HD5-EDA51K0Mobile Computer

ScanPal EDA51K Mobile Computer 5 Charging/Synchronization Please check to see if it contains the following items: Mounting Main Battery Synchronizing communication •ScanPal EDA51K Mobile Computer; •Main battery (3.8V, lithium-ion battery); •10W battery adapter; •Interchangeable adapter plug; •USB power cable; •Basic Guide Note: If you have ordered accessories for your terminal, please check that the accessories are also included in the packing. Please retain the original packing at all times. This is to facilitate return of ScanPal EDA51K terminal for maintenance or repair. Disclaimer: The manufacturer shall not be held responsible for any consequences arising from the user’s failure to follow the above recommendations or erroneous use of the mobile phone. Our product's operating system supports updates in official system. If the user adopts a third-party ROM system or make any revisions to the operating system through for example jail breaking, the system may be rendered unstable, in which case our company will not provide support to the user or bear any responsibility. EDA51K-0/EDA51K-1 is a part of ScanPal EDA51K series Use of wrong model of battery will pose a threat of explosion. Please dispose used battery according to instructions and local regulations. As far as possible dispose of the battery as product for recycling; do not dispose of it as normal thrash. Please ensure that all the component parts are dry before connecting the terminal/battery to external equipment. Damage to the equipment due to connection using wet parts is not covered by warranty. EDA51K is equipped with a battery which comes in separate packing. Please install the battery in accordance with the following steps. 1. Press the battery cover’s safety button and move it to the right unlocking position; 2. Remove the battery cover using its locking latch; 3. Insert the battery (first insert the battery at the battery connector end before pressing the rest of the battery to ensure that the battery is connected to the mobile phone); 4. Press the battery cover (first insert the part of the battery cover away from the battery connector before inserting the rest of the battery cover); 5. Move the battery safety to the left side locking position. Note: Please refer to the illustration on the next page on installation of battery. Press the battery cover before sliding the battery locking button towards the right to unlock it 1.Unlock the USB cover at the base of ScanPal EDA51K; 2.Connect ScanPal EDA51K with the computer using the USB charging cable Press the battery cover before sliding the battery cover locking button towards Press the left to lock it Press USB cover USB charging cable EDA51K -SC-QS Rev A 2020/09/09 EDA51K-0 EDA51K-1 Rear panel Camera lens Scanning engine Loudspeaker Battery cover safety lock Batter cover safety button Battery cover Cord lock J K I L Distance/light sensing Front panel Power indicator light Display screen Function key Function key Home key Return key Power key Self-definition key Scanner key Microphone jack Scan indicator light Quick Guide Remove the packing Left sideRight side Base Scanner key Scanner key Volume + Volume – Charging point USB Cover 5 Charging/Synchronization Charging 1.Unlock the USB cover at the base of ScanPal EDA51K; 2.Use USB charging cable to connect ScanPal EDA51K with power adapter; 3.Ensure that the interchangeable adapter is plugged into the power adapter; 4.Connect the power adapter to wall socket and begin charging ScanPaul EDA51K battery Using scanning engine Aim the beam at the bar code and adjust the angle between it and the bar code to obtain the best effect. The recommended distance between the device and the bar code is 4-10 inches (10-25 cm). 1.Click demo application on the interface and select the demo program; 2.Click ‘scan’ on the screen, or press the scanner key; 3.Aim ScanPaul EDA51K terminal at the bar code; 4.Adjust the aiming beam. To obtain the best performance one should avoid very small angle. By way of scanning the bar code's reflect, slowly move the aiming beam along the bar code; 5.The terminal will emit buzzer when decoding of the bar code is successful; this means information on the bar code has been captured by the terminal. Aiming beam The aiming beam becomes narrow when the terminal is close to bar code; conversely it becomes wider. When the bar code's measurement is smaller, the aiming beam must be closer to the bar code Conversely the aiming beam must be further away from the bar code. Technical Support For information on technical support, product after-sales service and repairs 2D image scanning beam position please visit: www.honeywellaidc.com User file For the version of this document in local language please visit: www.honeywellaidc.com. Patents For information on patents please refer to: www.honeywellaidc.com/patents. Duration of warranty repair Please visit: www.honeywellaidc.com/warranty_information To obtain information on warranty repair for your product. Disclaimer Honeywell International Inc. (HII) reserves the right to change the specifications and other information without notice. Under any circumstances the reader should check whether any such changes have been made. The information contained herein does not tantamount to any warranties/undertaking made by HII. HII shall not bear any direct or indirect losses for any technical or editorial error and omission. The text in this file contains proprietary information protected by copyright. Photocopying or duplication of any contents herein or translation of such contents into other languages is prohibited without HII’s prior written consent. Before using ScanPaul EDA51K terminal, charge it for at least 4 hours in accordance with its battery model using ScanPaul EDA51K charger. Note: Use of Honeywell’s external device, battery, USB charging cable and power adapter is recommended. Any damage caused to this product as a result of use of the above accessories that are not f…

Text truncated - open the document above for the full version.

Honeywell International Inc Honeywell Safety and Productivity Solutions 9680 Old Bailes Rd. Fort Mill, SC 29707 United States 9680 Old Bailes Rd. Fort Mill, SC 29707 United States ATTESTATION Date: Nov 20, 2020 Federal Communications Commission Authorization and Evaluation Division FCC ID: HD5-EDA51K0 Product: Mobile Computer Model: EDA51K-0 We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA. Sincerely, Name: Mandana Salahshour Position: Compliance Manager Honeywell International Inc Honeywell Safety and Productivity Solutions

Honeywell International Inc Honeywell Safety and Productivity Solutions 9680 Old Bailes Rd. Fort Mill, SC 29707 United States 9680 Old Bailes Rd. Fort Mill, SC 29707 United States Declaration of Authorization We Name: Honeywell International Inc Honeywell Safety and Productivity Solutions Address: 9680 Old Bailes Rd. Fort Mill, SC 29707 United States Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone, City: Suzhou Country China is authorized to apply for Certification of the following product(s): Product description: Mobile Computer Type designation: EDA51K-0 Trademark: Honeywell on our behalf. Date: Nov 20, 2020 Name: Mandana Salahshour Signature:

Honeywell International Inc Honeywell Safety and Productivity Solutions 9680 Old Bailes Rd. Fort Mill, SC 29707 United States 9680 Old Bailes Rd. Fort Mill, SC 29707 United States Date: Nov 20, 2020 Federal Communications Commission Authorization and Evaluation Division FCC ID: HD5-EDA51K0 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description Turn-up Information The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Name: Mandana Salahshour Position: Compliance Manager Honeywell International Inc Honeywell Safety and Productivity Solutions / BOM Li ist

Honeywell International Inc Honeywell Safety and Productivity Solutions 9680 Old Bailes Rd. Fort Mill, SC 29707 United States 9680 Old Bailes Rd. Fort Mill, SC 29707 United States Date: Nov 20, 2020 Federal Communications Commission Authorization and Evaluation Division FCC ID: HD5-EDA51K0 To Whom It May Concerm: This letter is to ascertain that the following information of applicant, product with model(s) have been the units used for conducting FCC compliance testing, the sDoC part will be tested by FCC recognized test lab. Product: Mobile Computer Model: EDA51K-0 If you have any question or concerns, pls. contact us. Signature: Name: Mandana Salahshour Position: Compliance Manager Honeywell International Inc Honeywell Safety and Productivity Solutions

Honeywell International Inc Honeywell Safety and Productivity Solutions 9680 Old Bailes Rd. Fort Mill, SC 29707 United States Non-SDR (Software Defined Radio) Cover Letter Date: July 20, 2020 Refer to KDB 442812 D01 SDR apps Guide v02r03. The following six questions can be used for determining if a radio can elect to be, or must be an SDR. 1. Can the RF parameters of the device be altered through software? Yes - go to 2. No, not an SDR Reply: Yes 2. Can third parties not permitted by the Commission through specific filings modify, configure, or load different software, or make configuration settings to operate the device or host hardware radio frequency parameters (frequency range, modulation type, maximum output power or other radio parameters) in any other way than granted (or expected to be granted)? Yes, must be an SDR. No - go to 3. Reply: No 3. Is the device capable of operating in any other in any other way Honeywell International Inc Honeywell Safety and Productivity Solutions 9680 Old Bailes Rd. Fort Mill, SC 29707 United States than granted, or will be, granted? Yes, - go to 4. No - go to 5. Reply: No 4. Is this a Part 15 client Device as defined in Section 15.202 (as opposed to a master device)? Yes, qualifies as a part 15 client devices - go to 5. No, must be an SDR. 5. Does the manufacturer elect SDR? Yes, elects to be an SDR. No, Not an SDR Reply: No Final conclusion: This product shall be approval as a Non-SDR which is declared by the applicant. Sign by: Print Name: Mandana Salahshour Title: Product Compliance

Report No.: 2011RSU005-UE 1 of 5 External Photo (1) EUT Photo (2) EUT Photo Report No.: 2011RSU005-UE (3) EUT Photo (4) EUT Photo Report No.: 2011RSU005-UE (5) EUT Photo (N6703 Engine) (6) EUT Photo (N3603 Engine) Report No.: 2011RSU005-UE (7) EUT Photo (8) EUT Photo Report No.: 2011RSU005-UE (9) EUT Photo (10) EUT Photo

Honeywell International Inc Honeywell Safety and Productivity Solutions 9680 Old Bailes Rd. Fort Mill, SC 29707 United States Label Location

Report No.: 2011RSU005-UE 1 of 11 Internal Photo (1) EUT Photo (2) EUT Photo Report No.: 2011RSU005-UE (3) EUT Photo (4) EUT Photo Report No.: 2011RSU005-UE (5) EUT Photo (6) EUT Photo Report No.: 2011RSU005-UE (7) EUT Photo (8) EUT Photo Report No.: 2011RSU005-UE (9) EUT Photo (10) EUT Photo Report No.: 2011RSU005-UE (11) EUT Photo (12) EUT Photo (N6703 Engine) Report No.: 2011RSU005-UE (13) EUT Photo (N3603 Engine) (14) EUT Photo Report No.: 2011RSU005-UE (15) EUT Photo (16) EUT Photo Report No.: 2011RSU005-UE (17) EUT Photo (18) EUT Photo Report No.: 2011RSU005-UE (19) EUT Photo (20) EUT Photo Report No.: 2011RSU005-UE (21) EUT Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 2011RU005-U7 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 11-22-2020 Page Number: 1 of 70 FCC ID: HD5-EDA51K0 Applicant: Honeywell International Inc. Honeywell Safety and Productivity Solutions Application Type: Certification Product: Mobile Computer Model No.: EDA51K-0 Brand Name: Honeywell FCC Rule Part(s): FCC 47 CFR Part 2.1093 Test Procedure(s): IEEE 1528: 2013 IEEE C95.1- 2005 Test Date: November 18 ~ 20, 2020 SAR MEASUREMENT REPORT Reviewed By: ( Jame Yuan ) Approved By: ( Robin Wu ) The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in IEEE1528, KDB 447498 and KDB 865664. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2011RSU005-U7 Page Number: 2 of 70 Revision History Report No. Version Description Issue Date Note 2011RSU005-U7 Rev. 01 Initial report 11-22-2020 Valid Report No.: 2011RSU005-U7 Page Number: 3 of 70 CONTENTS Description Page 1. General Information ............................................................................................................... 5 1.1. Applicant ....................................................................................................................... 5 1.2. Manufacturer ................................................................................................................ 5 1.3. Testing Facility .............................................................................................................. 5 2. Product Information ............................................................................................................... 6 2.1. General Description ...................................................................................................... 6 2.2. Product Specification Subjective to this Report ............................................................. 6 2.3. Description of Available Antennas ................................................................................ 7 2.4. Ancillary Equipment ...................................................................................................... 7 3. Summary of Test Result ........................................................................................................ 8 3.1. Test Standards ............................................................................................................. 8 3.2. Environment Condition ................................................................................................. 8 3.3. RF Exposure Limits ...................................................................................................... 8 3.4. Test Result Summary ................................................................................................... 9 4. Specific Absorption Rate (SAR).......................................................................................... 10 4.1. Introduction ................................................................................................................. 10 4.2. Definition .................................................................................................................... 10 5. DASY6 Measurement System ............................................................................................. 11 5.1. Introduction ................................................................................................................. 11 5.2. DASY6 Measurement System Diagram ...................................................................... 11 5.3. System Components Details ....................................................................................... 12 6. The SAR Measurement Procedure ..................................................................................... 23 6.1. Measurement Process Diagram.................................................................................. 23 6.2. Test Position Definition ............................................................................................... 24 6.3. Test Procedure ........................................................................................................... 27 7. System Verificaiton.............................................................................................................. 29 7.1. Tissue Check .............................................................................................................. 29 7.2. System Check ............................................................................................................ 32 8. Analysis and Results ........................................................................................................... 34 8.1. Antenna Location ........................................................................................................ 34 8.2. Conducted Power ....................................................................................................... 35 8.3. SAR Exclusion Analysis .............................................................................................. 38 Report No.: 2011RSU005-U7 Page Number: 4 of 70 8.4. SAR Test Results ....................................................................................................... 39 8.5. Estimated SAR Calculation ......................................................................................... 44 9. Simultaneous Transmission Analysis ................................................................................ 45 10. Test Equipment Used .......................................................................................................... 46 11. Measurem…
