reviewer : (Quality Manager) Approved & Authorized Signer : (Manager) FCC ID: GSO300082 SHENZHEN EMTEK CO., LTD. Report No.: ES120419075F Page 4 of 20 1. SUMMARY OF TEST RESULT EMISSION Description of Test Item Standard & Limits Results Conducted Disturbance at Mains Terminals FCC Part 15, Subpart B, Class B ANSI C63.4: 2009 Pass Radiated Disturbance FCC Part 15, Subpart B, Class B ANSI C63.4: 2009 Pass Note: N/A is an abbreviation for Not Applicable. FCC ID:…

Text truncated - open the document above for the full version.

1.1. Photos of Conducted Emission Measurement 1.2. Photos of Radiation Emission Measurement
