HD5-75EL0NDolpin 75e, Handheld Computer

REG-75E Rev (a)Dolphin 75e Handheld Computer Approvals by Country Refer to the Honeywell Scanning & Mobility compliance center at www.honeywellaidc.com/compliance to review and download any publicly available documentation pertaining to the certification of this product in a given country. Caution! - Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. Mise en garde! - Tout changement ou modification non expressément approuvées par le bénéficiaire de cet appareil peut annuler l'autorisation d'utiliser l'équipement. For body worn operation, this device has been tested and meets the limits regarding human exposure to electromagnetic radiation set forth in related FCC, IC and EC rules, guidelines and standards for use with the following body worn accessories: HOLSTER-2 and 6000-HOLSTER. Use of other accessories may not ensure compliance with the mentioned rules. Fonctionnement près du corps: ce dispositif a été testé et s'avère conforme aux règles et lignes directrices des normes FCC, IC et EC, relatives aux limites d'une exposition humaine sécuritaire au rayonnement électromagnétique pour une utilisation près du corps des accessoires suivants: HOLSTER-2 et 6000-HOLSTER. L'utilisation d'autres accessoires peut ne pas assurer la conformité avec les règles mentionnées. Dolphin RF Terminal—802.11a/b/g/n/ac and Bluetooth This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet helpful: “Something About Interference.” This is available at FCC local regional offices. Our company is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by our company. The correction is the responsibility of the user. Use only shielded data cables with this system. Canadian Compliance This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. 5GHz band: Sub-band 5.150 - 5.250 GHz of the 5GHz LE-LAN (License Exempt Local Area Network Devices) supported in this device is permitted for indoor operation only. Conformité à la règlementation canadienne Cet appareil est conforme aux normes RSS avec exemption de licence d'Industrie Canada. Son fonctionnement est assujetti aux conditions suivantes: 1. Cet appareil ne doit pas causer de brouillage préjudiciable. 2. Cet appareil doit pouvoir accepter tout brouillage reçu, y compris le brouil- lage pouvant causer un fonctionnement indésirable. Bande 5 Ghz: La bande inferieure de 5,150 à 5,250 GHz de la 5GHz LE-LAN (License Exempt Local Area Network Devices) pris en charge dans ce dispositif est autorisée pour une utilisation en intérieur uniquement. R&TTE Compliance Statement—802.11a/b/g/n/ac and Bluetooth The CE marking indicates compliance with the following directives: • 1995/5/EC R&TTE • 2011/65/EU RoHS (Recast) In addition, this product complies to 2006/95/EC Low Voltage Directive when supplied with the recommended power supply. European Contact: Hand Held Products Europe B.V. Nijverheidsweg 9-13 5627 BT Eindhoven The Netherlands Honeywell shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive. The equipment is intended for use throughout the European Community; PAN European Frequency Range: 2.400–2.4835 GHz. Operating Frequency Ranges: • 2400 - 2483.5 MHz, Wideband Data Transmission Systems (WLAN IEEE 802.11 b,g,n at 2.4 GHz); • 5150 - 5350 MHz and 5470 - 5725 MHz, Wideband Data Transmission Systems (WLAN/RLAN IEEE 802.11 a,n,ac at 5 GHz); • Operation on sub-band 5150 - 5350 MHz is permitted indoor only. Honeywell Scanning & Mobility Product Environmental Information Refer to www.honeywellaidc.com/environmental for the RoHS / REACH / WEEE information. USA, Canada NRTL Safety UL and C-UL listed: UL60950-1 2nd Edition and CSA C22.2 No. 60950-1-07 2nd Edition. LED Safety LEDs have been tested and classified as “EXEMPT RISK GROUP” to the Standard: IEC 62471:2006. Battery Safety Information RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. The battery should be disposed of by a qualified recycler or hazardous materials handler. Do not incinerate the batter…

Text truncated - open the document above for the full version.

Dolphin™ 75e powered by Android 4.4 User’s Guide Preliminary Draft, Not for Release - Please Review 2-3-2015 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII. HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material. HII disclaims any and all responsibility and liability for the selection and use of software and/or hardware to achieve intended results. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of HII. Web Address: www.honeywellaidc.com Trademarks Android, Google, Google Play and other marks are trademarks of Google Inc. The Bluetooth trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to Honeywell. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are the property of their respective owners. Patents For patent information, please refer to www.hsmpats.com. 2015 Honeywell International Inc. All rights reserved. Preliminary Draft, Not for Release - Please Review 2-3-2015 iii Chapter 1 - Dolphin 75e Terminal Agency Information Label Locations ....................................................................................................................1-1 Model Number and Serial Number.................................................................................1-1 Approvals by Country...........................................................................................................1-1 FCC Requirements ..............................................................................................................1-2 Dolphin RF Terminal—802.11a/b/g/n/ac, Bluetooth, and/or GSM .................................1-2 Canadian Compliance, Conformité à la règlementation canadienne ...................................1-2 RF Exposure Information (SAR) ..........................................................................................1-2 R&TTE Compliance Statement—802.11a/b/g/ac, Bluetooth ...............................................1-3 Honeywell Scanning & Mobility Product Environmental Information....................................1-3 USA, Canada NRTL Safety .................................................................................................1-3 LED Safety ...........................................................................................................................1-3 Pacemakers, Hearing Aids and Other Electrically Powered Devices ..................................1-3 Microwaves ..........................................................................................................................1-4 Chapter 2 - Getting Started Out of the Box ......................................................................................................................2-1 Memory Card Specifications ..........................................................................................2-1 Initial Setup for Dolphin 75e Terminal ..................................................................................2-1 Install the Battery ...........................................................................................................2-1 Charge the Battery .........................................................................................................2-2 Power On the Terminal ..................................................................................................2-4 Unlock the Screen..........................................................................................................2-4 Customize the Home Screen and Access Apps ..................................................................2-5 Status Bar ......................................................................................................................2-5 Notification Panel ...........................................................................................................2-6 Common Status and Notification Icons ..........................................................................2-6 Search Bar .....................................................................................................................2-7 Personalize the Home Screen Panels and Favorites Tray ............................................2-7 Apps and Widgets .........................................................................................................2-8 Navigation/Function Buttons ................................................................................................2-8 Hotkeys ..........................................................................................................................2-9 Virtual Keyboard ..................................................................................................................2-9 Using the Virtual Keyboard ............................................................................................2-9 Turning Power On/Off ..........................................................................................................2-9 Suspend Mode .....................................................................................................................2-9 Airplane Mode ....................................................................................................................2-10 Replacing the Battery............................................................................…

Text truncated - open the document above for the full version.

Honeywell International Inc Honeywell Scanning and Mobility 9680 Old Bailes Road Fort Mill, SC 29707 USA To Whom It May Concern: Subject: Attestation of Product Portion Equality We, Honeywell International Inc, located at 9680 Old Bailes Road, Fort Mill, SC 29707 USA, confirm that: Dolphin 75e models, 75eL0N, and 75eL00 with, FCC ID: HD5-75EL0N & IC ID: 1693B-75EL0N FCC ID: HD5-75EL00 & IC ID: 1693B-75EL00 Contain electrically identical Bluetooth and WLAN (2.4 and 5GHz) portions. The FCC part 15 / IC RSS-210 conducted test results from test of the Bluetooth and WLAN portions of the model 70eL0N are thus representative for those portions of the model variants 75eL00. Sincerely, Michael Robinson Compliance Manager, Scanning Systems January, 27, 2015

Honeywell International Inc Honeywell Scanning and Mobility 9680 Old Bailes Road Fort Mill, SC 29707 USA Date: January/19/2015 To whom it may concern: Honeywell International Inc, hereby declares that Wi-Fi channels 12 and 13 for Dolphin 75e with model numbers, 75eL0N (with FCC ID: HD5-75EL0N) and 705eL00 (with FCC ID: HD5-75EL00) are disabled via Software driver. The SW driver will disable the channels and modify the power according to the part number which contains special field for regulatory domain purposes. This part number is flashed during manufacturing process. The product respects all relevant provisions of FCC KDBs 594280 D01 Software Configuration Control v02r01 and 594280 D02 U-NII Device Security v01r01. Sincerely, Michael Robinson Phone: 315.554.6387 Email: [email protected]

Honeywell International Inc Honeywell Scanning and Mobility 9680 Old Bailes Road Fort Mill, SC 29707 USA January/19/2015 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: HD5-75EL0N Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request the exhibits listed hereafter and accompanying above identified application be kept confidential permanently. Schematics Block Diagram Parts List Operation Description Tune up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, ________________________ Michael Robinson Phone: 315.554.6387 Email: [email protected]

Honeywell International Inc Honeywell Scanning and Mobility 9680 Old Bailes Road Fort Mill, SC 29707 USA January, 19, 2015 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 RE : Certification Application FCC ID : HD5-75EL0N To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days from the date of grant:  External Photos  Internal Photos  Test Setup Photos  User Manual The application contains technical information, which Honeywell International Inc deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. We are informed and understand that we have to arrange cancellation of the short term confidentiality classification per written and timely request to the involved TCB, if a product release to the market is intended prior to the above specified short term confidentiality release date. We understand that the above listed exhibits will be automatically disclosed to the public at the specified short term confidentiality release date if not prolonged by the involved TCB upon our timely request (total of 180 days from date of grant is possible). Sincerely, Michael Robinson Compliance Manager, Scanning systems Tel: 315-554-6387 FAX: 315.554.6393 Email:[email protected]

Page 1 of 14 Dolphin ® 75e Paris WLAN/BT External Photographs NFC Model 75eL0N Revision History Ver. Description Date Author 1.0 Initial Release 10/30/2014 JPW Contains Information proprietary to Honeywell, Inc. Page 2 of 14 Dolphin 75e Paris WLAN/BT Photographs Brand Name Honeywell Model 75eL0N 1 Exterior Photographs Front Face & Right Side Page 3 of 14 Front Face & Left Side Page 4 of 14 Top Side (Headphone Jack, 2D Imager, On/Off Button) Page 5 of 14 Bottom Side (Speaker, Lanyard Attachment) Page 6 of 14 Top Side (On/Off Button, 2D Imager, Headset Jack, Extended Battery Cover) Page 7 of 14 Top Side (On/Off Button, 2D Imager, Headset Jack, Standard Battery Cover) Page 8 of 14 Back Side (8 MP Camera & Flash, Docking Contacts, Standard Battery Cover) Page 9 of 14 Back Side (8 MP Camera & Flash, Docking Contacts, Extended Battery Cover) Page 10 of 14 Back Side (8 MP Camera & Flash, Docking Contacts, Extended Battery Shown) Page 11 of 14 Back Side (8 MP Camera & Flash, Docking Contacts, Standard Battery Shown) Page 12 of 14 Back Side (8 MP Camera & Flash, Docking Contacts, Battery Removed, 4 Battery Cover Options) Page 13 of 14 NFC Antenna (Extended Battery Door on Left, Standard Battery Door on Right) Page 14 of 14 Intentionally blank

THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY AND CONFIDENTIAL MATERIAL OF HONEYWELL INTERNATIONAL INC AND SHALL NOT BE REPRODUCED, OR COPIED, OR USED AS A BASIS FOR MANUFACTURE OR SALE OF EQUIPMENT OR DEVICES WITHOUT WRITTEN PERMISSION. c REV#REV DESCRIPTION DESIGNED BY DATE ARTWORK LEVEL TITLE: A DRAWING NO: REV SCALE DO NOT SCALE SHEET 1 OF 1 DRAWING NO. DATE RELEASE LABEL, PARIS 75E, AGENCY PRINT ON DEMAND C 10/27/14 D.FLETCHER 10/06/14 A CC# 2014-2159 MATERIAL # ONE “A” Format Artwork Template No. 500030434, REV A NOTES REQUIRED FOR LABEL MANUFACTURER: 1. ROHS COMPLIANT RIBBONS. SEE ENVIRONMENTAL SPECIFICATION DOCUMENT #500007391 2. MATERIAL/ PROCESS: THERMAL TRANSFER USING UL APPROVED RIBBON & MATERIAL CONSTRUCTION ON .051MM THICK WHITE POLYESTER BACKED WITH PRESSURE SENSITIVE ADHESIVE. SIZE: 25.4MM X 25.4 MM. ALL PRINTING BLACK 3. SERIAL NUMBER: 2D DATA MATRIX 7 DOT EW (10 CHARACTER MAX) OF SERIAL NUMBER AS DESCRIBED IN CHART BELOW. 50121313 50121313 50121313-005, -006 50121313-001 North America Only WLAN, BT ( L00) 3 50121313-001, -002, -004 3 3 CHG CHS LABELS 01/12/15 B 2015-134 50121313-003 OBSOLETE TWO 50121313-005 Non- North America Skus WLAN, BT ( L00) 3 ADD -05, -06 01/29/15 C 2015-423 E296 50121313-002 North America Only WLAN, BT, NFC (L0N) Honeywell International Inc www.honeywellaidc.com Patents: www.hsmpats.com Use Honeywell International Inc Battery Pack Only MODEL: 75eL0N Anatel: XXXX-XX-XXXX IFETEL: XXXXXXXXX-XXXX-XX FCC ID: HD5-75EL0N IC: 1693B-75EL0N P/N: S/N: REV: D L P H I 75e N TM O 50121313-004 WLAN, BT, NFC (L0N) SIMPLIFIED CHINESE Made in China Input: 5V 1A Honeywell International Inc www.honeywellaidc.com Patents: www.hsmpats.com Use Honeywell International Inc Battery Pack Only MODEL: 75eL00 Anatel: XXXX-XX-XXXX IFETEL: XXXXXXXXX-XXXX-XX FCC ID: HD5-75EL00 IC: 1693B-75EL00 P/N: S/N: REV: D L P H I 75e N TM O Made in China Input: 5V 1A Honeywell International Inc www.honeywellaidc.com Patents: www.hsmpats.com Use Honeywell International Inc Battery Pack Only CMIIT ID: 2015AJ0202 MODEL: 75eL0N P/N: S/N: REV: D L P H I 75e N TM O 型号 Input: 5V 1A 输入 中国制造 无线信息终端 Made in China PRELIMINARY C Honeywell International Inc www.honeywellaidc.com Patents: www.hsmpats.com Use Honeywell International Inc Battery Pack Only MODEL: 75eL00 Anatel: XXXX-XX-XXXX P/N: S/N: REV: D L P H I 75e N TM O Made in China Input: 5V 1A 0682 3 E296 0682 Honeywell International Inc www.honeywellaidc.com Patents: www.hsmpats.com Use Honeywell International Inc Battery Pack Only MODEL: 75eL0N Anatel: XXXX-XX-XXXX P/N: S/N: REV: D L P H I 75e N TM O Made in China Input: 5V 1A 50121313-006 Non-North America Skus WLAN, BT, NFC (L0N) IMEI: XXXXXXXXXXXXXXXX MEID: XXXXXXXXXXXXXXXX MFG DC: XXXXXX Wheelie, FCC molded in Dolphin 75e Ip67 Housing 11/06/2014 Agency Data Matrix Code Data Matrix Code Data Matrix Code Data Matrix Code 50121313-001 WLAN, BT ( L00) 50121313-003 WLAN, BT (L00) SIMPLIFIED CHINESE E296 0682 E296 0682 50121313-002 WLAN, BT, NFC (L0N) Honeywell International Inc www.honeywellaidc.com Patents: www.hsmpats.com Use Honeywell International Inc Battery Pack Only MODEL: 75eL0N Anatel: XXXX-XX-XXXX IFETEL: XXXXXXXXX-XXXX-XX FCC ID: HD5-75EL0N IC: 1693B-75EL0N P/N: S/N: REV: D L P H I 75e N TM O 50121313-004 WLAN, BT, NFC (L0N) SIMPLIFIED CHINESE Made in China Input: 5V 1A Honeywell International Inc www.honeywellaidc.com Patents: www.hsmpats.com Use Honeywell International Inc Battery Pack Only FCC ID: HD5-75EL00 IC: 1693B-75EL00 CMIIT ID: XXXXXXXX MODEL: 75eL00 P/N: S/N: REV: D L P H I 75e N TM O 型号 Input: 5V 1A 输入 中国制造 无线信息终端 Made in China Honeywell International Inc www.honeywellaidc.com Patents: www.hsmpats.com Use Honeywell International Inc Battery Pack Only MODEL: 75eL00 Anatel: XXXX-XX-XXXX IFETEL: XXXXXXXXX-XXXX-XX FCC ID: HD5-75EL00 IC: 1693B-75EL00 P/N: S/N: REV: D L P H I 75e N TM O Made in China Input: 5V 1A Honeywell International Inc www.honeywellaidc.com Patents: www.hsmpats.com Use Honeywell International Inc Battery Pack Only FCC ID: HD5-75EL0N IC: 1693B-75EL0N CMIIT ID: XXXXXXXX MODEL: 75eL0N P/N: S/N: REV: D L P H I 75e N TM O 型号 Input: 5V 1A 输入 中国制造 无线信息终端 Made in China MATRL #: 50118726-001 50119320-001 (Stylus version)

Page 1 of 15 Dolphin ® 75e Paris WLAN/BT Internal Photographs NFC Model 75eL0N Revision History Ver. Description Date Author 1.0 Initial Release 10/30/2014 JPW Contains Information proprietary to Honeywell, Inc. Page 2 of 15 Dolphin 75e Paris WLAN/BT Photographs Brand Name Honeywell Model 75eL0N 1 Internal Photographs Back Side, Rear Panel Removed, Device w/ NFC (8 MP Camera & Flash, Docking Contacts) Page 3 of 15 Bottom Antenna Carrier (Length) Page 4 of 15 Bottom Antenna Carrier (Width) Page 5 of 15 Bottom Antenna Carrier Showing Speaker Page 6 of 15 Back Side, Rear Panel Removed (Length) Page 7 of 15 Top Antenna Carrier w/ Dual Band Wi-Fi Antenna, Flex Circuit for Microphone & Scan Buttons Page 8 of 15 Top Antenna Carrier Rear Side w/ Flex Circuit for Volume & Scan Buttons, Headset Jack Contacts Page 9 of 15 Back Side, Antenna Carriers Removed (Length) Page 10 of 15 Main Board (bottom), Shield Can Removed Page 11 of 15 Main Board (top), Shield Cans Removed (width) Page 12 of 15 Main Board (top), Shield Cans Removed (length) Page 13 of 15 Qualcomm QCA1990 NFC Controller & related circuitry beneath shield Main Board w/ NFC, Shield Cans Removed Epcos R088 LTCC Front-end Module for 802.11 a/ac/b/g/n WLAN and Bluetooth Qualcomm WCN3680 WLAN/BT Transceiver Page 14 of 15 (Shield Removed) Qualcomm QCA1990 NFC Controller Main Board w/ NFC, NFC Circuitry Page 15 of 15 Intentionally blank

FCC Listed #: A2LA Accredited IC Recognized # 3462B-1 CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected]  http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 V5.2 2013-02-15 © Copyright by CETECOM SAR Test Report FOR: Manufacturer: Honeywell International Inc. Model Numbers: 75eL00, 75eL0N FCC ID: HD5-75EL00 & HD5-75EL0N IC Certification Number: 1693B-75EL00 & 1693B-75EL0N Test Report #: SAR_HONEY_134_14001_FCC_Rev1 Date of Report: 2015-02-06 Test Report #: SAR_HONEY-134_14001_FCC_rev1 FCC ID: HD5-75EL00 & HD5-75EL0N Date of Report: 2015-02-06 IC ID.: 1693B-75EL00 & 1693B-75EL0N Page 2 of 25 V5.1 2013-01-09 This report shall not be reproduced except in full without the written approval of: CETECOM Inc.  SAR  411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. TABLE OF CONTENTS 1. Assessment ................................................................................................................................................... 4 2. Administrative Data .................................................................................................................................... 5 2.1. Identification of the Testing Laboratory Issuing the SAR Test Report ....................................... 5 2.2. Identification of the Client ................................................................................................................ 5 2.3. Identification of the Manufacturer .................................................................................................. 5 3. Equipment under Test (EUT) .................................................................................................................... 6 3.1. General Specification of the Equipment under Test ...................................................................... 6 3.2. Technical Specification of Supported Radios .................................................................................. 7 3.3. Identification of the Equipment Under Test (EUT) ....................................................................... 7 3.4. Identification of Accessory equipment ............................................................................................. 7 3.5. Maximum SAR values ....................................................................................................................... 8 3.6. Miscellaneous Information................................................................................................................ 8 4. Subject of Investigation .............................................................................................................................. 9 4.1. The IEEE Standard C95.1 and the FCC Exposure Criteria ......................................................... 9 4.2. The IEEE Standard C95.1 , FCC Exposure Criteria, and IC Exposure Criteria ....................... 9 4.3. SAR Limit ........................................................................................................................................... 9 5. Measurement Procedure........................................................................................................................... 10 5.1. General Requirements ..................................................................................................................... 10 5.2. Body-worn and Other Configurations ........................................................................................... 10 5.3. Procedure for assessing the peak spatial-average SAR ................................................................ 10 5.4. Determination of the largest peak spatial-average SAR .............................................................. 12 6. The Measurement System ........................................................................................................................ 13 6.1. Robot system specification .............................................................................................................. 13 6.2. Isotropic E-Field Probe for Dosimetric Measurements ............................................................... 14 6.3. Data Acquisition Electronics .......................................................................................................... 14 6.4. Phantoms .......................................................................................................................................... 14 6.5. Interpolation and Extrapolation schemes...................................................................................... 14 7. Uncertainty Assessment ............................................................................................................................ 15 7.1. Measurement Uncertainty Budget According to IEEE 1528:2013 ............................................. 15 7.2. Measurement Uncertainty Budget According to EN 62209......................................................... 16 Test Report #: SAR_HONEY-134_14001_FCC_rev1 FCC ID: HD5-75EL00 & HD5-75EL0N Date of Report: 2015-02-06 IC ID.: 1693B-75EL00 & 1693B-75EL0N Page 3 of 25 V5.1 2013-01-09 This report shall not be reproduced except in full without the written approval of: CETECOM Inc.  SAR  411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. 8. Test results summary ................................................................................................................................ 17 8.1. Conducted Average Output Power ................................................................................................ 17 8.2. Stand-Alone SAR Evaluation Exclusion ........................................................................................ 19 8.3. Test Positions and Configurations.................................................................................................. 19 8.4. SAR Results f…

Text truncated - open the document above for the full version.

FCC ID: HD5-75EL00 & HD5-75EL0N IC Cert. No.: 1693B-75EL00 & 1693B-75EL0N SAR Test Report - Appendix A - Plots Page 1 of 85 Plot 1 Date/Time: 11/19/2014 5:48:33 PM Test Laboratory: Cetecom Inc., SAR 3 Lab DUT: Honeywell; Type: Phone; Serial: 14269J005F Communication System: 802.11bgn 100% Duty Cycle; Frequency: 2437 MHz Medium: HBBL1900-3800_Batch 130605-1 Medium parameters used: f = 2437 MHz; σ = 1.868 mho/m; ε r = 39.057; ρ = 1000 kg/m 3 Phantom section: Right Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) Procedure Notes: Test Technician: Mike; Air Temperature: 22.2C; Medium Temperature: 21.9C; Comments: ; DASY Configuration:  Probe: ES3DV3 - SN3260; ConvF(4.56, 4.56, 4.56); Calibrated: 3/19/2014;  Sensor-Surface: 3mm (Mechanical Surface Detection), z = 2.0, 32.0  Electronics: DAE4 Sn1233; Calibrated: 3/17/2014  Phantom: SAM Rear; Type: QD000P40CC; Serial: TP:xxxx  DASY52 52.8.1(838); Right-Hand-Side/Touch Position/Area Scan (16x10x1): Measurement grid: dx=12mm…

Text truncated - open the document above for the full version.
