HEDAP20AGHiveAP 20 ag

Aerohive Deployment Guide Copyright Notice Copyright © 2007 Aerohive Networks, Inc. All rights reserved. Aerohive Networks, the Aerohive Networks logo, HiveOS, HiveAP, and HiveManager are trademarks of Aerohive Networks, Inc. All other trademarks and registered trademarks are the property of their respective companies. Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without receiving written permission from: Aerohive Networks, Inc. 2045 Martin Avenue, Suite 206 Santa Clara, CA 95050 P/N 330002-01, Rev. A Deployment Guide3 HiveAP Compliance Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: •Reorient or relocate the receiving antenna •Increase the separation between the equipment and receiver •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected •Consult the dealer or an experienced radio/TV technician for help FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Important: FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters (8 inches) between the radiator and your body. This transmitter must not be co- located or operating in conjunction with any other antenna or transmitter. Wireless 5 GHz Band Statements High power radars are allocated as primary users (meaning they have priority) of the 5250-5350 MHz and 5650-5850 MHz bands. These radars could cause interference and/or damage to the HiveAP when used in Canada. The term "IC" before the radio certification number only signifies that Industry Canada technical specifications were met. Industry Canada - Class B This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled "Digital Apparatus," ICES-003 of Industry Canada. Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe B prescrites dans la norme sur le matérial brouilleur: "Appareils Numériques," NMB-003 édictée par l'Industrie. EC Conformance Declaration Marking by the above symbol indicates compliance with the Essential Requirements of the R&TTE Directive of the European Union (1999/5/ EC). This equipment meets the following conformance standards: •EN 60950-1 (IEC 60950-1) - Product Safety •EN 301 893 - Technical requirements for 5 GHz radio equipment •EN 300 328 - Technical requirements for 2.4 GHz radio equipment •EN 301 489-1 / EN 301 489-17 - EMC requirements for radio equipment Countries of Operation and Conditions of Use in the European Community This device is intended to be operated in all countries of the European Community. Requirements for indoor vs. outdoor operation, license requirements and allowed channels of operation apply in some countries as described below. Note: The user must use the configuration utility provided with this product to ensure the channels of operation are in conformance with the spectrum usage rules for European Community countries as described below. •This device requires that the user or installer properly enter the current country of operation in the command line interface as described in the user guide, before operating this device. •This device will automatically limit the allowable channels determined by the current country of operation. Incorrectly entering the country of operation may result in illegal operation and may cause harmful interference to other systems. The user is obligated to ensure the device is operating according to the channel limitations, indoor/outdoor restrictions and license requirements for each European Community country as described in this document. •This device employs a radar detection feature required for European Community operation in the 5 GHz band. This feature is automatically enabled when the country of operation is correctly configured for any European Community country. The presence of nearby radar operation may result in temporary interruption of operation of this device. The radar detection feature will automatically restart operation on a channel free of radar. •The 5 GHz Turbo Mode feature is not allowed for operation in any European Community country. The current setting for this feature is found in the 5 GHz 802.11a Radio Settings Window as described in the user guide. •The 5 GHz radio's Auto Channel Select setting described in the user guide must always remain enabled to ensure that automatic 5 GHz channel selection complies with European requirements. The current setting for this feature is found …

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT 941122H03

FCC ID: HEDAP20AG FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 941122H03 941122H03 Page 10 941122H03

FCC ID: HEDAP20AG Report No.: SA941122H03A 1 Issued: Jan. 17, 2007 Reference No.:951121H01 RF EXPOSURE REPORT REPORT NO.: SA941122H03A MODEL NO.: HiveAP 20 ag ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Accton Technology Corporation ADDRESS: No.1, Creation Rd. III, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. FCC ID: HEDAP20AG Report No.: SA941122H03A 2 Issued: Jan. 17, 2007 Reference No.:951121H01 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz FCC ID: HEDAP20AG Report No.: SA941122H03A 3 Issued: Jan. 17, 2007 Reference No.:951121H01 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This is a stand alone radio device. So under normal use condition, it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: HEDAP20AG Report No.: SA941122H03A 4 Issued: Jan. 17, 2007 Reference No.:951121H01 6 Test Results 6.1 Antenna Gain There is one antenna provided to this EUT, please refer to the following table: Model No. Gain (dBi) Antenna Type Antenna Connector For 2.4GHz : 3 dBi FDS_2FED01+I3G For 5GHz : 5 dBi Dual Band Antenna, Dipole MMCX 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: For 2.4GHz 802.11b: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 123.027 0.039 1.0 6 2437 138.038 0.044 1.0 11 2462 56.234 0.018 1.0 802.11g: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 70.795 0.022 1.0 6 2437 245.471 0.077 1.0 11 2462 36.308 0.011 1.0 For 5GHz Operated in 5725 ~ 5850MHz band: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5745 251.189 0.158 1.0 3 5785 218.776 0.138 1.0 5 5825 213.796 0.135 1.0

FCC ID: HEDAP20AG Report No.: RF941122H03A 1 Report Format Version 2.0.4 Reference No.:951121H01 FCC TEST REPORT REPORT NO.: RF941122H03A MODEL NO.: HiveAP 20 ag RECEIVED: Nov. 25, 2005 TESTED: Dec. 05 to 21, 2005 ISSUED: Jan. 17, 2007 APPLICANT: Accton Technology Corporation ADDRESS: No.1, Creation Rd. III, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation TEST LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. This test report consists of 104 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. FCC ID: HEDAP20AG Report No.: RF941122H03A 2 Report Format Version 2.0.4 Reference No.:951121H01 Table of Contents 1. CERTIFICATION....................................................................................................5 2. SUMMARY OF TEST RESULTS............................................................................6 3. GENERAL INFORMATION.....................................................................................8 3.1 GENERAL DESCRIPTION OF EUT.......................................................................8 3.2 DESCRIPTION OF TEST MODES.......................................................................10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.......................11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.......................................13 3.4 DESCRIPTION OF SUPPORT UNITS..................................................................14 3.5 CONFIGURATION OF SYSTEM UNDER TEST...................................................15 4. TEST TYPES AND RESULTS (802.11b & g, 2400 ~ 2483.5MHz BAND)..............19 4.1 CONDUCTED EMISSION MEASUREMENT........................................................19 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT......................................19 4.1.2 TEST INSTRUMENTS..........................................................................................19 4.1.3 TEST PROCEDURES..........................................................................................20 4.1.4 DEVIATION FROM TEST STANDARD.................................................................20 4.1.5 TEST SETUP.......................................................................................................21 4.1.6 EUT OPERATING CONDITIONS.........................................................................21 4.1.7 TEST RESULTS...................................................................................................22 4.2 RADIATED EMISSION MEASUREMENT.............................................................26 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...........................................26 4.2.2 TEST INSTRUMENTS..........................................................................................27 4.2.3 TEST PROCEDURES..........................................................................................28 4.2.4 DEVIATION FROM TEST STANDARD.................................................................28 4.2.5 TEST SETUP.......................................................................................................29 4.2.6 EUT OPERATING CONDITIONS.........................................................................29 4.2.7 TEST RESULTS...................................................................................................30 4.3 6dB BANDWIDTH MEASUREMENT....................................................................38 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT..................................................38 4.3.2 TEST INSTRUMENTS..........................................................................................38 4.3.3 TEST PROCEDURE.............................................................................................39 4.3.4 DEVIATION FROM TEST STANDARD.................................................................39 4.3.5 TEST SETUP.......................................................................................................39 4.3.6 EUT OPERATING CONDITIONS.........................................................................39 4.3.7 TEST RESULTS...................................................................................................40 4.4 MAXIMUM PEAK OUTPUT POWER....................................................................46 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.....................46 4.4.2 INSTRUMENTS....................................................................................................46 4.4.3 TEST PROCEDURES..........................................................................................47 FCC ID: HEDAP20AG Report No.: RF941122H03A 3 Report Format Version 2.0.4 Reference No.:951121H01 4.4.4 DEVIATION FROM TEST STANDARD.................................................................47 4.4.5 TEST SETUP.......................................................................................................47 4.4.6 EUT OPERATING CONDITIONS.........................................................................47 4.4.7 TEST RESULTS...................................................................................................48 4.5 POWER SPECTRAL DENSITY MEASUREMENT................................................50 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT.............................50 4.5.2 TEST INSTRUMENTS..........................................................................................50 4.5.3 TEST PROCEDURE.............................................................................................51 4.5.4 DEVIATION FROM TEST STANDARD.…

Text truncated - open the document above for the full version.

PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (WITH ADAPTER) CONDUCTED EMISSION TEST (WITH POE) RADIATED EMISSION TEST (ANTENNA: FDS_2FED01+I3G + ADAPTER) 4 RADIATED EMISSION TEST (ANTENNA: FDS_2FED01+I3G + POE)
