HD5-RT10AL0NRT10A

RT10A Rugged Tablet powered by Android™ Quick Start Guide RT10A-EN-QS-01-AG Rev a 8/20 1 Out of the Box Make sure that your shipping box contains these items: • RT10A rugged tablet  (Model RT10AL0N or RT10AL1N) • Power supply (power cord sold separately) •Stylus • USB cable • Product documentation If you ordered accessories for your tablet, verify that they are also included with the order. Be sure to keep the original packaging in case you need to return the tablet for service. Note:RT10AL0N models do not include a WWAN radio. Memory Card Specifications Honeywell recommends the use of Single Level Cell (SLC) industrial-grade microSD™ or microSDXC™ memory cards with RT10 tablets for maximum performance and durability. Contact a Honeywell sales representative for additional information on qualified memory card options. 2 Tablet Features Microphone Touch Screen Home Button Fn1 Button Power Button Front Camera Kensington Lock Port Barcode Scanner  (model dependent) I/O Cover Light Sensor and  LED Indicators: -Wi-Fi -Link -Battery -Power I/O Panel (I/O cover open) Power Jack Audio Jack USB-A Port MicroSD Card Slot USB-C Port 3 Warning: To avoid possible hearing damage, do not listen at high volume levels for long periods. Camera Flash Micro SIM Card Cover/Slot Speaker Battery Speaker Docking Connector Battery Lock Battery Release Stylus Rear Camera Fn2 Button Volume/ Brightness Button Extension Port (cover not shown) Laser Safety Label Location (model dependent) 4 Install a Micro SIM Card Only RT10AL1N (WWAN) models support micro SIM card use for cellular phone features. 6 12 34 5 5 Note:Always power off the tablet before attempting to install or remove a card. Install a microSD Card (Optional) Note:Format the microSD card before initial use. Note:Always power off the tablet before attempting to install or remove a card. 7 1 2 6 Install the Battery The tablet ships with a Li-poly 7.7 VDC, 45.43 watt-hour battery manufactured for Honeywell International Inc. Charge the Tablet The RT10 rugged tablet ships with a partially charged battery. Charge the battery for a minimum of 1.5 hours. Using the tablet while charging the battery increases the time required to reach a full charge. 2 4 3 1 7 Turn the Power On or Off To turn the tablet on: •Press and hold the Power button for approximately 3 seconds until the blue LED power indicator lights up. To turn the tablet off: 1.Press and hold the Power button until the options menu appears. 2.Touch Power off. We recommend use of Honeywell Li-poly or Li-ion battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty. Ensure all components are dry prior to placing the battery in the computer. Mating wet components may cause damage not covered by the warranty. We recommend the use of Honeywell accessories and power adapters. Use of any non-Honeywell accessories or power adapters may cause damage not covered by the warranty. 12 8 Battery Replacement Hot Swap You can replace the battery on demand provided the following conditions are met: • The tablet has been powered on for at least 4 minutes. AND • You insert a new battery within 30 seconds. Swap Battery Mode Swap Battery mode places the tablet in a low power state so that the battery can be removed for a short time. To activate Swap Battery mode: 1.Press and hold the Power button until the options menu appears. 2.Touch Swap Battery and follow the on-screen instructions. 3.Once you replace the battery, press the Power button. Sleep Mode Sleep mode automatically turns the touch panel display off and locks the tablet to save battery power when the tablet is inactive for a programmed period of time. 1.Press and release the Power button to wake the tablet. 2.Drag the toward the top of the display to unlock the tablet. 9 Adjust the Display Sleep Time To adjust the amount of time before the display sleeps after inactivity: 1.Swipe up from the bottom of the Home screen to access all apps. 2.Touch Settings > Display > Advanced > Sleep. 3.Select the amount of time before the display goes to sleep. 4.Touch to return to the Home screen. About the Home Screen Notification / Status Bar Search Bar Home Screen  Panel Favorites Tray Navigation  Buttons 10 Navigation and Function Buttons For button locations, see Tablet Features. About Provisioning Mode After completing the out-of-box set up process, Provisioning mode is automatically turned off. Scanning a barcode to install applications, certificates, configuration files, and licenses on the tablet is restricted unless you enable Provisioning mode in the Settings app. To learn more, see the user guide. Scan a Barcode with the Scan Demo Note:For optimum performance, avoid reflections by scanning the barcode at a slight angle. 1.Swipe up from the bottom of the Home screen to access all apps. 2.Touch Demos > Scan Demo. ButtonDescription BackReturn to the previous screen. HomeReturn to the Home screen. Recent AppsView and switch between recently used apps. ScanPress the Fn2 button to trigger the scanner. Fn 11 3.Point the tablet at the barcode. 4.Press SCAN or the Fn2 button. Center the aiming beam over the barcode. 5.Release the button. The decode results appear on the screen. Note:In the Scan Demo app, not all barcode symbologies are enabled by default. If a barcode does not scan, the correct symbology may not be enabled. To learn how to modify the default app settings, see the user guide. Sync Data To move files between your RT10A and a computer: 1.Connect the RT10A to your computer using a USB charge/ communication accessory. 2.On the RT10A, swipe down from the top of the screen to see the notifications panel. 3.Touch the Android System notification twice, to open the options menu. 4.Select either File Transfer or PTP. 5.Open the file browser on your computer. 12 6.Browse to the RT10A. You can now copy, delete and move files or folders between the computer and RT10A as you would with any other storage drive (e.g., cut and paste or…

Text truncated - open the document above for the full version.

Page 1 R T10-ML-RS-01-AG Rev C RT10 Rugged Tablet Agency Models: RT10AL0N, RT10AL1N Product documentation is available at www.honeywellaidc.com. La documentation sur le produit est disponible à www.honeywellaidc.com. La documentation du produit est disponible sur le site www.honeywellaidc.com. La documentazione sul prodotto è disponibile sul sito www.honeywellaidc.com. Die Produktdokumentation ist unter www.honeywellaidc.com verfügbar. La documentación del producto está disponible en www.honeywellaidc.com. La documentación del producto está disponible en www.honeywellaidc.com. A documentação do produto está disponível em www.honeywellaidc.com. 卟嵶篑肑霼寫錛 www.honeywellaidc.comㄌ 欴嵶篑璠꧌锞羼鋅 www.honeywellaidc.com 醡嵶㇘ㆷ(ᄀ)ㇼ(가)㇗ᄭ www.honeywellaidc.com ᄞ 蝝霶豸腉ᄞᅵㄌ 헪컲졓컪쁢 www.honeywellaidc.com펞컪핆 쿦핖킃삖삲 . Документацию по изделию можно найти на сайте www.honeywellaidc.com. Ürün belgelerine www.honeywellaidc.com adresinden ulaşılabilir. ر وثائق المنتج على الموقع ّتتوف التالي .www.honeywellaidc.com בכתובת זמין המוצר תיעוד www.honeywellaidc.com. Publicly downloadable certificates are available at www.honeywellaidc.com/ compliance. Les certificats téléchargeables accessibles au public sont disponibles à www.honeywellaidc.com/ compliance. Les certificats téléchargeables publiquement sont disponibles sur www.honeywellaidc.com/ compliance. I certificati pubblicamente scaricabili sono disponibili sul sito Web www.honeywellaidc.com/ compliance. Zertifikate stehen unter www.honeywellaidc.com/ compliance öffentlich zum Download zur Verfügung. Hay certificados descargables disponibles públicamente en www.honeywellaidc.com/ compliance. Puede descargar los certificados de acceso público en www.honeywellaidc.com/ compliance. Certificados disponíveis ao público para download em: www.honeywellaidc.com/ compliance. 敳꨽堕炒割鲿馲霆勺霼霄꡼ www.honeywellaidc.com/ complianceㄌ 豥꨾豸稷Ꟛ割鯺馲阮剅锞鸤鏞 www.honeywellaidc.com/ compliance 簗菙ᄧ㇏ㆰ(가)(ᄌ)(차)㇘豸腉ᄣ鏾僇剅 ᄭㄉwww.honeywellaidc.com/ compliance ᄞ蝝霶豸腉ᄞᅵㄌ 뫃맪헏픊옪삲풂옪슪많쁳핆흫컪쁢 www.honeywellaidc.com/ compliance 펞컪묺쿦핖킃삖삲 . Публичные сертификаты доступны на странице www.honeywellaidc.com/ compliance. Halkın indirebileceği sertifikalar şu adreste mevcuttur: www.honeywellaidc.com/ compliance. الشهادات القابلة للتنزيل متاحة للعامة على الموقع www.honeywellaidc.com/ compliance. זמינות הצבור עבור להורדה אישורים בכתובתwww.honeywellaidc.com/ compliance FCC Part 15 Subpart B Class B This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with theinstructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio or television technician for help. If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. Honeywell International Inc. is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Honeywell International Inc.. The correction is the responsibility of the user. FCC 5GHz Statement High-power radar is allocated as the primary user of the 5.25- to 5.35-GHz and 5.65- to 5.85-GHz bands. These radar stations can cause interference with and/or damage to this device. Caution: Any changes or modifications made to this equipment not expressly approved by Honeywell International Inc. may void the authorization to operate this equipment. Mise en garde : Toute modification apportée à cet équipement ou l’usage de tout périphérique ou accessoire qui ne sont pas expressément approuvés par Honeywell International Inc. peut annuler l’autorisation d’utiliser cet équipement. Mise en garde : tous les changements ou les modifications apportés à cet équipement ou toute utilisation de périphériques ou accessoires non expressément approuvés par Honeywell International Inc. peuvent annuler l’autorisation d’utiliser cet équipement. Attenzione: qualsiasi variazione o modifica apportata a questa apparecchiatura, oppure qualsiasi utilizzo di qualsiasi periferica o accessorio, non espressamente approvati da Honeywell International Inc., potrebbero annullare l'autorizzazione concessa all'utente per utilizzare l'apparecchiatura. Vorsicht: Veränderungen an diesem Gerät sowie die Verwendung von Peripheriegeräten und Zubehör ohne ausdrückliche Genehmigung von Honeywell International Inc. können dazu führen, dass die Betriebsgenehmigung für dieses Gerät erlischt. Precaución: Cualquier modificación o cambio realizado en este equipo, o el uso de periféricos o de accesorios que no se haya aprobado expresamente por Honeywell International Inc., puede anular la autorización para utilizar este equipo. Precaución: cualquier cambio o modificación a este equipo, o el uso de cualquier periférico o accesorio que no esté expresamente aprobado por Honeywell Internati…

Text truncated - open the document above for the full version.

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com Date: August 26, 2020 Statement We, Honeywell International Inc, state that in RT10A product with model numbers RT10AL1N ( FCC ID#, HD5- RT10AL1N) and RT10AL0N ( FCC ID #, HD5-RT10AL0N), the regulatory label is placed under the battery inside the battery compartment, and it is visible to the users as they purchase the products and install the battery. Sincerely yours, Mandana Salahshour [email protected] Manager – Regulatory Compliance Honeywell International Inc SPS (Safety and Productivity Solutions) Office: +1-803-835-8190

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com Date: June 30, 2020 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for Confidentiality FCC ID: HD5-RT10AL0N To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely.  Block Diagram  Schematic Diagram  Part List  Operation Description  Tune-up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to the above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We request the commission to grant short-term confidentiality request on the following attachments for 180 days after the grant as outlined in Public Notice DA 04-1705.  External Photos  Internal Photos  Test Setup Photos  User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, Mandana Salahshour [email protected] Manager – Regulatory Compliance Honeywell International Inc SPS (Safety and Productivity Solutions) Office:+1-803-835-8190

Safety and Productivity Solutions 9680 Old Bailes Road Fort Mill, SC 29707 USA www.honeywell.com www.honeywellaidc.com Date: June 30, 2020 To whom it may concern, Please be notified that I, Mandana Salahshour, have designated Jones Tsai in Sporton International Inc. as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Jones Tsai in Sporton International Inc. on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti‐Drug Abuse Act of 1998, 21 U.S.C. 862. This authorization is limited to the product of as following: FCC ID: HD5‐RT10AL0N If you have any acknowledgement and response, please send it to Sporton International Inc. directly. Should you have any questions or comments regarding this matter, please don’t hesitate to contact me. Sincerely yours, Mandana Salahshour [email protected] Manager – Regulatory Compliance Honeywell International Inc SPS (Safety and Productivity Solutions) Office:+1-803-835-8190

Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 1 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N 720510 1. External Photograph of EUT Sample (with Battery 1) Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 2 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 3 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 4 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 5 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 6 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 7 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 8 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Sample (with Battery 2) Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 9 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 10 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 11 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 12 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 13 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 14 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 15 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 16 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N List of Accessory: Specification of Accessory AC Adapter Brand Name Edac Power Elec Model Name EA10733P-190 Power Rating I/P: 100-240 Vac, 2000mA , O/P: 19Vdc, 3420mA Power Cord 1.8 meter, shielded cable, with w/o ferrite core Battery 1 Brand Name Winmate Model Name BM101 Power Rating 7.7Vdc, 5900mAh Type Li-ion Battery 2 Brand Name Winmate Model Name BL101 Power Rating 7.4Vdc, 10280mAh Type Li-ion USB Cable Brand Name Shinintech Elec Model Name 16-450-E044 Signal Line Type 1.0 meter, shielded cable, without ferrite core Power Cable Signal Line Type 1.8 meter, shielded cable, without ferrite core Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 17 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 18 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N AC Adapter Photographs of EUT Report No.: EP052309 Brand Name: Honeywell / Model Name: RT10AL0N Sporton International (Kunshan) Inc. Page Number : 19 of 79 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : HD5-RT10AL0N Battery 1…

Text truncated - open the document above for the full version.

Sporton International (Kunshan) Inc. Page 1 of 31 TEL : +86-512-57900158 / FAX : +86-512-57900958 Issued Date : Aug. 26, 2020 FCC ID : HD5-RT10AL0N Form version: 181113 FCC SAR Test Report Report No. : FA052309 FCC SAR TEST REPORT APPLICANT : Honeywell International Inc. Honeywell Safety and Productivity Solutions EQUIPMENT : RT10A BRAND NAME : Honeywell Model Name : RT10AL0N FCC ID : HD5-RT10AL0N STANDARD : FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2013 The product was received on May 23, 2020 and testing was started from Aug. 05, 2020 and completed on Aug. 11, 2020. We, Sporton International (Kunshan) Inc., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International (Kunshan) Inc., the test report shall not be reproduced except in full. Reviewed by: Rose Wang / Supervisor Approved by: Kat Yin / Manager Sporton International (Kunshan) Inc. No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International (Kunshan) Inc. Page 2 of 31 TEL : +86-512-57900158 / FAX : +86-512-57900958 Issued Date : Aug. 26, 2020 FCC ID : HD5-RT10AL0N Form version: 181113 FCC SAR Test Report Report No. : FA052309 Table of Contents 1. Statement of Compliance ............................................................................................................................................. 4 2. Administration Data ...................................................................................................................................................... 5 3. Guidance Applied .......................................................................................................................................................... 5 4. Equipment Under Test (EUT) Information ................................................................................................................... 6 4.1 General Information ............................................................................................................................................... 6 5. RF Exposure Limits....................................................................................................................................................... 7 5.1 Uncontrolled Environment ...................................................................................................................................... 7 5.2 Controlled Environment .......................................................................................................................................... 7 6. Specific Absorption Rate (SAR) ................................................................................................................................... 8 6.1 Introduction ............................................................................................................................................................ 8 6.2 SAR Definition ........................................................................................................................................................ 8 7. System Description and Setup .................................................................................................................................... 9 7.1 E-Field Probe ........................................................................................................................................................10 7.2 Data Acquisition Electronics (DAE) .......................................................................................................................10 7.3 Phantom ................................................................................................................................................................ 11 7.4 Device Holder........................................................................................................................................................12 8. Measurement Procedures ...........................................................................................................................................13 8.1 Spatial Peak SAR Evaluation ................................................................................................................................13 8.2 Power Reference Measurement............................................................................................................................14 8.3 Area Scan .............................................................................................................................................................14 8.4 Zoom Scan ............................................................................................................................................................15 8.5 Volume Scan Procedures ......................................................................................................................................15 8.6 Power Drift Monitoring ...........................................................................................................................................15 9. Test Equipment List .....................................................................................................................................................16 10. System Verification ....................................................................................................................................................17 10.1 Tissue Simulating Liquids ....................................................................................................................................17 10.2 Tissue Verification ...........................................................................................................…

Text truncated - open the document above for the full version.

Sporton International (Kunshan) Inc. Page Number : 1 of 23 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: HD5-RT10AL0N Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR052309A FCC RF Test Report APPLICANT : Honeywell International Inc. Honeywell Safety and Productivity Solutions EQUIPMENT : RT10A BRAND NAME : Honeywell MODEL NAME : RT10AL0N FCC ID : HD5-RT10AL0N STANDARD : FCC Part 15 Subpart C §15.247 CLASSIFICATION : (DSS) Spread Spectrum Transmitter The product was received on May 23, 2020 and testing was completed on Jul. 09, 2020. We, Sporton International (Kunshan) Inc., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International (Kunshan) Inc., the test report shall not be reproduced except in full. Reviewed by: Jason Jia / Supervisor Approved by: James Huang / Manager Sporton International (Kunshan) Inc. No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International (Kunshan) Inc. Page Number : 2 of 23 TEL : +86-512-57900158 Report Issued Date : Aug. 27, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID: HD5-RT10AL0N Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR052309A TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION ..................................…

Text truncated - open the document above for the full version.
