H5OR41Car Alarm Receiver

OWNER’S MANUAL Model: PLUS-4800 For Technical Assistance, please call (800) 638-3600, or visit www.magnadyne.com R Vehicle Security PLUS-4800-UM.qxp 2/7/05 2:43 PM Page 1 2 Congratulations on your purchase of a quality Carbine automotive security system. Carbine automotive security products have been designed to provide the consumer with a product that is technologically superior and will provide years of trouble free operation. The information enclosed will provide a ready reference of the operation and maintenance of your new security system. Remote Control Transmitters 1. Exit the vehicle and close all entrances. 2. Press and release the LOCK button. The security system will respond as follows: A. The horn/siren will chirp one time. B. The LED indicator will begin to flash at a steady rate. C. The parking lights will flash one time. D. The starter disable device will become armed and the vehicle engine will not crank. E. All protected entrances are armed. Note:If the dome light is on or a sensor is active at the time you arm your security system, you will hear the horn/siren beep one time and then you will hear another beep from the horn/siren about 5 seconds later. The second beep is the active sensor warning indicator. This second beep tells you that the alarm is armed but one of the sensors has been temporarily deleted because it was “On” at the time the alarm was armed. The security system is now fully armed! Security System Operation:(using the transmitter to arm the security system) AB Note: The following information is valid only if your security system has been programmed to automatically arm. 1. Turn off the ignition key and exit the vehicle. 2. Close all protected entrances. After the last protected entrance is closed the horn/siren will chirp one time and the LED indicator will begin to flash fast. The fast flashing LED indicates that the automatic arming timer is counting down and the security system will become armed within 30 seconds. After 30 seconds has passed, the security system will respond in the following manner: Automatic Arming(without using the transmitter) Lock Unlock Panic Aux Regular Transmitter Lock Unlock Panic Aux Passive Transmitter (Optional) Passive Unlocking PLUS-4800-UM.qxp 2/7/05 2:43 PM Page 2 A. The horn/siren will chirp one time. B. The LED indicator will begin to flash slower. C. The parking lights will flash one time. D. All protected entrances are armed. Note 1:Re-opening a protected entrance before the system becomes armed will stop the arming timer. After closing the entrance the timer will begin counting again from zero. Note 2:If the vehicle has a delayed interior lighting system, the automatic arming timer will start counting after the interior lighting has turned itself Off. This could add up to 45 seconds to the total automatic arming countdown time (up to 75 seconds total arming delay). The security system is now fully armed! 3 Automatic Arming(without using the transmitter)(Continued) Press and release the UNLOCK button. The security system will respond as follows: A. The horn/siren will chirp two times. B1.The LED indicator will be Off (only if Auto Arming is programmed Off). B2.The LED indicator will be flashing very fast (only if Auto Arming is programmed On). C. The parking lights will flash two times. Note: If you are disarming the security system after it has been triggered and the horn/siren is sounding, the disarm chirps are automatically deleted. Disarming the Security System Using the Regular Transmitter(A) Override Switch Operation Your Carbine security system is supplied with a override switch system. This switch is used to override the security system in the event that the transmitters are lost or fail to operate, and to put the security system in non-operational mode. Disarming the Security System Using the Passive Transmitter (B) Note: When using the passive transmitter the on/off switch must be in the “On” position. A. Walk toward your vehicle and the security system will respond the same as pushing the UNLOCK button. The security system is now disarmed! PLUS-4800-UM.qxp 2/7/05 2:43 PM Page 3 4 Override Switch Operation(Continued) Override Operation:(Security System is Armed) 1. Enter the vehicle (the security system will begin sounding at this point). 2. Place the ignition key into the ignition switch and turn the switch to the “On” position. 3. Within 5 seconds of turning the ignition key “On”, place the override switch to the “On” position. 4. The horn/siren will stop sounding. 5. The LED indicator will be solid red. The security system is overridden. Note 1:If the override switch is already in the “On” position when you turn “On” the ignition key, the override function will be bypassed. Turn “Off” the ignition key, place the override switch in the “Off” position and try again. Note 2:If you fail to place the overrideswitch to the “On” position within 5 seconds of turning “On” the ignition key, the override function will be locked-out. Place the switch in the “Off” position, turn “Off” the ignition key and try again. Remote Panic: Press and hold the LOCK or PANIC button for more than 3 seconds and the security system will respond in the following manner: A. The horn/siren will begin sounding. B. The parking lights will begin flashing. To turn off the panic alarm, press and release the UNLOCK or PANIC button. The horn/siren will stop sounding and the parking lights will stop flashing. Note:If you do not turn off the panic feature with the transmitter, the panic alarm will sound for 60 seconds and then turn off by itself. Remote Valet Mode Operation: Activate Valet Mode 1. Turn the ignition key to the “Off” position and open any door. 2. Press and hold down the LOCK + * buttons. 3. The door locks will lock and unlock. Release the buttons. 4. The LED will begin to flash every 5 seconds indicating that the system is in Valet Mode. Exit Valet Mode 1. Turn the ignition key to the “Off” position and open any door. 2. Press…

Text truncated - open the document above for the full version.

P4800-BD1.SCH Title Size ADate File Number 2004-12-02 E:\DDB\P4800-1.DDB Revision Sheet of Drawn By :

Compliance Certification Services Inc. Report No.: 50218215 Date of Issue: March 2, 2005 Page PHOTOGRAPHS OF EUT

FCC ID LABEL FORMAT AND LOCATION Advance Security Inc. FCC ID: H5OR41 FCC ID: H5OR41 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Compliance Certification Services Inc. Report No.: 50218215 Date of Issue: March 2, 2005 Page Compliance Certification Services Inc. Report No.: 50218215 Date of Issue: March 2, 2005 Page

Compliance Certification Services Inc. Report No.: 50218215-F FCC ID: H5OR41 Date of Issue: March 2, 2005 Page 1 FCC 47 CFR PART 15 SUBPART B TEST REPORT For CAR ALARM RECEIVER Model: PLUS-4800 Trade Name: Advance Security Inc. Issued to Advance Security Inc. 3F, 48 Ta An Street, Hsi Chih, Taipei Hsien, TAIWAN R.O.C. Issued by Compliance Certification Services Inc. Hsintien Lab. No. 165, Chunghsen Road, Hsintien City Taipei Hsien, Taiwan TEL: (02) 2217-0894 FAX: (02) 2217-1029 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. Ltd. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Compliance Certification Services Inc. Report No.: 50218215-F FCC ID: H5OR41 Date of Issue: March 2, 2005 Page TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION..........................................................................................3 2 EUT DESCRIPTION..................................................................................................................4 3 TEST METHODOLOGY...........................................................................................................5 3.1 EUT SYSTEM OPERATION.............................................................................................5 3.2 DECISION OF FINAL TEST MODE...............................................................................5 4 SETUP OF EQUIPMENT UNDER TEST................................................................................6 5 FACILITIES AND ACCREDITATIONS.................................................................................7 5.1 FACILITIES.........................................................................................................................7 5.2 LABORATORY ACCREDITATIONS AND LISTINGS.................................................7 6 INSTRUMENT AND CALIBRATION.....................................................................................8 6.1 MEASURING INSTRUMENT CALIBRATION.............................................................8 6.2 TEST AND MEASUREMENT EQUIPMENT.................................................................8 7 LINE CONDUCTED & RADIATED EMISSION TEST........................................................9 7.1 LIMIT...................................................................................................................................9 7.2 TEST PROCEDURE OF LINE CONDUCTED EMISSION........................................10 7.3 TEST PROCEDURE OF RADIATED EMISSION.......................................................12 7.4 TEST RESULTS................................................................................................................14 APPENDIX I - PHOTOGRAPHS OF TEST SETUP..................................................................16 APPENDIX II - TEST RESULT OF FINAL DATAS.................................................................17 Compliance Certification Services Inc. Report No.: 50218215-F FCC ID: H5OR41 Date of Issue: March 2, 2005 Page 1 TEST RESULT CERTIFICATION Applicant: Advance Security Inc. 3F, 48 Ta An Street, Hsi Chih, Taipei Hsien, TAIWAN R.O.C. Manufacturer: Advance Security Inc. 3F, 48 Ta An Street, Hsi Chih, Taipei Hsien, TAIWAN R.O.C. Equipment Under Test: CAR ALARM RECEIVER Trade Name: Advance Security Inc. Model: PLUS-4800 Detailed EUT Description: See Item 2 of this report Date of Test: March 2, 2005 Applicable Standard Class / Limit Test Result FCC Part 15 Subpart B Class B No non-compliance noted Deviation from Applicable Standard None The above equipment was tested by Compliance Certification Services Inc. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, Subpart B and the measurement procedures were according to ANSI C63.4. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. Approved by: Reviewed by: Compliance Certification Services Inc. Report No.: 50218215-F FCC ID: H5OR41 Date of Issue: March 2, 2005 Page 2 EUT DESCRIPTION Product CAR ALARM RECEIVER Trade Name Advance Security Inc. Model PLUS-4800 Housing Type Plastic EUT Power Rating 12VDC from DC Power OSC/Clock Frequencies 4MHz Receiver Frequency 433.92MHz Number of Channels 1 Channel Operating Mode Point-to-Point Antenna Type Internal loop, which is built in EUT Note: The product is a composite system includes Transmitter and Receiver. This submittal(s) (test report) is intended for FCC ID: H5OR41 filing to comply with FCC Part 15 Subpart B Rules. The composite system (Transmitter) is intended for FCC ID: H5OT29 is compliance with FCC Part 15 Subpart C Rules. I/O PORT OF EUT I/O Port Type Q’TY TESTED WITH Note: Client consigns only one model sample (Model Number is PLUS-4800) to test. Compliance Certification Services Inc. Report No.: 50218215-F FCC ID: H5OR41 Date of Issue: March 2, 2005 Page 3 TEST METHODOLOGY 3.1 EUT SYSTEM OPERATION 1. Turn on the EUT by connect to DC power supply. 2. EUT receive the data from transmitter by pressing and hold the button. Note: Test program is self-repeating throughout the test. 3.2 DECISION OF FINAL TEST MODE 1. The following test mode(s) were scanned during the preliminary test: Mode: 1. NORMAL MODE 2. After the preliminary scan, the following test mode was found to produce the highest emission level. Radiation: Mode 1 Then, the EUT configuration and cable configuration of the above highest emission mode was recorded for all final test items. Compliance Certification Services Inc. Report No.: 50218215-F FCC ID: H5OR41 Date of Issue: March 2, 2005 Page 4 SETUP OF EQUIPMENT UNDER TEST Setup Diagram See test photographs attached in Appendix I for the actual connections between EUT and support equipment. Support Equipment No Device Type Model Serial No.…
