The whole world can talk for free. Skype.Com WA6102-ZZ VM1185T Skype Wi-Fi Phone User Guide User Guide Guide Skype Wi-Fi Phone IEEE 802.11b/g Wireless Phone VM1185T E032006-R01 150xxxxxxxxxxxxx i Compliances Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IMPORTANT NOTE: FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11. Japan VCCI Class B ii EC Conformance Declaration Marking by the above symbol indicates compliance with the Essential Requirements of the R&TTE Directive of the European Union (1999/5/EC). This equipment meets the following conformance standards: • EN 60950-1 (IEC 60950-1) - Product Safety • EN 300 328 - Technical requirements for 2.4 GHz radio equipment • EN 301 489-1, EN 301 489-17 - EMC requirements for radio equipment This device is intended for use in the following European Community countries: Requirements for indoor vs. outdoor operation, license requirements and allowed channels of operation apply in some countries as described below: • In Italy the end-user must apply for a license from the national spectrum authority to operate this device outdoors. • In Belgium outdoor operation is only permitted using the 2.46 - 2.4835 GHz band: Channel 13. • In France outdoor operation is only permitted using the 2.4 - 2.454 GHz band: Channels 1 - 7. • Austria• Belgium• Denmark • Finland• France• Germany • Italy• Luxembourg• Netherlands • Norway• Spain• Sweden • Switzerland• United Kingdom• Portugal • Greece• Ireland• Iceland iii Contents Chapter 1: Introduction 1-1 Package Checklist 1-1 Hardware Description 1-2 AC Power Charger 1-3 Mini USB Cable 1-3 Chapter 2: Installing the Battery 2-1 Charging the Battery 2-2 Powering On the Phone 2-3 Chapter 3: Getting Started 3-1 First-Time Startup 3-1 Understanding the Phone’s LCD Display 3-3 The Main Menu 3-5 The Power Key Menu 3-6 Creating a New Skype Account 3-7 Setting Up a Contact List 3-8 Making a Call 3-9 Call and Event Lists 3-9 Chapter 4: Managing Contacts 4-1 Adding a Contact 4-1 Searching for Contacts 4-3 The Contacts List Options Menu 4-5 Blocking a Contact 4-5 Chapter 5: Personal Skype Settings 5-1 Setting Your Profile 5-1 Changing Your Password 5-2 Privacy Settings 5-4 Phone Notifications 5-5 Chapter 6: Wi-Fi Network Settings 6-1 Finding Wi-Fi Networks 6-1 iv Contents Preferred Networks 6-3 Setting Access to Open Networks 6-4 Chapter 7: General Settings 7-1 Changing the Display Language 7-1 Changing Display Settings 7-2 Setting the Time and Date 7-3 Displaying Phone Settings 7-5 Appendix A: Specifications A-1 Appendix B: Skype End User License Agreement B-1 1-1 Chapter 1: Introduction The VM1185T is a Wi-Fi (IEEE 802.11b/g) wireless phone that enables you to make Skype calls without using a computer. The phone enables you to use your normal Skype account with complete mobility, allowing you to roam and talk within any Wi-Fi hotspot, or at any location where you have an Internet connection through a nearby access point. Package Checklist The VM1185T Skype Wi-Fi Phone package includes these items: •One Skype Wi-Fi Phone (VM1185T) • One Lithium-Ion battery •One headset •One mini USB cable •One AC power charger • This Quick Start Guide • Management Guide CD Inform your dealer if there are any incorrect, missing or damaged items. If possible, retain the carton, including the original packing materials. Use them to repack the product in case there is a need to return it. Introduction 1-2 Hardware Description Before preparing the Skype Wi-Fi Phone for use, first become familiar with its main keys, buttons, and other hardware features. 1.LCD Display — Color software menu display. 2.Navigation Key — Four-direction software navigation key. Pressing the key down selects the current option. 3.Right Soft Key — Negative action key. Cancels or returns to previous menu. 4.End/Power Key — Ends an active call. Turns the power on and off. • Press for more than two seconds to power the phone on. • When on, press for two to four seconds to access the Power Key menu. • Press for more than four seconds to power the phone off. USB/Power Charge Port Headset Jack Alphanumeric Ke…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID: HEDVM1185T FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

XX Made in XXXXXX DC Input Voltage Range: 5V ,1A or USB 146000041300E R01 FCC ID:HEDVM1185T XXXXXXXXXXX XXXXXXXXXXX Model Name:VM1185T XX

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 For adapter Model No.: DSA-5P-05 FUS 050100 Page 14 Page 15 Page 16

FCC ID: HEDVM1185T Report No. 950215H01 Operational Description This device is a Skype WiFi Phone, the maximum data rate could be up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT (Skype WiFi Phone) is powered from power adapter or battery. The antenna used in this product is PIFA antenna with Murata micro-coaxial connector. The other instruction, please have a look at the users manual.

Report no.: SA950215H011Report Format Version 2.0.3 SAR TEST REPORT REPORT NO.: SA950215H01 MODEL NO.: VM1185T (refer to page 5 for other models) RECEIVED: Feb. 10, 2006 TESTED: Feb. 10 ~Mar. 30, 2006 ISSUED: Mar. 30, 2006 APPLICANT: Accton Technology Corporation ADDRESS: 4F., No.16, Lane 77, Sing-ai Rd., Neihu District, Taipei City 114, Taiwan, (R.O.C.) ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 46 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. No. 2177-01 Report no.: SA950215H012Report Format Version 2.0.3 TABLE OF CONTENTS 1.CERTIFICATION.......................................................................................................3 2.GENERAL INFORMATION .......................................................................................4 2.1GENERAL DESCRIPTION OF EUT .........................................................................4 2.2GENERAL DESCRIPTION OF APPLIED STANDARDS ..........................................6 2.3GENERAL INOFRMATION OF THE SAR SYSTEM.................................................6 2.4GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION................9 3.DESCRIPTION OF SUPPORT UNITS ...................................................................12 4.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ...............................13 4.1.DESCRIPTION OF ANTENNA LOCATION ............................................................13 4.2.DESCRIPTION OF ASSESSMENT POSITION......................................................15 4.3.DESCRIPTION OF TEST MODE ...........................................................................18 4.4.SUMMARY OF TEST RESULTS ............................................................................19 5.TEST RESULTS .....................................................................................................20 5.1TEST PROCEDURES ............................................................................................20 5.2MEASURED SAR RESULTS..................................................................................22 5.3SAR LIMITS............................................................................................................29 5.4RECIPES FOR TISSUE SIMULATING LIQUIDS ...................................................30 5.5TEST EQUIPMENT FOR TISSUE PROPERTY .....................................................33 6.SYSTEM VALIDATION ...........................................................................................34 6.1TEST EQUIPMENT ................................................................................................34 6.2TEST PROCEDURE...............................................................................................35 6.3VALIDATION RESULTS..........................................................................................37 6.4SYSTEM VALIDATION UNCERTAINTIES..............................................................38 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES ......................................39 7.1.PROBE CALIBRATION UNCERTAINTY ................................................................39 7.2.ISOTROPY UNCERTAINTY...................................................................................40 7.3.BOUNDARY EFFECT UNCERTAINTY ..................................................................40 7.4.PROBE LINEARITY UNCERTAINTY .....................................................................41 7.5.READOUT ELECTRONICS UNCERTAINTY .........................................................41 7.6.RESPONSE TIME UNCERTAINTY........................................................................41 7.7.INTEGRATION TIME UNCERTAINTY ...................................................................42 7.8.PROBE POSITIONER MECHANICAL TOLERANCE ............................................43 7.9.PROBE POSITIONING...........................................................................................43 7.10. PHANTOM UNCERTAINTY ...................................................................................44 7.11. DASY4 UNCERTAINTY BUDGET .........................................................................45 8.INFORMATION ON THE TESTING LABORATORIES ...........................................46 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION Report no.: SA950215H013Report Format Version 2.0.3 1. CERTIFICATION PRODUCT: Skype WiFi Phone (refer to page 5 for other products) MODEL: VM1185T (refer to page 5 for other models) BRAND: Accton (refer to page 5 for other brands) APPLICANT: Accton Technology Corporation TESTED: Feb. 10 ~Mar. 30, 2006 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1093), RSS-102 FCC OET Bulletin 65, Supplement C (01-01), The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:Mar. 30, 2006 Rebecca Huang TECHNICAL ACCEPTANCE :, DATE:Mar. 30, 2006 Responsible for RF Stanely Hsu APPROVED BY:, DATE:Mar. 30, 2006 Gary Chang / Supervisor Report no.: SA950215H014Report Format Version 2.0.3 2. GENERAL IN…

Text truncated - open the document above for the full version.

A - 1 APPENDIX A: TEST DATA Liquid Level Photo Tissue HSL2450MHz D=155mm Tissue MSL2450MHz D=150mm A - 2 Date/Time: 2006/2/13 10:35:16 Test Laboratory: Advance Data Technology Right Head-Cheek-11b-Ch1-Mode 1 DUT: WiFi Phone ; Type: VM1185T ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 Phantom: SAM 12 Medium parameters used: f = 2412 MHz; σ = 1.82 mho/m; ε r = 39.9; ρ = 1000 kg/m 3 ; Liquid level: 155 mm Phantom section: Right Section ; DUT test position : Cheek ; Modulation type: CCK Antenna type : Inverted-F Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 20.9 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790; ConvF(4.74, 4.74, 4.74) ; Calibrated: 2004/12/20 - SENDER-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579; Calibrated: 2005/3/23 - Phantom: SAM 12; Type: SAM V4.0; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 Touch position - Low Channel 1/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.290 mW/g Touch position - Low Channel 1/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 10.5 V/m Peak SAR (extrapolated) = 0.472 W/kg SAR(1 g) = 0.264 mW/g; SAR(10 g) = 0.140 mW/g Maximum value of SAR (measured) = 0.297 mW/g A - 3 Date/Time: 2006/2/13 10:58:42 Test Laboratory: Advance Data Technology Right Head-Cheek-11b-Ch6-Mode 1 DUT: WiFi Phone ; Type: VM1185T ; Test Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 Phantom: SAM 12 Medium parameters used: f = 2437 MHz; σ = 1.85 mho/m; ε r = 39.8; ρ = 1000 kg/m 3 ; Liquid level: 155 mm Phantom section: Right Section ; DUT test position : Cheek ; Modulation type: CCK Antenna type : Inverted-F Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 20.9 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790; ConvF(4.74, 4.74, 4.74) ; Calibrated: 2004/12/20 - SENDER-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579; Calibrated: 2005/3/23 - Phantom: SAM 12; Type: SAM V4.0; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 Touch position - Mid Channel 6/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.346 mW/g Touch position - Mid Channel 6/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 11.5 V/m Peak SAR (extrapolated) = 0.581 W/kg SAR(1 g) = 0.322 mW/g; SAR(10 g) = 0.171 mW/g Maximum value of SAR (measured) = 0.362 mW/g A - 4 A - 5 Date/Time: 2006/2/13 11:26:36 Test Laboratory: Advance Data Technology Right Head-Cheek-11b-Ch11-Mode 1 DUT: WiFi Phone ; Type: VM1185T ; Test Frequency: 2462 MHz Communication System: 802.11b ; Frequency: 2462 MHz ; Duty Cycle: 1:1 Phantom: SAM 12 Medium parameters used: f = 2462 MHz; σ = 1.88 mho/m; ε r = 39.7; ρ = 1000 kg/m 3 ; Liquid level: 155 mm Phantom section: Right Section ; DUT test position : Cheek ; Modulation type: CCK Antenna type : Inverted-F Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 20.9 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790; ConvF(4.74, 4.74, 4.74) ; Calibrated: 2004/12/20 - SENDER-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579; Calibrated: 2005/3/23 - Phantom: SAM 12; Type: SAM V4.0; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 Touch position - High Channel 11/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.330 mW/g Touch position - High Channel 11/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 11.3 V/m Peak SAR (extrapolated) = 0.703 W/kg SAR(1 g) = 0.312 mW/g; SAR(10 g) = 0.168 mW/g Maximum value of SAR (measured) = 0.343 mW/g Touch position - High Channel 11/Zoom Scan (7x7x7) (7x7x7)/Cube 1: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 11.3 V/m Peak SAR (extrapolated) = 0.494 W/kg SAR(1 g) = 0.214 mW/g; SAR(10 g) = 0.109 mW/g Maximum value of SAR (measured) = 0.271 mW/g A - 6 Date/Time: 2006/2/13 11:57:13 Test Laboratory: Advance Data Technology Right Head-Tilt-11b-Ch1-Mode 2 DUT: WiFi Phone ; Type: VM1185T ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 Phantom: SAM 12 Medium parameters used: f = 2412 MHz; σ = 1.82 mho/m; ε r = 39.9; ρ = 1000 kg/m 3 ; Liquid level: 155 mm Phantom section: Right Section ; DUT test position : Tilt ; Modulation type: CCK Antenna type : Inverted-F Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 20.9 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790; ConvF(4.74, 4.74, 4.74) ; Calibrated: 2004/12/20 - SENDER-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579; Calibrated: 2005/3/23 - Phantom: SAM 12; Type: SAM V4.0; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 Tilt position - Low Channel 1/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.136 mW/g Tilt position - Low Channel 1/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.30 V/m Peak SAR (extrapolated) = 0.254 W/kg SAR(1 g) = 0.129 mW/g; SAR(10 g) = 0.069 mW/g Maximum value of SAR (measured) = 0.143 mW/g Tilt position - Low Channel 1/Zoom Scan (7x7x7) (7x7x7)/Cube 1: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.30 V/ma Peak SAR (extrapolated) = 0.230 W/kg SAR(1 g) = 0.090 mW/g; SAR(10 g) = 0.051 mW/g Maximum value of SAR (measured) = 0.098 mW/g A - 7 Date/Time: 2006/2/13 12:26:45 Test Laboratory: Advance Data Technology Right Head-Tilt-11b-Ch6-Mode 2 DUT: WiFi Phone ; Type: VM1185T ; Test Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 Phantom: SAM 12 Medium parameters used: f = 2437 MHz; σ = 1.85 mho/m; ε r = 39.8; ρ = 1000 kg/m 3 ; Liquid level:…

Text truncated - open the document above for the full version.

B - 1 APPENDIX B: ADT SAR MEASUREMENT SYSTEM C - 1 APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM D2: DOSIMETRIC E-FIELD PROBE D3: DAE SN: 579

D3: DAE D4: SYSTEM VALIDATION DIPOLE

Report No.: RF950215H011Report Format Version 2.0.4 FCC TEST REPORT REPORT NO.: RF950215H01 MODEL NO.: VM1188T , SMCWSP-100, WM4101, VM1185T, WSKP100, WM4201 RECEIVED: March 7, 2006 TESTED: March 10, 2006 ISSUED: March 11, 2006 APPLICANT: Accton Technology Corporation ADDRESS: 4F., No.16, Lane 77, Sing-ai Rd., Neihu District, Taipei City 114, Taiwan, (R.O.C.) ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. This test report consists of 76 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. No. 2177-01 Report No.: RF950215H012Report Format Version 2.0.4 Table of Contents 1CERTIFICATION...........................................................................................4 2SUMMARY OF TEST RESULTS...................................................................5 3GENERAL INFORMATION............................................................................6 3.1GENERAL DESCRIPTION OF EUT..............................................................6 3.2DESCRIPTION OF TEST MODES..............................................................10 3.3TEST MODE APPLICABLITY AND TESTED CHANNEL DETAIL:..............11 3.4GENERAL DESCRIPTION OF APPLIED STANDARDS..............................13 3.5DESCRIPTION OF SUPPORT UNITS........................................................14 3.6CONFIGURATION OF SYSTEM UNDER TEST.........................................15 4TEST TYPES AND RESULTS.....................................................................18 4.1CONDUCTED EMISSION MEASUREMENT..............................................18 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT............................18 4.1.2TEST INSTRUMENTS.................................................................................18 4.1.3TEST PROCEDURES.................................................................................19 4.1.4TEST SETUP..............................................................................................19 4.1.5EUT OPERATING CONDITIONS................................................................20 4.1.6TEST RESULTS..........................................................................................21 4.2RADIATED EMISSION MEASUREMENT...................................................25 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT.................................25 4.2.2TEST INSTRUMENTS.................................................................................26 4.2.3TEST PROCEDURES.................................................................................27 4.2.4TEST SETUP..............................................................................................28 4.2.5EUT OPERATING CONDITIONS................................................................28 4.2.6TEST RESULTS..........................................................................................29 4.2.7TEST RESULTS - DSSS.............................................................................33 4.2.8TEST RESULTS - OFDM............................................................................36 4.36DB BANDWIDTH MEASUREMENT..........................................................39 4.3.1LIMITS OF 6DB BANDWIDTH MEASUREMENT........................................39 4.3.2TEST INSTRUMENTS.................................................................................39 4.3.3TEST PROCEDURE....................................................................................40 4.3.4TEST SETUP..............................................................................................40 4.3.5EUT OPERATING CONDITIONS................................................................40 4.3.6TEST RESULTS –DSSS..............................................................................41 4.3.7TEST RESULTS-OFDM..............................................................................44 4.4MAXIMUM PEAK OUTPUT POWER..........................................................47 Report No.: RF950215H013Report Format Version 2.0.4 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT...........47 4.4.2TEST INSTRUMENTS.................................................................................47 4.4.3TEST PROCEDURES.................................................................................48 4.4.4TEST SETUP..............................................................................................48 4.4.5EUT OPERATING CONDITIONS................................................................48 4.4.6TEST RESULTS – DSSS.............................................................................49 4.4.7TEST RESULTS –OFDM.............................................................................50 4.5POWER SPECTRAL DENSITY MEASUREMENT......................................51 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT....................51 4.5.2TEST INSTRUMENTS.................................................................................51 4.5.3TEST PROCEDURE....................................................................................52 4.5.4TEST SETUP..............................................................................................52 4.5.5EUT OPERATING CONDITIONS................................................................52 4.5.6TEST RESULTS –DSSS..............................................................................53 4.5.7TEST RESULTS –OFDM.............................................................................56 4.6BAND EDGES MEASUREMENT............…

Text truncated - open the document above for the full version.

Report No.: RF950215H0169Report Format Version 2.0.4 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (MODE 1) Report No.: RF950215H0170Report Format Version 2.0.4 CONDUCTED EMISSION TEST (MODE 2) Report No.: RF950215H0171Report Format Version 2.0.4 RADIATED EMISSION TEST ( MODE 1) Report No.: RF950215H0172Report Format Version 2.0.4 RADIATED EMISSION TEST (MODE 2) Report No.: RF950215H0173Report Format Version 2.0.4 RADIATED EMISSION TEST ( MODE 3) Report No.: RF950215H0174Report Format Version 2.0.4 RADIATED EMISSION TEST (MODE 4)
