FCC ID: HAP8835T9 Model No: 8835 CIRCUIT DESCRIPTION In transmit push IC input pin F,B,L and R key ,Output of IC pin 8 drives Q2,output of Q2 drives the transformer L3,Which modulates the crystal 49.860Mhz controlled oscillator Q1. This oscillator is the transmitter. The antenna is transformer coupled to the oscillator. In receive L1 turning 49.860Mhz frequency And Q1 are RF amplifier and detector stages. IC control receiver signal to output pin F,B,L and R. Q10 ,Q11 and Q2,Q3 to driver Q12,Q13,Q14,Q15 and Q4,Q5,Q6,Q7 become driving the motor. ANTENNA AND GROUND CIRCUITRY This unit makes use of an external flexible 38 centimeters long antenna. The antenna is inductively coupled. The unit relies on the ground tract of the printed circuit board. No external ground is provided. Energy is supplied by a 9-volt battery.

F F C C C C - - T T E E S S T T R R E E P P O O R R T T REPORT NO.: 24584A/0/400F FCC – Test Report No. 24584A/0/400F Date: 2000-11-24 Page 2 of 11 FCC listed testlab acc. to Section 2.948 of the FCC - Rules in compliance with the requirements of ANSI C63.4 - 1992 Product: Test Track -- 49 MHz Transmitter Model: 8835 (49MHz) Applicant: ECHO TOYS LTD Manufacturer : ECHO TOYS LTD FCC – Test Report No. 24584A/0/400F Date: 2000-11-24 Page 3 of 11 TABLE OF CONTENTS 1. Cover sheet 2. Introduction 3. Table of Contents 4. Laboratory Report 5. Summary of Testresults 6. Test Equipment List 7. Radiated Emission Testprocedure 8. Interference Radiation (Datasheet) 9. Notes for Radiation Measurement (acc. to ANSI C63.4 - 1992) 10. Measurement of Emissions within Band Edges (Datasheet) 11. Notes for Measurement of Emissions within Band Edges FCC – Test Report No. 24584A/0/400F Date: 2000-11-24 Page 4 of 11 LABORATORY - REPORT APPLICANT: ADDRESS: ECHO TOYS LTD 8 A&B, Block 1, Tai Ping Industrial Centre 57 Ting Kok Road Taipo, NT HONG KONG DATE OF SAMPLE RECEIVED: 2000-11-02 DATE OF TESTING: 2000-11-24 DESCRIPTION OF SAMPLE: Product:Test Track -- 49 MHz Transmitter Manufacturer:ECHO TOYS LTD Model number:8835 (49MHz) Rating:DC 9V ('6F22' Size Battery x 1) for TX Country of Origin:P.R. CHINA INVESTIGATIONS REQUESTED: Measurements to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart C - Intentional Radiators RESULTS: See the attached test sheets CONCLUSIONS From the measurement data obtained, the tested sample was considered to have COMPLIED with the requirements for the relevant clauses of Federal Communications Commission Rules as specified above. _____________________________ Authorized Signature Remark : Purpose of those tests in this report is to provide the applicant with the necessary test data of their device for the submission to FCC with application for Equipment Authorization under the FCC Equipment Authorization Program. The tests themselves are not Approval Tests FCC – Test Report No. 24584A/0/400F Date: 2000-11-24 Page 5 of 11 Summary of Test Results Interference Radiation: Test result: O.K. Test data: See attached data sheet Interference Voltage: Test result: N.A. Test data: N.A. Measurement of Emissions within Band Edges Test result: O.K. Test data: See attached data sheet PHOTOGRAPH OF THE SAMPLE FCC – Test Report No. 24584A/0/400F Date: 2000-11-24 Page 6 of 11 TEST EQUIPMENT LIST EquipmentManufacturerModelSerial No.Remark Test ReceiverRohde & Schwarz ESH 3863497/01510KHz – 30MHz Test ReceiverRohde & Schwarz ESVP860688/02225MHz – 1,300 MHz Artificial Mains Network (LISN) SchwarzbeckNSLK 8127-- 2 x 10A, 50 Ω , 50 μ H 10KHz-30MHz Antenna SystemSchwarzbeckBBA 9106 / UHALP 9107 --30MHz – 1000MHz Antenna Mast System SchwarzbeckAM9104--Max. 4 meters height Spectrum Analyzer with Q. Peak Tektronix2712B0230069KHz – 1.8GHz Interface for Spectrum 2712 TektronixTD3F14A-- Test ReceiverRohde & Schwarz ESH 3892580/00610KHz – 30MHz Test ReceiverRohde & Schwarz ESVP863512/01225MHz – 1,300 MHz Impulse LimiterRohde & Schwarz ESH-3-Z2-- Artificial Mains Network (LISN) SchwarzbeckNSLK 8127-- 2 x 10A, 50 Ω , 50 μ H 10KHz-30MHz Antenna SystemSchwarzbeckBBA 9106 / UHALP 9107 --30MHz – 1000MHz Signal GeneratorRohde & Schwarz SWS 2879113/42100KHz – 1040 MHz Digital MultimeterTektronixDM2510GDM- 2510GTW10555 10KHz – 30MHz Turntable with Controller DrehtischDT312-- φ 120 cm FCC – Test Report No. 24584A/0/400F Date: 2000-11-24 Page 7 of 11 Radiated Emission Test Procedure Equipment under test (on turntable) Test receiver ESVP R & S Required test distance: 3m Antenna system Schwarzbeck BBA 9106/ UHALP 9107 91Interference Radiation Measurement of Radiated Emissions (30MHz-1000MHz) Acc:FCC Part 15 Subpart C IECC Ref:24584/0/400FTest Equipment Model:8835 (49MHz)Receiver: ESVP Rohde & Schwarz Applicant:ECHO TOYS LTDAntenna: Schwarzbeck BBA 9106 and UHALP 9107 Ser.Nr.:1 Set under test:Test Track Connected sets: - Operating mode:Power "On" Frequency (MHz) Horz. Reading dB(μV) Vert. Reading dB(μV) Antenna Factor (dB) Horiz. Test Result (μV/m) Vert. Test Result (μV/m) Limit (μV/m) Peak49.86475211.7 8651538 100,000 Av.49.8645.550.511.7728129410000 Harm.299.72232310.34646150 Harm.3149.58191615.05036150 Harm.4199.44<16<1616.5<42<42150 Harm.5249.3<16<1617.7<49<49200 Harm.6299.16<16<1620.0<63<63200 Harm.7349.02<16<1617.4<47<47200 Harm.8398.88<16<1618.3<52<52200 Harm.9448.74<16<1619.0<56<56200 Harm.10498.6<16<1619.7<61<61200 Harm.11548.46<16<1620.2<64<64200 Harm.12598.32<16<1620.9<70<70200 Harm.13648.18<16<1621.6<76<76200 Harm.14698.04<16<1622.4<83<83200 Harm.15747.9<16<1623.0<90<90200 Harm.16797.76<16<1623.7<96<96200 Harm.17847.62<16<1624.3<104<104200 Harm.18897.48<16<1625.0<112<112200 Harm.19947.34<16<1625.7<122<122200 0 20 40 60 80 100 120 101001000 MHz dBμV/m Data (Horz.)Data (Vert.)Limit FCC – Test Report No. 24584A/0/400F Date: 2000-11-24 Page 9 of 11 Notes for Radiation Measurement 1. Measurement facility: Measurement facility located at Fanling (Hong Kong), placed on file with the FCC Pursuant to Section 2.948 of the FCC Rules. 2. Distance between the EUT and measuring antenna: 3 meters. 3. Measuring instrumentations: Rohde & Schwarz ESVP Test Receiver ( 20 - 1300 MHz ) with a CISPR weighting QP detector, 6 dB bandwidth set at 120 KHz. In the frequency range above 1000 MHz Spectrum Analyzer FMSM26 and Analyzer Display Unit FSA- D are used, bandwidth set at 100 kHz. 4. Measuring antenna: Broad-band antenna for the frequency range 30 - 300 MHz and frequency range 300 - 1000 MHz, connected with 10 meters coaxial cable. Cable loss of the coaxial cable included in the Antenna Factor for measurement data. The antennas are capable of measuring both horizontal and vertical polarizations. In the frequnecy range above 1 GHz horn-antenna RGA 50/60 is used. 5. Frequency range scanned: The frequency range 30 - 5000 MHz has been scanned. Readings of the highest emissions relating to the limit were reported as above. 6.…
