H5OT17Car Alarm Transmitter

From: Denise Teng Sent: Tuesday, March 12, 2002 11:31 AM To: Mike Kuo Cc: Thu Tran; Chin Pang; Michael Heckrotte; Steve Cheng Subject: RE: ADVANCE SECURITY INC., FCC ID:H5OT17, AN02T1850 Hi Mike, Question #5: Please see attached file for the revised report. Thanks! regards, Denise -----Original Message----- From: Mike Kuo Sent: Monday, March 11, 2002 6:01 PM To: Denise Teng Cc: Thu Tran; Chin Pang; Michael Heckrotte; Steve Cheng Subject: RE: ADVANCE SECURITY INC., FCC ID:H5OT17, AN02T1850 Question #5: In accordance with the revised test report, 1 period is equal to 81.3 msecond. Since this period is less than 100msecond, you can not use 100msecond for your duty cycle correction factor. You should use 81.3msecond for calculation. As result, please provide revised test report by correcting the duty cycle factor and all related emission data. In this revised test report, you are still using average detector for above 1GHz tests. For pulse emission, the average reading is equal to Peak + 20log(M%). For frequency above 1GHz, average detector was used. Please correct the readings for above 1GHz. Best Regards Mike Kuo/ TCB Certifier -----Original Message----- From: Denise Teng Sent: Monday, March 11, 2002 3:57 PM To: Mike Kuo Cc: Thu Tran; Chin Pang; Michael Heckrotte; Steve Cheng Subject: RE: ADVANCE SECURITY INC., FCC ID:H5OT17, AN02T1850 Hi Mike, Question #1: Please see revised report in the attached file. The plot supports the one period is on page 12. Question #2: Please see page 16 and 17 of the revised report in the attached file. Question #3: Please see revised User manual in the attached file. Question #4: Please see NEW internal photos in the attached file. Thanks! regards, Denise -----Original Message----- From: CERTADM Sent: Friday, March 08, 2002 6:13 PM To: '[email protected]' Subject: ADVANCE SECURITY INC., FCC ID:H5OT17, AN02T1850 Notice_content ------------- Question #1: There are five duty cycle plots are provided. Marker points can not be seen. Please provide the description for each plot. In addition, there is no plot can support the one period is equal to 100ms. Question #2: For pulse emission, the average reading is equal to Peak + 20log(M%). For frequency above 1GHz, average detector was used. Please correct the readins for above 1GHz. Question #3: User manual does not contain information required under 15.21 of FCC rules. Please provide revised user manual to comply this requirement. Question #4: The internal photos are too small. Please provide additional internal photos. The internal photo should be clear enough to see the component number and traces. Best Regards Mike Kuo / TCB Certifier The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

PROPOSED FCC ID LABEL AND LOCATION ADVANCE SECURITY INC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: H5OT17 FCC ID LABEL FCC ID

02T1175-1 Advance Security Inc 02T1175-1 Advance Security Inc

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 433.92 MHz CAR ALARM TRANSMITTER MODEL NAME: TX220 TRADE NAME: ADVANCE FCC ID NO: H5OT17 REPORT NO: 02T1157-1 ISSUE DATE: FEBRUARY 20, 2002 Prepared for ADVANCE SECURITY INC. 3F, 48 TA AN STREET HIS-CHIH, TAIPEI HSIEN TAIWAN, R. O. C. Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 02T1157-1 FCC ID: H5OT17 DATE: FEBRUARY 20, 2002 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO:CCSUP4020B 561F MONTEREY RD., MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE........................................................................................3 2. Product Description.....................................................................................................................3 3. Test Facility.................................................................................................................................4 4. Measurement Standards...............................................................................................................4 5. Test Methodology........................................................................................................................4 6. Measurement Equipment Used....................................................................................................4 7. POWERLINE RFI LIMIT...........................................................................................................5 8. RADIATED EMISSION LIMITS...............................................................................................5 9. SYSTEM TEST CONFIGURATION.........................................................................................6 10. Test Procedure...........................................................................................................................7 11. Equipment Modifications...........................................................................................................8 12. TEST RESULT..........................................................................................................................9 12.1 Maximum Modulation Percentage (M%)................................................................................9 12.2 The Emissions Bandwidth.......................................................................................................9 TEST DATA • Maximum Modulation Percentage Plot • Emission Bandwidth Plot • Radiated Emission Worksheet for Peak Measurement • Radiated Emission Worksheet for Average Measurement REPORT NO: 02T1157-1 FCC ID: H5OT17 DATE: FEBRUARY 20, 2002 Page 3 of 17 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO:CCSUP4020B 561F MONTEREY RD., MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. VERIFICATION OF COMPLIANCE COMPANY NAME: ADVANCE SECURITY INC. 3F, 48 TA AN STREET HIS-CHIH, TAIPEI HSIEN, TAIWAN R. O. C. CONTACT PERSON: MICHAEL CHEN/PRESIDENT TELEPHONE NO.: 02-8648-1688 EUT DESCRIPTION: 433.92 MHz CAR ALARM TRANSMITTER MODEL NAME/NUMBER: TX220 TRADE NAME: ADVANCE FCC ID: H5OT17 DATE TESTED: 2/14/2002, 2/15/2002 TYPE OF EQUIPMENT SECURITY EQUIPMENT (INTENTIONAL RADIATOR) EQUIPMENT TYPE 433.92 MHz CAR ALARM TRANSMITTER MEASUREMENT PROCEDURE ANSI C63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 The above equipment was tested by Compliance Certification Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Warning : This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification will constitute fraud and shall nullify the document. Tested By: CHIN PANG EMC TECHNICIAN COMPLIANCE CERTIFICATION SERVICES Approved & Released By: THU CHAN SENIOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES REPORT NO: 02T1157-1 FCC ID: H5OT17 DATE: FEBRUARY 20, 2002 Page 4 of 17 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO:CCSUP4020B 561F MONTEREY RD., MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. PRODUCT DESCRIPTION Fundamental Frequency 433.92 MHz Power Source 12V Battery Transmitting Time Periodic < 5 seconds Associated Receiver Advance Security FCC ID: H5OR36 3. TEST FACILITY The 3/10/30 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facility was submitted to the Commission on May 27,1994. 4. MEASUREMENT STANDARD The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5. TEST METHODOLOGY F…

Text truncated - open the document above for the full version.

REPORT NO: 02T1157-1 FCC ID: H5OT17 DATE: FEBRUARY 20, 2002 Page 6 of 18 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO:CCSUP4020B 561F MONTEREY RD., MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 9. SYSTEM TEST CONFIGURATION Use a block of foam and combined it with EUT wrapping cable tie around it. This way it can test X.Y, and Z axis. To activate continuous transmission, place a small plastic block between rubber band and EUT push button. Radiated Open Site Test Set-up High Frequency Test Set-up
