TRANSMITTER OPERATION Transmitter Bu tton System Function Remark Lock Doors & Arm System Panic function Press and Hold for 3 seconds Car Locator Under armed mode - Arm and Delete The 2 Stage Shock Sensor Press twice within 3 seconds - Arm System and Hidden Alarm Fun ction Press within 3 seconds and Hold button for 2 seconds + Sil ent Arming / Disarming Ignition in "off" position. + Act ive Anti Car-Jacking Mode Ignition in "on" position press and hold for 2 seconds Unlock Doors & Disarm System - Two Steps Door Unlock & Disarm System Press twice within 3 seconds. Trunk Release (Channel 3) Press and Hold for 2 seconds - Pas sive Arming By-pass While the system Disarmed. Act ivate or Turn Off The Remote Start Press button once. + Cha nnel # 4 Timer Output ( 4 ) Optional + Swi tching code For 2nd Car Operation. For regular SL-91 remote transmitter Only ACTIVE LOCKING – LOCK & ARMING: 1. Press button on transmitter. 2. The siren or horn will chirp once and the parking lights will flash once indicating that the system is now armed. The vehicle doors will lock upon arming when interfaced with the security system. Note: Defective sensor reminder: If the siren or horn sounds 3 chirps, then you have left a door, trunk, or hood lid ajar. (OPTIONAL) SILENT LOCKING AND UNLOCKING: ARMING / DISARMING: Press the + button together on the transmitter to LOCK or UNLOCK your security system, No chirp sound will be heard; arm / disarm confirmation will be through the vehicles parking lights only. SHOCK SENSOR / OPTIONAL SENSOR BY-PASS: Pressing the button on the transmitter twice within 3 seconds will arm the security system and by-pass the shock sensor. The system will chirp one additional time to confirm the sensor bypass mode was activated. The sensor bypass feature is programmed to activate for one arming cycle only. The security system will return to normal operation during the next arming cycle PASSIVE LOCKING OR ARMING: Programmable Active arming / disarming is controlling your security system via the remote transmitter. This security system is equipped with an optional Passive Arming feature, which allows the security system to arm 30 seconds after the last door is closed. Operation is as follows. 1. Turn the ignition to the “OFF” position and exit the vehicle. 2. After all entrances are closed, the security system LED will flash fast for 30 seconds. If you reopen any door / hood / trunk, the security system LED will stop flashing. It will begin flashing again once all vehicleentrances are closed. 3. After 30-second timer has elapsed, the security system will automatically “ARM”. The siren or horn will chirp [1] time and the parking lights will flash [1] time. PASSIVE DOOR LOCKING: Programmable The vehicle doors will automatically lock after passive arming cycle has been completed. PASSIVE ARMING BY-PASS: While the system is disarmed, Press the button twice, the system will respond with [1] chirp and LED will turn “ON”. The security system will remain in this temporary state for as long as you wish. To exit passive by-pass, press the transmitter or buttons and the system will return to normal status. ACTIVE UN-LOCKING – UNLOCK & DISARM: 1. Press the button on the transmitter. 2. The siren or horn will chirp twice and parking lights will flash twice to indicate that the security system is now disarmed. The vehicle doors will unlock when interfaced with the security system. IGNITION CONTROL DOOR LOCKS. If the vehicle’s door locks have been interfaced to the security system, the system will automatically lock the vehicle's doors when the ignition is turned “ON” and /or unlock the vehicle’s doors when the ignition is turned “OFF”. TRUNK RELEASE: Press and hold button on transmitter for three seconds to remote control the trunk release or other electric devices. CAR LOCATOR: Press the button on the transmitter when the vehicle is in the armed / locked mode to active car locator function. The siren or horn will chirp 6 times. The parking light will flash 12 times, allowing you to easily locate your car. VALET MODE: (System is in Disarm Mode) The valet switch allows you to temporarily bypass all alarm function, eliminating the need to hand your transmitter to parking attendants or garage mechanics. When the system is in valet mode, all alarm functions and remote start functions are bypassed, however, the remote panic feature and remote door locks will remain operational. To use the valet mode, the system must first be disarmed either by using your remote transmitter, or by operating the Manual Override sequence. Get into/out valet mode using the ignition key. Enter Valet Mode: a). Under disarm mode, turn the ignition to “ ON\OFF\ON ” position. b). Press and hold valet switch for 3 seconds until the LED turns ON solid. The LED will remain on as long as the system is in 'valet mode'. Exit Valet Mode: a). Turn ignition 'ON\OFF\ON' . b). Push and hold valet switch for 3 seconds, The LED will turn off indicate the system are exiting the valet mode. Model SL-IVU-FM915 Lock icon will be displayed when the door locked. Unlock icon will be displayed when the door unlock Valet Mode Remote start and alarm functions shall be temporarily on hold. Hidden Alarm Mode The security system arm with hidden alarm function Hood Trigger Hood is illegally opened (Zone 1) Trunk Trigger Trunk is illegally opened (Zone 2) Door Open Warning Doors are illegally opened (Zone 3) Sensor Trigger Trigger on Sensor 1 (Zone 4) Ignition Trigger Ignition switch is illegally turned on (Zone 5) Sys tem trigger Remote Transmission You are transmitting the signal to control unit In – Range Indicator You are within the remote control range. Anti C ar - Jack Mode Activate the anti car-jacking mode Door Ajar Engine Cranking Your vehicle engine Cranking by remote control Engine Running Your vehicle's engine is running Timer Control Start Engine start automatically every 2 or 3 hours. Dail y Start Engine start automatically at the same time next day PAS…

Text truncated - open the document above for the full version.

RF_160, Issue 02 ADVANCE SECURITY INC. 3F, 48 Ta An Street, Hsi Chih, Phone : (886-2) 8648-1688 E-mail : [email protected] Taipei Hsien, TAIWAN R.O.C. Telexfax : (886-2) 8648-1689 Declaration of Authorization We Name: Advance Security Inc Address: 3F, 48, Ta An Street, Hsi Chih City: Taipei Country: Taiwan Declare that: Name Representative of agent: Lynn Kao(1) Agent Company name: Worldwide Testing Services (Taiwan) Co., Ltd. Address: 6F., No. 58, Lane 188, Ruey Kuang Road, Neihu District, City: Taipei 114, Country Taiwan is authorized to apply for FCC Certification of the following product(s): Product description: Remote Control Type designation: SL-IVU-FM915 Trademark: ./. on our behalf. Date: 2014-08-28 City: Taipei Name: Ted Lin Function: VICE PRESIDENT MARKETING & SALES Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 10-Aug-09 RF_501, Issue 5 Page 1 of 1 ADVANCE SECURITY INC. 3F, 48 Ta An Street, Hsi Chih, Phone : (886-2) 8648-1688 E-mail : [email protected] Taipei Hsien, TAIWAN R.O.C. Telexfax : (886-2) 8648-1689 To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: H5OTR62 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2014-08-28 Name and signature of applicant: Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

ADVANCE SECURITY INC. 3F, 48 Ta An Street, Hsi Chih, Phone : (886-2) 8648-1688 E-mail : [email protected] Taipei Hsien, TAIWAN R.O.C. Telexfax : (886-2) 8648-1689 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Applicant’s declaration concerning RF Radiation Exposure We hereby indicate that the product Product description: Remote Control Model No: SL-IVU-FM915 The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. The integral antennas used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within the host device. A safety statement concerning minimum separation distances from enclosure of the Product : Remote Control will be integrated in the user’s manual to provide end-users with transmitter operating conditions for satisfying RF exposure compliance. The appropriate information can be drawn from the test report no: W6D21406-14275-C-1 and the accompanying calculations. Company: Advance Security Inc Address: 3F, 48, Ta An Street, Hsi Chih Taipei Taiwan Date: 2014-08-28 Signature RESULT: Test standard : FCC KDB Publication 447498 10 D01v05 According to KDB447498 10 D01v05: SAR evaluation, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. The enclosure of the device provides ≥ 0.5 cm separation from the antenna elements to significant metal parts of the enclosure to minimize potential perturbations. Frequency Band:908.300 - 923.783 MHz Maximum Power fed to Antenna: 0.5358 mW Separation distances: Antenna feed center to metal parts of enclosure: > 5 mm Distance prescribed in user manual: > 5 mm MHz 5 10 15 20 25 mm 900 16 32 47 63 79 SAR Test Exclusion Threshold (mW) MHz 30 35 40 45 50 mm 900 95 111 126 142 158 SAR Test Exclusion Threshold (mW) MHz 50 60 70 80 90 100110120130140150160 170 180 190mm 900 158 218 278 338 398 458518578638698758818 878 938 998 mW

Registration number: W6D21406-14275-FCC FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 2 of 13 External Photos Registration number: W6D21406-14275-FCC FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 3 of 13 Registration number: W6D21406-14275-FCC FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 4 of 13 Registration number: W6D21406-14275-FCC FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 5 of 13 Registration number: W6D21406-14275-FCC FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 6 of 13 Registration number: W6D21406-14275-FCC FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 7 of 13

Registration number: W6D21406-14275-FCC FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 8 of 13 Internal Photos Registration number: W6D21406-14275-FCC FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 9 of 13 Registration number: W6D21406-14275-FCC FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 10 of 13

of Applicant: Advance Security Inc Address: 3F, 48, Ta An Street, Hsi Chih Taipei Taiwan Tested and Prepared by Worldwide Testing Services (Taiwan) Co., Ltd. FCC Registration No.: 930600 Industry Canada filed test laboratory Reg. No. IC 5679A-1 A2LA Accredited No.: 2732.01 Report No.: W6D21406-14275-C-1 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E-mail: [email protected] FCC PART 15 SUBPART C TEST REPORT for Remote Control Model No.: SL-IVU-FM915 FCC ID: H5OTR62 Registration number: W6D21406-14275-C-1 FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Page 1 of 38 TABLE OF CONTENTS 1 GENERAL INFORMATION ......................................................................................................2 1.1 Notes.....................................................................................................................................2 1.2 Testing laboratory ................................................................................................................3 1.2.1 Location........................................................................................................................3 1.2.2 Details of accreditation status......................................................................................3 1.3 Details of approval holder ....................................................................................................4 1.4 Application details................................................................................................................4 1.5 General information of Test item .........................................................................................4 1.6 Test standards .......................................................................................................................5 2 TECHNICAL TEST.....................................................................................................................6 2.1 Summary of test results ........................................................................................................6 2.2 Test environment ..................................................................................................................6 2.3 Test Equipment List .............................................................................................................7 2.4 General Test Procedure ........................................................................................................9 3 TEST RESULTS (ENCLOSURE).............................................................................................11 3.1 Peak Output Power (transmitter)........................................................................................12 3.2 RF Exposure Compliance Requirements ...........................................................................16 3.3 Out of Band Radiated Emissions .......................................................................................16 3.4 Transmitter Radiated Emissions in restricted Bands..........................................................17 3.5 Spurious emissions (tx) ......................................................................................................18 3.6 Carrier Frequency Separation.............................................................................................22 3.7 Number of Hopping Frequencies .......................................................................................25 3.7.1 Pseudorandom Frequency Hopping Sequence .......................................................26 3.7.2 Coordination of hopping sequences to other transmitters .........................................26 3.7.3 System Receiver Hopping Capability .........................................................................26 3.7.4 Equal Hopping Frequency Use ................................................................................26 3.8 Time of Occupancy (Dwell Time) .....................................................................................27 3.9 20dB Bandwidth.................................................................................................................31 3.10 Band-edge Compliance of RF Emissions...........................................................................34 3.11 Power Line Conducted Emission .......................................................................................37 Registration number: W6D21406-14275-C-1 FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Page 2 of 38 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the Worldwide Testing Services(Taiwan) Co., Ltd. Tester: September 16, 2014 Kent Lin Date WTS-Lab. Name Signature Technical responsibility for area of testing: September 16, 2014 Kevin Wang Date WTS Name Signature Registration number: W6D21406-14275-C-1 FCC ID: H5OTR62 Worldwide Testing Services(Taiwan) Co., Ltd. Page 3 of 38 1.2 Testing laboratory 1.2.1 Location OATS…
