HEDACCWN3301G802.11b Wireless 11Mbps LAN PC Card

Accton Technology Corporation No.1 Creation Rd. III, Science – based Industrial Park, Hsin Chu300, Taiwan, R.O.C. Tel:886-5770270 Fax:886-3-5783839 Inform Letter Dear Customer, According to FCC’s regulation, the following Declaration of Conformity has to be made by a company located in USA. They are: This device has been confirmed to be in compliance with the requirements of ANSI C63.4 & FCC part 15 regulations. The test result has been shown in the ADT test report with number RF910612R03. And this compliance is subject to the following two conditions: This device may not cause harmful interference and, This device must accept any interference received, including interference that may cause undesired operation. This declaration can be a separate sheet and be sure that the following message will be also included in this declaration: Product name, model name and trade name. Company name, and address of the one who is responsible for this declaration. Name, title, telephone and fax number as well as the signature of the contact person. Thanks for your attention.

802.11b Wireless PC Card Quick Installation Guide Quick Installation Guide 802.11b Wireless PC Card 11 Mbps Wireless PC Card Other trademarks or brand names mentioned herein are trademarks or registered trademarks of their respec- tive companies. WN3301G-P1 E062002-R01 i Contents Introduction 1 Package Checklist 1 Hardware Description 1 Features 2 Applications 2 System Requirements 3 Installation 3 Driver Installation 5 Windows 95/98/2000 Installation 5 Driver Installation for Windows NT 4.0 10 Network Configuration and Planning 13 Network Topologies 13 Ad-hoc Wireless LAN 13 Infrastructure Wireless LAN 14 Setting the Communication Domain 15 Stationary Wireless PCs 15 Roaming Wireless PCs 15 Configuration and Diagnostic Utility 16 Utility Installation 16 Using the Wireless LAN Utility 16 Troubleshooting 20 Adapter Installation Problems 20 Network Connection Problems 20 Compliances 22 Federal Communication Commission Interference Statement 22 CAUTION STATEMENT: 22 CSA Statement (Canada) 23 VCCI Class B Compliance (Japan) 23 CE Mark Declaration of Conformance for EMI and Safety (EEC) 24 Product Specifications 25 General Specifications 25 Software Drivers 26 Contents ii 1 Introduction The Wireless PC Card is an 11 Mbps wireless network adapter that seamlessly integrates with existing Ethernet networks to support applications such as mobile users or temporary conferences. This solution offers a high data rate and reliable wireless connectivity with considerable cost savings over wired LANs (which include long-term maintenance overhead for cabling). Just install enough wireless Access Stations to cover your network area, plug wireless cards into your devices, and start networking. Using this card in conjunction with the Access Station, you can create an instant network that integrates seamlessly with 10 Mbps Ethernet LANs. Moreover, moving or expanding your network is as easy as moving or installing additional Access Stations – no wires! Package Checklist The Wireless PC Card package includes: •1 Wireless PC Card (WN3301G-P1) •1 driver and utility CD •This Quick Installation Guide Hardware Description The Wireless PC Card supports 1, 2, 5.5 and 11 Mbps half-duplex connections to Ethernet networks. This card is fully compliant with 2.4 GHz DSSS CSMA/CA wireless networking as defined in IEEE 802.11b. It can be installed in any device with a Type II PCMCIA slot. It supports Windows 95 (OSR2.1 or above) /98/NT/2000. WN3301G-P1 Wireless PC Card 2 Features •1, 2, 5.5 and 11 Mbps data rate. •Wireless connection without the hassles and cost of cabling •Greater flexibility to locate or move networked PCs •Integrates with or replaces wired LANs at dramatically lower cost than wired alternatives •Seamless connectivity to wired Ethernet LANs augments existing networks quickly and easily •Easy installation •Working range up to 30 m (100 ft) at 11 Mbps, up to 100 m (300 ft) at 5.5 Mbps and lower (indoor communication) •Direct Sequence Spread-Spectrum (DSSS) technology provides robust, interference-resistant and secure wireless connection •Supports a wide range of systems (Win95 OSR2.1 or above/98/NT/2000) •Plug-and-Play •Provides a user-friendly interface for configuration •Enhances your network security with WEP data encryption •Built-in antenna Applications The Wireless products offer a fast, reliable, cost-effective solution for wireless client access to the network in applications like these: •Remote access to corporate network information E-mail, file transfer and terminal emulation •Difficult-to-wire environments Historic or old buildings, asbestos installations, and open areas where wiring is difficult to employ •Frequently changing environments Retailers, manufacturers and banks who frequently rearrange the workplace and change location •Temporary LANs for special projects or peak times Trade shows, exhibitions and construction sites which need a temporary setup for a short time period. Retailers, airline and shipping companies which need additional workstations for peak periods. Auditors who require workgroups at customer sites System Requirements 3 •Access to database for mobile workers Doctors, nurses, retailers, white-collar workers who need access to databases while being mobile in the hospital, retail store or office campus •SOHO (Small Office and Home Office) users SOHO users who need easy and quick installation of a small computer network System Requirements Before you install the Wireless PC Card, check your system for the following requirements: •A computer with a PCMCIA Type II slot, and a PCMCIA card and socket services compliant with revision 2.10 of the PCMCIA specification •Windows 95/98/NT/2000 (Prepare the Windows installation CD-ROM for use during installation.) •A minimum of 1500 Kbytes of free disk space for installing the driver and utility program •Other IEEE 802.11b-compliant devices installed in your service area Installation Warnings: •Network cards are sensitive to static electricity. To protect the card, always touch the metal chassis of your device before handling the card. 1. Turn on your device and boot your operating system. 2. Find an available Type II or Type III PCMCIA slot in your device. 3.With the PC Card’s 68-pin connector facing the PCMCIA slot and the “Model:WN3301G-P1” label facing up, slide the card completely into the PCMCIA slot as shown below. Note: The PCMCIA slot allows you to “hot swap” PC Cards any time, even when the power of your system is on. Wireless PC Card 4 4.For Windows 95 (OSR2.1 or above)/98/NT/2000, PCMCIA card and socket services compliant with revision 2.10 of the PCMCIA specification are required. Please check the documents of your PCMCIA driver before installing the software driver for the WN3301G-P1. 5.Install the appropriate network driver for your operating system. Drivers can be found on the driver CD. See “Driver Installation” on the next page for more information. 6.Install the configuration program for your wireless PC card. The…

Text truncated - open the document above for the full version.

FCC ID: HEDACCWN3301G ADT No.910612R03 Modular Approval Request Letter Advance Data Technology June 19, 2002 Dear Application Examiner, ACCTON TECHNOLOGY CORPORATION’s IEEE802.11b 11Mbps Wireless LAN Card, FCC ID: HEDACCWN3301G, would like to have your authorization for Limited Module Approval specific to the mobile device such as Access Point and Router. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip ISL3873BIK. 3. “The modular transmitter must have its own power supply regulation.” There is a regulator in the DC input port, the part number is AME8801. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a PCMCIA adapter card. Please see section Photographs of Test Configuration in the test report. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: HEDACCWN3301G ADT No.910612R03 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Dr. Alan Lane Manager of R&TTE Division Advance Data Technology

Subject: Re: Review of ACCTON TECHNOLOGY CORPORATION, FCC ID: HEDACCWN3301G To: [email protected] X-Mailer: Lotus Notes Release 5.0.8 June 18, 2001 From: [email protected] Date: Thu, 20 Jun 2002 15:38:36 +0800 X-MIMETrack: Serialize by Router on RF/ADT(Release 5.0.8 |June 18, 2001) at 2002/06/20 03:38:37 PM, Itemize by SMTP Server on LinKo/ADT(Release 5.0.8 |June 18, 2001) at 2002/06/20 03:40:17 PM, Serialize by Router on LinKo/ADT(Release 5.0.8 |June 18, 2001) at 2002/06/20 03:40:25 PM, Serialize complete at 2002/06/20 03:40:25 PM Dear Tim, Yes, this module will be sold only to the integrators, not the end users. Tha nk yo u. Alan

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3 Page 4

FCC ID LABEL LOCATION

FORM# R0-04D00-13 V.02 246000031100A UL Label R01 91 06 07 UL approve MM 0.2MM 0.072MM Black CHECK: APPROVE: MFG Factory: 1. NatSteel --------------------> AS 2. Accton --------------------------> AC 3. NatSteel------------------ > AI 4. NatSteel ------------> AM 5 Mototech---------------> AV 6. Accton --------------------------> None 7. CIS -------------------------> BH 8. Fair Job--------------------> BJ 9. Orient Semiconductor --> BY MFG Country: Vendor ID: Decide by import and export country Decide by Vendor Model:WN3301G FCC ID:HEDACCWN3301G 0560 ! Tested to Comply with FCC Part15 Standards FOR HOME OR OFFICE USE MFG Country (Arial Narrow, Point 4) MFG Factory (Arial Narrow, Point 4) Vendor ID (Arial Narrow, Point 4) 48.0 mm 40.0 mm WN3301G IEEE802.11b 11Mbps Wireless LAN Card R10*4 White mylor+pp Sylin

Page 5 Page 6 Page 7

FCC ID: HEDACCWN3301G ADT No.910612R03 Operational Description The transmitter of the EUT (IEEE802.11b 11Mbps Wireless LAN PC Card) is powered by host equipment via a PCMCIA interface. The antenna is Dipole antenna, and the antenna connector type is MMCX. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. This project is seeking the authorization of limited module approval specific to the mobile device such as Access Point and Router. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: HEDACCWN3301G ADT No.: 910612R03 FCC TEST REPORT REPORT NO.: RF910612R03 MODEL NO.: WN3301G ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:ACCTON TECHNOLOGY CORPORATION ADDRESS: No.1, Creation Rd., III, Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: HEDACCWN3301G ADT No.: 910612R03 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20 cm away from the body of the user. Warning statement for keeping 20 cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: HEDACCWN3301G ADT No.: 910612R03 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: HEDACCWN3301G ADT No.: 910612R03 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1 dBi or 1.26 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241231.551.78 6243731.551.78 11246231.411.77 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

FCC ID: HEDACCWN3301G Report No.: RF910612R03 1 Issued: June 19, 2002 FCC TEST REPORT REPORT NO.: RF910612R03 MODEL NO.: WN3301G RECEIVED: June 12, 2002 TESTED: June 13 ~ June 17 , 2002 APPLICANT:ACCTON TECHNOLOGY CORPORATION ADDRESS:No. 1, Creation Rd., III, Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 51 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: HEDACCWN3301G Report No.: RF910612R03 2 Issued: June 19, 2002 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS................................................................... 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................... 7 3.4DESCRIPTION OF SUPPORT UNITS.......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................. 9 4.1.2TEST INSTRUMENTS .................................................................................. 9 4.1.3TEST PROCEDURES................................................................................. 10 4.1.4TEST SETUP .............................................................................................. 10 4.1.5EUT OPERATING CONDITIONS.................................................................11 4.1.6TEST RESULTS.......................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT ................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................ 18 4.2.2TEST INSTRUMENTS ................................................................................ 19 4.2.3TEST PROCEDURES................................................................................. 20 4.2.4TEST SETUP .............................................................................................. 21 4.2.5EUT OPERATING CONDITIONS................................................................ 21 4.2.6TEST RESULTS.......................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .......................................................... 27 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................ 27 4.3.2TEST INSTRUMENTS ................................................................................ 27 4.3.3TEST PROCEDURE ................................................................................... 28 4.3.4TEST SETUP .............................................................................................. 28 4.3.5EUT OPERATING CONDITIONS................................................................ 28 4.3.6TEST RESULTS.......................................................................................... 29 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 33 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 33 4.4.2TEST INSTRUMENTS ................................................................................ 33 4.4.3TEST PROCEDURES................................................................................. 34 4.4.4TEST SETUP .............................................................................................. 34 4.4.5EUT OPERATING CONDITIONS................................................................ 34 FCC ID: HEDACCWN3301G Report No.: RF910612R03 3 Issued: June 19, 2002 4.4.6TEST RESULTS.......................................................................................... 35 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 36 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 36 4.5.2TEST INSTRUMENTS ................................................................................ 36 4.5.3TEST PROCEDURE ................................................................................... 37 4.5.4TEST SETUP .............................................................................................. 37 4.5.5EUT OPERATING CONDITIONS................................................................ 37 4.5.6TEST RESULTS.......................................................................................... 38 4.6BAND EDGES MEASUREMENT ................................................................ 42 4.6.1LIMITS OF BAND EDGES MEASUREMENT ............................................. 42 4.6.2TEST INSTRUMENTS ................................................................................ 42 4.6.3TEST PROCEDURE ................................................................................... 42 4.6.4EUT OPERATING CONDITION .................................................................. 43 4.6.5TEST RESULTS.......................................................................................... 43 4.7ANTENNA REQUIREMENT........................................................................ 46 4.7.1STANDARD APPLICABLE....................…

Text truncated - open the document above for the full version.

FCC ID: HEDACCWN3301G Report No.: RF910612R03 47 Issued: June 19, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: HEDACCWN3301G Report No.: RF910612R03 48 Issued: June 19, 2002 FCC ID: HEDACCWN3301G Report No.: RF910612R03 49 Issued: June 19, 2002 RADIATED EMISSION TEST FCC ID: HEDACCWN3301G Report No.: RF910612R03 50 Issued: June 19, 2002
