HBW1595Smart Video Intercom - L

114-5928-000 © 2023, The Chamberlain Group, LLC All Rights Reserved INSTALLATION MANUAL ADDENDUM CAPXLV2 - SMART VIDEO INTERCOM-L Here is a list of changes that supersede the information provided in the installation manual. • We recommend connecting no more than 4 OSDP readers to the OSDP port for the best performance. We are working to optimize the product to support up to 8 OSDP readers in a future release. • We are adding 8 diodes and 8 MOVs to protect the 8 relays on CAPXLV2. We are also adding 2 pack-in resistors in his box. • To provide extra protection to CAPXLV2, we recommend using a cover cap on the intercom lock hole. The cover cap is provided in the box. • K41-0398-000 will replace CAPXLCAM as the new camera service kit for CAPXLV2. • For UL installations, Supply Voltage 2 (POE) is 42 – 55 Vdc, 60 W max 802.3bt Type 3 four pair compatible max. • WiFi is supplemental for UL installations. • CAPXLV2 has an operating humidity range from 20% to 90% RH. 114-5928-000 © 2023, The Chamberlain Group, LLC All Rights Reserved • Access Control Unit Endurance: Level 2. This requirement supersedes the Access Control Unit Endurance: Level 4 stated in the installation manual. • FCC and ISED caution statements: ENGLISH FCC Caution： This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. ISED Caution： This product complies with ISED radiation exposure limits set forth for an uncontrolled environment. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. FRENCH Ce produit sont conformes aux limites ISED d'exposition aux rayonnements définies pour un environnement non contrôlé. Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une autre antenne ou transmetteur. SPANISH Precaución de la FCC: Este equipo cumple con los límites de exposición a la radiación de RF de la FCC establecidos para un entorno no controlado. Este dispositivo y su(s) antena(s) no deben estar ubicados ni funcionar junto con ninguna otra antena o transmisor. Precaución ISED: Este producto cumple con los límites de exposición a la radiación ISED establecidos para un entorno no controlado. Este dispositivo y su(s) antena(s) no deben estar ubicados ni funcionar junto con ninguna otra antena o transmisor.

myQ ® Community Smart Video Intercom L INSTALLATION MANUAL Model CAPXLV2 2 To reduce the risk of SEVERE INJURY or DEATH: • Disconnect power at the fuse box BEFORE proceeding. • To AVOID damaging gas, power or other underground utility lines, contact underground utility locating companies BEFORE digging. • ALL electrical connections MUST be made by a qualified individual. • ALL power and control wiring MUST be run in separate conduit. To protect against fire and electrocution: • Disconnect power BEFORE installing or servicing CAPXLV2. • NEVER connect a keypad/reader or lock to doors without first consulting the applicable fire code. • You MUST consult with, and get approval from, local fire officials BEFORE installing locks or devices on ANY doors that may be fire exits. • Use of egress push buttons may not be legal. Single action exits may be required. • ALWAYS obtain proper permits and approvals in writing BEFORE installing equipment. • ALWAYS ensure that the CAPXLV2 front lid is locked properly using the provided key after any servicing or maintenance of the product is complete and before operating the product. • NEVER leave any exposed wiring inside the cabinet. Safety Safety Symbol and Signal Word Review When you see these Safety Symbols and Signal Words on the following pages, they will alert you to the possibility of serious injury or death if you do not comply with the warnings that accompany them. The hazard may come from something mechanical or from electric shock. Read the warnings carefully. When you see this Signal Word on the following pages, it will alert you to the possibility of damage to your property or product if you do not comply with the cautionary statements that accompany it. Read them carefully. MECHANICAL ELECTRICAL WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer or birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. 3 ACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROLINTRODUCTION INTRODUCTION ACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROL INTRODUCTIONACCESS CONTROL ACCOUNT SETUPNETWORK/MOUNTINGPOWER INTRODUCTION ACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROL INTRODUCTIONACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROL INTRODUCTION CAPXLV2 Overview .......................................................4 Main Board Overview ....................................................5 Door of Control Board Overview....................................6 Carton Inventory ...........................................................7 Tools Needed ................................................................7 Dimensions ...................................................................8 System Specifications ...................................................8 Wire Specifications .......................................................9 PRE-INSTALL 1 Setup a myQ ® Community Account ............................10 Sign up for myQ ® Community Services ......................10 INSTALL 2 Remove Knockouts .....................................................11 Mount the CAPXLV2....................................................12 Install Antennas...........................................................13 Ground the Unit ...........................................................14 Connect Power ............................................................15 NETWORK 3 Connect Internet ..........................................................16 Validate Setup .............................................................16 ACCESS CONTROL 4 Gate Access (Wired)....................................................17 Gate Access (Wireless) ...............................................18 Door Access ................................................................19 OSDP Card Reader ......................................................20 Wiegand Card Reader..................................................21 Wiegand Output ..........................................................22 Postal Lock .................................................................23 Wiring Diagram ..........................................................24 Repair Parts ...............................................................25 Accessories ................................................................25 Configuration Sheet ....................................................26 Legal Disclaimers ......................................................27 Warranty .....................................................................28 1 SETUP 2 I NSTALL 3 CONNECT 4 ADD DEVI CES 1 SETUP 2 I NSTALL 3 CONNECT 4 ADD DEVI CES 4 ACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROLINTRODUCTION INTRODUCTION ACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROL INTRODUCTIONACCESS CONTROL ACCOUNT SETUPNETWORK/MOUNTINGPOWER INTRODUCTION ACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROL INTRODUCTIONACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROL CAPXLV2 Overview Front Panel Lock Microphone Port Speaker Port Postal Lock Location Proximity Reader Touchscreen Display Camera Window Door Control Board 1 Door Control Board 2 Postal Lock (if installed) Speaker Proximity Reader Main Board Camera Front Panel Lock Microphone 5 ACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROLINTRODUCTION INTRODUCTION ACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROL INTRODUCTIONACCESS CONTROL ACCOUNT SETUPNETWORK/MOUNTINGPOWER INTRODUCTION ACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROL INTRODUCTIONACCOUNT SETUPNETWORK/MOUNTINGPOWERACCESS CONTROL Main Board Overview INPUT/OUTPUTUSED FOR Power InConnect to external 24v power supply Ethernet/PoEConnect Ethernet Switch or Router for 10/100BaseT or PoE Injector for PoE power via RJ45 USB1Reserved for future use USB2Reserved for future use DOC 1Connect to Door of Control Board 1 DOC 2Connect to Door of Control Board 2 OSDP Connect RS-485 bus that can connect up to 8 OSDP readers in daisy…

Text truncated - open the document above for the full version.

23 Serrure postale 1. Retirez l’écrou à oreilles et le bouchon. Jetez l’écrou à oreilles et le bouchon. 2. Retirez les 4 écrous de montage des montants. 3. Installez le verrou postal à l’aide des 4 écrous de l’étape 2. 4. Coupez l’attache de fil installée en usine sur le commutateur de verrouillage postal. Le commutateur de la serrure postale est câblé en usine. REMARQUE : La longueur du câble de la serrure postale ne doit pas dépasser 98,5 pi (30 m). Serrure postale 24 ANTENNE WIFI Schéma de câblage • Nous ne sommes pas responsables des conflits entre les donnés énumérées dans le schéma de câblage et les exigences de vos codes de construction locaux. Ces données ne sont fournies qu’à titre indicatif. Vérifiez vos codes locaux AVANT l’installation. • Ne connectez PAS l’alimentation 24 V et l’alimentation POE à l’appareil en même temps. 25 Accessoires ARTICLENUMÉRO DE PIÈCE Porte de la carte de contrôle et des couverclesK41-0422-000 Kit de carte principaleK41-0366-000 Kit de plaque de montage du lecteurK41-0367-000 Kit d’assemblage du boîtier arrièreK41-0368-000 Kit de câblageK41-0369-000 Kit de haut-parleurK41-0370-000 Kit de panneau avant et d’affichageK41-0371-000 Commutateur de verrouillage postalK41-0219-000 Serrure à came et kitK41-0215-000 ARTICLENUMÉRO DE PIÈCE Kit de garniture pour montage encastréCAPXLV2TK Capot pour les applications sur socle et en surfaceCAPXLV2HOOD Plaque de garniture et capot ensembleCAPXLV2TKHD AlimentationK41-0227-000 KIT de caméra USBCAPXLCAM Rallonge d’antenne radio (15 pieds)G86LM Extension d’antenne Wi-Fi ® (15 pieds)WFAEXT Antenne d’extension Wi-Fi/Bluetooth ® WFBTEXT Antenne ESARMXMANTKIT Lecteur RFID UHF longue portéeLMSC1000 Clavier Wiegand/lecteur de proximitéKPR2000* Lecteur LiftMaster Smart et clavier avec prise en charge OSDPSRDRST ou SRDRKP Portail d’accès connecté 2 portesCAP2D Télécommande de visière à 3 boutons Passport MAXPPV3M Mini télécommande à 3 boutons Passport MAXPPK3M Mini télécommande de proximité à 3 boutons Passport MAXPPK3PHM Télécommande de visière à 1 bouton Passport LitePPLV1-X Télécommande de porte-clés à 1 bouton Passport LitePPLK1-X Mini télécommande de proximité à 1 bouton Passport LitePPLK1PH-X Pièces détachées * KPR2000 vérifié pour un usage complémentaire uniquement ** Disponible en paquets de 10 et 100, remplacez X par 10 ou 100 REMARQUE : Si vous possédez un modèle spécifique de lecteur ou de clavier qui n’est pas répertorié sur le site Web de LiftMaster, veuillez contacter le service d’assistance technique de LiftMaster pour déterminer la compatibilité. 26 Fiche de configuration Notez ci-dessous les données relatives à l’appareil et aux paramètres de configuration. Nom du CAPXLV2 : REMARQUE : Tout utilisateur du système est soumis aux conditions énoncées dans le CLUF du produit. Remarques : CONFIGURATION DE L’APPAREIL : Point d’accès 1 Nom de la porte/du portail : EntréesTypeNom de l’entréeFIN DE VIE (O/N)Mappage du matériel Première entrée surveillée Deuxième entrée surveillée Troisième entrée surveillée Quatrième entrée surveillée RelaisTypeNom du relaisN.O./N.F.N.O./N.F. Premier relais Deuxième relais LecteursTypeNom du lecteurMappage du matériel Premier lecteur Deuxième lecteur Remarques : Point d’accès 2 Nom de la porte/du portail : EntréesTypeNom de l’entréeFIN DE VIE (O/N)Mappage du matériel Première entrée surveillée Deuxième entrée surveillée Troisième entrée surveillée Quatrième entrée surveillée RelaisTypeNom du relaisN.O./N.F.N.O./N.F. Premier relais Deuxième relais LecteursTypeNom du lecteurMappage du matériel Premier lecteur Deuxième lecteur Remarques : 27 Avis de non-responsabilité Conformité avec la Commission fédérale des communications (FCC) Suite à des tests, cet équipement s’est avéré conforme aux limites d’un appareil numérique de classe B, en vertu de la section 15 du règlement de la FCC. Ces limites ont pour objet de fournir une protection raisonnable contre les interférences nuisibles dans une installation résidentielle ou lorsque l’équipement est utilisé dans un environnement commercial. Cet équipement produit, utilise et peut rayonner de l’énergie radiofréquente et, s’il n’est pas installé et utilisé conformément au manuel d’instructions, il risque de causer des interférences nuisibles aux communications radio. Toutefois, il n’est pas possible de garantir l’absence d’interférences dans une installation particulière. Si cet équipement cause des interférences nuisibles à la réception radio ou TV, ce qui peut être déterminé en l’éteignant puis en le rallumant, l’utilisateur est invité à essayer de corriger l’interférence en prenant au moins l’une des mesures suivantes : • Éloigner l’appareil de l’équipement ou du récepteur. • Brancher l’appareil sur un circuit différent de celui sur lequel le récepteur est branché. • Consulter le revendeur pour obtenir de l’aide. Conformité Canada-Underwriters Laboratories Le CAPXLV2 doit être installé conformément à la partie 1 du Code canadien de l’électricité. Avis de non-responsabilité et restrictions concernant la documentation Les données contenues dans ce document peuvent être modifiées sans préavis et ne représentent pas un engagement de la part de LiftMaster. Pour les données les plus récentes, visitez LiftMaster.com. Ce document et les données qu’il contient ne doivent pas être dupliqués, utilisés ou divulgués à d’autres pour l’approvisionnement ou la fabrication, sauf autorisation écrite de LiftMaster. L’information contenue dans ce document ou dans le produit lui-même est considérée comme la propriété exclusive de LiftMaster. Toutes les données contenues dans ce document ou dans les produits matériels et logiciels eux-mêmes sont protégées par le droit d’auteur et/ou d’autres lois sur la propriété intellectuelle des États-Unis Endurance de l’unité de contrôle d’accès UL 294 : Niveau 4, Endurance de la carte de compétence mobile niveau II en utilisant le téléphone portable Bluetooth 25 000 cycles, Sécurité de la ligne : Niveau 1, attaque destructrice…

Text truncated - open the document above for the full version.

Certification Application Attestation Statements Chamberlain Group LLC, The 300 Windsor Dr Oak Brook Illinois 60523 United States FRN: 0004301545 Subject: FCC ID: HBW1595 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) Chamberlain Group LLC, The certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) Chamberlain Group Inc, The (“the applicant”) certifies that, as of the date of the filing of this application, the applicant - is / - is not (3) identified on the Covered List as an entity producing “covered” equipment. Date: 2023-10-02 City: Oak Brook Name (2) : Thomas DeSilvia Function: Director Corporate Compliance Telephone number: 1-630-993-8618 Email address: [email protected] Signature: 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . (2): For FCC it must be the Grantee Code “owner” or the authorized agent. (3): double click on the appropriate box and select ‘’checked” then “OK”

U.S. Agent Designation for Service of Process (Applicant is Both Grantee and U.S. Agent) TO: Kiwa Nederland B.V. Wilmersdorf 50 7327 AC Apeldoorn Postbus 137 7300 AC Apeldoorn Netherlands ATTENTION: FCC Certification – Section 2.911(d)(7) Information This letter is to confirm that the Applicant will also serve as the U.S. Agent for Service of Process as required by 47 CFR 2.911(d)(7). The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The Applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information changes. Applicant & Agent Company name: Chamberlain Group LLC, The FRN: 0004301545 Grantee Code: HBW Contact person name: Thomas DeSilvia Agent name: Thomas DeSilvia Street address: 300 Windsor Dr ZIP/City/State 60523/Oak Brook/Illinois Telephone number: 1-630-993-8618 Email address: [email protected] Signature Contact person*: Date: 2023-10-02 Signature Agent*: Date: 2023-10-02 Note *Must be signed by both the applicant, and agent on behalf

DECLARATION OF AUTHORISATION Hereby, we Company Name: Chamberlain Group LLC,The Address: 300 Windsor Dr Oak Brook Illinois 60523 United States Declare that: Name of Representative of Agent: Kent Liu Agent Company name: BTL Inc. Address: 4F.,No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan is authorized to apply for Certification and signing related documents of the following product(s), including application form(s): Product Description: Smart Video Intercom-L Type Designation: CAPXLV2 Trademark: Liftmaster FCC ID: HBW1595 Signature: Date: 2023-10-02 City: Oak Brook Name: Thomas DeSilvia Function: Director Corporate Compliance Telephone: 1-630-993-8618 E-mail: [email protected]

Company Name: Chamberlain Group LLC, The Address: 300 Windsor Dr, Oak Brook, City: Illinois 60523 Country: United States To: Kiwa Netherlands B.V., Dept. FCC TCB Wilmersdorf 50 7327 AC Apeldoorn The Netherlands Subject: Request for confidentiality FCC ID: HBW1595 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby request non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Date: 2023-10-02 Name and signature of applicant: Thomas DeSilvia Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should state in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Kiwa NL B.V. at least 7 days before date of actual marketing or before expiration of the STC period

Wi-Fi Channel 12 and 13 Declaration Letter Date: 2023-10-02 We, the undersigned company Company Name: Chamberlain Group LLC,The Address: 300 Windsor Dr Oak Brook Illinois 60523 United States Declare that: Product description: Smart Video Intercom-L Type designation: CAPXLV2 Brand: Liftmaster FCC ID: HBW1595 Only channels 1~11 will be used in USA and Canada. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you. Sincerely, Signature: ________________________ Name: Thomas DeSilvia Tel: 1-630-993-8618 Email: [email protected]

Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 1 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 2 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 3 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 4 of 29 External antenna Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 5 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 6 of 29 Passive antenna Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 7 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 8 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 9 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 10 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 11 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 12 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 13 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 14 of 29

Artwork: 40-37178-20-A 2.35" x 1.30" x .10" (W x H x R) Shown at 100% ECN: 52185 12 Dec 2019 40-37178-2 PART NO.DATE CHAMBERLAIN GROUP INC. OAK BROOK, IL 60523, USA FCC ID: IC: 2666A- This device complies with Part 15 of the FCC rules and Innovation, Science, and Economic Development Canada license-exempt RSSs. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (B) / NMB-3 (B) HBW1595 1595 014D1595 Artwork: 132-3278-020 Rev A 2in x 1.25in x 0.05in (W x H x R) Shown at 100% ECN: 60451 09 March 2023 132-3278-020 Model: CAPXLV2 Serial Number: CONNECT POWER INPUT TO UNSWITCHED OUTLET ONLY INDOOR/OUTDOOR USE NEC CLASS 2 COUNTRY OF ORIGIN: INDIA INSTRUCTIONS: 114-5891-000 REV May be pat: www.liftmaster.com/patents CONTAINS FCC ID: VPYLBEE5HY1MW CONTAINS IC: 772C-LBEE5HY1MW Manufacturing Date: MAC: Wi-Fi MAC: Description: CONNECTED ACCESS PORTAL LARGE Location on the inside back of the enclosure

Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 15 of 29 Built-in antenna Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 16 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 17 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 18 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 19 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 20 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 21 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 22 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 23 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 24 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 25 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 26 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 27 of 29 Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 28 of 29 Built-in antenna Appendix No.: EP-2303T057-2 APPENDIX-EUT PHOTOS Project No.: 2303T057 Page 29 of 29

Report No.: BTL-FCCP-6-2303T057 Project No.: 2303T057 Page 1 of 9 Report Version: R02 FCC RF Exposure Report FCC ID: HBW1595 Report No. : BTL-FCCP-6-2303T057 Equipment : Smart Video Intercom - L Model Name : CAPXLV2 Brand Name : Liftmaster Applicant : Chamberlain Group LLC, The Address : 300 Windsor Dr, Oak Brook, Illinois, United States, 60523 Standard(s) : 47 CFR § 2.1091 FCC Guidelines for Human Exposure IEEE C95.1 Date of Receipt : 2023/3/20 Date of Test : 2023/6/15 ~ 2023/8/24 Issued Date : 2023/9/28 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Eddie Lee, Engineer Approved by : Jerry Chuang, Supervisor BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-6-2303T057 Project No.: 2303T057 Page 2 of 9 Report Version: R02 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-6-2303T057 Project No.: 2303T057 Page 3 of 9 Report Version: R02 REVISION HISTORY Report No. Version Description Issued Date Note BTL-FCCP-6-2303T057 R00 Original Report. 2023/9/13 Invalid BTL-FCCP-6-2303T057 R01 Revised report to address TCB’s comments. 2023/9/19 Invalid BTL-FCCP-6-2303T057 R02 Revised report to address TCB’s comments. 2023/9/28 Valid Report No.: BTL-FCCP-6-2303T057 Project No.: 2303T057 Page 4 of 9 Report Version: R02 1. LIMITS According to § 1.1310 Radiofrequency radiation exposure limits. (a) Specific absorption rate (SAR) shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in § 1.1307(b) of this part within the frequency range of 100 kHz to 6 GHz (inclusive). (b) The SAR limits for occupational/controlled exposure are 0.4 W/kg, as averaged over the whole body, and a peak spatial-average SAR of 8 W/kg, averaged over any 1 gram of tissue (defined as a tissue volume in the shape of a cube). Exceptions are the parts of the human body treated as extremities, such as hands, wrists, feet, ankles, and pinnae, where the peak spatial-average SAR limit for occupational/controlled exposure is 20 W/kg, averaged over any 10 grams of tissue (defined as a tissue volume in the shape of a cube). Exposure may be averaged over a time period not to exceed 6 minutes to determine compliance with occupational/controlled SAR limits. (c) The SAR limits for general population/uncontrolled exposure are 0.08 W/kg, as averaged over the whole body, and a peak spatial-average SAR of 1.6 W/kg, averaged over any 1 gram of tissue (defined as a tissue volume in the shape of a cube). Exceptions are the parts of the human body treated as extremities, such as hands, wrists, feet, ankles, and pinnae, where the peak spatial-average SAR limit is 4 W/kg, averaged over any 10 grams of tissue (defined as a tissue volume in the shape of a cube). Exposure may be averaged over a time period not to exceed 30 minutes to determine compliance with general population/uncontrolled SAR limits. (e) Limits for Maximum Permissible Exposure (MPE) to radiofrequency electromagnetic fields (Table 1). Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (i) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 *(100) ≤6 3.0-30 1842/f 4.89/f *(900/f 2 ) <6 30-300 61.4 0.163 1.0 <6 300-1.500 f/300 <6 1.500-100.000 5 <6 (ii) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) <30 1.34-30 824/f 2.19/f *(180/f 2 ) <30 30-300 27.5 0.073 0.2 <30 300-1.500 f/1500 <30 1.500-100.000 1.0 <30 f = frequency in MHz. * = Plane-wave equivalent power density. Report No.: BTL-FCCP-6-2303T057 Project No.: 2303T057 Page 5 of 9 Report Version: R02 2. APPLIED EXEMPTION CRITERIA Refer to KDB 447498 D04, ticked it…
