1 REMOTE ENGINE STARTER WITH ALARM SYSTEM OWNER’S MANUAL WARNINGS: As with any product that performs automatic functions, there are certain safety precautions that you must practice and be aware of. 1. Keep the transmitter out of children’s reach. 2. Do not leave anyone in the vehicle while running on remote control. 3. Alert servicing personnel that the vehicle can be started automatically. 4. Do not start the vehicle by remote while it’s in an enclosed area or garage. 5. Always apply the parking brake and lock the vehicle as you exit the vehicle. 6. The vehicle windows must be rolled up. 7. Should the unit malfunction, disconnect the fuse until the problem is corrected. 8. The use and operations of this system is the sole responsibility of the operator. 9. Some areas may have local ordinances that prohibit leaving a vehicle running on public streets. 10. Do not start the vehicle by remote while the standard transmission vehicle is parked at a steep place. OPERATION A. REMOTE TRANSMITTER OPERATION: Transmitter Button System Function Remark Lock Doors & Arm System - Arm and Delete The 2 Stage Shock Sensor. Press twice within 3 seconds - Arm System and Hidden Alarm Function Press within 3 seconds Car Locator Upon armed (3-second) Panic function Press and Hold for 3 seconds. + Silent Arming / Disarming Ignition in "off" position. + (2-second) Active Anti Car-Jacking Mode Ignition in "on" position press and hold for 2 seconds Unlock Doors & Disarm System - Two Steps Door Unlock & Disarm System Press twice within 3 seconds. (2-second) Trunk Release (Channel 3) Press and Hold for 2 seconds - Passive Arming By-pass While the system Disarmed. - Activate or Turn Off The Remote Start Press twice within 3 seconds. + Turbo Time Mode + Channel # 4 Timer Output B. LED display: LED Function LED Function Off Disarmed 2 flashes... pause Zone 2 / Trigger on Trunk/Hood Slow Flash Armed 3 flashes... pause Zone 3 / Trigger on Door Switch Fast Flash Passive Arming 4 flashes... pause Zone 4 / Trigger on Shock Sensor On (Solid) Valet Mode 5 flashes... pause Zone 5 / Trigger on Ignition Switch C. CHIRP INDICATORS: D. PARKING LIGHT: Chirp Function Parking light Function 1 chirp Arm 1 flash Arm 2 chirps Disarm 2 flashes Disarm 3 chirps Ajar Warning 3 flashes Disarm / Triggered 4 chirps Disarm / Triggered 12 flashes Car Locator 6 chirps Car Locator Constant On Under Remote Start 2 E. ALARM OPERATING CONDITION: Siren / Horn Parking Light LED Doors Starter Dome Light 1. Arming 1 or 3 Chirps 1 Flash Slow Flash Locking Disable 2. Disarming 2 or 4 Chirps 2 or 3 Flashes Unlocking Turns on for 30 -second 3. Trigger Alarming Flashes Slow Flash Disable Flashes 4. Panic Alarming Flashes Flashes 5. Car-Jacking Alarming Flashes Disable Flashes 6. Car Locator 6 Chirps 12 Flashes Locking F. ACTIVE ARMING – LOCK & ARM: 1. Press button on the transmitter. 2. The siren will chirp once and parking light will flash once indicating that the system is now armed. The vehicle door will lock and dome light turns on for 10 seconds upon arming when interfaced with the security system. System Arm Door Ajar Trunk / Hood Ajar AJAR WARNING: If the siren sounds 3 chirps, then you have left a door, trunk, or hood lid ajar. (See Alarm Feature “I - 4 Programming) SILENT ARMING / DISARMING: Press the transmitter and buttons at the same time will arm or disarm your security system, No chirp sound will be heard, arm / disarm confirmation will be through the vehicles parking lights only. SHOCK SENSOR BY-PASS: Press the button on the transmitter two times within 3 seconds will arm the security system and by-pass the shock sensor. The system will chirp one additional time to confirm the sensor bypass mode was activated. The sensor bypass feature is programmed to activate for one arming cycle only. The security system will return to normal operation during the next arming cycle. HIDDEN ALARM FUNCTION: Press the button first; within 3 seconds press the button to activate the hidden alarm function. The security system will arm and with “Hidden Alarm Function”. The siren / horn will be silenced even if the sensor is triggered in the armed status. G. PASSIVE ARMING Active arming / disarming is controlling your security system via the remote transmitter. This security system is equipped with an optional Passive Arming feature, which allows the security system to arm 30 seconds after the last door is closed. Operation is as follows. 1. Turn the ignition to the “OFF” position and exit the vehicle. 2. After all entrances are closed, the security system LED will flash fast for 30 seconds. If you reopen any door / hood / trunk, the security system LED will stop flashing. It will begin flashing again once the vehicle all entrances are closed. 3. After 30-second timer has elapsed, the security system will automatically “ARM”. The siren will chirp [1] time and the parking lights will flash [1] time. PASSIVE ARMING WITH PASSIVE DOOR LOCKING (See Alarm Feature “I - 2” Programming): The vehicle doors will automatically lock after passive arming cycle has been completed. PASSIVE ARMING BY-PASS: While the system disarmed, Press the button twice, the security will respond with [1] chirp and LED will turn “ON”. The security system will remain in this temporally state for as long as you wish. To exit passive by-pass, press the transmitter or button and the system will return to normal status. H. ACTIVE DISARMING – UNLOCK & DISARM: 1. Press button on the transmitter. 2. The siren will chirp twice and parking light flash twice to indicating that the security system is now disarmed. The vehicle’s door will unlock and dome light turns on for 30 seconds upon disarming when interfaced with the security system. 3 System Disarm Trunk/Hood Trigger Doors Trigger Shock Sensor Trigger Ignition Trigger TAMPER DISARMING: If alarm triggered, upon disarm the system, siren chirp 4 times, parking light flash 3 times. PATHWAY ILLUMINATION (See Alarm Feature “II - 4” Programming): This feature …

Text truncated - open the document above for the full version.

1 2 34 ABCD 4 3 2 1 D CBA Title Number Revision Size A4 Date: 21-Mar-2006 Sheet of File: D:\DDB\TRX\TRX-722RF.ddb Drawn By: T/R SW RECEIVE U1 POWER AMP Q2 TRANSMIT TXEN TXDATA +3V RXEN RXDATA GND ANT AX-722RF(BLOCK) ADVANCE SECUTITY INC. 1

ADVANCED ADVANCE SECURITY INC. 3F, 48 Ta An Street, Hsi Chih, Phone : (886-2) 8648-1688 E-mail : [email protected] Taipei Hsien, TAIWAN R.O.C. Telexfax : (886-2) 8648-1689 Date: August 18, 2005 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Testing Division of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS Testing Division as our agent, we still recognize that we are responsible to: comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. ADVANCE SECURITY INC. TED LIN SALES MANAGER REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

Compliance Certification Services Inc. Report No.: 60329204 Date of Issue: April 19, 2006 Page 1 Total Page: 6 Rev. 00 PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 60329204 Date of Issue: April 19, 2006 Page 2 Rev. 00 Compliance Certification Services Inc. Report No.: 60329204 Date of Issue: April 19, 2006 Page 3 Rev. 00

FCC ID LABEL FORMAT AND LOCATION Applicant: Advance Security Inc. FCC ID: H5OTR17 FCC ID: H5OTR17 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Compliance Certification Services Inc. Report No.: 60329204 Date of Issue: April 19, 2006 Page 4 Rev. 00 Compliance Certification Services Inc. Report No.: 60329204 Date of Issue: April 19, 2006 Page 5 Rev. 00 Compliance Certification Services Inc. Report No.: 60329204 Date of Issue: April 19, 2006 Page 6 Rev. 00

AX722 Operational Description The 2 way pager is a very low-powered remote control/ monitoring device used in motoring the automobile security status as well as in remotely arming/disarming car security system and other optional features like vibration or audible peping warning sound during alert mode. Its features and functions are described in the attached pager. The transmission is powered by a 1.5 V AAA battery and works on 433.92 Mhz single fixed frequency. Details of circuit diagram and block diagram are shown on the attached sheets. the other 4 buttons which if pressed will produce the digital control signals and modulate the carrier signal. The carrier signal is generated by a crystal oscillator/ amplifter circuit composed of a 433.92 Mh crystal and a npn transmitter The modulated output of RF amplifier stage is coupled to the coil. All the turning and verification are done by manufactuer during the production process and no adjustment is allowed by any consumer. No external ground is needed in such device. The module will be transmitting when the RF module data input is Hi; the module will stop transmitting when the RF module data input is Low. The single is controlled by the CPU control data input inside the control unit. Normally the transmitting time is about 0.6 seconds, the maximum is lasting for 4.5seconds.

1 2 34 ABCD 4 3 2 1 D CBA Title Number Revision Size A4 Date: 21-Mar-2006 Sheet of File: D:\DDB\TRX\TRX-722RF.ddb Drawn By: TRX-722RF(FCC) ADVANCE SECURITY INC. 1 LNASRC 8 LNAIN 7 AVDD 6 PAOUT 5 TX/RX2 4 TX/RX1 3 ESOUT 2 PAVDD 1 LNAOUT 9 MIXIN+ 10 MIXIN- 11 MIXOUT 12 IF IN- 13 IF IN+ 14 PD- 15 PD+ 16 DS- 17 DS+ 18 OP+ 19 DF 20 RSSI 21 T/R 22 ENABLE 23 DATA 24 N.C 25 DVDD 26 HVIN 27 AGC2 28 AGC1 29 AGC0 30 XTAL1 31 XTAL2 32 U1 MAX7030 X1 17.63417MHz C10100P C11100P C22104 3V R96K8 L2 22NH C2 220P C1 680P C18 10P C7 104 C4220P C12100P L3 22NH 3V L4 22NH C176P8 ANT1ANTENNA L1 22nH C13100P C14100P L618NH C6 220P 3V C19152 C8104C9104 R10100KR11100K C5220P C20470P C3 220P C15103 3V L8 68NH C256P8 3V L9100H C23103 Q2 520 R1822K C3210P R1610R C30100P TX-DATA L12 27nH 1234 W1CON4 1234 W2CON4 1.5V TXENRXEN TX-DATA GND 3V RX-DATA MOT TXEN 3V GND IN OUT GND FL110.7MHZ G G2 1 MOT1 MOT MOT RX-DATA L5 22NH PCB LONG LINE 2mm C16 15P C2147UF 3V R1 10UH CA1P5

Compliance Certification Services Inc. Report No.: 60329204-RP1 FCC ID: H5OTR17 Date of Issue: April 19, 2006 Page 1 of 27 FCC ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS For INTENTIONAL RADIATOR of Car Alarm Transceiver FCC ID Number : H5OTR17 Trade Name : Advance Security Inc. Model Number : AX722 Agency Series : N/A Report Number : 60329204-RP1 Date : April 19, 2006 Issued to Advance Security Inc. 3F, 48 Ta An Street, Hsi Chih, Taipei Hsien, TAIWAN R.O.C. Issued by Compliance Certification Services Inc. Hsintien Lab. No. 165, Chunghsen Road, Hsintien City Taipei Hsien, Taiwan TEL: (02) 2217-0894 FAX: (02) 2217-1029 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. Ltd. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Rev. 00 Compliance Certification Services Inc. Report No.: 60329204-RP1 FCC ID: H5OTR17 Date of Issue: April 19, 2006 Page 2 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE................................................................3 2. PRODUCT DESCRIPTION.................................................................................4 3. TEST FACILITY....................................................................................................4 4. MEASUREMENT STANDARDS........................................................................4 5. TEST METHODLOGY.........................................................................................4 6. MEASUREMENT EQUIPMENT USED............................................................5 7. POWERLINE RFI LIMIT....................................................................................5 8. RADIATED EMISSION LIMITS........................................................................6 9. SYSTEM TEST CONFIGURATION..................................................................6 10. TEST PROCEDURE..............................................................................................8 11. EQUIPMENT MODIFICATIONS......................................................................9 12. TEST RESULT.....................................................................................................10 12.1. MAXIMUM MODULATION PERCENTAGE (M%)...............................10 12.2. THE EMISSIONS BANDWIDTH.................................................................10 APPENDIX I TEST DATA........................................................................................11 Rev. 00 Compliance Certification Services Inc. Report No.: 60329204-RP1 FCC ID: H5OTR17 Date of Issue: April 19, 2006 Page 3 1. VERIFICATION OF COMPLIANCE COMPANY NAME : Advance Security Inc. 3F, 48 Ta An Street, Hsi Chih, Taipei Hsien, TAIWAN R.O.C. CONTACT PERSON : Michael Chen / President TELEPHONE NO. : 886-2-8648-1688 EUT DESCRIPTION : Car Alarm Transceiver MODEL NAME/NUMBER : AX722 FCC ID : H5OTR17 DATE TESTED : April 03, 2006 ~ April 14, 2006 REPORT NUMBER : 60329204-RP1 TYPE OF EQUIPMENT SECURITY EQUIPMENT (INTENTIONAL RADIATOR) EQUIPMENT TYPE 433.92 MHz Car Alarm Transceiver MEASUREMENT PROCEDURE ANSI 63.4 / 2003 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 The above equipment was tested by Compliance Certification Services Inc. for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Warning: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services Inc. will constitute fraud and shall nullify the document. Approved by: Reviewed by: Rev. 00 Compliance Certification Services Inc. Report No.: 60329204-RP1 FCC ID: H5OTR17 Date of Issue: April 19, 2006 Page 4 2. PRODUCT DESCRIPTION Fundamental Frequency 433.92 MHz Power Source 1.5VDC Battery Transmitting Time Periodic < 5 seconds Associated Receiver FCC ID: H5OTR16 3. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at No. 165, Chunghsen Road, Hsintien City, Taipei Hsien, Taiwan, R.O.C. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 4. MEASUREMENT STANDARDS The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/2003. 5. TEST METHODOLOGY For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) Rev. 00 Compliance Certification Services Inc. Report No.: 60329204-RP1 FCC ID: H5OTR17 Date of Issue: April 19, 2006 Page 5 6. MEASUREMENT EQUIPMENT USED Open Area Test Site # E Name of Equipment ManufacturerModel Serial Number Calibration Due SITE NSA CCS E Site N/A 10/07/2006 EMI TEST RECEIVER R&S DSAI-D / ESBI-RF 827832/001 82706/003 03/13/2007 ANTENNA SCHAFFNER CBL 6112B 2802 09/24/2006 AMPLIFIER MCL ZKL-1R5 D100704 12/15/2006 CABLE SUHNER RG 214 N-TYPE#E4 11/16/2006 THERMO- HYGRO METER TFA N/A NO.6 11/02/2006 ATTENUATOR Midwest MicrowaveMOD 219 AT10-2 12/15/2006 EMC ANALYZER (100Hz-22GHz) HP 8566B 2937A06102 06/30/2006 ANTENNA (1-18GHz) EMCO 3115 00022256 01/12/2007 AMPLIFIER (1-18GHz) HP 8449B 3008A01266 02/06/2007 CABLE (1-18GHz) JYEBAO LL142 SMA#RS1 02/06/2007 CABLE (1-18GHz) HUBER +SUHNER SUCOFLEX 104SMA#RS3 02/06/2007 CABLE …
