HED-FON2100Wireless Access Point

Required components Broadband connection(ADSL, cable, etc)ADSL Router or cablemodem from yourInternet Service ProviderWireless device, either alaptop or another devicewith a wireless adapter 11 . Before getting started... ADSL CABLE Router or Modem WiFi AC Adapter A network cable (white) Quick Installation Guide 2 . What's in the Box? Quick Installation Guide 3 ENGLISH Before installing MR3201A, check thatyou have the correct components tojoin MR3201A. 1. Your ISP's router or cable modem is compatible (see figures) and has an unused LAN Ethernet port. 2. Your ISP's router works properly and you can access Internet without problems. 44 La Fonera 1. Connect one end of the white network cable to MR3201A's internet port. 2 . Connect the other end of the network cable to one of your ISP router's LAN Ethernet ports. 3. Plug in MR3201A. 4. Check that MR3201A’s Power and LAN lights are on. Not compatible with MR3201A Compatible with MR3201A 3 . Install MR3201A Connect MR3201A now 4 WiFi Router - ADSL Router - ADSL Modem cable Modem USB - ADSL Your ISP's ADSL Router or cable modem MR3201A You don't need to make any changes in your current connection beforeinstalling MR3201A, but check that: 1 3 2 x OK OK OK OK x We'll show you a specific form for you to register your access point in the MR3201A Community.If you don't register it, we'll show you a reminder alert in the User Zone like the one in the figure. 1. Find the "Wireless Network Connection" icon in your computer. In Windows XP, it is located in the task bar (see figure).For other operating systems, check the User Manual. 2. Right click with your mouse on this icon and select "View available wireless networks" and a window similar to this one will appear: Quick Installation Guide 5 5 4 . Connect to MR3201A Your device (laptop, desktop computer, etc.) must have a wireless networkcard to be able to find and connect to WiFi networks.If your device isn't WiFi-ready, check the User Manual in the CD to configure MR3201A using a network cable. Register MR3201A Private Public a b MR3201A sends out two WiFi signals: a public one (MR3201A_AP) and a privateone (MyPlace).If you can't see signals, click on the "Refresh network list" button ( a ).If the problem persists, check that you've installed MR3201A properly.If you see MR3201A private signal but do not find the public signal, check theUser Manual, since you will need to make some network configurationadjustments in MR3201A. 3. MR3201A needs to be registered through public signal. Select the "AP" signal and click on the "Connect" button ( b ).A few seconds later you'll see a message informing that you're connected to the "AP" signal. 4. Open your browser (Internet Explorer, Firefox...) and you'll see Access Portal. 5. To access your User Zone, log in with the email and password you used to register in the MR3201A Community. ENGLISH FCC Regulations: zThis device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. zThis device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. zThis device complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation. zThe antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
