HD570ELG0Enterprise Digital Assistant (EDA)

Dolphin™ 70e Black with Windows ® Embedded Handheld 6.5 User’s Guide Preliminary Draft 5/26/13, Not for Release Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII. HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of HII. Web Address: www.honeywellaidc.com Trademarks Dolphin is a trademark or registered trademark of Hand Held Products, Inc. in the United States and/or other countries. Microsoft, Windows, Windows Mobile, Windows Phone, Windows Embedded Handheld, Windows CE, Windows 98 Second Edition, Windows NT, Windows 2000, Windows ME, Windows XP, Windows 7, Windows Vista, ActiveSync, Outlook, and the Windows logo are trademarks or registered trademarks of Microsoft Corporation. The Bluetooth trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to Honeywell. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are the property of their respective owners. Patents For patent information, please refer to www.honeywellaidc.com/patents. ©2013 Honeywell International Inc. All rights reserved. Preliminary Draft 5/26/13, Not for Release Table of Contents iii Chapter 1 - Dolphin 70e Black Terminal Agency Information Label Locations ....................................................................................................................1-1 Model Number, Serial Number and IMEI Labels............................................................1-1 LED Safety ...........................................................................................................................1-1 LED Safety Statement....................................................................................................1-1 UL and C-UL Statement.......................................................................................................1-2 Approvals by Country...........................................................................................................1-2 R&TTE Compliance Statement—802.11a/b/g/n, Bluetooth, and/or GSM............................1-2 FCC Requirements ..............................................................................................................1-3 Dolphin RF Terminal—802.11a/b/g/n, Bluetooth, and/or GSM ......................................1-3 Canadian Compliance..........................................................................................................1-3 Conformité à la règlementation canadienne ..................................................................1-4 RF Exposure Information (SAR) ..........................................................................................1-4 For European Community Users .........................................................................................1-5 Waste Electrical and Electronic Equipment Information ......................................................1-5 China RoHS .........................................................................................................................1-5 Pacemakers, Hearing Aids and Other Electrically Powered Devices ..................................1-6 Hearing Aid Compatibility (HAC)..........................................................................................1-6 Microwaves ..........................................................................................................................1-6 Chapter 2 - Getting Started Out of the Box ......................................................................................................................2-1 Initial Setup for Dolphin 70e Black Terminals ......................................................................2-1 Using the USB Charge/Communication Cable (Model 70e-USB ADAPTERKIT) ..........2-2 The Home Screen ................................................................................................................2-4 Title Bar..........................................................................................................................2-4 Icons in the Title Bar ......................................................................................................2-5 Horizontal Scroll .............................................................................................................2-7 Tile Bar...........................................................................................................................2-7 Virtual Keyboard.............................................................................................................2-8 The Start Menu ....................................................................................................................2-9 Navigating the Start Menu..............................................................................................2-9 Pop-Up Menus .....................................................................................................................2-9 File Explorer .......................................................................................................................2-10 File Provisioning on the Dolphin 70e Black........................................................................2-11 Search....................................................................................................…

Text truncated - open the document above for the full version.

Honeywell International Inc Honeywell Scanning and Mobility 9680 Old Bailes Road Fort Mill, SC 29707 USA April/17/2013 To Whom It May Concern: Subject: Appropriateness of Pre-Production Sample for Certification Testing We, Honeywell International Inc, located at 9680 Old Bailes Road, Fort Mill SC 29707 USA, confirm that the pre-production sample(s) provided for certification testing of our Dolphin 70e Black models, 70E1, 70E2, 70E3 with related FCC ID: HD570ELGN & IC ID: 1693B-70E1 and FCC ID: HD570ELG0 & IC ID: 1693B-70E2 and FCC ID: HD570EL00 & IC ID: 1693B-70E3 fully represents the final version of the models as it will be released to the market, in all relevant parts, Sincerely, Michael Robinson Compliance Manager, Scanning Systems

Honeywell International Inc Honeywell Scanning and Mobility 9680 Old Bailes Road Fort Mill, SC 29707 USA April/17/2013 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: HD570ELG0 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request the exhibits listed hereafter and accompanying above identified application be kept confidential permanently. Schematics Block Diagram Parts List Operation Description Tune up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, ________________________ Michael Robinson

Honeywell International Inc Honeywell Scanning and Mobility 9680 Old Bailes Road Fort Mill, SC 29707 USA April, 17, 2013 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 RE : Certification Application FCC ID : HD570ELG0 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days from the date of grant:  External Photos  Internal Photos  Test Setup Photos  User Manual The application contains technical information, which Honeywell International Inc deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. We are informed and understand that we have to arrange cancellation of the short term confidentiality classification per written and timely request to the involved TCB, if a product release to the market is intended prior to the above specified short term confidentiality release date. We understand that the above listed exhibits will be automatically disclosed to the public at the specified short term confidentiality release date if not prolonged by the involved TCB upon our timely request (total of 180 days from date of grant is possible). Sincerely, Michael Robinson Compliance Manager, Scanning systems Tel: 315-554-6387 FAX: 315.554.6393 Email:[email protected]

External Pictures: Models: Honeywell 70eLGN/ 70eLG0/ 70eL00 Dolphin 70e Black Enterprise Digital Assistant FCC ID: HD570ELGN/ HD570ELG0/ HD570EL00 IC ID: 1693B-70E1/ 1693B-70E2/ 1693B-70E2 Front View: Side View: Side View: Top View: Bottom View: Back Cover: EUT With Thick Back Cover: EUT With Thin Back Cover: Battery Options: Thick Battery: Thin Battery Option: Labels: 70eL00 70eLG0 70eLGN Holster-1

THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY AND CONFIDENTIAL MATERIAL OF HONEYWELL INTERNATIONAL INC AND SHALL NOT BE REPRODUCED, OR COPIED, OR USED AS A BASIS FOR MANUFACTURE OR SALE OF EQUIPMENT OR DEVICES WITHOUT WRITTEN PERMISSION. c REV#REV DESCRIPTION DESIGNED BY DATE ARTWORK LEVEL TITLE: A DRAWING NO: REV SCALE DO NOT SCALE SHEET 1 OF 1 DRAWING NO. DATE RELEASE LABEL,DOLPHIN BLACK , AGENCY PRINT ON DEMAND C 09/26/12 D.FLETCHER 03/20/12 A CC# 2012-912 MATERIAL # TWO “A” Format Artwork Template No. 500030434, REV A NOTES REQUIRED FOR LABEL MANUFACTURER: 1. ROHS COMPLIANT RIBBONS. SEE ENVIRONMENTAL SPECIFICATION DOCUMENT #500007391 2. MATERIAL/ PROCESS: THERMAL TRANSFER USING UL APPROVED RIBBON & MATERIAL CONSTRUCTION ON .051MM THICK WHITE POLYESTER BACKED WITH PRESSURE SENSITIVE ADHESIVE. SIZE: 25.4MM X 25.4 MM. ALL PRINTING BLACK 3. SERIAL NUMBER: REF. L3-GLBL-MKT-1366 2D DATA MATRIX 7 DOT EW (10 CHARACTER MAX) OF SERIAL NUMBER AS DESCRIBED IN CHART BELOW. Table 1. Serial Number Format Year Day of Year Location Sequential Number 0 5 1 2 3 0 1 2 3 4 Table 2. Serial Number Fields Fields Range Description Year 01 to 99 01 = 2001 Day of Year 001 to 365 001 = January 1 Location 0-9, A, B, C, D, F See Table 3 Table 3 FoxCon Location CharacterOutsource Partner Info J Products Used Dolphin Black 50110651 50110651 50110651-001, -004, -005, -006 3 50110651-003 WLAN, BT 3 50110651-002 WLAN, BT, GSM/CDMA (SL9090) ADD HEBREW 01/21/13 B 2013-27 50110651-002 THREE ADD BLACK, REV 02/12/13 C 2013-552 N21909 Input: 5V 1A 0682 Honeywell International Inc www.honeywellaidc.com Pat.: www.honeywellaidc.com/patents Use Honeywell International Inc Battery Pack Only 0682 N21909 Input: 5V 1A FCC ID: HD570ELG0 IC: 1693B-70E2 MODEL: 70eLG0 Cofetel: xxxxxxxxxxxx Anatel: xxxxxxxxxxxx P/N: S/N: REV: D L P H I 70e N TM O Honeywell International Inc www.honeywellaidc.com Pat.: www.honeywellaidc.com/patents Use Honeywell International Inc Battery Pack Only FCC ID: HD570EL00 IC: 1693B-70E3 MODEL: 70eL00 Cofetel: xxxxxxxxxxxx Anatel: xxxxxxxxxxxx P/N: S/N: REV: D L P H I 70e N TM O , J שלבסוללהרקתשתמש Honeywell International Inc שלבסוללהרקתשתמש Honeywell International Inc 3 50110651-005 BT WLAN GSM, GPS (SL8092) EU BANDS 3 50110651-006 BT WLAN GSM, GPS (SL8092) with NFC N21909 MODEL: 70eLWN Honeywell International Inc www.honeywellaidc.com Pat.: www.honeywellaidc.com/patents Cofetel: xxxxxxxxxxxx Anatel: xxxxxxxxxxxx Use Honeywell International Inc Battery Pack Only P/N: Input: 5V 1A 0682 D L P H I 70e N TM O D L P H I 70e N TM O 50110651-004 WLAN,BT,NFC 3 50110651-001 WLAN, BT, GSM/CDMA(SL9090) /NFC Honeywell International Inc www.honeywellaidc.com Pat.: www.honeywellaidc.com/patents Use Honeywell International Inc Battery Pack Only FCC ID: HD570ELGN IC: 1693B-70E1 Cofetel: xxxxxxxxxxxx Anatel: xxxxxxxxxxxx MODEL: 70eLGN N21909 P/N: S/N: REV: Input: 5V 1A 0682 D L P H I 70e N TM O OBSOLETE BLACK BLACK BLACK N21909 MODEL: 70eLW0 Honeywell International Inc www.honeywellaidc.com Pat.: www.honeywellaidc.com/patents Cofetel: xxxxxxxxxxxx Anatel: xxxxxxxxxxxx Use Honeywell International Inc Battery Pack Only P/N: S/N: REV: Input: 5V 1A 0682 BLACK BLACK S/N: REV: BT Sale into Costa Rica can happen with a new sku and if the keep out area of the certification stamp is off the label as shown. Per Mandana, the cert must also be placed on the packaging.

Internal Pictures: Models: Honeywell 70eLGN/ 70eLG0/ 70eL00 Dolphin 70e Black Enterprise Digital Assistant FCC ID: HD570ELGN/ HD570ELG0/ HD570EL00 IC ID: 1693B-70E1/ 1693B-70E2/ 1693B-70E2 Back Cover Removed: Module Info: Main Board: Main Board with Shield Cans removed: Main Board- back section: NFC Module: GSM/CDMA Main and Diversity Antennas BT/WLAN Antenna NFC Antenna

FCC: Accredited IC recognized # 3462B-1 CETECOM Inc. 411 Dixon Landing Road
Milpitas, CA 95035
U.S.A. Phone: + 1 (408) 586 6200
Fax: + 1 (408) 586 6299
E)mail: [email protected]
http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 V4.0 2012)07)20 The BLUETOOTH trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to CETECOM Inc. © Copyright by CETECOM FCC Test Report FOR: Honeywell International Inc. Model: 70eLG0 Product Description: Dolphin 70E Black Enterprise Digital Assistant (EDA) FCC ID: HD570ELG0 IC ID: 1693B.70E2 FCC Part 15B TEST REPORT #: EMC_HONEY_095_12001_70eLG0_15B DATE: 2013.05.22 Test Report #: EMC_HONEY_095_12001_70eLG0_15B FCC ID: HD570ELG0 Date of Report 2013#05#22 IC ID: 1693B#701E2 Page 2 of 20 TABLE OF CONTENTS 1 Assessment _____________________________________________________________________ 3 2 Administrative Data _____________________________________________________________ 4 2.1 Identification of the Testing Laboratory Issuing the Test Report __________________________ 4 2.2 Identification of the Client __________________________________________________________ 4 2.3 Identification of the Manufacturer ___________________________________________________ 4 3 Equipment under Test (EUT) ______________________________________________________ 5 3.1 Specification of the Equipment under Test ____________________________________________ 5 3.2 Identification of the Equipment Under Test (EUT) _____________________________________ 5 3.3 Identification of Accessory equipment ________________________________________________ 5 3.4 Environmental Conditions during test: _______________________________________________ 6 3.5 Dates of testing: ___________________________________________________________________ 6 4 Subject of Investigation __________________________________________________________ 7 5 Summary of Measurement Results _________________________________________________ 7 6 Radiated Emissions ______________________________________________________________ 8 6.1 §15.109 Radiated emission limits. Unintentional Radiators: _____________________________ 8 6.2 Measurement Procedure: ___________________________________________________________ 9 6.3 Sample Calculations for Radiated Measurements______________________________________ 11 6.4 Testing Notes: ___________________________________________________________________ 11 6.5 Results _________________________________________________________________________ 12 7 AC Power Line Conducted Emissions ______________________________________________ 14 7.1 § 15.107 Conducted limits. Unintentional Radiators __________________________________ 14 7.2 Measurement Procedure: __________________________________________________________ 15 7.3 Results: _________________________________________________________________________ 17 8 Test Equipment and ancillaries used for tests ________________________________________ 18 9 Test Setup Diagrams ____________________________________________________________ 19 10 Revision History _______________________________________________________________ 20 Test Report #: EMC_HONEY_095_12001_70eLG0_15B FCC ID: HD570ELG0 Date of Report 2013#05#22 IC ID: 1693B#701E2 Page 3 of 20 1 Assessment The following device was tested against the applicable criteria specified in FCC rules Part 15B of the Code of Federal Regulations and no deviations were ascertained during the course of the tests performed. Company Description Model # Honeywell International Inc Dolphin 70E Black Enterprise Digital Assistant (EDA) 70eLG0 Responsible for Testing Laboratory: 2013#05#22 Compliance Franz Engert (Acting Lab Manager) Date Section Name Signature Responsible for the Report: 2013#05#22 Compliance Tunji Yusuf (EMC Engineer) Date Section Name Signature The test results of this test report relate exclusively to the test item specified in Section3. CETECOM Inc. USA does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of CETECOM Inc. USA. Test Report #: EMC_HONEY_095_12001_70eLG0_15B FCC ID: HD570ELG0 Date of Report 2013#05#22 IC ID: 1693B#701E2 Page 4 of 20 2 Administrative Data 2.1 Identification of the Testing Laboratory Issuing the Test Report Company Name: CETECOM Inc. Department: Compliance Address: 411 Dixon Landing Road Milpitas, CA 95035 U.S.A. Telephone: +1 (408) 586 6200 Fax: +1 (408) 586 6299 Acting Lab Manager: Franz Engert Test Engineer: Tunji Yusuf 2.2 Identification of the Client Applicant’s Name: Honeywell International Inc Street Address: 700 Visions Drive City/Zip Code Skaneateles Falls, NY 13153 Country USA Contact Person: Michael Robinson Phone No. +1 (315) 554 6387 Fax: +1 (315) 554 6393 e.mail: [email protected] 2.3 Identification of the Manufacturer Manufacturer’s Name: Same as client. Manufacturers Address: City/Zip Code Country Test Report #: EMC_HONEY_095_12001_70eLG0_15B FCC ID: HD570ELG0 Date of Report 2013#05#22 IC ID: 1693B#701E2 Page 5 of 20 3 Equipment under Test (EUT) 3.1 Specification of the Equipment under Test Model No: 70eLG0 Product Description: Dolphin 70E Black Enterprise Digital Assistant (EDA) Radios included: 1. Sierra Wireless SL9090 Radio Module • 850/900/1800/1900Mhz GSM power class 4/1 GPRS Class B, Multislot 10 operation EDGE Multislot class 12 operation • 850/1900/2100 Mhz WCDMA / HSPA+ HSDPA Category 10 data rate # 14.4 Mbps HSUPA Category 6 data rate # 5.76 Mbps • 800/1900 Mhz CDMA 1xRTT / EV#D0 CDMA EVDO Rev A data rate # 3.1 Mbps 2. WLAN 802.11 a/b/g/n Murata LBEH5Z9UWC module with TI WL1273L Chipset 2.4 and 5.0 GHz bands of operation 3. GPS 1575.42 MHz FCC ID: HD570ELG0 IC ID: 1693B#701E2 Rated Operating Voltage Range…

Text truncated - open the document above for the full version.

Project #: EMC_ HONEY_095_12001 FCC ID: HD570ELGN, HD570ELG0, HD570EL00 Date of Report : 2013-05-22 IC ID: 1693B-70E1, 1693B-70E2, 1693B-70E3 Page 1 of 2 Test Setup Photographs Model Number: 70eLGN, 70eLG0, 70eL00 Product Description: Dolphin 70E Black Enterprise Digital Assistant (EDA) Manufacturer: Honeywell International Inc. FCC ID: HD570ELGN, HD570ELG0, HD570EL00 IC ID: 1693B-70E1, 1693B-70E2, 1693B-70E3 Test Site Information: CETECOM Inc. Milpitas, CA USA Project #: EMC_ HONEY_095_12001 FCC ID: HD570ELGN, HD570ELG0, HD570EL00 Date of Report : 2013-05-22 IC ID: 1693B-70E1, 1693B-70E2, 1693B-70E3 Page 2 of 2 Radiated Emissions Test Setup: 30MHz- 1GHz Measurement setup: >1GHz Measurement setup:
