Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
http://www.3com.com/ Part No. DUA0085-5AAA04 Published October 2002 OfficeConnect ® Cable/DSL Gateway Wireless Cable/DSL Gateway User Guide 3C857 3CRWE52196 (3CRWE52196 Only) 3Com Corporation 5400 Bayfront Plaza Santa Clara, California 95052-8145 Copyright © 2002, 3Com Technologies. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from 3Com Technologies. 3Com Technologies reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of 3Com Technologies to provide notification of such revision or change. 3Com Technologies provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. 3Com may make improvements or changes in the product(s) and/or the program(s) described in this documentation at any time. If there is any software on removable media described in this documentation, it is furnished under a license agreement included with the product as a separate document, in the hard copy documentation, or on the removable media in a directory file named LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy, please contact 3Com and a copy will be provided to you. UNITED STATES GOVERNMENT LEGEND If you are a United States government agency, then this documentation and the software described herein are provided to you subject to the following: All technical data and computer software are commercial in nature and developed solely at private expense. Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or as a “commercial item” as defined in FAR 2.101(a) and as such is provided with only such rights as are provided in 3Com’s standard commercial license for the Software. Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree not to remove or deface any portion of any legend provided on any licensed program or documentation contained in, or delivered to you in conjunction with, this User Guide. Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not be registered in other countries. 3Com, OfficeConnect and the 3Com logo are registered trademarks of 3Com Corporation. Intel and Pentium are registered trademarks of Intel Corporation. Microsoft, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Novell and NetWare are registered trademarks of Novell, Inc. UNIX is a registered trademark in the United States and other countries, licensed exclusively through X/Open Company, Ltd. Netscape Navigator is a registered trademark of Netscape Communications. JavaScript is a trademark of Sun Microsystems WiFi and the WiFi logo are trademarks of WECA (Wireless Ethernet Compatibility Alliance) IEEE and 802 are trademarks of the Institute of Electrical and Electronics Engineers, Inc. All other company and product names may be trademarks of the respective companies with which they are associated. ENVIRONMENTAL STATEMENT It is the policy of 3Com Corporation to be environmentally-friendly in all operations. To uphold our policy, we are committed to: Establishing environmental performance standards that comply with national legislation and regulations. Conserving energy, materials and natural resources in all operations. Reducing the waste generated by all operations. Ensuring that all waste conforms to recognized environmental standards. Maximizing the recyclable and reusable content of all products. Ensuring that all products can be recycled, reused and disposed of safely. Ensuring that all products are labelled according to recognized environmental standards. Improving our environmental record on a continual basis. End of Life Statement 3Com processes allow for the recovery, reclamation and safe disposal of all end-of-life electronic components. Regulated Materials Statement 3Com products do not contain any hazardous or ozone-depleting material. Environmental Statement about the Documentation The documentation for this product is printed on paper that comes from sustainable, managed forests; it is fully biodegradable and recyclable, and is completely chlorine-free. The varnish is environmentally-friendly, and the inks are vegetable-based with a low heavy-metal content. CONTENTS ABOUT THIS GUIDE Naming Convention7 Conventions8 Feedback about this User Guide8 Related Documentation9 Product Registration9 1INTRODUCING THE GATEWAY OfficeConnect Cable/DSL Gateway and Wireless Cable/DSL Gateway11 Gateway Advantages13 Package Contents13 Minimum System and Component Requirements14 Front Panel14 Rear Panel16 2HARDWARE INSTALLATION Introduction19 Safety Information19 Positioning the Gateway19 Using the Rubber Feet20 Wall Mounting20 Before you Install your Gateway21 Powering Up the Gateway22 Connecting the Gateway22 Wireless Only23 3SETTING UP YOUR COMPUTERS Obtaining an IP Address Automatically25 Windows 200025 Windows XP27 Windows 95/98/ME27 Macintosh27 Disabling PPPoE and PPTP Client Software28 Disabling Web Proxy28 4RUNNING THE SETUP WIZARD Accessing the Wizard29 Password32 Time Zone32 WAN Settings33 LAN Settings38 DHCP38 Wireless Settings39 Summary40 5GATEWAY CONFIGURATION Navigating Through the Gateway Configuration Pages41 Main Menu41 Option Tabs42 Welcome Screen42 Notice Board43 Password43 Wizard44 LAN Settings44 Unit Configuration44 DHCP Clients List45 Wireless Settings46 Configuration46 Encryption48 Connection Control50 Client List53 Profile53 Internet Settings55 Connection to ISP56 Firewall61 Virtual Servers61 Special Applications63 PC Privileges65 …
Text truncated - open the document above for the full version.
American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 November 6, 2002 RE: Accton Technology Corporation FCC ID: HED3CRWE52196 After a review of the submitted information, I have a few comments on the above referenced Application. 1) Page 90 & 93 of the users manual states the device may use shielded or unshielded Ethernet cables. However pages 114 & 117 state that shielded cables must be used. Please explain if the device was tested with shielded Ethernet as it could not be confirmed in the test report. If shielded cables were not necessary, please remove the references in the users manual on pages 114 & 117, however if they were, please modify page 90 & 93 as appropriate. 2) The RF exposure statements on pages 117 & 118 need to have the prohibition of co-location added to them. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.
Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6 Page 7
LABEL LOCATION FOR FCC ID
8 0 . 0 0 m m 100.00 mm
Page 8 Page 9 Page 10 Page 11 Page 12
FCC ID: HED3CRWE52196 ADT No.911009R01 Operational Description The transmitter of the EUT is powered by power adapter and connected with PC through RJ45 port. The antenna used in this product is Dipole Antenna. The antenna connector is MMCX connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11,22Mbps.
FCC ID: HED3CRWE52196 ADT No.: 911009R10 FCC TEST REPORT REPORT NO.: RF911009R10 MODEL NO.: 3CRWE52196 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:ACCTON TECHNOLOGY CORPORATION ADDRESS: No. 1, Creation Rd., III, Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: HED3CRWE52196 ADT No.: 911009R10 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20 cm away from the body of the user. Warning statement for keeping 20 cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: HED3CRWE52196 ADT No.: 911009R10 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: HED3CRWE52196 ADT No.: 911009R10 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1Bi or 1.26 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241231.621.78 6243732.661.81 11246231.191.77 The minimum allowable distance is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 20 cm separation distance with the antenna.
FCC ID: HED3CRWE52196 Report No.: RF911009R101Issued: Nov. 4, 2002 FCC TEST REPORT REPORT NO.: RF911009R10 MODEL NO.: 3CRWE52196 RECEIVED: Oct. 3, 2002 TESTED: Oct. 4 ~ Nov. 1, 2002 APPLICANT:ACCTON TECHNOLOGY CORPORATION ADDRESS:No. 1, Creation Rd., III, Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 58 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: HED3CRWE52196 Report No.: RF911009R102Issued: Nov. 4, 2002 Table of Contents 1CERTIFICATION...........................................................................................4 2SUMMARY OF TEST RESULTS..................................................................5 3GENERAL INFORMATION...........................................................................6 3.1GENERAL DESCRIPTION OF EUT.............................................................6 3.2DESCRIPTION OF TEST MODES...............................................................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS..............................7 3.4DESCRIPTION OF SUPPORT UNITS.........................................................8 4TEST TYPES AND RESULTS......................................................................9 4.1CONDUCTED EMISSION MEASUREMENT................................................9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT......................................................9 4.1.2TEST INSTRUMENTS..........................................................................................................9 4.1.3TEST PROCEDURES.........................................................................................................10 4.1.4TEST SETUP......................................................................................................................11 4.1.5EUT OPERATING CONDITIONS........................................................................................12 4.1.6TEST RESULTS (A)............................................................................................................13 4.1.7TEST RESULTS (B)............................................................................................................19 4.2RADIATED EMISSION MEASUREMENT...................................................25 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT.........................................................25 4.2.2TEST INSTRUMENTS........................................................................................................26 4.2.3TEST PROCEDURES.........................................................................................................27 4.2.4TEST SETUP......................................................................................................................28 4.2.5EUT OPERATING CONDITIONS........................................................................................28 4.2.6TEST RESULTS (A)............................................................................................................29 4.2.7TEST RESULTS (B)............................................................................................................31 4.2.8TEST RESULT....................................................................................................................33 4.36dB BANDWIDTH MEASUREMENT..........................................................36 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT................................................................36 4.3.2TEST INSTRUMENTS........................................................................................................36 4.3.3TEST PROCEDURE...........................................................................................................37 4.3.4TEST SETUP......................................................................................................................37 4.3.5EUT OPERATING CONDITIONS........................................................................................37 4.3.6TEST RESULTS..................................................................................................................38 4.4MAXIMUM PEAK OUTPUT POWER..........................................................42 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT...................................42 4.4.2INSTRUMENTS...................................................................................................................42 4.4.3TEST PROCEDURES.........................................................................................................43 4.4.4TEST SETUP......................................................................................................................43 4.4.5EUT OPERATING CONDITIONS........................................................................................43 4.4.6TEST RESULTS..................................................................................................................44 4.5POWER SPECTRAL DENSITY MEASUREMENT.....................................45 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT...........................................45 4.5.2TEST INSTRUMENTS........................................................................................................45 4.5.3TEST PROCEDURE...........................................................................................................46 4.5.4TEST SETUP......................................................................................................................46 FCC ID: HED3CRWE52196 Rep…
Text truncated - open the document above for the full version.
FCC ID: HED3CRWE52196 Report No.: RF911009R1056Issued: Nov. 4, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: HED3CRWE52196 Report No.: RF911009R1057Issued: Nov. 4, 2002 RADIATED EMISSION TEST
13-1, Lane 19, WenShan 3rd., St. · Taoyuan · Taiwan
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.41 GHz - 2.46 GHz | 33.00 mW |
