HDTTX045-27Transmitter for remote control toy

FCC ID: HDTTX045-27 Report Number: C80710M1 19121 EL TORO RD., SILVERADO, CALIFORNIA 92676 PHONE: (949) 589-0700 FAX: (949) 589-7700 Page 1 FCC SUBPART C TEST REPORT for LOW POWER COMMUNICATION DEVICE - TRANSMITTER TX045-27 Prepared for: KIN YAT INDUSTRIAL CO., LTD. BLK A, 7/F, GALAXY FACTORY BUILDING 25-27 LUK HOP ST. SAN PO KONG, KOWLOON, HONG KONG COMPATIBLE ELECTRONICS INC. 19121 EL TORO RD. SILVERADO, CALIFORNIA 92676 (714) 589-0700 DATE: July 14, 1998 REPORTAPPENDICESTOTAL BODY A B C PAGES 18 4 4 3 27 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. FCC ID: HDTTX045-27 Report Number: C80710M1 19121 EL TORO RD., SILVERADO, CALIFORNIA 92676 PHONE: (949) 589-0700 FAX: (949) 589-7700 Page 2 TABLE OF CONTENTS SECTIONTITLEPAGE GENERAL REPORT SUMMARY04 SUMMARY OF TEST RESULTS05 1.PURPOSE06 2.ADMINISTRATIVE DATA07 2.1Location of Testing07 2.2Traceability Statement07 2.3Cognizant Personnel07 2.4Date Test Sample was Received07 2.5Disposition of the Test Sample07 2.6Abbreviations and Acronyms07 3.APPLICABLE DOCUMENTS08 4.DESCRIPTION OF TEST CONFIGURATIONS09 4.1Description of Test Configuration – EMI09 4.1.1Cable Construction and Termination10 5.LIST OF EUT, ACCESSORIES AND TEST EQUIPMENT11 5.1EUT and Accessory List11 5.2Test Equipment12 6.TEST SITE DESCRIPTION13 6.1Test Facility Description13 6.2EUT Mounting, Bonding and Grounding13 7.TEST PROCEDURES14 7.1Emissions Test14 7.1.1Radiated Emissions Test14 7.1.1.1Radiated Emissions Data15 10 kHz to 30 MHz16 30 MHz to 272 MHz17 8.CONCLUSIONS18 FCC ID: HDTTX045-27 Report Number: C80710M1 19121 EL TORO RD., SILVERADO, CALIFORNIA 92676 PHONE: (949) 589-0700 FAX: (949) 589-7700 Page 3 LIST OF APPENDICES APPENDIXTITLE A Test Setup Diagrams and Photos B Antenna and Effective Gain Factors C Modifications to the EUT LIST OF FIGURES FIGURETITLE 1 Plot Map And Layout of Test Site FCC ID: HDTTX045-27 Report Number: C80710M1 19121 EL TORO RD., SILVERADO, CALIFORNIA 92676 PHONE: (949) 589-0700 FAX: (949) 589-7700 Page 4 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced in any form unless done so in full. This report must not be used to claim product endorsement by NVLAP or any other agency of the U.S. Government. Device Tested:Low Power Communication Device - Transmitter TX045-27 S/N: N/A Device Description:The EUT is a 27 MHz radio transmitter for a toy. Modifications:The EUT was modified in order to meet the specifications. Please see list in Appendix C. Manufacturer:Kin Yat Industrial Co., Ltd. Blk A, 7/F, Galaxy Factory Building 25-27 Luk Hop St. San Po Kong, Kowloon, Hong Kong Test Dates:July 9 and 10, 1998. Test Deviations:The test procedure was not deviated from during the testing. FCC ID: HDTTX045-27 Report Number: C80710M1 19121 EL TORO RD., SILVERADO, CALIFORNIA 92676 PHONE: (949) 589-0700 FAX: (949) 589-7700 Page 5 SUMMARY OF TEST RESULTS TESTDESCRIPTIONRESULTS 1Radiated RF Emissions, 10 kHz - 272 MHz.Complies with the limits of sections 15.205, 15.209 and 15.227 of FCC Title 47, Part 15, Subpart C 2Conducted RF emissions, 450 kHz - 30 MHzThis test is not applicable. The EUT is powered by a 9 volt battery. FCC ID: HDTTX045-27 Report Number: C80710M1 19121 EL TORO RD., SILVERADO, CALIFORNIA 92676 PHONE: (949) 589-0700 FAX: (949) 589-7700 Page 6 1.PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Low Power Communication Device – Transmitter, model: TX045-27. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4: 1992. The tests were performed in order to determine whether the electromagnetic emissions from the Low Power Communication Device - Transmitter, referred to as EUT hereafter, are within the specification limits defined by FCC Title 47, Part 15, Subpart C, sections 15.205, 15.209, and 15.227. FCC ID: HDTTX045-27 Report Number: C80710M1 19121 EL TORO RD., SILVERADO, CALIFORNIA 92676 PHONE: (949) 589-0700 FAX: (949) 589-7700 Page 7 2.ADMINISTRATIVE DATA 2.1Location of Testing The EMI/EMC tests described herein were performed at the test facility of Compatible Electronics, 19121 El Toro Rd., Silverado, California. 2.2Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST). 2.3Cognizant Personnel Kin Yat Industrial Co., Ltd. Andy ChanEngineering Compatible Electronics, Inc. Jesse A. MetoyerTest Engineer Victor RatinoffLab Manager 2.4Date Test Sample was Received The test sample was received on July 9, 1998. 2.5Disposition of the Test Sample The test sample has not yet been returned to Kin Yat Industrial Co., Ltd. 2.6Abbreviations and Acronyms The following abbreviations and acronyms may be used in this document. HPHewlett PackardRFRadio Frequency P/NPart NumberEMIElectromagnetic Interference LISNLine Impedance Stabilization NetworkS/NSerial Number ITEInformation Technology EquipmentEUTEquipment Under Test FCC ID: HDTTX045-27 Report Number: C80710M1 19121 EL TORO RD., SILVERADO, CALIFORNIA 92676 PHONE: (949) 589-0700 FAX: (949) 589-7700 Page 8 3.APPLICABLE DOCUMENTS The following documents are referenced or used in the preparation of this EMI Test Report. SPECTITLE FCC Title 47, Part 15 1997 FCC Rules - Radio frequency devices (including digital devices). ANSI C63.4 1992 Methods of measurement of radio-noise emissions from low-voltage electrical and elec…
