H52PT-3032Modem

Quick Installation Guide Ver. A 3030-0005 Fax Modem Table of Contents Chapter 1 Introduction Your Modem ................................... Features.............................................. System Requirements........................ Package Checklist ............................. Chapter 2 Installations Hardware Installation ....................... Installation Procedures for Windows NT4.0 ................................ Installation Procedures for Windows 98 ..................................... Installation of Communication Software ........................................... Installation Procedures for Windows 2000 ................................. AT Commands.................................... 1 2 2 4 5 6 9 10 Table of Contents 3 11 1 Chapter 1 Introduction The Voice/Fax/Data Modem connects your computer to Internet, and all kinds of BBS, and other popular Fax / Modems. This manual describes the features, procedures of installations, and AT command set... etc. of this modem. Your modem... There are indicator lights and connectors on the front and back side of this modem. Following is the meaning of these light and connectors for your reference: 1. External Front Panel RD : Received Data indicator. TD : Transmitted Data indicator. CD : Carrier Detect indicator. OH : Off Hook. MR : Modem Ready. PHONE : Phone jack. LINE : Telephone line jack. RS232 : RS232 cable socket. AC-IN : AC adapter input. ON/OFF : Power switch. 2. External Rear Panel 2 Chapter 1 Features This modem supports the following communica- tion standards. ITU-T is known as CCITT. Data ITU-T V.90 z ITU-T V.34, V.32bis, V.32, V.22bis, V.22 Bell 103 & 212A V.42bis & MNP 5 ( Data compression ) V.42 & MNP2-4 ( Error correction ) Fax V.17 ( 14400bps FAX ) V.29 ( 9600bps FAX ) V.27ter ( 4800bps FAX ) z z z z z z z Voice Voice/Audio mode z System Requirements ƒWindows NT 4.0, Windows 95, Windows 98, Windows 2000. 3 Chapter 1 The package contains the following items: One fax modem One piece of phone cable One Disk One AC Adaptop The fax modem Quick Installation Guide If any of these items are missing or damaged, please contact your dealer or sales representative for assistance. z z One piece of RS-232 cable z z z Package Checklist z 4 Chapter 2 Installations This chapter describes how to install and power on you fax modem. Hardware Installation Before complete the hardware installation be aware not to power on the modem 1. Plug the male end of the RS-232RS-232 RS-232RS-232 RS-232 cable into the connector marked RS-232RS-232 RS-232RS-232 RS-232 ( ) on the back of the modem. 2. Plug the other end of this cable into the serial port on the back of your computer. 3. ( Be sure your modem is Power off ) Plug the power cable into the AC-INAC-IN AC-INAC-IN AC-IN connector ( ) on the back of the modem. e f 4. Plug the power adapter into a wall outlet. 5 Chapter 2 7. Turn your modem on( ). The MR MR MR MR MR lights should light up. 8. Turn your computer on. g 5. Plug one end of the phone cable into the modem‘s LINELINE LINELINE LINE jack ( ). Plug the other end into the phone outlet. 6. To use telephone and the modem on the same line, plug one end of the optional phone cable into the PHONE PHONE PHONE PHONE PHONE jack( ) on the modem; plug the other end into the phone. Lift the telephone handset and listen for a DIALDIAL DIALDIAL DIAL TONE TONE TONE TONE TONE to check the connection. Installation Procedures for Windows NT4.0 c d 1.When enter to the Winnt operating system, select the modem item in the control panel, the following dialog box will appear, please select “do not detect my modem...”, then click Next. 2.Select install from disk, the following dialog box appear, please specify the path of the driver, (a:\winnt), then click Next. 3.Varies type of modems will show in a dialog box, please select ( “Topic 56000bps External Fax Voice Modem”) , then click Next. Installation Procedures for Windows 98 1. Once you have completed the hardware installation, power on your computer. When running Win 98, your system will detect a new device and the following message will appear. click Next . 6 Chapter 2 4.Please select the COM port which attach to your modem, then click Next 5.You have installed the modem successfully . 6.If you want to configure the setting of your modem, please select the modem item in the control panel, a dialog box with modem status will appear. 2. Select the “search for the best driver for your device (Recommended)” option, then click Next . 7 Chapter 2 3. Place the disk containing the driver of Win 9X into your floppy disk drive. Specify the location of the modem driver, e.g., A:\ WIN9X . click Next . 4. The following message will appear. click Next . 5. The installation has been completed. click Finish. 8 Chapter 2 6. After the installation of Fax Voice Modem was completed, your system will detect Wave Device for Voice Modem and the following message will appear . click Next and then you could follow Step2 to Step5 to finish the installation . 9 Chapter 2 Installation Procedures for Windows 2000 1. Once you have completed the hardware installation, power on your computer. When running Win 2000, your system will detect a new device. click Next. 2.Select the “search for the best driver for your device (Recommended) “option, then click Next. 3. Place the disk containing the driver of Win 2000 into your floppy disk drive. Select the “specify location”, then click Next. 4. Browse the proper location of the driver path, A:\WIN2000, then cilck Next. 5. Click Nexit. 6. Please read the Digital Signature, then click Yes. 7. To complete the installation, click Finish. 10 Chapter 2 11 Chapter 2 AT Commands Most people use the communication software programs to tell modems what to do. Therefore, you may not use the commands in this chapter. However, if you prefer to communicate with your modem directly, you can type the commands described below. This chapter describes how to work in the terminal mode. The disk contains deta…
