HBW7359Remote Control Transmitter

Single Button Remote ControlModel 950ESTD 3-Button Remote ControlModel 953ESTD TO ERASE ALL CODES FROM MEMORY REMOTE CONTROLS MODELS 950ESTD & 953ESTD To prevent possible SERIOUS INJURY or DEATH from a moving gate or garage door:• ALWAYS keep remote controls out of reach of children. NEVER permit children to operate, or play with remote controls. • Activate gate or door ONLY when it can be seen clearly, is properly adjusted, and there are no obstructions to door travel. • ALWAYS keep gate or garage door in sight until completely closed. NEVER permit anyone to cross path of moving gate or door. Press and hold the button on the remote control that you wish to use. “click” “click” Release the button when the garage door opener lights blink or two clicks are heard. If programming toother products, press the button asecond time to activate the product. Locate the Learn button. Press and immediately release the Learn button. The Learn LED will glow steadily for 30 seconds. Within 30 seconds... For use with MyQ™ Garage Door Openers. The code between the remote control and the receiver changes with each use, randomly accessing over a billion new codes. Refer to your product manual for the location of the learn button.NOTE: Your product may look different than the products illustrated in this manual. When deactivating any unwanted remote control code, all previous codes will be erased. Press and hold the Learn button on garage door opener or other product until the learn LED goes out (approximately 6 seconds). All previous codes are now erased. Reprogram each remote control you wish to use. ® LED LED PROGRAM USING THE GARAGE DOOR OPENER PROGRAM USING THE DOOR CONTROL Press the LEARN button again, the LED will flash once. Press the LEARN button on the door control to enterProgramming Mode. The command LED will flash once. The command LED will flash once again. Press and hold the button on the remote control that you wish to use. Release the button when the garage door opener lights blink or two clicks are heard. If programming to other products, press the button a second time to activate the product. “click” “click” REPLACEMENT PARTS3V2032 Lithium battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10A20 Visor Clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29B137 ONE YEAR LIMITED WARRANTYThe Chamberlain Group, Inc. warrants to the first consumer purchaser of this product that it is free from defect in materials and/or workmanship for a period of 1 year from the date of purchase.3-BUTTON REMOTE CONTROLS Press and hold the button down until the door or gate starts to move. The remote control will operate from up to 3 car lengths away on typical installations. Installations and conditions vary, contact an installing dealer for more information. HOW TO USE THE REMOTE CONTROL Additional buttons on the remote control can be programmed to operate up to 3 devices such as additional garage door openers, light controls, gate operators or access control systems. NOTICE: To comply with FCC and or Industry Canada rules (IC), adjustment or modifications of this receiver and/or transmitter are prohibited, except for changing the code setting or replacing the battery. THERE ARE NO OTHER USER SERVICEABLE PARTS.Tested to Comply with FCC Standards FOR HOME OR OFFICE USE. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 3V2032 Pry open the case first in the middle (1), then at each side (2 and 3) with the visor clip. Remove the old battery. Dispose of old batteries properly. Insert replacement batteries positive side up. Replace the batteries with only 3V2032 coin cell batteries. Replace cover. THE REMOTE CONTROL BATTERYThe lithium battery should produce power for up to 5 years. If the battery is low, the remote control's LED will not flash when the button is pressed. To replace battery: To prevent possible SERIOUS INJURY or DEATH:• NEVER allow small children near batteries.• If battery is swallowed, immediately notify doctor.To reduce risk of fire, explosion or chemical burn:• Replace ONLY with 3V2032 coin batteries.• DO NOT recharge, disassemble, heat above 212° F (100° C) or incinerate. 1 2 3 TO CONTROL THE GARAGE DOOR OPENER LIGHTS With the door closed, press and hold the remote control button that you want to control the light. Press and hold the LIGHT button on the door control. + Press and hold the LOCK button on the door control. After the garage door opener lights flash,release all buttons. + “click” “click” This feature is only available on garage door openers equipped with a multi-function door control and a remote control with mor e than one button. Not available with external receiver. A remote control button can be programmed to operate the garage door opener lights without opening the door. Test by pressing the remote control button. The garage door opener lights should turn on or off but the door should not move. CÓMO BORRAR TODOS LOS CÓDIGOS DE LA MEMORIA CONTROLES REMOTOS MODELOS 950ESTD Y 953ESTD Para evitar la posibilidad de LESIONES GRAVES o incluso la MUERTE debido al movimiento de un portón o puerta de garaje: • Mantenga SIEMPRE los controles remotos fuera del alcance de los niños. NUNCA permita que los niños utilicen o jueguen con los controles remotos. • Active el portón o la puerta SÓLO cuando se pueda ver claramente, cuando esté ajustada adecuadamente y cuando no haya obstrucciones en su recorrido. • Mantenga SIEMPRE a la vista el portón o la puerta del garaje hasta que cierre completamente. NUNCA permita que alguien cruce el camino de un portón o una puerta en movimiento. PRECAUCIÓN ADVERTENCIA ADVERTENCIA ADVERTENCIAADVERTENCIA ADVERTENCIA Oprima de nuevo el botón “LEARN”…

Text truncated - open the document above for the full version.

845 Larch Ave. Elmhurst, IL 60126 Phone 630.993.6306 Fax 630.516.6863 Email: [email protected] April 18, 2011 Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 c.c. Underwriters Laboratories Inc. 333 Pfingsten Road Norhtbrook, IL 60062 To whom it may concern: I, the undersigned, hereby authorize Bart Mucha of Underwriters Laboratories Inc to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Bart Mucha of UL on our behalf, shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Yours sincerely, Barbara Kelkhoff Regulatory Project Manager II Chamberlain Group, Inc. 845 Larch Ave. Elmhurst, IL. 60126

FCC ID: HBW7359

ASSEMBLED IN MEXICO MODEL FCC ID: IC: 2666A- DATE CHAMBERLAIN GROUP INC. ELMHURST, IL 60126, USA 132C2708-2B PATENT # 7,071,850 7,561,075 Artwork: 132LA2708-20-B 1" x 1" x .063" (W x H x R) Shown at 100% ECN: 05762 12 May 2011

FCC ID: HBW7359

FCC ID: HBW7359

Underwriters Laboratories Inc. A not-for-profit organization dedicated 333 Pfingsten Rd. to public safety and committed to Northbrook, IL 60062 quality service for over 100 years Tel: (847) 272-8800 Underwriters Laboratories Inc. 333 Pfingsten Rd. Northbrook, IL 60062 www.ul.com/emc (847) 272-8800 Job Number: 1001332966 Project Number: 11CA02898 Rev.1 File Number: MC3181 Date: February 4, 2011 Model: 1D7359-2 Electromagnetic Compatibility Test Report For Chamberlain Group Inc. Copyright  2010 Underwriters Laboratories Inc. Underwriters Laboratories Inc. authorizes the above-named company to reproduce this Report provided it is reproduced in its entirety. Job #:1001332966 Project #: 11CA02898 Rev.1 File #: MC3181 Page 2 of 37 Model Number: 1D7359-2 Client Name: Chamberlain Group Inc. Underwriters Laboratories Inc. 333 Pfingsten Rd. Northbrook, IL 60062 USA Tel.: 847 272-8800 Rev. No 1.0 EMC Report 2010-87-EM-F0042 Test Report Details Tests Performed By: Underwriters Laboratories Inc. 333 Pfingsten Rd. Northbrook, IL 60062 Tests Performed For: Chamberlain Group Inc. 845 Larch Av Elmhurst, IL 60126 Applicant Contact: Hank Sieradzki Phone: (630) 993-6564 E-mail: [email protected] Test Report Date: February 4, 2011 Product Type: Periodic Transmitter Product standards FCC Part 15, Subpart C, 15.231 & RSS-210 Model Number: 1D7359-2 EUT Category: Periodic Low Power 3 channel Transmitter Testing Start Date: January 4, 2011 Date Testing Complete: January 10, 2011 Overall Results: Compliant Underwriters Laboratories Inc. reports apply only to the specific samples tested under stated test conditions. All samples tested were in good operating condition throughout the entire test program. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. Underwriters Laboratories Inc. shall have no liability for any deductions, inferences or generalizations drawn by the client or others from Underwriters Laboratories Inc. issued reports. This report shall not be used to claim, constitute or imply product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the US government. This report may contain test results that are not covered by the NVLAP or A2LA accreditation. The scope of accreditation is limited to the specific tests that are listed on the NVLAP and/or A2LA websites referenced at the end of this report. Job #:1001332966 Project #: 11CA02898 Rev.1 File #: MC3181 Page 3 of 37 Model Number: 1D7359-2 Client Name: Chamberlain Group Inc. Underwriters Laboratories Inc. 333 Pfingsten Rd. Northbrook, IL 60062 USA Tel.: 847 272-8800 Rev. No 1.0 EMC Report 2010-87-EM-F0042 Report Directory 1.0 G E N E R A L - Product Description ..................................................................................................................4 1.1 Equipment Description ...................................................................................................................................4 1.2 Device Configuration During Test ..................................................................................................................4 1.2.1 Equipment Used During Test: ....................................................................................................................4 1.2.2 Input/Output Ports: .....................................................................................................................................4 1.2.3 EUT Internal Operating Frequencies: ........................................................................................................4 1.2.4 Power Interface: .........................................................................................................................................4 1.3 EUT Configurations ........................................................................................................................................5 1.4 EUT Operation Modes ....................................................................................................................................5 2.0 Summary ............................................................................................................................................................5 2.1 Deviations from standard test methods ..........................................................................................................5 2.2 Device Modifications Necessary for Compliance ...........................................................................................5 2.3 Reference Standards .....................................................................................................................................6 2.4 Results Summary ...........................................................................................................................................6 3.0 Calibration of Equipment Used for Measurement ..............................................................................................7 4.0 EMISSIONS TEST RESULTS ............................................................................................................................7 4.1 Test Conditions and Results – Occupied Bandwidth .....................................................................................8 4.2 Test Conditions and Results – Cease Operation ........................................................................................ 12 4.3 Test Conditions and Results – Pulse Train ................................................................................................. 16 4.4 Test Conditions and Results – RADIATED EMISSIONS Fundamental and Spurious ............................... 29 Appendix A - Accreditations and Authorizations .......................................................................................................... 35 Appendix B – Test Setup Photos ............…

Text truncated - open the document above for the full version.
