HSW-2410GModular 2.4 GHz Transceiver

WIT2410 2.4GHz Spread Spectrum Wireless Industrial Transceiver Integration Guide 3079 Premiere Pkwy Ste 140 Duluth, Georgia 30097 www.cirronet.com +1 (678) 684-2000 Important Regulatory Information Cirronet Product FCC ID: HSW-2410G IC 4492A-2410G FCC s MPE Requirements Information to user/installer regarding FCC s Maximum Permissible Exposure (MPE) limits. Notice to users/installers using the 24 dBi parabolic dish antenna in conjunction with all Cirronet RF products. FCC rules limit the use of this antenna, when connected to Cirronet RF products for point-to-point applications only. It is the responsibility of the installer to ensure that the system is prohibited from being used in point-to-multipoint applications, omni-directional applications, and applications where there are multiple co-located intentional radiators transmitting the same information. Any other mode of operation using this antenna is forbidden. This module shall not be co-located inside a device with another transmitter. In the case of location with other devices at a fixed site installation, Users and installers must be provided with appropriate antenna installation instructions and transmitter operating conditions, including antenna co-location requirements of §1.1307(b)(3), for satisfying RF exposure compliance. Note: This unit has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at their expense. Notice to users/installers using the following fixed antennas, with Cirronet RF products: Andrews 24dBi parabolic dish Andrews 18dBi parabolic dish Cushcraft 15dBi Yagi, Mobile Mark 14dBi Corner Reflector, Mobile Mark 9dBi Corner Reflector The field strength radiated by any one of these antennas, when connected to Cirronet RF products, may exceed FCC mandated RF exposure limits. FCC rules require professional installation of these antennas in such a way that the general public will not be closer than 2 m from the radiating aperture of any of these antennas. End users of these systems must also be informed that RF exposure limits may be exceeded if personnel come closer than 2 m to the apertures of any of these antennas. Notice to users/installers using the following mobile antennas, with Cirronet RF products: Mobile Mark 12dBi omni-directional, Mobile Mark 9dBi omni-directional, MaxRad 5dBi whip, Cirronet Patch antenna, Ace 2dBi dipole, Mobile Mark 2dBi Stub The field strength radiated by any one of these antennas, when connected to Cirronet RF products, may exceed FCC mandated RF exposure limits. FCC rules require professional installation of these antennas in such a way that the general public will not be closer than 20 cm from the radiating aperture of any of these antennas. End users of these systems must also be informed that RF exposure limits may be exceeded if personnel come closer than 20 cm to the apertures of any of these antennas. Declaration of Conformity Warning! The RLAN transceiver within this device uses a band of frequencies that are not completely harmonized within the European Community. Before using, please read the European Operation Section of the Products User’s Guide for limitations. 0889 is the identification number of RADIO FREQUENCY INVESTIGATION LTD - Ewhurst Park, Ramsdell RG26 5RQ Basingstoke, United Kingdom – the Notified Body having performed part or all of the conformity assessment on the product. The WIT2410 to which this declaration relates is in conformity with the essential requirements of the R&TTE directive 1999/5/EC and complies with the following standards and/or other normative documents: For InterfacesFor RLAN Transceiver EN 55022 EN 55024 EN 300 328 EN 301 489 -1, -17 EN 60950 Use Within the European Union The WIT2410 is intended for use within the European Community States and in the following non-European Union States: Norway & Switzerland Use of the WIT2410 in France When used in France, the WIT2410 can only be operated with the France hopping pattern selected. This is accomplished by setting the pe parameter to 1. Refer to European Union Settings in this manual for details. Canadian Department of Communications Industry Canada (IC) Notice Canadian Department of Communications Industry Canada (IC) Notice This apparatus complies with Health Canada’s Safety Code 6 / IC RSS 102. "To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors may be subject to licensing." ICES-003 This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the radio interference regulations of Industry Canada. Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de Classe B prescrites dans le règlement sur le brouillage radioélectrique édicté par Industrie Canada. NOTE! Any changes of modifications not expressly approved by the party responsible for compliance could void the user’s authority operate the equipment. TABLE OF CONTENTS 1. INTRODUCTION......................................................................................................................1 1.1. Why Spread Spectrum?.........................................................................................................1 1.2. Frequency Hopping vs. Direct Sequence..............…

Text truncated - open the document above for the full version.

AGENCY AGREEMENT Federal Communications Commission P.O. Box 429 Columbia, MD 21045 Date: March 16, 2006 Gentlemen: By signature below, we hereby appoint United States Technologies, Inc. (U.S. Tech) to act as our agent with regard to all FCC equipment authorizations. This appointment will remain in effect until otherwise notified. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Al Patrick,Date: June 30, 2004 Sr. Compliance EngineerAl Patrick Cirronet [email protected] 5375 Oakbrook Parkway Norcross, GA 30093 678 684 2000 ext. 138

WIT2410G Product EMC Information CONFIDENTIALITY REQUEST Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: March 16, 2006 Gentlemen: Cirronet Inc respectfully requests confidentiality of certain materials provided with the submission of the WIT2410G under FCC ID: HSW-2410G in accordance with FCC Regulations 0.459. The confidentiality request applies to the schematics, block diagrams, and Theory of Operation. The WIT2410G has been developed at considerable effort and expense by Cirronet Inc.. These items are considered as Trade Secrets and therefore public access to the proprietary material could possible result in duplication of equipment that could severely damage the company's business advantage. I appreciate your assistance in this matter. Sincerely, Al Patrick,Date: March 16, 2006 Sr. Compliance Engineer Cirronet Inc. 5375 Oakbrook Parkway Norcross, GA 30093 678 684 2000 ext. 138 [email protected]

April 12, 2006 Dear Application Examiner Regarding Part 15 Unlicensed Modular Transmitter Approval, the following requirements called out in FCC Public Notice DA 00-1407 are observed: 1. The WIT2410G has its own RF shielding. 2. The WIT2410G modular transmitter has buffered modulation/data inputs to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over- modulation. 3. The WIT2410G employs on board power supply regulation to the transmitter portion of the module, utilizing IC U12 within the module. 4. The WIT2410G employs a MMCX connector. According to FCC Public Notice, DA 00-2225, the MMCX qualifies as a unique antenna coupler. 5. The WIT2410G was tested in a stand-alone configuration. 6. The WIT2410G has a label with the FCC ID: HSW-2410G 7. The WIT2410G complies with FCC 15.247 for Frequency Hopping Spread Spectrum Operation. An Integration Guide is provided for every module sold. This guide instructs the integrator in the proper operation of the device. The text in the guide specifies FCC Part 15 compliance: 8. The use of the WIT2410G in any application where the antenna is 20 cm or less distance to the body for mobile antennas and 2 m or less distance to the body for fixed antennas is not allowed. This is specified in the Integration Guide previous to the Table of Contents. The text follows: FCC s MPE Requirements Information to user/installer regarding FCC s Maximum Permissible Exposure (MPE) limits. Notice to users/installers using the 24 dBi parabolic dish antenna in conjunction with all Cirronet RF products. FCC rules limit the use of this antenna, when connected to Cirronet RF products for point-to-point applications only. It is the responsibility of the installer to ensure that the system is prohibited from being used in point-to- multipoint applications, omni-directional applications, and applications where there are multiple co-located intentional radiators transmitting the same information. Any other mode of operation using this antenna is forbidden. Notice to users/installers using the following fixed antennas, with Cirronet RF products: Andrews 24dBi parabolic dish Andrews 18dBi parabolic dish Hyperlink Technologies 24dBi Parabolic Dish The field strength radiated by any one of these antennas, when connected to Cirronet RF products, may exceed FCC mandated RF exposure limits. FCC rules require professional installation of these antennas in such a way that the general public will not be closer than 2 m from the radiating aperture of any of these antennas. End users of these systems must also be informed that RF exposure limits may be exceeded if personnel come closer than 2 m to the apertures of any of these antennas. Notice to users/installers using the following mobile antennas, with Cirronet RF products: Digital Wireless Corp 3 dBi patch Mobile Mark 6dBi omni-directional, Mobile Mark 9dBi omni-directional, Mobile Mark 9dBi Corner Reflector Mobile Mobile Mark 14dBi Corner Reflector MaxRad 5dBi whip, MaxRad 5dBi Magnetic Mount whip Cirronet 6dBi Patch antenna, Cirronet 12dBi Patch antenna, Ace 2dBi dipole, Cushcraft 15dBi Yagi, Mobile Mark 2.5 dBi Vehicle Mount Stub FCC rules require installation of these antennas in such a way that the general public will not be closer than 20 cm from the radiating aperture of any of these antennas. End users of these systems must also be informed that RF exposure limits may be exceeded if personnel come closer than 20 cm to the apertures of any of these antennas. Al Patrick Sr. Compliance Engineer Cirronet Inc. [email protected]

3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com 4/21/2006 Mr. Doug Noble ATCB RE: Cirronet FCC ID: HSW-2410G Below is my response for your comments on this Application. 1.) Please upload External Photos with shields on for this application. Uploaded 2.) Please upload Schematics for this application. Schematics were uploaded, they were located with the block diagram section. They have been removed and moved to their own section and uploaded. 3.) Please revise RF Exposure Information to include calculations for the mobile antennas and upload to ATCB. RF exposure section contains both mobile and fixed RF exposure calculations. 4.) Please upload SAR attestation for Industry Canada. See RSS-102 November 2005 last two pages. Uploaded. 5.) It appears that a modular approval is desired for this device. When modular approval is requested, a cover letter addressing each of the modular issues in the FCC guidance document must be provided. Please provide a cover letter addressing each of the modular requirements. Uploaded. 6.) Spectrum Analyzer and LISN are out of calibration in test report. At the time of testing, both the Spectrum Analyzer and the LISN were in calibration. The 8448 has been removed, since it was not used. The LISN Cal dates have been updated. The corrected report has been uploaded. 3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com 7.) The RF exposure exhibit lists frequencies from 2400.9 – 2476.2. However the 731 form lists 2401.69 – 2469.89, the test report lists 2400.15 – 2469.81, and the theory of operation cites 2401.6896 – 2469.888. What are the lowest and highest channels? All exhibits should be consistent. Please correct as necessary. The correct frequencies are 2401.6896-2469.888. Output Power was corrected to reflect the maximum power output frequency, but due to the short pulsing of the signal to simulate a constant output, the spectrum analyzer recorded spikes slightly lower than the actual lower frequency, but representative of the maximum power output. Form 731 has been corrected. 8.) The manual appears to be missing information of 15.21. Please update. If I have missed this please accept my apologies and tell me where it is. Manual updated and uploaded. 9.) Please provide information concerning “the system receivers shall have input bandwidths that match the hopping channel bandwidths of their corresponding transmitters and shall shift frequencies in synchronization with the transmitted signals”. Please provide information for this. Uploaded. 10.) ID label info in the manual states "Contains TX FCC ID: HSW-2410. On the 731 it is HSW-2410G which is correct? With or without the “G”? With the “G”. Manual corrected. 11.) A peak plot is missing on page 119 of the test report please retest or find this plot and put it in the revised test report . Retested, added, and report modified. 12.) Please upload Block Diagram for this application. Already uploaded. Re-sent. Into Block Diagram file. Please contact me with any further questions. Sincerely, Louis A. Feudi Vice President of Operations and Engineering

3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com 4/27/2006 Mr. Doug Noble ATCB RE: Cirronet FCC ID: HSW-2410G Below is my response for your comments on this Application. 1) Section 2.4 of the report cites Class B, while the manual cites A. Please have clarified/corrected I believe the manual you have reviewed may be the first draft submitted. The second draft, titled “M-2410-0000 WIT2410 Integration Guide Rev G1” has been corrected to reflect class B on page 2. If there is another section that references Class A, please notify me and it will be corrected. I have also updated “Rev G2” to address the issues below. 2) Section 7.3 (operational description) and 9.3 (integration guide/manual) cites N connectors with the user using loc-tite. The user is not allowed to be given this responsibility and therefore is in violation of 15 antenna requirements for non-standard connectors. The operational description is the integrators guide. Please use the “rev G2” version for both. As in previous applications, this unit is not intended for sale to user. This product is intended for integrators, who will manufacture a product with the antenna attached. Cirronet Corporation follows the following procedure, as detailed in our test report: To ensure compliance with 15.203, Cirronet Corporation attaches reverse-sex TNC or N connectors to all antennas except the 12 dBi and 6 dBi Patch antennas. Cirronet Corporation. has arranged for the manufacturers of the antennas to provide reverse-sex TNC or N connectors for these antennas. OEM customers wanting to use one of these antennas in their product will first need to obtain a special part number from Cirronet Corporation to give to the antenna manufacturer. The manufacturer, upon receipt of this number, will know to attach the reverse-sex TNC or N connector (or SMA in the case of the dipole) to the end of the antenna cable before shipping. 3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com The customer then purchases an adapter cable from Cirronet Corporation that will connect the MMCX port on the module to the reverse-sex connector on the antenna. No other type of commercially available antenna will attach to this reverse-sex TNC or N connector (or SMA for the case of the dipole). Given the nonstandard nature of the interconnect between module and antenna and the difficulty involved in circumventing that connection, Cirronet Corporation feel that this procedure meets the requirements called out in 15.203. The integration guide has been changed to reflect this connector type. 3a) RF exposure information needs work.....First solution shows level in excess of the limit (should have calculated distance not power density @ 20 cm). Corrected and uploaded. 3b) Mobile operation appears to have information regarding fixed contained in it. Corrected and uploaded. 3) Prohibition of co-location does not appear in the manual. See statement added to page 2 of the integration guide, “rev G2”. Please contact me with any further questions. Sincerely, Louis A. Feudi Vice President of Operations and Engineering

U.S. Technologies, Inc.FCC Part 15 C Rev: 040103 Report Number:05-0311Issue Date: March 31, 2006 Customer: Cirronet Corporation Model: WIT2410 G PHOTOGRAPHS External Photos U.S. Technologies, Inc.FCC Part 15 C Rev: 040103 Report Number:05-0311Issue Date: March 31, 2006 Customer: Cirronet Corporation Model: WIT2410 G PHOTOS OF THE TESTED EUT The following photos are attached: Photo 1.Top of EUT, Cover On Photo 2.Bottom of EUT, Cover On Photo 3.Top of EUT, Cover Open U.S. Technologies, Inc.FCC Part 15 C Rev: 040103 Report Number:05-0311Issue Date: March 31, 2006 Customer: Cirronet Corporation Model: WIT2410 G Photo 1.Top of EUT, Cover On U.S. Technologies, Inc.FCC Part 15 C Rev: 040103 Report Number:05-0311Issue Date: March 31, 2006 Customer: Cirronet Corporation Model: WIT2410 G Photo 2.Bottom of EUT, Cover On U.S. Technologies, Inc.FCC Part 15 C Rev: 040103 Report Number:05-0311Issue Date: March 31, 2006 Customer: Cirronet Corporation Model: WIT2410 G Photo 3.Top of EUT, Cover Open

U.S. Technologies, Inc.FCC Part 15 C Rev: 040103 Report Number:05-0311Issue Date: March 31, 2006 Customer: Cirronet Corporation Model: WIT2410 G SECTION 5 PHOTOGRAPHS Internal Photos U.S. Technologies, Inc.FCC Part 15 C Rev: 040103 Report Number:05-0311Issue Date: March 31, 2006 Customer: Cirronet Corporation Model: WIT2410 G PHOTOS OF THE TESTED EUT The following photos are attached: Photo 12.Top of EUT, Cover Removed Photo 13.Bottom of EUT, Cover Removed U.S. Technologies, Inc.FCC Part 15 C Rev: 040103 Report Number:05-0311Issue Date: March 31, 2006 Customer: Cirronet Corporation Model: WIT2410 G Photo 12.Top of EUT, Cover Removed U.S. Technologies, Inc.FCC Part 15 C Rev: 040103 Report Number:05-0311Issue Date: March 31, 2006 Customer: Cirronet Corporation Model: WIT2410 G Photo13.Bottom of EUT, Cover Removed

U.S. Technologies, Inc FCC Part 15C Rev: 040103Report Number:05-0311 Issue Date: March 20, 2006CustomerC:irronet Corporation Model:WIT2410 G RF EXPOSURE U.S. Technologies, Inc FCC Part 15C Rev: 040103Report Number:05-0311 Issue Date: March 20, 2006CustomerC:irronet Corporation Model:WIT2410 G 5.1 RF Safety Requirements to 2.1091 for Mobile Transmitters The unit under evaluation has various external antennas. Cirronet Corporation calculated the MPE emission values for a WIT2410 with each of the antennas. The maximum power density occurs when using the 24 dBi dish for fixed applications and with the 15 dBi Yagi for mobile applications. They used the formula shown in OET Bulletin 65 and calculated the minimum distance between antenna and unsuspecting user as 50.2 cm for fixed applications and 20 cm for mobile applications. Cirronet Corporation will sell the WIT2410 with one of the following antennas. MANUFACTURER TYPE OF ANTENNA MODELGAIN dB TYPE OR CONNECTOR Fixed Antennas Andrews Parabolic Dish26T-2400A 24 dBi Reverse N to MMCX via adapter cable Hyperlink Technologies, Inc. Parabolic Dish 2424GC24 dBi Reverse N to MMCX via adapter cable Andrews Parabolic Dish18T-2400 A 18 dBi Reverse N to MMCX via adapter cable Mobile Antennas ACE DipoleACE-2400NF 2 dBi Reverse SMA to MMCX via adapter cable Cushcraft Yagi PC2415-RTNF15 dBi Reverse TNC to MMCX via adapter cable Mobile Mark Omni-Directional OD6-2400-RNTC6 dBi Reverse TNC to MMCX via adapter cable Mobile Mark Corner Reflector SCR14-2400PTA- RTNC 14 dBiReverse TNC to MMCX via adapter cable Mobile Mark Corner ReflectorSCR9-2400-RN 9 dBi Reverse N to MMCX via adapter cable Mobile Mark Vehicle Mount StubRM3-2400-RTNC 2.5 dBi Reverse TNC to MMCX via adapter cable Mobile Mark OmniOD9-2400MUF24005 9 dBi Reverse TNC to MMCX via adapter cable MaxRad WhipMUF24005.RTNC 5 dBi Reverse TNC to MMCX via adapter cable MaxRad Whip Magnetic Mount (Mobile Vehicle Whip) MUF24005.RTNC 5 dBi Reverse TNC to MMCX via adapter cable Digital Wireless Corporation PatchPA2400Appx. 3 dBi Reverse TNC to MMCX via adapter cable Cirronet Corporation Patch GA Tech12 dBi Non-standard MMCX Cirronet Corporation Patch PA24106dBi Non-standard MMCX U.S. Technologies, Inc FCC Part 15C Rev: 040103Report Number:05-0311 Issue Date: March 20, 2006CustomerC:irronet Corporation Model:WIT2410 G 5.1 RF Safety Requirements to 2.1091 for Mobile Transmitters – Cont. Power Output The EUT’s maximum expected output power as shown in Section 2.6 was Frequency of Fundamental (GHz) Measurement (dBm)* Measurement (W)* FCC Limit* (Watt) 2400.1517.1051.29 1.0 2435.6317.8360.67 1.0 2469.8118.3969.02 1.0 * Measurement includes 0.1 dB for cable loss Worst Case Antennas The maximum EIRP expected for fixed installations is with the +24 dBi gain Andrews parabolic dish antenna. This would yield a maximum EIRP of 18.4 dBm + 24 dBi = +42.4 dBm. The maximum EIRP expected for mobile installations is with the +15dBi gain Yagi antenna. This would yield and maximum EIRP of 18.4 dBm + 15 dBi = +33.4 dBm. U.S. Technologies, Inc FCC Part 15C Rev: 040103Report Number:05-0311 Issue Date: March 20, 2006CustomerC:irronet Corporation Model:WIT2410 G 5.1 RF Safety Requirements to 2.1091 for Mobile Transmitters – Cont. Source Based Time Averaging Additionally, source based time averaging may be applied as the worse case transmit duty cycle is given as follows: Worst Case Transmit Duty Cycle for WIT2410 This factor was calculated by first determining the worst case scenario for system operation - worst case being defined as the scenario when the WIT2410 would be transmitting the longest period during a dwell. This worst case operating scenario is as follows: 1)point-to-point operation (only two units communicating with one another) 2)data flow is almost completely unidirectional (that is, one radio is relaying a large amount of data to the other radio with only synchronization data being passed back the other direction) 3)The amount of data being fed to the sending radio is exactly portioned out to fit the maximum packet size allowable (280 bytes). The radio cannot send more than 280 bytes on a single channel – additional data must be sent on the next hop. For this example, a remote unit is transferring a large data file to a base unit. The maximum transmit time by Remote on a single channel would be: = 280 bytes * 8 bits/byte * (1/460.8 Kbps) = 4.86 ms The minimum hop duration for this scenario would be 6.94 ms. This transmit pattern would continue on each channel and is considered repetitive. Therefore, for purposes of MPE, the transmission duty cycle correction factor is then calculated as: Duty cycle = (on time)/(total time) = 4.86/6.94 = 70.0 % This yields for a duty cycle correction of 10 log (0.70) = -1.5 dB. Therefore the maximum EIRP for fixed installations may be expected to be +42.4 dBm – 1.5 dB = +40.9 dBm Antilog(40.9 dBm/10) = 12,302.69 mW The maximum EIRP for mobile installations may be expected to be +33.4 dBm – 1.5 dB = +31.9 dBm Antilog(31.9 dBm/10) = 1548.8 mW U.S. Technologies, Inc FCC Part 15C Rev: 040103Report Number:05-0311 Issue Date: March 20, 2006CustomerC:irronet Corporation Model:WIT2410 G 5.1 RF Safety Requirements to 2.1091 for Mobile Transmitters – Cont. MPE Calculations The limits for this unit (uncontrolled exposure) are 1.0 mW/cm 2 . Taking the RF Denisty Field Equation: Fixed Installations S = (EIRP in mW)/(4πR 2 ) and solving for Distance R S = 12302.69/4π20 2 S = 12302.69/5026.55 S = 2.5 mW/cm 2 Solving the above equation yields R = SQRT ((EIRP in mW)/(S4π)) R (cm) = SQRT (12302.69(mw)/(1.0(mW/cm 2 )*4*π)) = 31.3 cm for fixed installations And Mobile Installations S = 1,548.80/4π 20 2 S = 1,548.8/5026.55 S = 0.308mw/cm 2 All manual instructions will specify 20 cm for mobile installations and 2 meters for fixed installations.

1 Cirronet FCC Part 15, Certification Application WIT2410G Spread Spectrum Transceiver UST Project: 05-0311 Issue Date: March 16, 2006 3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com 2 I certify that I am authorized to sign for the manufacturer and that all of the statements in this report and in the Exhibits attached hereto are true and correct to the best of my knowledge and belief: UNITED STATES TECHNOLOGIES, INC. (AGENT RESPONSIBLE FOR TEST): By: Name: Louis A. Feudi __________ Title: Operations Manager Date: March 16, 2006 _ Cirronet Corporation 5375 Oakbrook Parkway Norcross, GA 30093 By: Name: Title: Date: This report shall not be reproduced except in full. This report may be copied in part only with the prior written approval of U.S. Technologies. The results contained in this report are subject to the adequacy and representative character of the sample provided. 3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com FCC ID: HSW-2410G 1 MEASUREMENT/TECHNICAL REPORT COMPANY NAME:Cirronet MODEL:WIT2410G FCC ID:HSW-2410G DATE:March 16, 2006 This report concerns (check one): Original grant X Class II change_____ Equipment type: 2.4 GHz Spread Spectrum Transceiver Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? yes_____ No X If yes, defer until:_________________ date N.A. agrees to notify the Commission by N.A. date of the intended date of announcement of the product so that the grant can be issued on that date. Report prepared by: United States Technologies, Inc. 3505 Francis Circle Alpharetta, GA 30004 Phone Number: (770) 740-0717 Fax Number: (770) 740-1508 FCC ID: HSW-2410G 2 TABLE OF CONTENTS AGENCY AGREEMENT SECTION 1 GENERAL INFORMATION 1.1Product Description 1.2Related Submittal(s) SECTION 2 TESTS AND MEASUREMENTS 2.1Configuration of Tested EUT 2.2Test Facility 2.3Test Equipment 2.4Modifications 2.5Antenna Description 2.6Peak Power ( Bandedge Antenna Conducted at Antenna Terminal) 2.7Antenna Conducted Spurious Emissions 2.8Peak Radiated Spurious Emissions 2.9 Average Radiated Spurious Emissions 2.10 Bandedge Requirements 2.11 Minimum 20 dB Bandwidth 2.12 Number of Hopping Channels 2.13 Average Time of Occupancy per Channel 2.14 Power Line Conducted Emissions for Transmitter 2.15 Radiated Emissions for Digital Device & Receiver 2.16 Power Line Conducted for Digital Device & Receiver 2.17 Channel Separation SECTION 3 LABELING INFORMATION SECTION 4 BLOCK DIAGRAM(S)/ SCHEMATIC(S) SECTION 5 PHOTOGRAPHS SECTION 6 THEORY OF OPERATION SECTION 7 USER'S MANUAL FCC ID: HSW-2410G 3 LIST OF FIGURES AND TABLES FIGURES 1)Test Configuration 2) Photograph(s) for Spurious and Conducted Emissions 3) Peak Output Power 4) Conducted Spurious Emissions 5) Peak Radiated Spurious Emissions 6) Bandedge Compliance Antenna Conducted 7) 20 dB Bandwidth 8) Number of Hopping Channels 9) Channel Separation TABLES 1)EUT and Peripherals 2) Test Instruments 3) Peak Power Output 4) Peak Radiated Spurious Emissions 5) Average Radiated Spurious Emissions 6) 20 dB Bandwidth 7) Number of Hopping Channels 8) Conducted Emissions 9) Radiated Emissions for Digital Device and Receiver FCC ID: HSW-2410G 4 SECTION 1 GENERAL INFORMATION FCC ID: HSW-2410G 5 GENERAL INFORMATION 1.1Product Description The Equipment Under Test (EUT) is a Cirronet, Model WIT2410G modular 2.4 GHz spread spectrum transceiver. The EUT will be used with one of 15 different antennas. FCC ID: HSW-2410G 6 1.2Related Submittal(s)/Grant(s) The EUT will be used to send/receive data. The transceiver presented in this report will be used with other like transceivers: The EUT is subject to the following authorizations: a)Certification as a transceiver (modular approval) b)Verification as a digital device The information contained in this report is presented for the certification & verification authorization(s) for the EUT. The manufacturer desires to seek a modular approval on this device. FCC ID: HSW-2410G 7 SECTION 2 TESTS AND MEASUREMENTS FCC ID: HSW-2410G 8 TEST AND MEASUREMENTS 2.1Configuration of Tested System The sample was tested per ANSI C63.4, Methods of Measurement from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz (1992). Conducted and radiated emissions data were taken with the test receiver or spectrum analyzer's resolution bandwidth adjusted to 9 kHz and 120 kHz, respectively. All measurements are peak unless stated otherwise. The video filter associated with the spectrum analyzer was off throughout the evaluation process.…

Text truncated - open the document above for the full version.
