HBW7675Garage door opener w/900MHz FHSS transceiver

CONTENTS Important Safety Instructions ......... 2-3 Operation....................................4 Using the Door Control..................5 Programming-Door Control Panel ....6 Programming - Remote Controls ......7 To Erase the Memory ...................7 To Open the Door Manually ............8 Battery Backup*..........................8 Adjustment ..................................9 Program the Travel .................... 10 Test the Safety Reversal System .... 11 Test the Protector System ® .......... 11 Maintenance .............................. 12 Troubleshooting ...................... 13-14 Repair Parts .............................. 15 Warranty .................................. 16 PREMIUM Series Garage Door Opener The Chamberlain Group, Inc. 845 Larch Avenue Elmhurst, Illinois 60126-1196 ■ Please read this guide and the enclosed safety materials carefully! ■ The door WILL NOT CLOSE unless the Protector System ® is connected and properly aligned. ■ Periodic checks of the garage door opener are required to ensure safe operation. ■ This garage door opener is ONLY compatible with MyQ™ and Security✚ 2.0™ accessories. ■ DO NOT enable the Timer-to-Close feature if you are installing the garage door opener on a one-piece door. The Timer-to-Close is to be used ONLY with sectional doors. ■ Attach enclosed warning labels to the location indicated on label. www.liftmaster.com Serial Number: Date of Purchase: User’s Guide FOR RESIDENTIAL USE ONLY Write down the following information for future reference: . The images throughout this manual are for reference and your product may look different. CONTACT INFORMATION Leave this Users Guide with the homeowner. *If applicable. 2 Safety Symbol and Signal Word Review This garage door opener has been designed and tested to offer safe service provided it is installed, operated, maintained and tested in strict accordance with the instructions and warnings contained in this manual. When you see these Safety Symbols and Signal Words on the following pages, they will alert you to the possibility of serious injury or death if you do not comply with the warnings that accompany them. The hazard may come from something mechanical or from electric shock. Read the warnings carefully. Mechanical Electrical When you see this Signal Word on the following pages, it will alert you to the possibility of damage to your garage door and/or the garage door opener if you do not comply with the cautionary statements that accompany it. Read them carefully. IMPORTANT INSTALLATION INSTRUCTIONS To reduce the risk of SEVERE INJURY or DEATH: WARNING WARNING WARNING WARNING 1. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS. 2. Install garage door opener ONLY on properly balanced and lubricated garage door. An improperly balanced door may NOT reverse when required and could result in SEVERE INJURY or DEATH. 3. ALL repairs to cables, spring assemblies and other hardware MUST be made by a trained door systems technician BEFORE installing opener. 4. Disable ALL locks and remove ALL ropes connected to garage door BEFORE installing opener to avoid entanglement. 5. Install garage door opener 7 feet (2.13 m) or more above fl oor. 6. Mount the emergency release within reach, but at least 6 feet (1.83 m) above the fl oor and avoiding contact with vehicles to avoid accidental release. 7. NEVER connect garage door opener to power source until instructed to do so. 8. NEVER wear watches, rings or loose clothing while installing or servicing opener. They could be caught in garage door or opener mechanisms. 9. Install wall-mounted garage door control: • within sight of the garage door. • out of reach of children at minimum height of 5 feet (1.5 m). • away from ALL moving parts of the door. 10. Place entrapment warning label on wall next to garage door control. 11. Place manual release/safety reverse test label in plain view on inside of garage door. 12. Upon completion of installation, test safety reversal system. Door MUST reverse on contact with a 1-1/2" (3.8 cm) high object (or a 2x4 laid fl at) on the fl oor. 13. To avoid SERIOUS PERSONAL INJURY or DEATH from electrocution, disconnect ALL electric and battery power BEFORE performing ANY service or maintenance. 14. DO NOT enable the Timer-to-Close functionality if operating either one-piece or swinging garage doors. To be enabled ONLY when operating a sectional door. 15. SAVE THESE INSTRUCTIONS. Important Safety Instructions NOTE: For complete installation instructions visit www.liftmaster.com to print the entire owner’s manual. 3 IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of SEVERE INJURY or DEATH: WARNING WARNING WARNING WARNING 1. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS. 2. ALWAYS keep remote controls out of reach of children. NEVER permit children to operate or play with garage door control push buttons or remote controls. 3. ONLY activate garage door when it can be seen clearly, it is properly adjusted, and there are no obstructions to door travel. 4. ALWAYS keep garage door in sight and away from people and objects until completely closed. NO ONE SHOULD CROSS THE PATH OF THE MOVING DOOR. 5. NO ONE SHOULD GO UNDER A STOPPED, PARTIALLY OPENED DOOR. 6. If possible, use emergency release handle to disengage trolley ONLY when garage door is CLOSED. Use caution when using this release with the door open. Weak or broken springs or unbalanced door could result in an open door falling rapidly and/or unexpectedly and increasing the risk of SEVERE INJURY or DEATH. 7. NEVER use emergency release handle unless garage doorway is clear of persons and obstructions. 8. NEVER use handle to pull garage door open or closed. If rope knot becomes untied, you could fall. 9. After ANY adjustments are made, the safety reversal system MUST be tested. 10. Safety reversal system MUST be tested every month. Garage door MUST reverse on contact with 1-1/2" high (3.8 cm) object (or a 2x4 laid fl at) on the fl oor. Failure to adjust the garage door opener pro…

Text truncated - open the document above for the full version.

845 Larch Ave. Elmhurst, IL 60126 Phone 630.993.6306 Fax 630.516.6863 Email: [email protected] June 8, 2012 Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID:HBW7675 Request for Confidentiality In accordance with 47 C.F.R. Section 0.457(d) and 0.459, we, Chamberlain Group, Inc., hereby request confidentiality for the block diagram, schematic, parts list and theory of operation/technical description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. I would appreciate your prompt attention to the submittal. If there are any questions, please call me at 630-993-6306 or send a fax to 630-516- 6863. Sincerely, Barbara Kelkhoff Regulatory Project Manager II Chamberlain Group, Inc. 845 Larch Ave. Elmhurst, IL. 60126

100W Max26W Max WARNING • AVERTISSEMENT WARNING: To avoid SERIOUS PERSONAL INJURY or DEATH from electrocution, disconnect ALL electric and battery power BEFORE performing ANY maintenance. AVERTISSEMENT: Pour éviter des BLESSURES GRAVES ou la MORT par électrocution, débrancher l’alimentation électrique et de batterie AVANT TOUTE intervention de maintenance. PART NO.: ASSEMBLED IN MEXICO CHAMBERLAIN GROUP INC. ELMHURST IL, 60126, USA DATE: IC: 2666A - FCC ID: Artwork: 132LA2759-10-A 6.2" x 1.85" x 0.12" (W x H x R) Shown at 100% ECN: 05783 22 March 2011 132B2759-1 TO PROGRAM REMOTE CONTROL 1. Press and release the LEARN button. 2. Within 30 seconds, press and HOLD remote control button. 3. When garage door opener light flashes, release remote control button. TO ERASE ALL CODES 1. Press and HOLD the LEARN button for 6 seconds. The LED will turn ON. 2. Release the LEARN button when LED turns OFF. PROGRAMMATION POUR CHAQUE TÉLÉCOMMANDE 1. Appuyez sur le bouton APPRENTISSAGE et relâchez. 2. Dans les 30 secondes, pesez sur le bouton-poussoir de la télécommande. 3. Dès que la lampe de l’ouvre-porte de garage clignote, relâchez le bouton de la télécommande. POUR EFFACER TOUS LES CODES 1. Pesez sur le bouton APPRENTISSAGE pendant au moins 6 secondes. La lampe-témoin s’allumera. 2. Relâchez le bouton APPRENTISSAGE dès que la lampe-témoin s’éteint. Learn Button Bouton Apprentissage Learn LED lampe-témoin

Engineering Test Report No. 1103663-01 Rev. B Page 20 of 110 Figure 2 Test Setup for Radiated Emissions – 30MHz to 1GHz, Horizontal Polarization Test Setup for Radiated Emissions – 30MHz to 1GHz, Vertical Polarization Engineering Test Report No. 1103663-01 Rev. B Page 21 of 110 Figure 3 Test Setup for Radiated Emissions – 1GHz to 5GHz, Horizontal Polarization Test Setup for Radiated Emissions – 1GHz to 5GHz, Vertical Polarization
