HD5-CK67X0NMobile Computer

CK67 powered by Android™ Quick Start Guide CK67-A-EN-QS-01 Rev (a-AG3 ) 06/24 Preliminary Draft for Review, Not for Release 1 Agency Models CK67 Series: CK67X0N, CK67X1N Out of the Box Make sure that your shipping box contains these items: • CK67 mobile computer • Rechargeable 3.6 VDC Li-ion battery •Hand strap •Cable • Product documentation If you ordered accessories for your mobile computer, verify that they are also included with the order. Be sure to keep the original packaging in case you need to return the mobile computer for service. Note:CK67X0N models do not include a WWAN radio. Memory Card Specifications Honeywell recommends the use of Single Level Cell (SLC) industrial grade microSD™ or microSDHC™ memory cards with mobile computers for maximum performance and durability. Contact a Honeywell sales representative for additional information on qualified memory card options. Preliminary Draft for Review, Not for Release 2 Computer Features Speaker Out for Bluetooth Low Energy Beacon* Power Button Proximity and Ambient Light Sensor Touch Panel Keyboard (model dependent) Scan Status LED Imager (LED / Laser Aperture) Scan Buttons Front Camera Microphone Microphone Battery Status/ Notification LED Keypad Status LEDs *Part of Honeywell’s Device Finder solution. Preliminary Draft for Review, Not for Release 3 Battery Latch (under hand strap) NFC Antenna Location Scan Button Hand Strap I/O Connector Speaker Port Speaker Port Laser Safety Label Location microSD Card Door USB-C Port Cover Battery Rear Camera and Flash Preliminary Draft for Review, Not for Release 4 Install a Nano-SIM Card For CK67X1N models only. Either a nano-SIM card or embedded SIM (eSIM) is used to activate the phone and connect to a mobile network. Supported SIM type and activation method vary by model and model configuration. Refer to the user guide for additional information on eSIM or nano-SIM activation and provisioning. ! Always power off the computer before attempting to install or remove a card. 1 2 4 3 Preliminary Draft for Review, Not for Release 5 Install a microSD Card (Optional) Note:Format the microSD card before initial use. ! Always power off the computer before attempting to install or remove a card. 12 4 3 Preliminary Draft for Review, Not for Release 6 About the Battery The mobile computer ships with a Li-ion 3.6 VDC, 25.2 watt- hour battery manufactured for Honeywell International Inc. ! Before you attempt to use, charge or replace the battery in the device, carefully read all labels, markings and product documentation provided in the box or online at sps.honeywell.com. To learn more about Battery Maintenance for Portable Devices, go to honeywell.com/PSS-BatteryMaintenance. Avant d’essayer d’utiliser, de charger ou de remplacer la batterie de l’appareil, lisez attentivement toutes les étiquettes, marquages et documentation du produit fournis dans la boîte ou en ligne à sps.honeywell.com. Pour en savoir plus sur l’Entretien de Batteries pour Appareils Portables, consultez-le honeywell.com/PSS-BatteryMaintenance. ! We recommend use of Honeywell Li-ion battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty. Nous recommandons l’utilisation de batteries Li-ion de la marque Honeywell. L’utilisation d’une batterie d’un autre fabricant est susceptible de provoquer des dommages non couverts par la garantie. ! Ensure all components are dry prior to placing the battery in the computer. Mating wet components may cause damage not covered by the warranty. Assurez-vous que tous les composants sont secs avant d’insérer la batterie dans l’ordinateur. L’insertion de composants humides risque de provoquer des dommages non couverts par la garantie. Preliminary Draft for Review, Not for Release 7 Install the Battery 1 2 3 Preliminary Draft for Review, Not for Release 8 Install the Hand Strap Charge the Mobile Computer The CK67mobile computer ships with a partially charged battery. Charge the battery with a CK67 Series charging device for a minimum of 3 hours. Note:Using the computer while charging the battery increases the time required to reach a full charge. If the mobile computer is drawing more current than supplied by the charging source, charging will not take place. Snap Snap Preliminary Draft for Review, Not for Release 9 CK67 series mobile computers are designed for use with CK67 charging accessories. For more information, see the CK67 Series Accessory Guide available for download at sps.honeywell.com. About the USB Type C Connector You can use the provided USB cable to charge the mobile computer from a host device (e.g., laptop or desktop computer). The connected host device must supply a minimum power output of 5V, 0.5A to the CK67 or the battery will not charge. Turn Power On/Off The first time you power on the computer, a Welcome screen appears. You can either scan a configuration barcode or use the Wizard to manually set up the computer. Once setup is complete, the Welcome screen no longer appears on startup and Provisioning mode is automatically turned off (disabled). ! We recommend the use of Honeywell accessories and power adapters. Use of any non-Honeywell accessories or power adapters may cause damage not covered by the warranty. Nous recommandons d’utiliser des accessoires et des adaptateurs secteur de marque Honeywell. L’utilisation de tout accessoire ou adaptateur secteur d’une autre marque est susceptible de provoquer des dommages non couverts par la garantie. ! Ensure all components are dry prior to mating the computers and batteries with peripheral devices. Mating wet components may cause damage not covered by the warranty. Assurez-vous que tous les composants sont secs avant de raccorder les ordinateurs et les batteries à des périphériques. L’insertion de composants humides risque de provoquer des dommages non couverts par la garantie. Preliminary Draft for Review, Not for Release 10 To turn the computer on: • Press and hold the Power button for approx…

Text truncated - open the document above for the full version.

Page 1 CK67-ML-RS-02 Rev (a)CK67 Mobile Computer Agency Models: CK67X0N Product documentation is available at sps.honeywell.com. La documentation sur le produit est disponible à sps.honeywell.com. La documentation du produit est disponible sur le site sps.honeywell.com. La documentazione sul prodotto è disponibile sul sito sps.honeywell.com. Die Produktdokumentation ist unter sps.honeywell.com verfügbar. La documentación del producto está disponible en sps.honeywell.com. La documentación del producto está disponible en sps.honeywell.com. A documentação do produto está disponível em sps.honeywell.com. ❡ᄩ俒咓霼⿬錛 sps.honeywell.comկ 欴ᄩ俒⟝꧌锞⿮鋅 sps.honeywell.com כزًُٝؗس醡ᄩ sps.honeywell.com կׅדⵃ欽〳腉ד 헪컲졓컪쁢sps.honeywell.com 펞컪핆쿦핖킃삖삲 .           sps.honeywell.com. ر وثائق المنج عل الموقع الال ّ توف .sps.honeywell.com Publicly downloadable certificates are available at honeywell.com/PSScompliance. Les certificats téléchargeables accessibles au public sont disponibles à honeywell.com/PSScompliance. Les certificats téléchargeables publiquement sont disponibles sur honeywell.com/PSScompliance. I certificati pubblicamente scaricabili sono disponibili sul sito Web honeywell.com/PSScompliance. Zertifikate stehen unter honeywell.com/ PSScompliance öffentlich zum Download zur Verfügung. Hay certificados descargables disponibles públicamente en honeywell.com/PSScompliance. Puede descargar los certificados de acceso público en honeywell.com/PSScompliance. Certificados disponíveis ao público para download em: honeywell.com/PSScompliance. 㥵꨽Ⱆ䒓♴鲿涸霆⛼霼霄꡼ honeywell.com/PSScomplianceկ 㥶꨾〳ⰗꟚ♴鯺涸阮剅锞鸤鏞 honeywell.com/PSScompliance ծכ鏾僇剅ז〳腉س٦ٗٝؐتח♧菙 honeywell.com/PSScompliance דⵃ欽〳 կׅד腉 뫃맪헏픊옪삲풂옪슪많쁳핆흫컪쁢 honeywell.com/PSScompliance 펞컪묺쿦핖킃삖삲 .              honeywell.com/PSScompliance. الشهادات القابلة للنزيل ماحة للعامة عل الموقع honeywell.com/PSScompliance. Caution: Any changes or modifications made to this equipment not expressly approved by Honeywell International Inc. may void the authorization to operate this equipment. MISE EN GARDE : Tout changement ou modification apporté(e) à cet équipement qui n'est pas expressément approuvé(e) par Honeywell International Inc. peut annuler l'autorisation d'utiliser cet équipement. Mise en garde : tous les changements ou les modifications apportés à cet équipement non expressément ap pro uvés par Honeywell International Inc. peuvent annuler l'autorisation d'utiliser cet équipement. Attenzione: qualsiasi variazione o modifica apportata a questa apparecchiatura, non espressamente approvata da Honeywell International Inc., potrebbe annullare l'autorizzazione concessa all'utente per utilizzare l'apparecchiatura. Vorsicht: Von Honeywell International Inc. nicht ausdrücklich genehmigte Veränderungen an diesem Gerät können dazu führen, dass die Betriebsgenehmigung für dieses Gerät erlischt. Precaución: Cualquier modificación o cambio realizado en este equipo, no expresamente aprobado por Honeywell International Inc., puede anular la autorización para utilizar este equipo. Precaución: cualquier cambio o modificación a este equipo que no esté expresamente aprobado por Honeywell International Inc. puede invalidar la autorización para usarlo. Atenção: qualquer alteração ou modificação não aprovada expressamente pela Honeywell International Inc. neste equipamento poderá invalidar a autorização de operá-lo. 岤䠑 㼆劥霃㢊鵳遤⟣⡦劢絑 Honeywell International Inc. 僈烁 ⲥ雽涸刿佖䧴⥝佖〳腊⠔⢪乼⡲ 劥霃㢊涸䱇勉㣟佪կ 岤䠑 ⳝ劢竤 Honeywell International Inc. 僈焷ⲥ鏪示乲荈 隶刿䧴佖鸤劥鏤⪔罏〳腋搂奚ⱄ 乽⡲劥鏤⪔ 陨デ : Honeywell International ךֿծח׃ז䪫钠ז僇爙涸ךInc. ֿծה׷ׅ何㢌כ׋ת堣㐻׾㢌刿 זח搀⸬ָ׷埄ꣲׅ堣㐻׾乼⡲ך կׅת׶ָ֮׷㜥さ 훊픦 : Honeywell International Inc. 펞픦킲킇핆픒짩힎팘픎 짷쩣픊옪쫆핳찒읊쪎몋쏞쁢 맪혾쁢몋푾핳찒읊핟솧쿦핖쁢 킇핆핂�콚쇮쿦핖킃삖삲 .    !                   Honeywell International Inc.        "     . تحذير: قد تؤدي أي تغييرات أو تعديلات عل هذا ال78از غ4ر مصادق عليها من شركة .Honeywell International Inc إل إلغاء ترخ4ص تشغيل هذا ال78از. 802.11 Caution: A Wireless Network Administrator should review the operating restrictions and use with a properly configured access point. Models: CK67X0N FCC Part 15 Subpart B Class B This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio or television technician for help. If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. Honeywell International Inc. is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Honeywell International Inc. T…

Text truncated - open the document above for the full version.

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com 120623-17 rev 9 Certification Application Attestation Statements Date: July 25, 2024 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) ______ Honeywell International Inc______ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ______ Honeywell International Inc______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☑ - is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates – see KDB 986446 Question 5) as an entity producing “covered” equipment. Thank you, By: __________________________ Cindy Jiang (Signature 2 ) (Print name) 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters must be placed on appropriate letterhead. Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com 120623-17 rev 9 Title: Global Regulatory Compliance Manager Company: Honeywell International Inc Telephone: +86(512)82258162

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com U.S. Agent Designation for Service of Process (Applicant is Both Grantee and U.S. Agent) TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information This letter is to confirm that the Applicant will also serve as the U.S. Agent for Service of Process as required by 47 CFR 2.911(d)(7). The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The Applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information changes. Applicant Company name: HONEYWELL INTERNATIONAL INC FRN #: 0022970339 Grantee Code: HD5 Contact Name: Cindy Jiang Street Address: 9680 Old Bailes Rd City/Province/Zip: Fort Mill/ South Carolina/ 29707 Telephone No: +86(512)82258162 Email: [email protected] Applicant Signature 1 : Date: July 15, 2024 Signed by (Printed Name/Title): Cindy Jiang/ Global Regulatory Compliance Manager 1 - Letters must be placed on appropriate letterhead. The signee for the applicant must be one of the following: Applicant (grantee) contact of record in the FCC’s authorization system, or authorized officers or employee of the applicant (grantee).

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com 061224-33a Request for Confidentiality Date: July 25, 2024 Subject: Confidentiality Request for: _FCC ID: HD5-CK67X0N _& IC: 1693B-CK67X0N ______ Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term --------------------------- External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term --------------------------- Test Setup Photos ☐ Short Term ☐ Permanent * 3 User’s Manual _____Honeywell International Inc. ______ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality for FCC Applications: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of __ (specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Short Term Confidentiality for Industry Canada Applications: Starting May 2022, ISED will recognize short term confidentiality on certain exhibits until the intended date of marketing. The applicant requests the exhibits selected above as short term confidential be withheld from public view until: (specify ISED expiration date / date of marketing) . Sincerely, 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com 061224-33a By: __________________________ Cindy Jiang (Signature/Title 3 ) (Print name) 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com Cover L etter Federal Communications Commission Authorization and Evaluation Division FCC ID: HD5-CK67X0N Please be notified that we, the undersigned, Honeywell International Inc declares that the product which bears the above FCC ID is also compliant with the FCC requirements for Supplier’s Declaration of Conformity(SDoC). And the SDoC procedure shall be carried out prior to marketing the device in the US. Sincerely, _________________ Name: Cindy Jiang Title: Global Regulatory Compliance Manager Date: July 25, 2024

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com Declaration of Authorization We Name: Honeywell International Inc Address: 9680 Old Bailes Rd. Fort Mill, SC 29707 United States Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: Mobile Computer FCC ID: HD5-CK67X0N Model No.: CK67X0N Sincerely, ________________ Name: Cindy Jiang Title: Global Regulatory Compliance Manager Date: 25 July 2024

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com Declaration letter We, Honeywell International Inc declares: For our business and marketing purpose, the product supports the following configures. All the configures use the same PCBA. They have the same schematics and PCB layout. Product information: Product Name: Mobile Computer Model: CK67X0N FCC ID: HD5-CK67X0N IC: 1693B-CK67X0N This product has 3 types of scanners and 5 types of keypads: Scanner S0703 S0803FR S0803 -- -- Keypad Alpha Numeric Numeric Large Numeric 53keys Alpha Numeric 42keys Numeric Sincerely, _________________ Name: Cindy Jiang Title: Global Regulatory Compliance Manager Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com Date: 09 August 2024

Report No.: 2405TW0107-UE 1 of 25 External Photograph (1) EUT Photo – S0703SR with Alpha (2) EUT Photoo –S0703SR with Alpha Report No.: 2405TW0107-UE 2 of 25 (3) EUT Photo –S0703SR with Alpha (4) EUT Photo –S0703SR with Alpha Report No.: 2405TW0107-UE 3 of 25 (5) EUT Photo –S0703SR with Alpha (6) EUT Photoo –S0703SR with Alpha Report No.: 2405TW0107-UE 4 of 25 (7) EUT Photo –S0703SR with Alpha (8) EUT Photoo –S0703SR with Alpha Report No.: 2405TW0107-UE 5 of 25 (9) EUT Photo –S0803FR with Alpha (10) EUT Photoo –S0803FR with Alpha Report No.: 2405TW0107-UE 6 of 25 (11) EUT Photo –S0803FR with Alpha (12) EUT Photoo –S0803FR with Alpha Report No.: 2405TW0107-UE 7 of 25 (13) EUT Photo –S0803FR with Alpha (14) EUT Photoo –S0803FR with Alpha Report No.: 2405TW0107-UE 8 of 25 (15) EUT Photo –S0803FR with Alpha (16) EUT Photoo –S0803XLR with Alpha Report No.: 2405TW0107-UE 9 of 25 (17) EUT Photo –S0803XLR with Alpha (18) EUT Photoo –S0803XLR with Alpha Report No.: 2405TW0107-UE 10 of 25 (19) EUT Photo –S0803XLR with Alpha (20) EUT Photoo –S0803XLR with Alpha Report No.: 2405TW0107-UE 11 of 25 (21) EUT Photo –S0803XLR with Alpha (22) EUT Photoo –S0803XLR with Alpha Report No.: 2405TW0107-UE 12 of 25 (23) EUT Photo –S0803XLR with Alpha Report No.: 2405TW0107-UE 13 of 25 (24) EUT Photo –Numeric (25) EUT Photoo –Numeric Report No.: 2405TW0107-UE 14 of 25 (26) EUT Photo –Numeric (27) EUT Photoo –Numeric Report No.: 2405TW0107-UE 15 of 25 (28) EUT Photo –Numeric (29) EUT Photoo –Numeric Report No.: 2405TW0107-UE 16 of 25 (30) EUT Photo – Large Numeric (31) EUT Photoo – Large Numeric Report No.: 2405TW0107-UE 17 of 25 (32) EUT Photo – Large Numeric (33) EUT Photoo – Large Numeric Report No.: 2405TW0107-UE 18 of 25 (34) EUT Photo – Large Numeric (35) EUT Photoo – Large Numeric Report No.: 2405TW0107-UE 19 of 25 (36) EUT Photo – 53keys (37) EUT Photoo - 53keys Report No.: 2405TW0107-UE 20 of 25 (38) EUT Photo – 53keys (39) EUT Photoo - 53keys Report No.: 2405TW0107-UE 21 of 25 (40) EUT Photo – 53keys (41) EUT Photoo - 53keys Report No.: 2405TW0107-UE 22 of 25 (42) EUT Photo - 42keys (43) EUT Photo - 42keys Report No.: 2405TW0107-UE 23 of 25 (44) EUT Photo - 42keys (45) EUT Photo - 42keys Report No.: 2405TW0107-UE 24 of 25 (46) EUT Photo - 42keys (47) EUT Photo - 42keys Report No.: 2405TW0107-UE 25 of 25 (48) EUT Photo (Brand: Honeywell, M/N: CK65-BTSC) (49) EUT Photo (Brand: Honeywell, M/N: CK65-BTSC)

CK67_Label location for WLAN SKU Label A : Label B Label C Label D Label E

PANTONE BLACK C. 12 PY_Chen MAY-02/24 CK67 AGENCY LABEL, COO VN TBD A TBD MAY-02/24 TBD RELEASE A (A) TBD WLAN SKU Brand Owner: Honeywell International Inc Marketing Prod. Series Name: CK67 sps.honeywell.com For patent information, see www.hsmpats.com Model/ : CK67X0N 型号/型號 Mobile Computer/ 无线数据终端/手持電腦 I/O port: 5V 2A USB-C port: 5V 3A (Std. Alpha) FCC ID:HD5-CK67X0N IC ID:1693B-CK67X0N CAN ICES (B) / NMB (B)

Report No.: 2405TW0107-UI 1 of 17 Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2405TW0107-UI 2 of 17 (3) EUT Photo (4) EUT Photo Report No.: 2405TW0107-UI 3 of 17 (5) EUT Photo (6) EUT Photo Report No.: 2405TW0107-UI 4 of 17 (7) EUT Photo (8) EUT Photo Report No.: 2405TW0107-UI 5 of 17 (9) EUT Photo (10) EUT Photo Report No.: 2405TW0107-UI 6 of 17 (11) EUT Photo (12) EUT Photo Report No.: 2405TW0107-UI 7 of 17 (13) EUT Photo (14) EUT Photo Report No.: 2405TW0107-UI 8 of 17 (15) EUT Photo (16) EUT Photo Report No.: 2405TW0107-UI 9 of 17 (17) EUT Photo (18) EUT Photo Report No.: 2405TW0107-UI 10 of 17 (19) EUT Photo (20) EUT Photo Report No.: 2405TW0107-UI 11 of 17 (21) EUT Photo (22) EUT Photo Report No.: 2405TW0107-UI 12 of 17 (23) EUT Photo (24) EUT Photo Report No.: 2405TW0107-UI 13 of 17 (25) EUT Photo (26) EUT Photo Report No.: 2405TW0107-UI 14 of 17 (27) EUT Photo (28) EUT Photo Report No.: 2405TW0107-UI 15 of 17 (29) EUT Photo (30) EUT Photo Report No.: 2405TW0107-UI 16 of 17 (31) EUT Photo (32) EUT Photo Report No.: 2405TW0107-UI 17 of 17 (33) EUT Photo (34) EUT Photo

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2024/7/31 System Check_Head_13MHz DUT: CLA13-1011 Communication System: UID 0, CW; Frequency: 13 MHz Medium: HSL_13_240731 Medium parameters used: f = 13 MHz; σ = 0.757 S/m; ε r = 53.4; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN3931; ConvF(18.48, 18.48, 18.48) @ 13 MHz; Calibrated: 2023/10/24 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn376; Calibrated: 2023/9/14 - Phantom: ELI V5.0 (20deg probe tilt); Type: QD OVA 001 BB; Serial: 1227 - Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7501) Pin=1000mW/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.779 W/kg Pin=1000mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 31.39 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 0.986 W/kg SAR(1 g) = 0.514 W/kg; SAR(10 g) = 0.319 W/kg Smallest distance from peaks to all points 3 dB below = 16 mm Ratio of SAR at M2 to SAR at M1 = 52.9% Maximum value of SAR (measured) = 0.771 W/kg 0 dB = 0.771 W/kg = -1.13 dBW/kg Date: 2024-07-05 System Check_Head_2450MHz DUT: D2450V2 - SN929 Communication System: CW ; Frequency: 2450.000 MHz Medium: HSL_2450_240705 Medium parameters used: f= 2450.000 MHz; σ= 1.84 S/m; ε r = 39.1 Ambient Temperature: 23.4°C; Liquid Temperature: 22.4°C DASY6 Configuration: - Probe: EX3DV4 - SN7625; ConvF(7.67, 7.67, 7.67); Calibrated: 2023-12-14 - Sensor-Surface: 1.4 mm - Electronics: DAE4 Sn376; Calibrated: 2023-09-14 - Phantom: ELI V8.0 (20deg probe tilt); Serial: 2192; Section: Flat - Measurement Software: 16.2.4.2524 - UID: CW Pin=17.0dBm/Area Scan (40.0 mm x 80.0 mm): Measurement Grid: 10.0 mm x 10.0 mm SAR (1g) = 2.31 W/kg; SAR (10g) = 1.10 W/kg; Pin=17.0dBm/Zoom Scan (30.0 mm x 30.0 mm x 30.0 mm): Measurement Grid: 5.0 mm x 5.0 mm x 1.5 mm Power Drift = 0.02 dB SAR (1g) = 2.36 W/kg; SAR (8g) = 1.25 W/kg; SAR (10g) = 1.13 W/kg Smallest distance from peaks to all points 3 dB below = 9.0 mm Ratio of SAR at M2 to SAR at M1 = 82.1 % Date: 2024-07-14 System Check_Head_2450MHz DUT: D2450V2 - SN929 Communication System: CW; Frequency: 2450.000 MHz Medium: HSL_2450_240714 Medium parameters used: f= 2450.000 MHz; σ= 1.84 S/m; ε r = 39.2 Ambient Temperature: 23.4°C; Liquid Temperature: 22.4°C DASY6 Configuration: - Probe: EX3DV4 - SN7813; ConvF(6.91, 7.0, 7.64); Calibrated: 2024-05-30 - Sensor-Surface: 1.4 mm - Electronics: DAE4 Sn1805; Calibrated: 2024-05-22 - Phantom: ELI V8.0 (20deg probe tilt); Serial: 2192; Section: Flat - Measurement Software: 16.2.4.2524 - UID: CW Pin=17.0dBm/Area Scan (40.0 mm x 80.0 mm): Measurement Grid: 10.0 mm x 10.0 mm SAR (1g) = 2.50 W/kg; SAR (10g) = 1.17 W/kg; Pin=17.0dBm/Zoom Scan (30.0 mm x 30.0 mm x 30.0 mm): Measurement Grid: 5.0 mm x 5.0 mm x 1.5 mm Power Drift = -0.02 dB SAR (1g) = 2.53 W/kg; SAR (8g) = 1.33 W/kg; SAR (10g) = 1.21 W/kg Smallest distance from peaks to all points 3 dB below = 9.0 mm Ratio of SAR at M2 to SAR at M1 = 80.8 % Date: 2024-07-04 System Check_Head_5250MHz DUT: D5GHzV2 - SN1006 Communication System: CW ; Frequency: 5250.000 MHz Medium: HSL_5G_240704 Medium parameters used: f= 5250.000 MHz; σ= 4.65 S/m; ε r = 35.5 Ambient Temperature: 23.5°C; Liquid Temperature: 22.5°C DASY6 Configuration: - Probe: EX3DV4 - SN7625; ConvF(5.48, 5.48, 5.48); Calibrated: 2023-12-14 - Sensor-Surface: 1.4 mm - Electronics: DAE4 Sn376; Calibrated: 2023-09-14 - Phantom: ELI V8.0 (20deg probe tilt); Serial: 2192; Section: Flat - Measurement Software: 16.2.4.2524 - UID: CW Pin=17.0dBm/Area Scan (40.0 mm x 80.0 mm): Measurement Grid: 10.0 mm x 10.0 mm SAR (1g) = 3.20 W/kg; SAR (10g) = 0.945 W/kg; Pin=17.0dBm/Zoom Scan (22.0 mm x 22.0 mm x 22.0 mm): Measurement Grid: 4.0 mm x 4.0 mm x 1.4 mm Power Drift = 0.08 dB SAR (1g) = 3.75 W/kg; SAR (8g) = 1.37 W/kg; SAR (10g) = 1.11 W/kg Smallest distance from peaks to all points 3 dB below = 7.4 mm Ratio of SAR at M2 to SAR at M1 = 66.1 % Date: 2024-07-06 System Check_Head_5250MHz DUT: D5GHzV2 - SN1006 Communication System: CW; Frequency: 5250.000 MHz Medium: HSL_5G_240706 Medium parameters used: f= 5250.000 MHz; σ= 4.64 S/m; ε r = 35.5 Ambient Temperature: 23.6°C; Liquid Temperature: 22.6°C DASY6 Configuration: - Probe: EX3DV4 - SN7625; ConvF(5.48, 5.48, 5.48); Calibrated: 2023-12-14 - Sensor-Surface: 1.4 mm - Electronics: DAE4 Sn376; Calibrated: 2023-09-14 - Phantom: ELI V8.0 (20deg probe tilt); Serial: 2192; Section: Flat - Measurement Software: 16.2.4.2524 - UID: CW Pin=17.0dBm/Area Scan (40.0 mm x 80.0 …

Text truncated - open the document above for the full version.
