HD5-CT4XVDWLSPKVehicle Dock

CHAPTER 12 CT4x Series Accessories User Guide57 WIRELESS VEHICLE DOCKS A Wireless Vehicle Dock securely fastens your device in a moving vehicle while also providing charging capabilities for wireless batteries. It has a hard-wired 3-pin power cable and can be used for a mobile computer with or without a protective boot. Features Holding Bay Power Cable/ Connector CT4X-VD-WL CT4X-VD-WL-SPK Speaker NFC Tag Adapter for use without protective boot Adapter for use without protective boot Power Cable/ Connector Holding Bay LED LED Screws to secure adapter Screws to secure adapter Preliminary Draft, Not for Release Preliminary Draft, Not for Release 58CT4x Series Accessories User Guide Out of the Box Make sure that your shipping box contains these items: •Wireless vehicle dock (CT4X-VD-WL or CT4X-VD-WL-SPK) •Adapter for use without protective boot •Product documentation If any of these items are missing or appear damaged, contact your Customer Account Representative. Keep the original packaging in the event that you need to return the wireless vehicle dock for service or if you want to store the wireless vehicle dock while not in use. RAM Attachment Plate Access for USB-C port on device (CT4X-VD-CNV only) Preliminary Draft, Not for Release Preliminary Draft, Not for Release CT4x Series Accessories User Guide59 Mount the Wireless Vehicle Dock You can mount a wireless vehicle dock to your vehicle with a RAM mount (sold separately). Mounting hardware required: •RAM mount •Appropriate screws and nuts Connect Power The vehicle to which you connect the wireless vehicle dock should supply 2 A to the computer. The operating temperature is -20 °C to 50 °C (-4 °F to 122 °F). The wireless vehicle dock requires a power adapter cable (sold separately). 1. Connect the wireless vehicle dock power cable to the power adapter cable and screw the two cables together. 2. Plug the power adapter into the power port on the vehicle. Power Adapter Power Cable/Connector Preliminary Draft, Not for Release Preliminary Draft, Not for Release 60CT4x Series Accessories User Guide Charge the Battery Pack 1. If your computer does not have a boot attached, insert the adapter into the wireless vehicle dock. Use the screws in the adapter to secure the adapter to the dock. If your computer has a boot attached, proceed to step 2. CT4X-VD-WL CT4X-VD-WL-SPK Preliminary Draft, Not for Release Preliminary Draft, Not for Release CT4x Series Accessories User Guide61 2. Insert the computer with a battery installed into the wireless vehicle dock. LED Indicator When the computer is placed in the wireless vehicle dock, the color of the LED on the dock indicates the charging status. •Green indicates the wireless battery is charging. •Red indicates an error when charging the wireless battery. Connect to the Speaker Model CT4X-VD-WL-SPK includes a speaker that you can use if Bluetooth and NFC are enabled on the computer. When the computer is placed in the wireless vehicle dock, the NFC tags in the dock and the computer pair both devices and create a Bluetooth audio connection. •To turn Bluetooth On or Off, go to Settings > Connected devices > Connection preferences > Bluetooth. •To turn NFC On or Off, go to Settings > Connected devices > Connection preferences > NFC. Preliminary Draft, Not for Release Preliminary Draft, Not for Release 62CT4x Series Accessories User Guide Disconnect the Speaker When the computer is removed from a CT4X-VD-WL-SPK wireless vehicle dock, the devices are unpaired and the speaker is disconnected. Note:After removing a computer from a CT4X-VD-CNV-SPK wireless vehicle dock, wait at least 5 seconds before reinserting it. This pause will allow time for audio to transfer from the computer speaker back to the dock speaker. About the Phone When the computer receives or makes a phone call while it is in a model CT4X-VD- WL-SPK, the speaker on the wireless vehicle dock will provide audio. Preliminary Draft, Not for Release Preliminary Draft, Not for Release Page 1 CT40-ACC-ML-RS-06 Rev ACT30 XP/CT40/CT40 XP/CT45/CT45 XP/CT47/CT60/CT60 XP/CW45 Accessories and EDA52 Display Dock and Ethernet/Net Bases Agency Models: CT40-HB, CT40-EB, CT40-CB, CT40-NB, CT30P-QBC, CT40-QBC, CT40-DB, CT40-SN, CT40-VD, CT45-VD, ME-5bay-CB, CW45-8675-CBL, CW45-USBC-CBL, CW45-EXT-KPD, CT4X-QBC, CT4X-VD-WL, CT4X-VD-WL-SPK Publicly downloadable certificates are available at honeywell.com/PSScompliance. Les certificats téléchargeables accessibles au public sont disponibles à honeywell.com/PSScompliance. Les certificats téléchargeables publiquement sont disponibles sur honeywell.com/PSScompliance. I certificati pubblicamente scaricabili sono disponibili sul sito Web honeywell.com/PSScompliance. Zertifikate stehen unter honeywell.com/ PSScompliance öffentlich zum Download zur Verfügung. Hay certificados descargables disponibles públicamente en honeywell.com/PSScompliance. Puede descargar los certificados de acceso público en honeywell.com/PSScompliance. Certificados disponíveis ao público para download em: honeywell.com/PSScompliance. 㥵꨽Ⱆ䒓♴鲿涸霆⛼霼霄꡼ honeywell.com/PSScomplianceկ 㥶꨾〳ⰗꟚ♴鯺涸阮剅锞鸤鏞 honeywell.com/PSScompliance ծכ鏾僇剅ז〳腉س٦ٗٝؐتח♧菙 honeywell.com/PSScompliance דⵃ欽〳 կׅד腉 뫃맪헏픊옪삲풂옪슪많쁳핆흫컪쁢 honeywell.com/PSScompliance 펞컪묺쿦핖킃삖삲 .       honeywell.com/PSScompliance. الشهادات القابلة للنزيل ماحة للعامة عل الموقع honeywell.com/PSScompliance. Product documentation is available at sps.honeywell.com. La documentation sur le produit est disponible à sps.honeywell.com. La documentation du produit est disponible sur le site sps.honeywell.com. La documentazione sul prodotto è disponibile sul sito sps.honeywell.com. Die Produktdokumentation ist unter sps.honeywell.com verfügbar. La documentación del producto está disponible en sps.honeywell.com. La documentación del producto está disponible en sps.honeywell.com. A documentação do produto está disponível em sps.honeywell.com. ❡ᄩ俒咓霼⿬錛 sps.honeywell.comկ 欴ᄩ俒⟝꧌锞⿮鋅 sps.honeywell.com כزًٝ…

Text truncated - open the document above for the full version.

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 04-03-2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing and Part 2.911(d)(5)(ii) Filing FCC ID: HD5-CT4XVDWLSPK 1. Honeywell International Inc (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Honeywell International Inc (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Applicant signature: Applicant printed name: Cindy Jiang

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 04-03-2024 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: HD5-CT4XVDWLSPK Honeywell International Inc (“the applicant”) certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: FRN: 0022970339 Name: HONEYWELL INTERNATIONAL INC Address: 9680 OLD BAILES RD, FORT MILL, SC 29707, United States Contact Person: Cindy Jiang Tel.: (704) 627-6011 Email: [email protected] Sincerely, Honeywell International Inc Cindy Jiang, Global Regulatory Compliance Manager Applicant signature:

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: HD5-CT4XVDWLSPK Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________ Name: Cindy Jiang Title: Global Regulatory Compliance Manager Date: 2024-04-03

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com Declaration of Authorization We Name: Honeywell International Inc Address: 9680 Old Bailes Rd. Fort Mill, SC 29707 United States Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: Vehicle Dock FCC ID: HD5-CT4XVDWLSPK Model No.: CT4X-VD-WL-SPK Sincerely, _ ________________ Name: Cindy Jiang Title: Global Regulatory Compliance Manager Date: 2024-04-03

Report No.: 2403RSU013-UE 1 of 3 External Photograph (1) EUT Photo (2) EUT Photo Report No.: 2403RSU013-UE 2 of 3 (3) EUT Photo (4) EUT Photo Report No.: 2403RSU013-UE 3 of 3 (5) EUT Photo (6) EUT Photo

SCALE 1:1 Material No.: 3014-7648-001 Speaker version PN: XXXXXXXXXX SN: XXXXXXXXXX Brand owner:Honeywell International Inc www.automation.honeywell.com Patent: www.hsmpats.com Vehicle Dock/车载充电底座 Made In China/中国制造 Model/型号: CT4X-VD-WL-SPK Inpit/输入: 12/24V DC FCC ID: HD5-CT4XVDWLSPK IC: 1693B-CT4XVDWLSPK Label area SPK SKU

Report No.: 2403RSU013-UE 1 of 9 EUT Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2403RSU013-UE 2 of 9 (3) EUT Photo (4) EUT Photo Report No.: 2403RSU013-UE 3 of 9 (5) EUT Photo (6) EUT Photo Report No.: 2403RSU013-UE 4 of 9 (7) EUT Photo (8) EUT Photo Report No.: 2403RSU013-UE 5 of 9 (9) EUT Photo (10) EUT Photo Report No.: 2403RSU013-UE 6 of 9 (11) EUT Photo (12) EUT Photo Report No.: 2403RSU013-UE 7 of 9 (13) EUT Photo (14) EUT Photo Report No.: 2403RSU013-UE 8 of 9 (15) EUT Photo (16) EUT Photo Report No.: 2403RSU013-UE 9 of 9 (17) EUT Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 2403RSU013-U5 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 2024-04-07 Template Version:0.0 1 of 12 RF MEASUREMENT REPORT FCC ID: HD5-CT4XVDWLSPK Applicant: Honeywell International Inc Honeywell Safety and Productivity Solutions Product: Vehicle Dock Model No.: CT4X-VD-WL-SPK Brand Name: Honeywell FCC Rule Part(s): FCC Part 2.1091 Result: Complies Test Date: 2024-03-22 ~ 2024-04-05 Reviewed By: Jame Yuan Approved By: Robin Wu The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2403RSU013-U5 2 of 12 Revision History Report No. Version Description Issue Date Note 2403RSU013-U5 V01 Initial Report 2024-04-07 Valid Report No.: 2403RSU013-U5 3 of 12 CONTENTS Description Page 1. General Information ................................................................................................................................ 4 1.1. Applicant ...................................................................................................................................... 4 1.2. Manufacturer ................................................................................................................................ 4 1.3. Testing Facility ............................................................................................................................. 4 1.4. Product Information ...................................................................................................................... 5 1.5. Radio Specification ...................................................................................................................... 5 2. Measuring Instrument ............................................................................................................................. 6 3. Measurement Uncertainty ....................................................................................................................... 7 4. Test Result ................................................................................................................................................ 8 4.1. Test Limits .................................................................................................................................... 8 4.2. Test Mode ..................................................................................................................................... 9 4.3. Test Setup .................................................................................................................................... 9 4.4. Test Environment Condition ......................................................................................................... 9 4.5. Test Result ................................................................................................................................. 10 4.6. Simultaneous Exposure Analysis ............................................................................................... 12 Report No.: 2403RSU013-U5 4 of 12 1. General Information 1.1. Applicant Honeywell International Inc Honeywell Safety and Productivity Solutions 9680 Old Bailes Rd. Fort Mill, SC 29707 United States 1.2. Manufacturer Honeywell International Inc Honeywell Safety and Productivity Solutions 9680 Old Bailes Rd. Fort Mill, SC 29707 United States 1.3. Testing Facility Test Site – MRT Suzhou Laboratory Laboratory Location (Suzhou - Wuzhong) D8 Building, No.2 Tian’edang Rd., Wuzhong Economic Development Zone, Suzhou, China Laboratory Location (Suzhou - SIP) 4b Building, Liando U Valley, No.200 Xingpu Rd., Shengpu Town, Suzhou Industrial Park, China Laboratory Accreditations A2LA: 3628.01 CNAS: L10551 FCC: CN1166 ISED: CN0001 VCCI: R-20025 G-20034 C-20020 T-20020 R-20141 G-20134 C-20103 T-20104 Test Site – MRT Shenzhen Laboratory Laboratory Location (Shenzhen) 1G, Building A, Junxiangda Building, Zhongshanyuan Road West, Nanshan District, Shenzhen, China Laboratory Accreditations A2LA: 3628.02 CNAS: L10551 FCC: CN1284 ISED: CN0105 Test Site – MRT Taiwan Laboratory Laboratory Location (Taiwan) No. 38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: 3261 FCC: 291082, TW3261 ISED: TW3261 Report No.: 2403RSU013-U5 5 of 12 1.4. Product Information Product Name Vehicle Dock Model No. CT4X-VD-WL-SPK EUT Identification No. 20240307Sample#07 Brand Name Honeywell WPT Specification 144kHz NFC Specification 13.56MHz(tag) Bluetooth Specification V5.0 (Dual Mode) Antenna Information Refer to Section 1.5 Power Voltage 12/24VDC Operating Temperature -20 ~ 50°C Note: The information of EUT was provided by the manufacturer, and the accuracy of the information shall be the responsibility of the manufacturer. 1.5. Radio Specification Frequency Range 144kHz Modulation ASK Antenna Type Coil Antenna Note: For other features of this EUT, test report will be issued separately. Report No.: 2403RSU013-U5 6 of 12 2. Measuring Instrument Instrument Manufacturer Model No. Asset No. Cali. Interval Cali. Due Date Test Site Broadband Field Meter narda NBM 550 MRTSUE06897 3 years 2026-10-26 SIP-AC1 B-Field Probe narda 100 cm² MRTSUE06919 3 years 2026-10-29 SIP-AC1 Exposure Level Tester narda ELT-400 MRTSUE06920 3 years 2026-10-29 SIP-AC1 H-Field Probe narda HF 3061 MRTSUE06921 3 years 2026-10-26 SIP-AC1 Thermohygrometer testo 608-H1 MRTSUE06616 1 year 2024-10-28 SIP-AC1 Report No.: 2403RSU013-U5 7 of 12 3. Measurement Uncertainty Magnetic Field Emissions (A/m) 1Hz-10Hz: 12.74% 10Hz-120kHz: 2.91% 120kHz-400kHz: 3.98% Electric Field Emissions (V/m) 100kHz-6.5GHz: 39.42% Report No.: 2403RSU013-U5 8 of 12 4. Test Result 4.1. Test Limits §1.13…

Text truncated - open the document above for the full version.

MRT Technology (Suzhou) Co., Ltd Report No.: 2403RSU013-U3 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 2024-03-29 Template Version:0.0 1 of 22 RF MEASUREMENT REPORT FCC ID: HD5-CT4XVDWLSPK Applicant: Honeywell International Inc Honeywell Safety and Productivity Solutions Product: Vehicle Dock Model No.: CT4X-VD-WL-SPK Brand Name: Honeywell FCC Classification: Part 15 Low Power Transmitter Below 1705 kHz (DCD) FCC Rule Part(s): Part15 Subpart C (Section 15.209) Result: Complies Received Date: 2024-03-07 Test Date: 2024-03-16 ~ 2024-03-20 Reviewed By: Jame Yuan Approved By: Robin Wu The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2013. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2403RSU013-U3 2 of 22 Revision History Report No. Version Description Issue Date Note 2403RSU013-U3 V01 Initial Report 2024-03-29 Valid Report No.: 2403RSU013-U3 3 of 22 CONTENTS Description Page 1. General Information ................................................................................................................................ 5 1.1. Applicant ...................................................................................................................................... 5 1.2. Manufacturer ................................................................................................................................ 5 1.3. Testing Facility ............................................................................................................................. 5 1.4. Product Information ...................................................................................................................... 6 1.5. Radio Specification under Test .................................................................................................... 6 2. Test Configuration ................................................................................................................................... 7 2.1. Test Mode ..................................................................................................................................... 7 2.2. Test System Connection Diagram................................................................................................ 7 2.3. Applied Standards ........................................................................................................................ 8 2.4. Test Environment Condition ......................................................................................................... 8 3. Antenna Requirements ........................................................................................................................... 9 4. Measuring Instrument ........................................................................................................................... 10 5. Decision Rules and Measurement Uncertainty .................................................................................. 11 5.1. Decision Rules ............................................................................................................................ 11 5.2. Measurement Uncertainty ........................................................................................................... 11 6. Test Result .............................................................................................................................................. 12 6.1. Summary .................................................................................................................................... 12 6.2. 20dB Bandwidth Measurement .................................................................................................. 13 6.2.1. Test Limit .................................................................................................................................... 13 6.2.2. Test Procedure ........................................................................................................................... 13 6.2.3. Test Setting ................................................................................................................................ 13 6.2.4. Test Setup .................................................................................................................................. 13 6.2.5. Test Result ................................................................................................................................. 13 6.3. General Field Strength Measurement ........................................................................................ 14 6.3.1. Test Limit .................................................................................................................................... 14 6.3.2. Test Procedure ........................................................................................................................... 14 6.3.3. Test Setting ................................................................................................................................ 14 6.3.4. Test Setup .................................................................................................................................. 15 6.3.5. Test Result ................................................................................................................................. 16 6.4. AC Conducted Emissions Measurement ................................................................................... 17 6.4.1. Test Limit ...............................................................................................................................…

Text truncated - open the document above for the full version.

AmphenolMobileConsumerProducts Amphenol ApprovalSheet C-9184-15-000-13 CUSTOMER:Honeywell FINEP/N:C-9184-15-000-13 DESC:TXMODULE DATE:2024-04-07 VERSION:TA PREPAREDBYCHECKEDBYAPPROVEDBYCUSTOMERAPPROVE ETHANCAIKARSONDAIJIMMYHE AmphenolMobileConsumerProducts 1.CoilOverview 2.MechanicalSpecifications Size 42.5*54.75*3.4mm CableType 155#Class,E345710.φ0.1mm×120Strands酒精/丙酮自粘 丝包线 WindingSpecification AFA ， 7TsX2layer Storagecondition STORAGETEMPERATURERANGE:20°C～25°C; STORAGEHUMIDITYRANGE:≤70%; STORAGEPERIOD:6~12Months Manufacturingsiteandaddress No.158ZhongGangRd,XiTangGermanIndestrialPark HaiyanCounty,Zhejiang,PRChina,314300 Operatingtemperaturerange －20°C～＋85°C 3.MechanicalDrawing AmphenolMobileConsumerProducts AmphenolMobileConsumerProducts 4.Electricalcharacteristics ITEMUNITINSTRUMENTCONDITIONSVALUES Ls μH IM-3532100KHz/1V 14.44±0.25 Ls/ ≥180 DCR mΩ25°C 29REF 5.Windingspecification WIRETURNSMETHOD 155#Class,E345710. φ0.1mm×120Strands酒精/ 丙酮自粘丝包线 7Ts×2LayerAFA

Report No.: 2403RSU013-UT FCC 15.247 Test Setup Photograph Description: Radiated Spurious Emission Test Setup for 9kHz ~ 30MHz Description: Radiated Spurious Emission Test Setup for 30MHz ~ 1GHz Report No.: 2403RSU013-UT Description: Radiated Spurious Emission Test Setup for 1GHz ~ 18GHz Description: Radiated Spurious Emission Test Setup for 18GHz ~ 25GHz Report No.: 2403RSU013-UT Description: Conducted Test Setup Report No.: 2403RSU013-UT FCC 15.209 Test Setup Photograph Mode 1 Description: Radiated Spurious Emission Test Setup for 9kHz ~ 30MHz Mode 1 Description: Radiated Spurious Emission Test Setup for 30MHz ~ 1GHz Report No.: 2403RSU013-UT Mode 2 Description: Radiated Spurious Emission Test Setup for 9kHz ~ 30MHz Mode 2 Description: Radiated Spurious Emission Test Setup for 30MHz ~ 1GHz Report No.: 2403RSU013-UT MPE Test Setup Photograph Mode 1 Description: RF Exposure Test Setup for Electric Field Emissions Mode 2 Description: RF Exposure Test Setup for Electric Field Emissions Report No.: 2403RSU013-UT Mode 1 Description: RF Exposure Test Setup for Magnetic Field Emissions Mode 2 Description: RF Exposure Test Setup for Magnetic Field Emissions
