H5OT53Remote Control

. TO REMOTE START THE VEHICLE: When you want to start your vehicle, • Press on the two way or button on the standard transmitter. Press Twice if the unit is programmed for safety start • The parking light will activate to indicate the re mote start received the signal. • The engine will start in approximately 5 seconds. • Once the engine is running, after couple seconds t he parking lights will turn on and the climate controls will activate and adjust t he vehicle’s interior temperature to your preset setting. • The vehicle will run for a programmable 5 to 30 mi nute cycle before shutting down. NOTE: The Remote Start Unit will not start the vehi cle if any one of the following conditions exists: 1. The hood is opened. 2. The brake pedal is pressed. 3. The optional remote start enable toggle is switc hed to the “OFF” position. (If installed) 4. The gear selector is in any gear other then “PAR K” or “NEUTRAL”. SAFE START (Child safety mode) Factory default is set to press the or button once on the transmitter to start the vehicle. Safety Start feature can be programmed to eliminate an accidental remote start: 1. The user presses the transmitter or buttons twice within 3 seconds to start the vehicle. NOTE: Contact your installing dealer to de-activate this feature for one push start OPERATE THE VEHICLE WHILE RUNNING FROM THE REMOTE S TART: To operate the vehicle while the engine is running from the remote start, • Insert the ignition key and turn it to “ON” (not t he start) position. • Press the brake pedal. Note : If the brake pedal is pressed before the key is i n the ON position, the engine will shut down. TEMPORARY STOP FEATURE: This feature allows the vehicle to remain running a fter the key has been removed from the ignition. This feature is useful for occasions when you wish to exit and lock the vehicle for short periods of time, but would like t o leave the motor running and the climate control on. • Before turning off the engine, press the or button on the transmitter and the LED indicator will flash 3 times to confirm ent er. • Turn the ignition key to OFF position. (The engine will stay running.) • The engine will run until the pre-programmed time elapsed or shutdown input is received. TO TURN OFF THE REMOTE START: When the engine is running (by remote start), if yo u want to stop it, Press or button TWICE on the remote transmitter under the r emote start mode. . Press the brake pedal The vehicle will shut down and turn off the parking light to indicate the engine has stopped. SHUT-DOWN INPUT FOR REMOTE STARTER: If any of the following conditions exist while the system is operating, the engine will not start or will shut down immediately : 1. The hood is opened. 2. The brake pedal is pressed. 3. Engine is over-revved. {“Tachometer checking typ e” only} 4. The pre-programmed run time (5 /10 / 20 / 30 min utes) has elapsed. 5. Press or button twice on the remote transmitter under remot e start mode. 6. The vehicle refused to start running after {3} u nsuccessful attempts. E ncore Automotive Systems, LLC. All rights reserved . For Warranty information, Please go to www.encoreautomotivesystems.com and download the complete user’s manual. For customer service, please call us toll free @ (855) GO-ENCORE 855.463.6267 . 8:00-5:00 PST Thanks for your purchase! ENCORE LIMITED LIFETIME WARRANTY PROVISIONS ( U.S. ,Continental U.S. and Canada Only) 1. Encore Automotive Systems LLC. WARRANTS that this n ew unit has been thoroughly inspected and tested at the factory prio r to delivery. Your Encore equipment is guaranteed for “life” to the original purchaser/user of the equipment and the original vehicle in which it was installed by an authorized installer under the following conditions: If the pr oduct proves defective (according to Encore’s testing) within the first ye ar, the defective unit may be exchanged or repaired free of charge. “Proof of Pu rchase” (dated sales receipt) must accompany all warranty returns; otherwise, your return will be rejected and sent back. After one (1) year, the purchaser should ship the unit prepaid to Encore with a money order in the amount of $30.00 t o cover shipping and handling charges 2. Exclusion to the Limited Lifetime Warranty Provisio n: All two-way LCD and two- way OLED remote transceivers are excluded from the Limited Lifetime Warranty noted in paragraph no.1. All two-way LCD and two-wa y OLED remote transceivers are guaranteed to the original purchas er for a period of one year from date of purchase. If the product proves to be defective within the first year, the defective unit may be exchanged or repair ed free of charge. All other provisions stated on this card apply. 3. This WARRANTY will be considered void if the equipm ent has been misused, neglected, improperly serviced or installed, altere d, dropped or damaged by water, contrary to the Encore OPERATIONS MANUAL. O r, if used with accessories not approved by Encore, which may have contributed to the defect. See note below regarding product installation**. 4. The purchaser’s remedies under this WARRANTY shall be limited to the repair or replacement of electronic components only. THE FOLLOWING IS NOT COVERED: Damages or deterioration to cases, batteries, cove rs and cabinets; the cost of repairs, replacement and labor of which shall be borne by the purchaser even if occurring during the WARRANTY per iod. 5. Any equipment or parts which are claimed to be defe ctive under this WARRANTY must be sent to the Encore Service center with “proof of purchase” at the purchaser’s expense prior to such return, a Return Authorization Number needs to be obtained. Encore will return the equip ment, charges prepaid. Warranty Service can be provided through the dealer where the equipment is originally purchased. 6. Any unexpired WARRANTY shall be applicable to equip ment and parts in the possession of the original purchaser only. 7. THIS WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRA NTIES, EXPRESSED OR IMPLIED,…

Text truncated - open the document above for the full version.

ADVANCE SECURITY INC. 3F, 48 Ta An Street, Hsi Chih, Phone : (886-2) 8648-1688 E-mail : [email protected] Taipei Hsien, TAIWAN R.O.C. Telexfax : (886-2) 8648-1689 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2015-07-21 To whom it may concern: We, the undersigned, hereby authorize Worldwide Testing Services (Taiwan) Co., Ltd to act on our behalf in all matters relating to applications for equipment authorization FCC ID: H5OT53 including the signing of all documents related to these matters. Any and all acts carried out by Worldwide Testing Services (Taiwan) Co., Ltd on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature Name: Ted Lin Title: VICE PRESIDENT MARKETING & SALES Company: Advance Security Inc

ADVANCE SECURITY INC. 3F, 48 Ta An Street, Hsi Chih, Phone : (886-2) 8648-1688 E-mail : [email protected] Taipei Hsien, TAIWAN R.O.C. Telexfax : (886-2) 8648-1689 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2015-07-21 Request for Long-Term Confidentiality Company name: Advance Security Inc FCC ID: H5OT53 FCC Part 15 Certification To whom it may concern: In accordance with §§ 0.457(d) and 0.459 of CFR 47, Company name hereby requests Long-Term confidentiality of all Block Diagrams, Schematics, Operational Description attachments for the subject application. These documents contain detailed system and equipment description and related information about the product which Advance Security Inc considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Advance Security Inc considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Signa ture Name: Ted Lin Title: VICE PRESIDENT MARKETING & SALES Company: Advance Security Inc

Registration number: W6M21507-15149-FCC FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 2 of 10 External Photos Registration number: W6M21507-15149-FCC FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 3 of 10 Registration number: W6M21507-15149-FCC FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 4 of 10 Registration number: W6M21507-15149-FCC FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 5 of 10

FCC ID: H5OT53

Registration number: W6M21507-15149-FCC FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 6 of 10 Internal Photos Registration number: W6M21507-15149-FCC FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 7 of 10 Registration number: W6M21507-15149-FCC FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 8 of 10 Registration number: W6M21507-15149-FCC FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 9 of 10

of Applicant: Advance Security Inc Address: 3F, 48, Ta An Street, Hsi Chih Taipei Taiwan Tested and Prepared by Worldwide Testing Services (Taiwan) Co., Ltd. FCC Registration No.: 930600 Industry Canada filed test laboratory Reg. No. IC 5679A-1, IC 5107A-1 A2LA Accredited No.: 2732.01 Report No.: W6M21507-15149-C-1 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E-mail: [email protected] FCC PART 15 SUBPART C TEST REPORT for Remote Control Model No.: TRE719AB FCC ID: H5OT53 Registration number: W6M21507-15149-C-1 FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd page 1 of 20 TABLE OF CONTENTS 1 GENERAL INFORMATION..................................................................................................................2 1.1 NOTES..........................................................................................................................................2 1.2 TESTING LABORATORY................................................................................................................3 1.2.1 Location ..................................................................................................................................3 1.2.2 Details of accreditation status ................................................................................................3 1.3 DETAILS OF APPROVAL HOLDER...................................................................................................3 1.4 APPLICATION DETAILS.................................................................................................................4 1.5 TEST ITEM....................................................................................................................................4 1.6 T EST STANDARDS.........................................................................................................................4 2 TECHNICAL TEST..............................................................................................................................5 2.1 SUMMARY OF TEST RESULTS........................................................................................................5 2.2 T EST ENVIRONMENT....................................................................................................................5 2.3 TEST EQUIPMENT UTILIZED..........................................................................................................6 2.4 GENERAL TEST PROCEDURE........................................................................................................8 3 T EST RESULTS (ENCLOSURE)............................................................................................................9 3.1 T RANSMISSION REQUIREMENTS.................................................................................................10 3.1.1 Limit of Transmission Time ..................................................................................................10 3.1.2 Active Time ...........................................................................................................................10 3.2 O UTPUT POWER (FIELD STRENGTH) ..........................................................................................11 3.3 OUT OF BAND RADIATED EMISSIONS.........................................................................................12 3.4 T RANSMITTER RADIATED EMISSIONS IN RESTRICTED BANDS....................................................13 3.5 SPURIOUS EMISSION RADIATED, TRANSMITTER.........................................................................14 3.6 CHANNEL BANDWIDTH..............................................................................................................16 3.7 A NTENNA REQUIREMENT...........................................................................................................17 3.8 DUTY CYCLE.............................................................................................................................18 3.9 CONDUCTED MEASUREMENT AT (AC) POWER LINE..................................................................19 Registration number: W6M21507-15149-C-1 FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd page 2 of 20 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the Worldwide Testing Services(Taiwan) Co., Ltd. Tester: July 27, 2015 Robert Ren Date WTS-Lab. Name Signature Technical responsibility for area of testing: July 27, 2015 Kevin Wang Date WTS Name Signature Registration number: W6M21507-15149-C-1 FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd page 3 of 20 1.2 Testing laboratory 1.2.1 Location OATS No.5-1, Lishui, Shuang Sing Village, Wanli Dist., New Taipei City 207, Taiwan (R.O.C.) 3 meter semi-anechoic chamber No.35, Aly. 21, Ln. 228, Ankang Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) TEL:886-2-6613-0228 FAX:886-2-2791-5046 Company Worldwide Testing Services(Taiwan) Co., Ltd. 6F, NO. 58, LANE 188, RUEY-KUANG…

Text truncated - open the document above for the full version.

Registration number: W6M21507-15149-FCC FCC ID: H5OT53 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 10 of 10 Set Up Photo of Radiated Emission
