HEDAC1200Dualband Outdoor AP, 802.11ac Outdoor Dual Band Access Point

Quick Star t Guide 802.11 ac Outdoor Stand‐Alone Access Point SkyFire™ AC1200 and SkyFire™ AC866 Brand : IgniteNet & Edge‐CorE The AC1200 and the AC866 are single‐ and dual‐band access points (APs) that are housed in a waterproof enclosure for mounting outdoors. The units include a built‐ in mounting bracket for attaching to a 1.5 to 6‐inch pole and they can be powered through their Ethernet cable connection from a power injector module that is installed indoors. The Outdoor Stand‐Alone Access Points include these models: ◆ SF‐AC1200 — dual‐band w/integrated 5 GHz antenna and 2x RP‐SMA (2.4 GHz) ◆ SF‐AC1200‐1 — dual‐band w/ 2x RP‐SMA (5 GHz) and 2x RP‐SMA (2.4 GHz) ◆ SF‐AC1200‐2 — dual‐band w/integrated 5 GHz antenna and 2.4 GHz antenna ◆ ECWO5320 —802.11ac Outdoor Dual Band Access Point ◆ ECWO5320‐L —802.11ac Outdoor Dual Band Access Point ◆ SF‐AC866 — single‐band w/integrated 5 GHz antenna ◆ SF‐AC866‐1 — single‐band w/ 2x RP‐SMA (5 GHz) Note: For Safety and Regulatory information, refer to the Safety and Regulatory Information document included with the AP. www.ignitenet.com –12– – Getting Started This section provides an overview of the access point, and introduces some basic concepts about wireless networking. It also describes the basic settings required to access the management interface. This section includes these chapters: ◆ “Introduction” on page 12 Section I –13– Introduction The access point (AP) runs software that includes a network management agent. The agent offers a variety of management options, including SNMP and a web‐ based interface. The AP can also be accessed via Telnet or SSH for configuration using a command line interface (CLI). Configuration Options The access point’s web agent allows you to configure AP parameters, monitor wireless connections, and display statistics using a standard web browser such as Internet Explorer 9.x or later, Mozilla Firefox 5 or later, and Google Chrome 35 or later. The AP’s web management interface can be accessed from any computer attached to the network. The CLI program can be accessed remotely by a Telnet or Secure Shell (SSH) connection over the network. The CLI is used primarily for technical support. The AP’s management agent also supports SNMP (Simple Network Management Protocol). This SNMP agent permits the AP to be managed from any computer in the network using network management software. The AP’s web interface, console interface, and SNMP agent allow you to perform management functions such as: ◆ Set management access user names and passwords ◆ Configure IP settings ◆ Configure SNMP parameters ◆ Configure 2.4 GHz and 5 GHz radio settings ◆ Control access through wireless security settings ◆ Filter packets using Access Control Lists (ACLs) ◆ Download system firmware ◆ Download or upload configuration files ◆ Display system information and statistics 1 –14– Chapter 1 | Introduction Network Connections Network Connections Prior to accessing the AP’s management agent through a network connection, you must first configure it with a valid IP address, subnet mask, and default gateway using the web interface, or the DHCP protocol. The AP has a static default management address of 192.168.2.1 and a subnet mask of 255.255.255.0. If the AP’s default IP address is not compatible with your network or a DHCP server is not available, the AP’s IP address must be configured manually through the web interface. First connect to the AP’s Ethernet 1 port and log in to the web interface, as described in “Connecting to the Web Interface” on page 13. Follow the steps described in “Setup Wizard” on page 15 to select your country and specify one of the configuration methods. Then configure the AP with an IP address that is compatible with your network as described under “LAN Settings” on page 33. Once the AP’s IP settings are configured for your network, you can access the AP’s management agent from anywhere within the attached network. The AP can be managed by any computer using a web browser, or from a network computer using SNMP network management software. Connecting to the Web Interface The AP offers a user‐friendly web‐based management interface for the configuration of all the unit’s features. Any PC directly attached to the unit can access the management interface using a web browser, such as Internet Explorer 9.x or later, Mozilla Firefox 5 or later, and Google Chrome 35 or later. You may want to make initial configuration changes by connecting a PC directly to the AP’s LAN port. The AP has a default management IP address of 192.168.2.1 and a subnet mask of 255.255.255.0. You must set your PC IP address to be on the same subnet as the AP (that is, the PC and AP addresses must both start with192.168.2.x). To access the AP’s web management interface, follow these steps: 1. Use your web browser to connect to the management interface using the default IP address of 192.168.2.1. 2. Log in to the interface by entering the default user name “root” with the password “admin123”, then click Login. –15– Chapter 1 | Introduction Connecting to the Web Interface Note: It is strongly recommended to change the default user name and password the first time you access the web interface. For information on changing user names and passwords, see “User Accounts” on page 57. Figure 1: Login Page –16– Chapter 1 | Introduction Setup Wizard Setup Wizard The Setup Wizard is designed to help you configure the basic settings required to get the AP up and running. Step 1 Select Your Country – Select the access point’s country of operation from the drop‐ down menu. You must set the AP’s country code to be sure that the radios operate according to permitted local regulations. That is, setting the country code restricts operation of the AP to the radio channels and transmit power levels permitted for wireless networks in the specified country. Figure 2: Select Your Country Caution: You must set the country code to the country of operation. Setting the country code ensur…

Text truncated - open the document above for the full version.

Accton Technology Corporation No.1, Creation Rd. III, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. Declaration for no non-US channel operation April 20, 2015 FCC ID: HEDAC1200 We, Accton Technology Corporation declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you!

Accton Technology Corporation No.1, Creation Rd. III, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. P R O F E S S I O N A L I N S T A L L A T I O N A T T E S T A T I O N Date: 2015-04-20 FCC ID: HEDAC1200 To Whom It May Concern: Please be advised that due to the unique Market and function targeted by this product, this product will need special trained professional in configuring and installing the product. We hereby declare that the product will be distributed through controlled distribution channel which has special trained professional to install this product and will not be sold directly to the general public through retail store. Thank you for your attention. Sincerely yours,

Accton Technology Corporation No.1, Creation Rd. III, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. Date: 2015-04-20 FCC ID: HEDAC1200 AUTHORIZATION LETTER To whom it may concern: We, the undersigned, hereby authorize (name: Amanda Wu and Title: Senior Specialist)of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners relating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by (name: Amanda Wu and Title: Senior Specialist) of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours,

Accton Technology Corporation No.1, Creation Rd. III, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. Date: 2015-04-20 FCC ID: HEDAC1200 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Software Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours,

Accton Technology Corporation No.1, Creation Rd. III, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. Date: 2015-04-20 FCC ID: HEDAC1200 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until (2015/9/30) in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours,

Report No.: 140402E02F Page 1 Reference No.: 150304E07 CONSTRUCTION PHOTOS OF EUT Model No.: SF-AC1200 Report No.: 140402E02F Page 2 Reference No.: 150304E07 Report No.: 140402E02F Page 3 Reference No.: 150304E07 Model No.: SF-AC1200-1 Report No.: 140402E02F Page 4 Reference No.: 150304E07 Report No.: 140402E02F Page 5 Reference No.: 150304E07 Model No.: SF-AC1200-2 Report No.: 140402E02F Page 6 Reference No.: 150304E07 Model No.: ECWO5320 Report No.: 140402E02F Page 7 Reference No.: 150304E07 Model No.: ECWO5324 Report No.: 140402E02F Page 8 Reference No.: 150304E07 PoE Model No.: NU24-F240100-I2 Report No.: 140402E02F Page 9 Reference No.: 150304E07

FCC IDΚHEDAC1200 LABEL LOCATION Brad name : IgniteNet Model name : SF-AC1200 FCC ID: HEDAC1200

Report No.: 140402E02F Page 1 Reference No.: 150304E07 CONSTRUCTION PHOTOS OF EUT Model No.: SF-AC1200 Report No.: 140402E02F Page 2 Reference No.: 150304E07 Report No.: 140402E02F Page 3 Reference No.: 150304E07 Report No.: 140402E02F Page 4 Reference No.: 150304E07 Report No.: 140402E02F Page 5 Reference No.: 150304E07 Report No.: 140402E02F Page 6 Reference No.: 150304E07 Internal antenna 1 (Brand Name: Accton / Model Name: 123800000297A) Report No.: 140402E02F Page 7 Reference No.: 150304E07 Report No.: 140402E02F Page 8 Reference No.: 150304E07 External antenna 1 (Brand Name: Cortec / Model Name: AN2400-0334RS) Report No.: 140402E02F Page 9 Reference No.: 150304E07 Report No.: 140402E02F Page 10 Reference No.: 150304E07 Report No.: 140402E02F Page 11 Reference No.: 150304E07 Report No.: 140402E02F Page 12 Reference No.: 150304E07 Model No.: SF-AC1200-1 Report No.: 140402E02F Page 13 Reference No.: 150304E07 Report No.: 140402E02F Page 14 Reference No.: 150304E07 Report No.: 140402E02F Page 15 Reference No.: 150304E07 Report No.: 140402E02F Page 16 Reference No.: 150304E07 Report No.: 140402E02F Page 17 Reference No.: 150304E07 External Antenna 1 (Brand Name: Cortec / Model Name: AN2400-0334RS) Report No.: 140402E02F Page 18 Reference No.: 150304E07 Report No.: 140402E02F Page 19 Reference No.: 150304E07 External Antenna 2 (Brand Name: Cortec / Model Name: AN5000-0301RS) Report No.: 140402E02F Page 20 Reference No.: 150304E07 Report No.: 140402E02F Page 21 Reference No.: 150304E07 Report No.: 140402E02F Page 22 Reference No.: 150304E07 Report No.: 140402E02F Page 23 Reference No.: 150304E07 Model No.: SF-AC1200-2 Report No.: 140402E02F Page 24 Reference No.: 150304E07 Report No.: 140402E02F Page 25 Reference No.: 150304E07 Report No.: 140402E02F Page 26 Reference No.: 150304E07 Report No.: 140402E02F Page 27 Reference No.: 150304E07 Internal Antenna 2 ((2.4GHz & 5GHz) / Brand Name: Accton / Model Name: 123800000295A) Report No.: 140402E02F Page 28 Reference No.: 150304E07 Internal antenna 2 ((2.4GHz) / Brand Name: Accton / Model Name: 123800000295A) Report No.: 140402E02F Page 29 Reference No.: 150304E07 Report No.: 140402E02F Page 30 Reference No.: 150304E07 Report No.: 140402E02F Page 31 Reference No.: 150304E07 Internal antenna 2 ((5GHz) / Brand Name: Accton / Model Name: 123800000295A) Report No.: 140402E02F Page 32 Reference No.: 150304E07 Report No.: 140402E02F Page 33 Reference No.: 150304E07 Model No.: ECWO5320 Report No.: 140402E02F Page 34 Reference No.: 150304E07 External antenna 1 (Brand Name: Cortec / Model Name: AN2400-0334RS) Report No.: 140402E02F Page 35 Reference No.: 150304E07 Report No.: 140402E02F Page 36 Reference No.: 150304E07 Report No.: 140402E02F Page 37 Reference No.: 150304E07 Report No.: 140402E02F Page 38 Reference No.: 150304E07 Internal antenna 3 (Brand Name: Accton / Model Name: OAP1232RL-FLF-EC) Report No.: 140402E02F Page 39 Reference No.: 150304E07 Report No.: 140402E02F Page 40 Reference No.: 150304E07 Report No.: 140402E02F Page 41 Reference No.: 150304E07 Report No.: 140402E02F Page 42 Reference No.: 150304E07 Report No.: 140402E02F Page 43 Reference No.: 150304E07 Model No.: ECWO5324 Report No.: 140402E02F Page 44 Reference No.: 150304E07 External antenna 1 (Brand Name: Cortec / Model Name: AN2400-0334RS) Report No.: 140402E02F Page 45 Reference No.: 150304E07 Report No.: 140402E02F Page 46 Reference No.: 150304E07 External Antenna 2 (Brand Name: Cortec / Model Name: AN5000-0301RS) Report No.: 140402E02F Page 47 Reference No.: 150304E07 Report No.: 140402E02F Page 48 Reference No.: 150304E07 Report No.: 140402E02F Page 49 Reference No.: 150304E07 Report No.: 140402E02F Page 50 Reference No.: 150304E07

Report No.: SA140402E02F Page No. 1 / 8 Report Format Version: 6.1.1 Reference No.: 150304E07 RF Exposure Report Report No.: SA140402E02F FCC ID: HEDAC1200 Test Model: SF-AC1200, SF-AC1200-1, SF-AC1200-2 Series Model: ECWO5320, ECWO5320-L, ECWO5320-C, ECWO5324, ECWO5324-L, ECWO5324-C Received Date: Apr. 08, 2014 Test Date: Mar. 19 to Apr. 10, 2015 Issued Date: Apr. 17, 2015 Applicant: Accton Technology Corporation Address: No.1, Creation Rd. III, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SA140402E02F Page No. 2 / 8 Report Format Version: 6.1.1 Reference No.: 150304E07 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Antenna Gain ...................................................................................................................................... 6 3 Calculation Result of Maximum Conducted Power ........................................................................... 7 Report No.: SA140402E02F Page No. 3 / 8 Report Format Version: 6.1.1 Reference No.: 150304E07 Release Control Record Issue No. Description Date Issued SA140402E02F Original release. Apr. 17, 2015 Report No.: SA140402E02F Page No. 5 / 8 Report Format Version: 6.1.1 Reference No.: 150304E07 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA140402E02F Page No. 6 / 8 Report Format Version: 6.1.1 Reference No.: 150304E07 2.4 Antenna Gain 1. The antennas provided to the EUT, please refer to the following table: External antenna 1 (Signal Band Ant.) Brand Name: Cortec / Model Name: AN2400-0334RS Transmitter Circuit Antenna Type Connecter Type Antenna Gain(dBi) <excluding cable loss> Inside EUT Outside EUT Net. Gain (dBi) Frequency range (MHz to MHz) Cable Loss (dB) Cable Length (mm) Cable Loss (dB) Cable Length (mm) Chain (0) Dipole RP-SMA 2.65 1 250 1.5 500 0.15 2400~2500 Chain (1) Dipole RP-SMA 2.65 1 250 1.5 500 0.15 2400~2500 External antenna 2 (Signal Band Ant.) Brand Name: Cortec / Model Name: AN5000-0301RS Transmitter Circuit Antenna Type Connecter Type Antenna Gain(dBi) <excluding cable loss> Inside EUT Outside EUT Net. Gain (dBi) Frequency range (MHz to MHz) Cable Loss (dB) Cable Length (mm) Cable Loss (dB) Cable Length (mm) Chain (0) Dipole RP-SMA 2.7 1.2 250 2.9 500 -1.4 5150~5850 Chain (1) Dipole RP-SMA 2.7 1.2 250 2.9 500 -1.4 5150~5850 Internal antenna 1 (Signal Band Ant.) Brand Name: Accton / Model Name: 123800000297A Transmitter Circuit Antenna Type Connecter Type Antenna Gain(dBi) Frequency range (MHz to MHz) Chain (0) Patch Array MMCX 13.81 5150~5850 Chain (1) Patch Array MMCX 13.72 5150~5850 Internal antenna 2 (Dual Band Ant.) Brand Name: Accton / Model Name: 123800000295A Transmitter Circuit Antenna Type Connecter Type Antenna Gain(dBi) Freque…

Text truncated - open the document above for the full version.

Report No.: RF140402E02F Page No. 1 / 107 Report Format Version: 6.1.1 Reference No.: 150304E07 FCC Test Report Report No.: RF140402E02F FCC ID: HEDAC1200 Test Model: SF-AC1200, SF-AC1200-1, SF-AC1200-2 Series Model: ECWO5320, ECWO5320-L, ECWO5320-C, ECWO5324, ECWO5324-L, ECWO5324-C Received Date: Apr. 08, 2014 Test Date: Apr. 08 to 16, 2014 and Mar. 19 to Apr. 09, 2015 Issued Date: Apr. 17, 2015 Applicant: Accton Technology Corporation Address: No.1, Creation Rd. III, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF140402E02F Page No. 2 / 107 Report Format Version: 6.1.1 Reference No.: 150304E07 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes .................................................................................................................. 11 3.2.1 Test Mode Applicability and Tested Channel Detail ........................................................................... 12 3.3 Duty Cycle of Test Signal .................................................................................................................. 14 3.4 Description of Support Units ............................................................................................................. 15 3.4.1 Configuration of System under Test .................................................................................................. 16 3.5 General Description of Applied Standards ........................................................................................ 17 4 Test Types and Results ...................................................................................................................... 18 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 18 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 18 4.1.2 Test Instruments ................................................................................................................................ 19 4.1.3 Test Procedures ................................................................................................................................. 22 4.1.4 Deviation from Test Standard ............................................................................................................ 22 4.1.5 Test Setup .......................................................................................................................................... 23 4.1.6 EUT Operating Conditions ................................................................................................................. 24 4.1.7 Test Results (Mode 1) ........................................................................................................................ 25 4.1.8 Test Results (Mode 2) ........................................................................................................................ 44 4.2 Conducted Emission Measurement ................................................................................................…

Text truncated - open the document above for the full version.

Report No.: RF140402E02F-1 Page No. 1 / 132 Report Format Version:6.1.1 Reference No.: 150304E07 FCC Test Report Report No.: RF140402E02F-1 FCC ID: HEDAC1200 Test Model: SF-AC1200, SF-AC1200-1, SF-AC1200-2 Series Model: ECWO5320, ECWO5320-L, ECWO5320-C, ECWO5324, ECWO5324-L, ECWO5324-C Received Date: Mar. 04, 2015 Test Date: Mar. 19 to Apr. 09, 2015 Issued Date: Apr. 17, 2015 Applicant: Accton Technology Corporation Address: No.1, Creation Rd. III, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF140402E02F-1 Page No. 2 / 132 Report Format Version:6.1.1 Reference No.: 150304E07 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes .................................................................................................................. 11 3.2.1 Test Mode Applicability and Tested Channel Detail ........................................................................... 12 3.3 Duty Cycle of Test Signal .................................................................................................................. 15 3.4 Description of Support Units .............…

Text truncated - open the document above for the full version.
