HD5MXTY3Barcode Scanner with BT

™ User’s Guide 2020/3820 Cordless System Disclaimer Hand Held Products, Inc. (“Hand Held Products“) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult Hand Held Products to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of Hand Held Products. Hand Held Products shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material. This document contains proprietary information which is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of Hand Held Products. © 2004-2007 Hand Held Products, Inc. All rights reserved. Web Address: www.handheld.com Microsoft® Pocket PC 2002, Windows®, Windows NT®, Windows 2000, Windows ME, Windows XP, ActiveSync®, Outlook®, and the Windows logo are trademarks or registered trademarks of Microsoft Corporation. The Bluetooth ® word mark and logos are owned by Bluetooth SIG, Inc. The 2020/3820 system meets or exceeds the requirements of all applicable standards organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow. Please read these guidelines carefully before using your 2020/3820 system. FCC Class B Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio or television technician for help. If necessary, the user should consult the dealer or an experienced radio/ television technician for additional suggestions. The user may find the following booklet helpful: “Something About Interference.” This is available at FCC local regional offices. Hand Held Products, Inc. is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Hand Held Products, Inc. The correction is the responsibility of the user. Use only shielded data cables with this system. Caution: Any changes or modifications made to this equipment not expressly approved by Hand Held Products, Inc. may void the FCC authorization to operate this equipment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. To maintain compliance with FCC RF exposure guidelines, use only the accessories specified by the manufacturer. ! Agency Compliance Statements Canadian Compliance This Class B digital apparatus complies with Canadian ICES-003. Operation is subject to the following conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. 3. To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. Conformité à la règlementation canadienne Cet appareil numérique de la Classe B est conforme à la norme ICES-003 du Canada. Son fonctionnement est assujetti aux conditions suivantes : 1. Cet appareil ne doit pas causer de brouillage préjudiciable. 2. Cet appareil doit pouvoir accepter tout brouillage reçu, y compris le brouillage pouvant causer un fonctionnement indésirable. 3. Pour éviter toute interférence radio avec le service concédé, cet appareil doit être utilisé en intérieur et à l'écart des fenêtres pour pouvoir fournir une protection maximale.L’équipement (ou son antenne de transmission) installé à l’extérieur est soumis à licence. This device meets or exceeds the requirements of all applicable standards organiza- tions for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow. Please read these guidelines carefully before using your device. Regulatory and Safety Approvals USA: FCC Part 15, Class B Canada: ICES-003 Regulatory Approvals for Bluetooth Radio Devices RF devices are designed to comply with the most current applicable standards on safe levels of RF energy developed by the Institute of Electrical and Electronics Engineers (IEEE) and the American National Standards Institute (ANSI) and have been recom- mended for adoption by the Federal Communications Commission (FCC…

Text truncated - open the document above for the full version.

™ User’s Guide 2020/4820/4820 i 2D Cordless Imaging System Disclaimer Hand Held Products, Inc. (“Hand Held Products”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult Hand Held Products to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of Hand Held Products. Hand Held Products shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material. This document contains proprietary information which is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of Hand Held Products. © 2005-2007 Hand Held Products, Inc. All rights reserved. Web Address: www.handheld.com Microsoft® Pocket PC 2002, Windows®, Windows NT®, Windows 2000, Windows ME, Windows XP, ActiveSync®, Outlook®, and the Windows logo are trademarks or registered trademarks of Microsoft Corporation. The Bluetooth ® word mark and logos are owned by Bluetooth SIG, Inc. The 2020/4820/4820i system meets or exceeds the requirements of all applicable standards organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow. Please read these guidelines carefully before using your 2020/4820/4820i system. FCC Class B Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio or television technician for help. If necessary, the user should consult the dealer or an experienced radio/ television technician for additional suggestions. The user may find the following booklet helpful: “Something About Interference.” This is available at FCC local regional offices. Hand Held Products, Inc. is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Hand Held Products, Inc. The correction is the responsibility of the user. Use only shielded data cables with this system. Caution: Any changes or modifications made to this equipment not expressly approved by Hand Held Products, Inc. may void the FCC authorization to operate this equipment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. To maintain compliance with FCC RF exposure guidelines, use only the accessories specified by the manufacturer. ! Agency Compliance Statements Canadian Compliance This Class B digital apparatus complies with Canadian ICES-003. Operation is subject to the following conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. 3. To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. Conformité à la règlementation canadienne Cet appareil numérique de la Classe B est conforme à la norme ICES-003 du Canada. Son fonctionnement est assujetti aux conditions suivantes : 1. Cet appareil ne doit pas causer de brouillage préjudiciable. 2. Cet appareil doit pouvoir accepter tout brouillage reçu, y compris le brouillage pouvant causer un fonctionnement indésirable. 3. Pour éviter toute interférence radio avec le service concédé, cet appareil doit être utilisé en intérieur et à l'écart des fenêtres pour pouvoir fournir une protection maximale.L’équipement (ou son antenne de transmission) installé à l’extérieur est soumis à licence. This device meets or exceeds the requirements of all applicable standards organiza- tions for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow. Please read these guidelines carefully before using your device. Regulatory and Safety Approvals USA: FCC Part 15, Class B Canada: ICES-003 Regulatory Approvals for Bluetooth Radio Devices RF devices are designed to comply with the most current applicable standards on safe levels of RF energy developed by the Institute of Electrical and Electronics Engineers (IEEE) and the American National Standards Institute (ANSI) and have been recom- mended for adoption by the Federal …

Text truncated - open the document above for the full version.

Date: 2-Jan-2008 Hand Held Products Model Number Similarities Dear Sir/Madam, I am writing this letter to inform you that several of our products are going through a Radio Module design change due to end-of-life module. The new radio module fits the same PCB footprint and requires no other electrical changes for compatibility. The product’s model numbers will stay the same and there will be no notification to the field marketing, as the product applications are interchangeable old or new radio module. The product contents are remaining the same otherwise, with other changes being the labeling contents and software. Product differences: 1. 3820 model family series: Linear optic engine, commercial housing construction. 2. 4820 model family series: Same items are the internal electrical PCB and schematic, radio and antenna, battery, internal mechanicals and external housing as 3820. Differences are the model and label changes, and the optical engine package (camera chip, plastic chamber, lens, mtg bracket) that reads the image of the barcode. 3. 4820i model family series: uses all the internal electrical, battery, internal mechanicals and optics as 4820. The external housing is the more rugged style of the industrial housing. a. Housing handle change b. Housing cover change c. Housing end cap (bottom of handle) change d. Also, changes to the LED light pipes, and brand-name logos for the aesthetics of the housings 4. NOTE: all models use the same PCB and electrical schematic. All models have the same version software stack for radio communications. All models use the same radio. All models use the same radio antenna. There are no changes amongst any of the models on the radio communications and power, they are all identical. Model numbers for the IC certificates and for FCC are on next page. Trade names are all Hand Held Products, with logo of: Please contact me if you have questions. Best Regards, Michael Robinson Product Compliance Manager-Imaging Systems Phone: 315-554-6387 E-mail: [email protected] Reference Old Model Number references New Model Family and Model Numbers LogoComments IT2020, 2020, 2020-5, 2020- 5x, etc. 2020 2020-5BE ƒ BT radio – version 1 ƒ Compatible with cordless scanners’ product families N/A 4820 4820SF0C1CBE 4820SR0C1CBE ƒ BT radio – version 1 ƒ 5000 optic engine family ƒ General use housing IT5620 3820 3820SR0C0BE ƒ BT radio – version 1 ƒ General use housing 4820i N/A ƒ BT radio – version 1 ƒ 5000 optic engine family 4820ISRE ƒ Industrial use housing 4820ISFE Model family FCC ID number with new radio (2008) IC number with new radio 2008) QC890 HD5QC900B 1693B-TY3B 3820 HD5MXTY3 1693B-TY3B 4820 HD5MXTY3 1693B-TY3B 4820i HD5MXTY3 1693B-TY3B 2020-5 HD5MXTY3B 1693B-TY3B

Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 4-Jan-2008 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b) (4) of the Freedom of Information Act, <Company Name> requests confidentiality for the following products: FCC ID Number Product Title/Model HD5MXTY3B Bluetooth Cordless Base / 2020-5 family HD5MXTY3 Bluetooth Cordless Scanners / 3820, 4820, 4820i model families For the product stated above, we request that the following information be held confidential: 1) Electrical Schematics of the Circuitry 2) Block Diagram 3) Parts List 4) Tune-up Procedure 5) Operational Description No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain Hand Held Products’ trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our mobile handset. This material is not customarily available to the general public and we request that it be withheld from public inspection. The Applicant understands that pursuant to Paragraph § 0.479, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Michael Robinson Product Compliance Manager – Imaging Systems Hand Held Products, Inc.

6-Dec-2007 Letter of Authorization To whom it may concern, We the undersigned, hereby authorize CETECOM Inc. (411 Dixon Landing Road, Milpitas, CA 95035, Tel.408 586 6200) to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CETECOM Inc., on our behalf shall have the same effect as acts of our own. The authorization from Hand Held Products is valid 90 days from the date of this letter. Sincerely, Michael Robinson Product Compliance Manager – Imaging Systems Hand Held Products, Inc.

3820, 4820 and 4820i Top view Side view

Required Safety Labels Scanner Compliance Label locations Item Number, Serial Number and Revision Information location NOTES 1. COLORS : BLUETOOTH BACKGROUND: PANTONE PROCESS BLACK LABEL BACKGROUND: NONE BLUE TOOTH SYMBOL: PANTONE PROCESS WHITE ALL OTHER GRAPHICS BLACK 2. REFERENCE PRO-E DRAWING FOR DIE CUT AND MATERIAL CONSTRUCTION. THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY AND CONFIDENTIAL MATERIAL OF HAND HELD PRODUCTS, INC. AND SHALL NOT BE REPRODUCED, OR COPIED, OR USED AS A BASIS FOR MANUFACTURE OR SALE OF EQUIPMENT OR DEVICES WITHOUT WRITTEN PERMISSION. c REV#REV DESCRIPTION DESIGNED BY DATE ARTWORK LEVEL TITLE: A DRAWING NO: REV SCALE DO NOT SCALE SHEET 1 OF 1 DRAWING NO. DATE RELEASE LABEL, MATRIX RETAIL & COMMERCIAL A ONE 12/20/07 D. FLETCHER 12/20/07 A ECN# 5000000xxxxx 3. ROHS COMPLIANT INKS. SEE HAND HELD DOCUMENT #500007391 FCC ID:HD5MXTY3 IC: 1693B-QC900B S/N ITEM REV S/N ITEM REV Input: 4.5-12V .4A MATRL #MECH DRW #END ITEMPRE-RELEASE NOTES Preliminary release for new radio. Will need to update with ICASA, NOM and possibly GS or Telec CORDLESS ORANGE AND GRAY HOUSINGS. specials/ blk housings not adressed 500003638 CORDED ORANGE AND GRAY HOUSINGS. EXCLUDES DPM, blk housings Preliminary release for new housing. Will need to update with GS. New label required for DPM also when new housings are released. 500003638 PRELIMINARY MATRL# 100005248 MATRL# 100005249 500016990 500016990 100005248 100005249

Internal Photos 3820, 4820 and 4820i 3820 Top view 3820 Component side 4820 Top view 4820 Top view Back side Chip Antenna BT Radio

Bluetooth Qualification Test Facility (BQTF) FCC listed A2LA certified IC recognized # 3462B CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2113686 Board of Directors: Dr. Harald Ansorge, Dr. Klaus Matkey, Hans Peter May V1.1 2003-03-01 The BLUETOOTH trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to CETECOM Inc. © Copyright by CETECOM FCC Test Report FCC Part 15.247 & IC RSS-210, issue 7 for FHSS systems for Hand Held Products,Inc. Barcode Scanner/Imager-I.T.E. equipment Model Number: 3820, 4820 and 4820i FCC ID: HD5MXTY3 IC-ID: 1693B-TY3B TEST REPORT #: EMC_HANDH_049_07002-01_FCC-IC_BT. DATE: January 02, 2008 Test Report #: EMC_HANDH_049_07002-01_FCC-IC_BT. Date of Report : January 02, 2008 Page 2 of 81 TABLE OF CONTENTS 1 Assessment_____________________________________________________________________ 4 Technical responsibility for area of testing: ______________________________________________ 4 EMC & Radio __________________________________________________________________________________ 4 This report is prepared by: ____________________________________________________________ 4 EMC & Radio __________________________________________________________________________________ 4 2 Administrative Data _____________________________________________________________ 5 2.1 Identification of the Testing Laboratory Issuing the SAR Assessment Report__________________ 5 2.2 Identification of the Client __________________________________________________________ 5 2.3 Identification of the Manufacturer ___________________________________________________ 5 3 Equipment under Test (EUT) ______________________________________________________ 6 3.1 Specification of the Equipment under Test_____________________________________________ 6 3.2 Identification of the Equipment Under Test (EUT) ______________________________________ 6 3.3 Identification of Accessory equipment ________________________________________________ 6 4 Subject of Investigation __________________________________________________________ 7 5 Measurements (Radiated) _________________________________________________________ 8 5.1 MAXIMUM PEAK OUTPUT POWER § 15.247 (RADIATED) ___________________________ 8 5.1.1 LIMIT SUB CLAUSE § 15.247 (b) (1) (2) (3) (4)_______________________________________________ 8 5.1.2 Test Results_____________________________________________________________________________ 8 5.2 RESTRICTED BAND EDGE COMPLIANCE RADIATED §15.247/15.205 ________________ 18 5.2.1 LIMITS _______________________________________________________________________________ 18 5.2.2 Results Lower Restricted Band 2310 MHz to 2390 MHz ________________________________________ 19 5.2.3 Results Upper Restricted Band 2483.5 MHz to 2500 MHz _______________________________________ 25 5.3 TRANSMITTER SPURIOUS EMISSIONS RADIATED § 15.247/15.205/15.209 ____________ 31 5.3.1 LIMITS _______________________________________________________________________________ 31 5.3.2 RESULTS _____________________________________________________________________________ 32 5.4 RECEIVER SPURIOUS EMISSIONS ______________________________________________ 44 6 Measurements (CONDUCTED) ___________________________________________________ 49 6.1 MAXIMUM PEAK OUTPUT POWER § 15.247 (CONDUCTED) ________________________ 49 6.1.1 LIMIT SUB CLAUSE § 15.247 (b) (1) ______________________________________________________ 49 6.1.2 RESULTS: ____________________________________________________________________________ 49 6.2 20dB BANDWIDTH ______________________________________________________________ 59 6.2.1 LIMIT SUB CLAUSE § 15.247 (a) (1) (i) (ii) (iii) _____________________________________________ 59 6.2.2 RESULTS: ____________________________________________________________________________ 59 6.3 EMISSION LIMITATIONS § 15.247 (c) (1) _________________________________________ 69 6.4 CARRIER FREQUENCY SEPARATION____________________________________________ 73 6.4.1 LIMIT SUB CLAUSE § 15.247 (a) (1) (i) (ii) (iii) _____________________________________________ 73 6.4.2 RESULTS: ____________________________________________________________________________ 73 Test Report #: EMC_HANDH_049_07002-01_FCC-IC_BT. Date of Report : January 02, 2008 Page 3 of 81 6.5 NUMBER OF HOPPING CHANNELS ______________________________________________ 75 6.5.1 LIMIT SUB CLAUSE § 15.247 (a) (1) (iii)___________________________________________________ 75 6.5.2 RESULTS: ____________________________________________________________________________ 75 6.6 TIME OF OCCUPANCY (DWELL TIME)___________________________________________ 77 6.6.1 LIMIT SUB CLAUSE § 15.247 (a) (1) (i) (ii) (iii) _____________________________________________ 77 6.6.2 RESULTS: ____________________________________________________________________________ 77 6.7 AC POWER LINE CONDUCTED EMISSIONS § 15.107/207 ___________________________ 78 6.7.1 Limits ________________________________________________________________________________ 78 7 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS ________________________ 79 8 BLOCK DIAGRAMS ___________________________________________________________ 80 Test Report #: EMC_HANDH_049_07002-01_FCC-IC_BT. Date of Report : January 02, 2008 Page 4 of 81 1 Assessment The following is in compliance with the applicable criteria specified in FCC rules Part 15.247 of the Code of Federal Regulations. Company Description Model # Hand Held Products,Inc. Barcode Scanner/Imager- I.T.E. equipment 3820, 4820 and 4820i Technical responsibility for area of testing: 01/02/2008 EMC & Radio Lothar Schmidt (Director Antenna and Regulatory Services) Date Section Name Signature This report is prepared by: 01/02/2008 EMC & Radio Val Tankov (Project Engineer) Date Section Name Signature The test results of this test report relate exclusively to th…

Text truncated - open the document above for the full version.

PAGE 1 OF 4 Bluetooth Qualification Test Facility (BQTF) FCC listed# A2LA Certified IC recognized # 3462B CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2113686 Board of Directors: Dr. Harald Ansorge, Dr. Klaus Matkey, Hans Peter May © Copyright by CETECOM Test Setup Photos FCC Part 15.247 / RSS 210, issue 7 FOR: Barcode Verifier MODEL #: 3820, 4820 and 4820i Hand Held Products Inc. FCC ID: HD5MXTY3 IC: 1693B- TY3B Reference test report no.: EMC_HANDH_049_07002-01_FCC-IC_BT PAGE 2 OF 4 This report shall not be reproduced except in full without the written approval of: CETECOM, Inc. 1 TEST SETUP PHOTOS RADIATED EMISSIONS - Front PAGE 3 OF 4 This report shall not be reproduced except in full without the written approval of: CETECOM, Inc. RADIATED EMISSIONS - Back PAGE 4 OF 4 This report shall not be reproduced except in full without the written approval of: CETECOM, Inc. CONDUCTED EMISSIONS
