H5OR34Car Alarm Receiver

FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two condition.(1).this device may not cause harmful interference. (2).this device must accept any interference received, including interference that may cause undesired operation Warning: Note: This equipment has been tested and found to comply with the limits for digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, used and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference in to radiate communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: l Reorient or relocate the receiving antenna l Increase the separation between the equipment and receiver. l Connect the equipment into an outlet on a circuit different form that to which the receiver in connected. l Consult the dealer or an experienced radio/TV technician for help. THE MANUFACTURER IS NOT RESPONSIBKE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH ODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. ’

Photo # 1. Front View Photo # 2. Rear View

NEUTRON EMC LAB. FCC ID: H5OR34 5/16 2. Product Labeling 2-1. FCC ID Label 2.8 cm FCC ID : H5OR34 4.7cm The remained portion of label statement required by FCC is attached in the user’s manual. 2-2 Location of Label on EUT

Photo # 1. Unit partially Disassembled Photo # 2. Unit partially Disassembled Photo # 3. Unit partially Disassembled Photo # 4. Unit partially Disassembled

(ALA-520) Operational Description The ADVANCE SECURITY INC. Model: ALA-520 (referred to as the EUT in this report) is a Receiver of car alarm security system which offers wireless remote control, ideal for use in vehicle security system to activate the function of center door lock control system and car searching except the alarm system. A major technical descriptions of EUT is described as following: A). Operation Frequency: 433.92 MHz B). Antenna Designation: Non User Replaceable (Fixed) C). Type : Super regenerative Receiver D). Power Supply : DC 12V, Battery Operated ≤ The radio frequency car-alarm is a system that it controllers locking(arm) and unlocking(disarm) the door of vehicle by wireless remote controller. This system consists of transmitter and receiver. The receiver(EUT) is fixed inside the vehicle and powered 12V from car battery. It works intermittently to prevent the battery exhaustion and check the vehicle status. It is designed to operate on a single fixed frequency 433.93MHz by frequency modulation. It runs continuously to receive the signals completely, when the receiving module in receiver detects several synchronous codes, unique identification code, security code and function code transmitted from transmitter. After receiving the signal, the 8bit CPU in receiver decides which operation will be performed. And then driving circuit in receiver performs selected operations by pressing the button of the remote transmitter.

NEUTRON EMC LAB. FCC ID: H5OR34 1/15 MEASUREMENT/TECHNICAL REPORT APPLICTNT:ADVANCE SECURITY INC. MODEL NO.:ALA-520 FCC ID: H5OR34 This report concerns ( check one ) : Original Grant ̧ Class II Change Equipment type:433.92MHz AUTO ALARM SYSTEM RECEIVER (Receiver) Deferred grant requested per 47CFR 0.457(d)(1)(ii)? Yes No ̧ If yes, defer until: (date) We, the undersigned, agree to notify the Commission by (date) / / of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No ̧ If no, assumed Part 15, Subpart B for unintentional radiator the new 47 CFR (10-1-90 Edition) provision. Report Prepared by Testing House Neutron Engineering Inc. for Company NameADVANCE SECURITY INC. Address3F., No. 48, TA AN ST., HIS CHIH CITY, TAIPEI, TAIWAN, R.O.C. Applicant Signature Michael Chen / President NEUTRON EMC LAB. FCC ID: H5OR34 2/15 CERTIFICATION We hereby certify that: The test data, data evaluation , test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (1992) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15 , Subpart B. Prepared by Carol Chen Reviewed by Vincent Su Approved by George Yao Issued Date July 03, 1998 Report No. NEI-FCCB-01217 Company Stamp NEUTRON ENGINEERING INC. No. 132-1, Lane 329, Sec. 2, Palain Rd., Shijr Jen, Taipei, Taiwan TEL: (02) 2646-5426 FAX : (02) 2646-6815 NEUTRON EMC LAB. FCC ID: H5OR34 3/15 Table of Contents 1.General Information...................................................................................................................... 1-1 Product Description................................................................................................................4 1-2 Related Submittal(s)/Grant(s)..................................................................................................4 1-3 Test Methodology...................................................................................................................4 1-4 Test Facility............................................................................................................................4 2.System Test Configuration............................................................................................................. 2-1 EUT Configuration.................................................................................................................5 2-2 EUT Exercise...........................................................................................................................5 2-3 Test Procedure..........................................................................................................................5 2-4 Limitation...............................................................................................................................6 2-5 Special Accessories................................................................................................................6 2-6 Equipment Modifications.......................................................................................................6 2-7 Test Set-UP............................................................................................................................7 2-8 Test Equipment........................................................................................................................8 3.Block Dia-9 4.Radiated Measurement Photos.............................................................................. 4-2 Radiated Measurement Photos.......................................................................................10 5.Radiated Emission Datas .............................................................................................................. 5-1 Radiated Emission Data...........................................................................................................11 5-2 Field Strength Calculation.......................................................................................................12 5-3 Correction Factor Table VS Frequency....................................................................................13 6.Attachment...................................................................................................................................... A. Photos of Tested EUT. ...............................................................................................................14 B. User Manual................................................................................................................................15 NEUTRON EMC LAB. FCC ID: H5OR34 4/15 1. GENERAL INFORMATION 1-1. Product Description The ADVANCE SECURITY INC. Model: ALA-520 (referred to as the EUT in this report) is a Re- ceiver of car alarm security system which offers wireless remote control, ideal for use in vehicle security system to activate the function of center door lock control system and car searching except the alarm system. A major technical descriptions of EUT is described as following: A). Operation Frequency: 433.92 MHz B). Antenna Designation: Non User Replaceable (Fixed) C). Type : Super regenerative Receiver D). Power Supply : DC 12V, Battery Operated ≤ 1-2. Related Submittal(s) / Grant (s) This is an equipment authorization for filing, the Receiver portion of wireless remote control car alarm security system, FCC ID : H5OR34 1-3. Test Methodology Both conducted and radiated testing were performed according to the procedures in ANSI C63.4 (1992). Radiated testing was performed at an antenna to EUT distance 3 meters. 1-4. Test Facility The open area test site and conducted measurement facility used to collect the radiated data is located on the address of No. 132-1, Lane 329, Sec. 2, Palain Road, Shijr Jen, Taipei, Taiwan, R.O.C. of NEU- TRON E…

Text truncated - open the document above for the full version.

NEUTRON EMC LAB. FCC ID: H5OR34 10/15 4. Radiated Measurement Photos 4-1. Radiated Measurement Photos
