HBW7966FCC Part 15 Remote Control Transmitter

3-BUTTON REMOTE CONTROLS MODELS 890MAX, 893MAX, AND 895MAX To prevent possible SERIOUS INJURY or DEATH from a moving gate or garage door: • ALWAYS keep remote controls out of reach of children. NEVER permit children to operate or play with remote controls. • Activate gate or door ONLY when it can be seen clearly, is properly adjusted and there are no obstructions to door travel. • ALWAYS keep gate or garage door in sight until completely closed. NEVER permit anyone to cross path of moving gate or door. LED LED Locate the Program button on the remote control. Locate the Learn button on the garage door opener. NOTE: Your garage door opener may look different. OROR Learn LED Learn LED Learn LED Green or Red/Orange Purple Yellow Program Button 2 3 Press and release the remote control button you want to use... 4 To exit programming mode, press any remote control button except the button that was just programmed. Install the visor clip (not applicable for Model 890MAX). 6 The garage door opener will activate. To test, press the programmed button on the remote control... 1 Press and release the Learn button on the garage door opener. Within 30 seconds... The Learn LED will light. Check to see if the garage door opener light bulb blinks. If not, wait for the remote control LED to light solid then slowly press and release the remote control button again. Repeat until the light bulb blinks. DO NOT press the button after the light bulb blinks. 5 To enter programming mode, press the Program button until the LED on the front of the remote control turns on. Safety Pin or Paper Clip Visor Clip MODEL 893MAX MODEL 890MAX PREPARE PROGRAMMING THE REMOTE CONTROL 893MAX 890MAX MODEL 895MAX 895MAX LEDs 890MAX 895MAX 893MAX Can be used as a replacement remote control for 80 Series, 970 Series, and 370 Series LiftMaster remote controls. Compatible with 315 MHz or 390 MHz garage door openers manufactured after January 1, 1993. Make sure the garage door opener has a working light bulb because it is a programming indicator. For use with gate operators, commercial door operators, or other products that are 315 MHz or 390 MHz and have a Learn button. Refer to your product manual for the location of the Learn button. BATTERY The LED(s) on your remote control will stop flashing when the battery is low and needs to be replaced. To replace battery, open the case as shown. Insert battery positive side up (+). Replace the battery with only 3V2032 or 3V2016 coin cell batteries (depending on the model). Dispose of old battery properly. To prevent possible SERIOUS INJURY or DEATH: • NEVER allow small children near batteries. • If battery is swallowed, immediately notify doctor. To reduce risk of fire, explosion or chemical burn: • Replace ONLY with 3V2032 coin batteries. • DO NOT recharge, disassemble, heat above 212° F (100° C) or incinerate. 1-800-528-9131 114A3930B © 2013, The Chamberlain Group, Inc. All Rights Reserved REPLACEMENT PARTS 3V2032 Lithium Battery (Models 893MAX & 890MAX) . . . . . . . . . . 10A20 3V2016 Lithium Battery (Model 895MAX) . . . . . . . . . . . . . . . . . . . . 10A19 Visor Clip (Model 893MAX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29B137 Visor Clip (Model 895MAX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29C151 1 2 3 WARRANTY www.liftmaster.com ONE YEAR LIMITED WARRANTY The Chamberlain Group, Inc. warrants to the first consumer purchaser of this product that it is free from defect in materials and/or workmanship for a period of 1 year from the date of purchase. Pry open the case with a screwdriver blade. 890MAX Pry open the case fi rst in the middle (1), then at each side (2 and 3) with the visor clip. 893MAX Remove the two screws and open the case. 895MAX 3V2032 3V2016 Additional buttons on the remote control can be programmed to operate up to 3 devices such as additional garage door openers, light controls, gate operators or access control systems. Press and hold the button down until the door or gate starts to move. The remote control will operate from up to 3 car lengths away on typical installations. Installations and conditions vary, contact an installing dealer for more information. HOW TO USE THE REMOTE CONTROL NOTICE: To comply with FCC and or Industry Canada rules (IC), adjustment or modifications of this receiver and/or transmitter are prohibited, except for changing the code setting or replacing the battery. THERE ARE NO OTHER USER SERVICEABLE PARTS. This device complies with Part 15 of the FCC rules and IC RSS- 210. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

TÉLÉCOMMANDES 3 BOUTONS MODÈLES 890MAX, 893MAX ET 895MAX Afin d’éliminer les risques de BLESSURES GRAVES ou de MORT découlant de l’actionnement d’une clôture ou d’une porte de garage : • TOUJOURS garder les télécommandes hors de la portée des enfants. NE jamais laisser un enfant manipuler une télécommande ni jouer avec. • Actionner la clôture ou la porte UNIQUEMENT lorsqu’elle est clairement visible, correctement ajustée et que le mécanisme est libre de toute entrave. • TOUJOURS garder la clôture ou la porte de garage en vue jusqu’à sa fermeture complète. NE permettez à quiconque de passer lorsqu’une clôture ou une porte est en mouvement. AVERTISSEMENT Voyant DEL Voyant DEL Recherchez le bouton « Program » sur la télécommande. Localiser le bouton « Learn » sur l’ouvre-porte de garage. REMARQUE : Votre ouvre-porte de garage peut avoir une apparence différente. OUOU Voyant DEL « Learn » Vert ou rouge/orange Violet Jaune Bouton « Program » Voyant DEL « Learn » Voyant DEL « Learn » 2 3 Appuyer sur le bouton de la télécommande que vous souhaitez utiliser, puis le relâcher... 4 Pour quitter le mode de programmation, appuyer sur n’importe quel bouton de la télécommande sauf celui qui vient d’être programmé. Installer la pince de pare-soleil (non applicable sur le modèle 890MAX). 6 L’ouvre-porte de garage se met alors à fonctionner. Pour tester, appuyer sur le bouton programmé de la télécommande... 1 Appuyer sur le bouton « Learn » de l’ouvre-porte de garage, puis le relâcher. Dans un délai de 30 secondes... Le voyant DEL « Learn » s’allume. Vérifier si l’ampoule de l’ouvre-porte de garage clignote. Si ce n’est pas le cas, attendre que le voyant DEL de la télécommande s’allume continuellement, puis appuyer sur le bouton de la télécommande avant de le relâcher doucement à nouveau. Répéter l’opération jusqu’à ce que l’ampoule clignote. NE PAS appuyer sur le bouton une fois que l’ampoule clignote. 5 Pour passer en mode de programmation, appuyer sur le bouton « Program » jusqu’à ce que le voyant DEL sur la partie frontale de la télécommande s’allume. Épingle de sûreté ou trombone Pince de pare-soleil MODÈLE 893MAX MODÈLE 890MAX PRÉPARATION PROGRAMMATION DE LA TÉLÉCOMMANDE 893MAX 890MAX MODÈLE 895MAX 895MAX Voyants DEL 890MAX 895MAX 893MAX Utilisation possible en tant que télécommande de remplacement aux télécommandes LiftMaster séries 80, 970 et 370. Compatibles avec les ouvre-portes de garage 315 MHz ou 390 MHz, fabriqués après le 1er janvier 1993. S’assurer que l’éclairage de l’ouvre-porte de garage fonctionne, dans la mesure où il s’agit d’un témoin de programmation. Pour une utilisation avec des actionneurs de barrière, des actionneurs commerciaux de porte ou d’autres produits fonctionnant à une fréquence de 315 MHz ou 390 MHz et équipés de bouton « Learn ». Reportez-vous au manuel de votre produit pour connaître l’emplacement du bouton « Learn ». PILE Le ou les voyants DEL de la télécommande s’arrêtent de clignoter lorsque la pile est faible et doit être remplacée. Pour remplacer la pile, ouvrir le boîtier, comme illustré. Insérer la pile avec le côté positif vers le haut (+). Remplacer la pile uniquement avec des piles boutons 3V 2032 ou 3V 2016 (selon le modèle). Se débarrasser de la pile usagée convenablement. Pour prévenir d’éventuelles BLESSURES GRAVES ou LA MORT : • NE jamais laisser de petits enfants à proximité des piles. • Aviser immédiatement un médecin en cas d’ingestion d’une pile. Pour réduire le risque d’incendie, d’explosion ou de brûlure chimique: • Remplacer les piles UNIQUEMENT par des piles capsules 3V2032. • NE PAS recharger, ni démonter, ni chauffer à une température supérieure à 100 °C (212 °F), ni incinérer. AVERTISSEMENT 1-800-528-9131 114A3930B © 2013, The Chamberlain Group, Inc. Tous droits réservés PIÈCES DE RECHANGE Pile au lithium 3 V 2032 (modèles 893MAX et 890MAX) . . . . . . . . . . . 10A20 Pile au lithium 3 V 2016 (modèle 895MAX) . . . . . . . . . . . . . . . . . . . . . 10A19 Pince de pare-soleil (modèle 893MAX) . . . . . . . . . . . . . . . . . . . . . . . 29B137 Pince de pare-soleil (modèle 895MAX) . . . . . . . . . . . . . . . . . . . . . . . 29C151 1 2 3 GARANTIE www.liftmaster.com GARANTIE LIMITÉE D’UN AN La société Chamberlain Group, Inc. garantit à l’acheteur initial que le produit est exempt de tout défaut de matériaux ou de fabrication pendant une période d’un an à compter de la date d’achat. Ouvrir le boîtier à l’aide de la lame d’un tournevis. 890MAX Ouvrir le boîtier d’abord au milieu (1), puis de chaque côté (2 et 3) à l’aide de la pince de pare-soleil. 893MAX Retirer les deux vis et ouvrir le boîtier. 895MAX 3V2032 3V2016 Il est possible de programmer d’autres boutons de la télécommande pour faire fonctionner jusqu’à trois appareils tels que d’autres ouvre-portes de garage, commandes d’éclairage, actionneurs de barrière ou systèmes de contrôle d’accès. Appuyer sur le bouton et le maintenir enfoncé jusqu’à ce que la porte ou la barrière commence à bouger. La télécommande fonctionne habituellement jusqu’à une distance maximum de trois véhicules. Les installations et les conditions peuvent varier. Communiquer avec un revendeur-installateur pour plus de renseignements. UTILISATION DE LA TÉLÉCOMMANDE AVIS : Les règles de la FCC ou d’Industrie Canada (IC), ou les deux, interdisent tout ajustement ou toute modification de ce récepteur et/ou de cet émetteur, sauf pour modifier le code ou pour remplacer la pile. IL N’EXISTE AUCUNE AUTRE PIÈCE SUSCEPTIBLE D’ÊTRE ENTRETENUE PAR L’UTILISATEUR. Cet appareilest conforme aux dispositions de la partie 15 du règlement de la FCC et de l’norme IC RSS-210. L’utilisation est sujette aux deux conditions ci-après : (1) ce dispositif ne peut causer des interférences nuisibles, et (2) ce dispositif doit accepter toute interférence reçue, y compris une interférence pouvant causer un fonctionnement non désiré.

845 Larch Ave. Elmhurst, IL 60126 Phone 630.993.6306 Fax 630.516.6863 Email: [email protected] February 26, 2013 Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 c.c. UL LLC. 333 Pfingsten Road Northbrook, IL 60062 To whom it may concern: I, the undersigned, hereby authorize Bart Mucha, of UL LLC, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Bart Mucha of UL on our behalf, shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL as our agent, we still recognize that we are responsible to: a) Comply with the relevant provisions of the certification program; b) Make all necessary arrangements for the conduct of the evaluation, including provision for Examining documentation and access to all areas, records (including internal audit reports) And personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) Make claims regarding certification only in respect of the scope for which certification has been granted; d) Do not use our product certification in such a manner as to bring the Certification Division Into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) Upon suspension or cancellation of certification, discontinue use of all advertising matter That contains any reference thereto and returns any certification documents as required by the Certification Division; f) Use certification only to indicate the products are certified as being in conformity with Specified standards; g) Endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) Ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) Keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) Take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) Document the actions taken. This authorization is valid until further written notice from the applicant. Yours sincerely, Barbara Kelkhoff Regulatory Project Manager II Chamberlain Group, Inc. 845 Larch Ave. Elmhurst, IL. 60126

845 Larch Ave. Elmhurst, IL 60126 Phone 630.993.6306 Fax 630.516.6863 Email: [email protected] February 26, 2013 Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID:HBW7966 Request for Confidentiality In accordance with 47 C.F.R. Section 0.457 and 0.459, we, Chamberlain Group, Inc., hereby request confidentiality for the block diagram, schematic and operational description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. I would appreciate your prompt attention to the submittal. If there are any questions, please call me at 630-993 -6306 or send a fax to 630-516- 6863. Sincerely, Barbara Kelkhoff Regulatory Project Manager II Chamberlain Group, Inc. 845 Larch Ave. Elmhurst, IL. 60126

HBW7966

HBW7966

HBW7966

UL LLC An organization dedicated 333 Pfingsten Rd. to public safety and committed to Northbrook, IL 60062 quality service for over 100 years Tel: (847) 272-8800 UL LLC 333 Pfingsten Rd. Northbrook, IL 60062 www.ul.com/emc (847) 272-8800 Project #: SR9617362 Order Number: 10004849 File Number: MC15343 Date: March 04, 2013 Model: 1D7966 Electromagnetic Compatibility Test Report For Chamberlain Group Inc. Copyright  2012 UL LLC UL LLC authorizes the above-named company to reproduce this Report provided it is reproduced in its entirety. Order #: 10004849 Project#: SR9617362 File #: MC15343 Page 2 of 77 Model Number: 1D7966 Client Name: Chamberlain Group Inc. UL LLC 333 Pfingsten Rd. Northbrook, IL 60062 USA Tel.: 847 272-8800 Rev. No 1.0Rev. No 1.0 EMC Report 2012-87-EM-F0042 Test Report Details Tests Performed By: UL LLC 333 Pfingsten Rd. Northbrook, IL 60062 Tests Performed For: Chamberlain Group Inc. 845 Larch Av Elmhurst, IL 60126 Applicant Contact: Hank Sieradzki Phone: (630) 993-6564 E-mail: [email protected] Test Report Date: March 04, 2013 Product Type: Universal Periodic Transmitter (Bling) Product standards FCC Part 15, Subpart C, 15.231 & RSS-210 Model Number: 1D7966 EUT Category: Wireless Device Testing Start Date: February 20, 2013 Date Testing Complete: March 03, 2013 Overall Results: Compliant UL LLC reports apply only to the specific samples tested under stated test conditions. All samples tested were in good operating condition throughout the entire test program. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. UL LLC shall have no liability for any deductions, inferences or generalizations drawn by the client or others from UL LLC issued reports. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, any agency of the Federal Government, or any agency of any government. This report may contain test results that are not covered by the NVLAP or A2LA accreditation. The scope of accreditation is limited to the specific tests that are listed on the NVLAP and/or A2LA websites referenced at the end of this report. Order #: 10004849 Project#: SR9617362 File #: MC15343 Page 3 of 77 Model Number: 1D7966 Client Name: Chamberlain Group Inc. UL LLC 333 Pfingsten Rd. Northbrook, IL 60062 USA Tel.: 847 272-8800 Rev. No 1.0Rev. No 1.0 EMC Report 2012-87-EM-F0042 Report Directory 1.0 G E N E R A L - Product Description ..................................................................................................................5 1.1 Equipment Description ...................................................................................................................................5 1.2 Device Configuration During Test ..................................................................................................................5 1.2.1 Equipment Used During Test: ....................................................................................................................5 1.2.2 Input/Output Ports: .....................................................................................................................................5 1.2.3 Power Interface: .........................................................................................................................................5 1.3 EUT Configurations ........................................................................................................................................6 1.4 EUT Operation Modes ....................................................................................................................................6 1.5 Rational for EUT Configuration ......................................................................................................................6 2.0 Summary ............................................................................................................................................................7 2.1 Deviations from standard test methods ..........................................................................................................7 2.2 Device Modifications Necessary for Compliance ...........................................................................................7 2.3 Reference Standards .....................................................................................................................................7 2.4 Results Summary ...........................................................................................................................................7 3.0 Calibration of Equipment Used for Measurement ..............................................................................................8 4.0 EMISSIONS TEST RESULTS ............................................................................................................................8 4.1 Configuration 2 Test Data ..............................................................................................................................9 4.1.1 Test Conditions and Results – Occupied Bandwidth .................................................................................9 4.1.2 Test Conditions and Results – Cease Operation .................................................................................... 13 4.1.3 Test Conditions and Results – Pulse Train ............................................................................................. 17 4.1.4 Test Conditions and Results – RADIATED EMISSIONS Fundamental and Spurious ........................... 31 4.2 Configuration 3 Test Data ........................................................................................................................... 36 4.2.1 Test Conditions and Results – Occupied Bandwidth .............................................................................. 36…

Text truncated - open the document above for the full version.

Order #: 10004849 Project#: SR9617362 File #: MC15343 Page 75 of 77 Model Number: 1D7966 Client Name: Chamberlain Group Inc. UL LLC 333 Pfingsten Rd. Northbrook, IL 60062 USA Tel.: 847 272-8800 Rev. No 1.0Rev. No 1.0 EMC Report 2012-87-EM-F0042 Appendix B Test Setup Photos X-Axis Setup, no clip Y-Axis Setup, with clip Z-Axis setup, no clip Radiated Emissions Setup Near Field Measurements
