H5OT62Remote Control

2 Ignition controlled door lo cks & unlocks Igniti on c ontro lled door locks only Igniti on c ontro lled door unlo cks only Wit hout igniti on contro lled door locks & unlo cks 3 0.8-second Door lock pulses. 3.5-second Door lo ck p ulse. Double pulse unlock Comfort feature 4 3rd Channel Tr unk Pulsed, 3r d Channel Tr unk Momentary 5 + Button = Silent Arm/Disarm B utton = channel 4 AUX 1 6 + Gray Wire = Tr unk (Channel 3) Output Gray Wire = Two Step Door Unlock Output 7. + Horn chirp 20 mS Hor n chirp 50 mS Horn chirp 30 mS Horn chirp 10 mS SL-3S QUICK START INSTALLATION MANUAL If you are not proficient in the installation of this product or would like a full version of the installation manual, Please visit our web site @ www.silencer.com FOR PROFESSIONAL INSTALLATION ONLY! ALARM FEATURE “A” PROGRAMMING: 1. Turn the Ignition 'switch ‘ON/OFF’ 3 TIMES and stay in OFF position. 2. Push the Valet switch 3 times and hold in on the 3 rd pus h. W hen a long chirp is heard, rel eas e the valet switch. Y ou ar e now in the Alarm feature A pr ogramming m ode. 3. Press the transmitter button corres ponding to the feature you want to program. 4. Press the transmitter button again to c hange the f eatur e. Simply keep pressi ng the tr ansmitter button again until the modul e advances to your desired s etti ng. Press Tr ansmitter Button One Chirp / LED one pulse Factory Default Setting Two Chirps /LE D tw o pu lses Thr ee Chirps /LED three pulses Four Chirps /LED four pulses 1 Active arming Pa ssiv e arming without passive door locking Pa ssiv e arming with passive door locki ng. 2 Automatic Rearm off Autom atic Rearm on 3 45 seconds delay Door Ajar error chirp. Ins tant Door Ajar error chirp 4 Siren Confirmation chirp on only All Confirmati on chirps On Horn Confirmati on chir p on only All Confirmat ion chirps off 5 + White wire= Dome Li ght Output Whi te wire= 4th Channel pulsed Whi te =4th channel Mom entary Whi te =4th channel Latc hed 6 + Lock/Arm & Unlock/Disarm Confirmation Chirps Lock/Arm Confirmati on Chirp Only 7.+ ALARM with Keyless Entry Keyless E ntry ONLY 8.+ Car Jacking feature Off Car Jacki ng featur e On Exit: Tur n Ignition to 'ON' positi on, or leav e it for 15 seconds . 3 l ong chirps will confirm exit. ALARM FEATURE “B” PROGRAMMING: 1 Turn the Ignition 'switch ‘ON/OFF’ 3 TIM ES and stay in OFF position. 2 Push the Valet switch 4 times and hold in on the 4 th pus h. W hen a long chirp is hear d, rel ease the valet switch. Y ou are now in the Alarm feature ʻBʼ pr ogramming mode. 3 Press the transmitter button corres ponding to the feature you want to program. Press Tr ansmitter Button One Chirp / LED one pulse Factory Default Setting Two Chirps / LED two pulses Thr ee C hirps / L ED three pulses Four Chirps / LED four pulses 1 Pathway illumi nati on featur e “ off” Parki ng light turns “on” for 30- sec ond upon an unlo ck si gnal Parki ng light turns “on” for 30- sec ond unlock si gnal & 10- lock ALARM FEATURE “C” PROGRAMMING: 1. Turn the Ignition 'switch ‘ON/OFF’ 3 TIMES and stay in OFF position. 2. Push the Valet switch 5 times and hold on the 5 th push until a long chirp is heard then rel eas e the valet switch. Y ou ar e now in the Alarm feature ‘C’ p rogramming m ode. 3. Press and hold the transmitter button for two seconds to enter shock sensor program mode. Press Tr ansmitter Button One Chirp / LED one pulse Factory Default Setting Two Chirps / LED two pulse 1 Shock Sensor Program Mode 2. ADS DBI protocol Forti n DB I Pr otocol 3 + No Function DBI s tar t output on channel 4 ADJUST AND TEST THE SENSITIVITY LEVEL OF THE SHOCK SENSOR Turn the Ignition switch ‘ON/OFF’ 3 TIMES and stay in OFF position. Push the Valet switch 5 times holding in on the 5th push. until a long chirp will be heard. Release the valet switch. You are now in the f eature ‘Shock Sensor’ programming mode. Press and hold button for 2 seconds. One long siren chirp will indicate the unit is ready to accept adjustments o f the shock sensor. Press button on the transmitter onc e. This will decrease s ensitivity level b y one. Each tim e the button is pus hed and a decreas e is made the siren/horn chirp will respond with [1] chirp. Two chirps indic ate the minimum sensitivity. War n away & full t ri gger will be deleted whe n minimum sensitivity is selected. Shock sensor OFF. Pre ss button on the transmitter onc e. This will increase sensitivity level b y one. Each tim e an increas e is made the siren/horn chirp will respond with [1] chirp. Two chirps indicate the maximum sensitivity. Hi t the bumper or strong metal par t of the vehicl e to tes t the threshol d level of the sensor. a) . Activate the warn-away (first s tage the shock senso r), t he siren will emi t a s hor t chir p. b) . Activate the full a larm (second stage the shock sensor), the siren will emi t a l ong chirp. Wh en y ou ar e s atisfi ed with t he s etti ng, press the button to lock i n the adjustment. One long siren chirp will indic ate t he unit has locked i n the adjustment. Note: If 30 seconds of inactivity e xpires o r y ou turn ON the i gniti on during of above steps, the unit will exit the program mode. Three l ong chirps will confirm e xi t. Button IM-QR-SL-3S rev A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Quick Start OPERATIONS MANUAL Please register your product at www.silencer.com/manual . CHANGING THE BATTERY IN YOUR TRANSMITTERS TRANSMITTER OPERATION Transmitter Button System FunctionRemark Bu tton Lock door / ARM ARM (OPTIONAL) –Button Arm and Delete Optional Sensor Press twice. (OPTIONAL) Bu tton Car Locator While System Armed. Bu tton f or 3 seconds Panic f unction Press 3 seconds Bu tton Unlock Door / DISARM – Bu tton Two Steps Door Unlock & Disarm System Press twice within 3 sec onds. (optional …
