HSW-2411MFHSS Module

WIT2411 2.4GHz Spread Spectrum Wireless Industrial Transceiver Integration Guide (PRELIMINARY) October 18, 2001 5375 Oakbrook Parkway Norcross, Georgia 30093 www.cirronet.com +1 (678) 684-2000 If the WIT2411 is installed within another device the outside of the device into w hich the WIT2411 is installed must also display a label referring to the enclosed module. The label required for the WIT2411 module is as follows: Transmitter Module FCCID: HSW-2411M. About This Manual This manual is designed to allow integration of the Cirronet WIT2411 OEM module into complete products. Care has been taken to try and make sure all of the information in this manual is accurate. However, specifications can change over time and Cirronet cannot guarantee the accuracy of this information. If you have any questions on any information in this manual, please contact Cirronet Technical Support at +1-678 684 2000. Note: This unit has been tested and found to comply with the limits for a class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environme nt. This equip me nt ge nerates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Commensurate with EIRP limits specified in FCC Rules 15.247b, this device may not be used with antennas that exceed 36dB of gain in point-to-point applications or 16dB of gain in multi-point applications. Cirronet is a trademark of Cirronet Incorporated. All other trademarks belong to their respective companies. Notice to WIT2411 users/installers using the following fixed antenna: Mobile Mark 9dBi Corner Reflector The field strength radiated by this antenna, when connected to a transmitting WIT2411 module, may exceed FCC mandated RF exposure limits. FCC rules require professional installation of this antenna in such a way that the general public will not be closer than 2 m from the radiating aperture this antenna. End users of these systems must also be informed that RF exposure limits may be exceeded if personnel come closer than 2 m to the aperture of this antenna. Notice to WIT2411 users/installers using the following mobile antennas: Mobile Mark 9dBi omnidirectional, Cirronet 6dBi patch, Ace 2dBi dipole, The field strength radiated by any one of these antennas, when connected to a transmitting WIT2411 module, may exceed FCC mandated RF exposure limits. FCC rules require professional installation of these antennas in such a way that the general public will not be closer than 20 cm from the radiating aperture of any of these antennas. End users of these systems must also be informed that RF exposure limits may be exceeded if personnel come closer than 20 cm to the apertures of any of these antennas. Declaration of Conformity We, Cirronet Incorporated 5375 Oakbrook Parkway Norcross, Georgia 30093 USA declare under our sole responsibility that the product, WIT2411 To which this declaration relates is in conformity with the following standards or other normative documents: ETS 300 328 (November 1996) ETS 300 826 EN60950 following the provisions of the R&TTE Directive. Norcross, GeorgiaJanuary 29,2001 Timothy D. Cutler Vice President Use Within the European Union The WIT2411 is intended for use within the following European Community States: Austria, Belgium, Denmark, Finland France, Germany, Greece, Ireland, Italy, Luxembourg, The Netherlands, Portugal, Spain, Sweden and the United Kingdom The WIT2411 is also intended for use in the following non-European Union States: Iceland, Norway, Switzerland Use of the WIT2411 in France When used in France, the WIT2411 can only be operated with the France hopping pattern selected. This is accomplished by setting the pe parameter to TBD. Refer to Section 5.3 Protocol Commands for details. Use of the WIT2411 in Spain When used in Spain, the WIT2411 can only be operated with the Spain hopping pattern selected. This is accomplished by setting the pe parameter to TBD. Refer to Section 5.3 Protocol Commands for details. Use of the WIT2411 in Another Product Manufacturers that incorporate the WIT2411 into a product they place on the market in the European Union must notify the national authority responsible in the relevant Member State for spectrum management of the intention to place such equipment on its national market.

5015 B.U. Bowman Drive, Buford, Georgia 30518 www.acstestlab.com 770-831-8048 E X C E L L E N C E I N C O M P L I A N C E T E S T I N G November 28, 2001 RE: Reply to correspondence reference number 21356 731 Confirmation Number: EA102697 FCC ID: HSW-2411M Applicant: Cirronet Agent: ACS Inc. Mr. Dayhoff: We provide the following reply to your inquiry: Item #1 - Please show the calculated MPE safe distance for each antenna provided with the system, in order to prove compliance with RF Exposure requirements. This information must be provided in the User Manual as well to give warning of RF Exposure levels near the antenna. Please provide the text of your proposed manual warning. A draft user’s manual was submitted with the filing on 10/25/01. On page 3 of the manual, instructions to the user are given for each antenna. The instructions indicate the antennas are to be professionally installed only, and in such a way that nearby persons do not come within 2 meters of the fixed mounted antenna, and 20cm from the mobile antennas. The calculated safe distance of the highest gain mobile antenna is 5.63cm, therefore the specified distance of at least 20cm, will more than ensure compliance with RF exposure requirements. I have included t he text below: Notice to WIT2411 users/installers using the following fixed antenna: Mobile Mark 9dBi Corner Reflector The field strength radiated by this antenna, when connected to a transmitting WIT2411 module, may exceed FCC mandated RF exposure limits. FCC rules require professional installation of this antenna in such a way that the general public will not be closer than 2 m from the radiating aperture this antenna. End users of these systems must also be informed that RF exposure limits may be exceeded if personnel come closer than 2 m to the aperture of this antenna. Notice to WIT2411 users/installers using the following mobile antennas: Mobile Mark 9dBi omnidirectional, Cirronet 6dBi patch, Ace 2dBi dipole, The field strength radiated by any one of these antennas, when connected to a transmitting WIT2411 module, may exceed FCC mandated RF exposure limits. FCC rules require professional installation of these antennas in such a way that the general public will not be closer than 20 cm from the radiating aperture of any of these antennas. End users of these systems must also be informed that RF exposure limits may be exceeded if personnel come closer than 20 cm to the apertures of any of these antennas. 5015 B.U. Bowman Drive, Buford, Georgia 30518 www.acstestlab.com 770-831-8048 E X C E L L E N C E I N C O M P L I A N C E T E S T I N G Item #2 - Please explain how the module meets the eight requirements of FCC Public Notice DA 00-1407. 1. The device has it’s ow n RF shielding and does not rely on host devices to comply with part 15 limits. The device complies with the limits in a standalone configuration as represented in the test report. External photos, with and without the RF Shielding were submitted on 10/9/01. 2. All modulation is internal to the device, so there is no method to achieve excessive data rates or over- modulation. 3.Digital and RF power is taken from the AC/DC converter(9V), and regulated to 3.3V through a linear regulator (Micrel 5209). The Loop components are subregulated from this 3.3 by a Toshiba TK11233. 4. Section 7.1 of the test report submitted to the commission on 10/9/01 states how compliance with 15.203 is ensured. I have included the text of that section below as well: “7.1 Antenna Requirement - FCC Section 15.203 To ensure compliance with 15.203, we propose attaching a reverse-sex SMA connector to the 2dBi Stub, and a reverse N to the 9dBi omni and the 9dBi corner reflector. The 6dBi patch employs the specialty MMCX connector and so is exempt. We have arranged for the manufacturer of the stub antenna to provide reverse-sex SMA connector for this antenna. OEM customers wanting to use this antenna in their product will first need to obtain a special part number from Cirronet to give to the antenna manufacturer. The manufacturer, upon receipt of this number, will know to attach the reverse- sex SMA connector to the end of the antenna before shipping. The customer then purchases an adapter cable from Cirronet that will connect the MMCX port on our module to the reverse-sex connector on the antenna. No other type of commercially available antenna will attach to this reverse-sex SMA. This same process will also be used with the 9dBi omni antenna and the corner reflector but using reverse N connectors rather than reverse SMA. Given the nonstandard nature of the interconnect between module and antenna and the difficulty involved in circumventing that connection, we believe that this procedure meets the requirements called out in 15.203. The special Cirronet part numbers for the three antennas equipped with reverse sex connectors are listed below. Mobile Mark 9dBi Corner ReflectorSCR9-2400-RN ACE 2dBi Stubby ACE-2400NF Mobile Mark 9dBi OmniOD9-2400-RN” 5. The device was tested in a standalone configuration and complies with the part 15 emission limits regardless of the device into which it is eventually installed. The 5015 B.U. Bowman Drive, Buford, Georgia 30518 www.acstestlab.com 770-831-8048 E X C E L L E N C E I N C O M P L I A N C E T E S T I N G device is typically powered by the host device therefore conducted emissions do not apply. All data cables to the device during testing were at least 10cm to prevent coupling from the case of the module to supporting equipment. All accessories and supporting equipment were unmodified or commercially available. Set up photograph during the test is given below: 6. A sample label was submitted on 10/17/01 and a clarification sent on 10/25/01. In addition, the users manual submitted on 10/25/01 contains information to the installer about the labeling requirements. That text contained in the manual is show n below for reference: “If the WIT2411 is installed within another device the outside of…

Text truncated - open the document above for the full version.

LXE, Inc. 125 Technology Parkway Norcross, GA 30092-9200 USA TEL: (770) 447-4224 FAX: (770) 447-6928 EMAIL: [email protected] Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: HSW-2411M Dear Sir: The following application is submitted on behalf of Cirronet, Inc for evaluation for a modular approval under Part 15 subpart C. The device meets al of the requirements of a module as defined in Public Notice DA-1407. The device was tested and was found to be in compliance with the rules. Sincerely, R. Sam Wismer RF Approvals Engineer LXE, Inc. enc(s).

CONFIDENTIALITY REQUEST Federal Communications Commission Date: August 27, 2001 Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentle me n: Cirronet respectfully requests confidentiality of certain materials provided with the submission of the WIT2411 under FCC ID: HSW-2411M in accordance with FCC Regulations 0.459. The confidentiality request applies to the schematics, theory of operation, and block diagrams contained in exhibits of this filing. The WIT2411 has been developed at considerable effort and expense by Cirronet. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company's business advantage. I appreciate your assistance in this matter. Sincerely, Name: James F. Kiernan Signature: Title: Sr. RF Engineer Date: August 29, 2001

Federal Communications Commission Date: August 27, 2001 P.O. Box 429 Columbia, MD 21045 Gentle me n: I hereby appoint Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of HSW-2411M under Part 15 of the FCC Rules and Regulations. I certify that all exhibits contained in this filing properly describe the device or system for which aut horization is sought, that the information described in the User's Manual will be provided with each item manufactured or distributed by the applicant, and that the labels described in the filing will be affixed to each item manufact ured or distributed by the applicant. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Name:James F. Kiernan Signature:_______________________________ Title:Sr. RF Engineer Date: August 29, 2001

Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 1 APPENDIX A EUT PHOTOGRAPHS Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 2 Figure 1: EUT Front with Shield Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 3 Figure 2: EUT front with shield removed Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 4 Figure 3: EUT Back Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 5

Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 1 APPENDIX B ANTENNA PHOTOGRAPHS Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 2 Figure 1: 2 dBi Omni Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 3 Figure 2: 6dBi Patch Front Figure 3: 6dBi Patch Back Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 4 Figure 4: Mobile Mark 9dBi Corner Reflector

Model: WIT2411FCC ID: HSW-2411M ACS Project Number: 01-08008Page: 1 APPENDIX E SAMPLE LABEL Model: WIT2411FCC ID: HSW-2411M ACS Project Number: 01-08008Page: 2 FIGURE 1: SAMPLE LABEL CIRRONET INC, MODEL: WIT2411 This device complies with part 15 of the FCC Rules. Operation is subject to the followi ng two conditio ns: (1) this device may not cause harmful interference, and (2) this device must accept any interference, i ncluding interference that may cause undesired operation. FCC ID: HSW-2411M

CIRRONET INC. MODEL: WIT2411 This device comp lies with Part 15 of the FCC Rules. Op eration is subject to the following two conditions: (1) this device may not cause harmfu l interferen ce, and (2) t his device must accep t any int er- ference r eceived, in cludin g interference that may cause undesired op eration. FCC ID: HSW-2411M

Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 1 APPENDIX A EUT PHOTOGRAPHS Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 2 Figure 1: EUT Front with Shield Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 3 Figure 2: EUT front with shield removed Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 4 Figure 3: EUT Back Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 5

FCC Part 15 Subpart C Frequency Hopping Spread Spectrum Transmitter Certification Test Report (Modular Approval) Manufacturer: Cirronet, Inc. Model: WIT2411 FCC ID: HSW-2411M Rules Section: 15.247(Modular Approval) Test Begin Date: September 10, 2001 Test End Date: September 25, 2001 Report Issue Date: October 9, 2001 Test Result: PASS Prepared by: R. Sam Wismer Engineering Manager Table of Contents 1.0 General3 1.1 Introduction 3 1.2 Product Description3 1.2.1 General3 1.2.2 Intended Use3 1.2.3 Technical Specifications3 1.2.4 Antennas3 2.0 Location of Test Facility 4 2.1 Description of Test Facility4 2.2 Radiated Test Site Illustration4 3.0 Applicable Standards and References 5 4.0 List of Test Equipment5 5.0 Support Equipment5 6.0 EUT Setup Block Diagram6 7.0 Summary of Tests6 7.1 Section 15.203 - Antenna Requirement6 7.2 Section 15.207 - Power Line Conducted Emissions7 7.3 Section 15.209 - Radiated Emissions7 7.4 Section 15.247(b)(1) – Peak Output Power8 7.5 Section 15.247(a)(2)(iii) – Channel Usage8 7.5.1 20dB Bandwidth9 7.5.2 Hopping Channels9 7.5.3 Adjacent Channels10 7.5.4 Channel Dwell Time10 7.6 Section 15.247(c) - Spurious Emissions10 7.6.1 RF Conducted Spurious Emissions10 7.6.2 Radiated Spurious Emissions(Restricted Bands)11 7.6.2.1 Test Procedure11 7.6.2.2 Duty Cycle Correction Factor11 7.6.2.3 Correction Factors and Sample Calculations12 7.6.2.4 Test Results12 8.0 RF EXPOSURE - Section 15.247(b)(4)13 9.0 CONCLUSION13 Appendix A - Conducted Spurious Emissions Appendix B - Radiated Spurious Emissions Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 3 1.0 GENERAL 1.1 Introduction The purpose of this report is to demonstrate compliance with Part 15, Subpart C of the FCC’s Code of Federal Regulations. 1.2 Product Description 1.2.1 General The Equipment Under Test (EUT), is the Model WIT2411 manufactured by Cirronet Inc. Located at the following address: Cirronet Inc. 5375 Oakbrook Parkway Norcross, GA 30093 USA Detailed Photographs of the EUT are filed separately as appendix A. 1.2.2 Intended Use The WIT2411 is a wide band frequency hopping spread spectrum transmitter module designed to be integrated into fixed location devices. 1.2.3 Technical Specifications Table 1.2.3-1: Specifications Frequency Band2400-2483.5 MHz Number of Channels43 Channel Bandwidth1.625 MHz Channel Spacing1.8432 MHz Maximum User Rate1.8432 Mbps Output power17 to 18dBm nominal Operating Voltage3.3 v Rx Sensitivity-87 to –90 dBm (BER 10 -5 ) 1.2.4 Antennas Table 1.2.4-1 below gives the antennas that will be employed with the WIT2411. Photographs are submitted separately as appendix B with this filing. Table 1.2.4-1: Antennas Mfg.Mfg.AntennaGainConnectorSystem EIRP Model No.Type(dBi)Type(dBm) Mobile Mark0D9-2400-RNOmni9N-Female26 Mobile MarkSCR9-2400-RNCorner Reflector9N-Female26 Ace Communication ACE-2400NFOmni2SMA-M19 CirronetA-7030-0192Patch6MMCX23 Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 4 2.0 LOCATION OF TEST FACILTY All testing except for radiated spurious emissions was performed at: ACS, Inc. 3630 Burnette Park Dr. Suwanee, GA 30024 Radiated spurious emissions was performed in a 3 meter semi-anechoic chamber at an ACS facility located at: ACS, Inc.(Formerly CTL) 137 Airport Road Liberty, SC 29657 2.1 DESCRIPTION OF TEST FACILITY All tests were conducted at an ACS facility specifically prepared for this testing. The 3 meter semi- anechoic chamber meets the Normailzed Site Attenuation (NSA) characteristics of ANSI C63.4:1992, Industry Canada RSS 212, CISPR 16 and EN 55022:1998. This site has been fully described, submitted to, and accepted by, the FCC and Industry Canada A nonconductive remotely controlled turntable approximately 0.91m x 1.2m x 0.8m was used to measure radiated emissions from all sides of the EUT. The turntable has a center opening that allows cabling to be routed directly down to the conducting ground plane. 2.2 Radiated Emissions Testing Facility Drawing All dimensions are in meters(m) Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 5 Figure 2.2-1: Semi-Anechoic Chamber Emission Test Set-up 3.0 APPLICABLE STANDARD REFERENCES The following standards were used: 1 - ANSI C63.4-1992: Method of Measurements of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the 9KHz to 40GHz 2 - US Code of Federal Regulations (CFR): Title 47, Part 15, Subpart C: Radio Frequency Devices, Intentional Radiators (October 2000) 3 - FCC OET Bulletin 65 Appendix C - Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields 4.0 LIST OF TEST EQUIPMENT All test equipment used for regulatory testing is calibrated yearly or according to manufacturers specifications. Table 4-1: Test Equipment MFG NameItem NameModel #:Serial #Recal Date: Hewlett PackardAmp, .01-26.5 GHz83006A3104A0054311/30/01 Microwave CircuitsHigh-Pass FilterH3G020G20001 DC98531/27/01 RF Cables (High Freq. Short) NoneCopper11/17/01 RF Cables (High Freq. Double) 7015/6986MFR-5750011/17/01 ChaseBi-Log Antenna10/20/01 5.0 SUPPORT EQUIPMENT Table 5-3: Support Equipment ManufacturerEquipment TypeModel NumberSerial NumberFCC ID AT&T GISComputer700017-26152639None TVM Professional MonitorMD-14 I +SNone11BMD-1452 UnknownMouseM-SAS51LZA83800046JNZ211167 VolgenAC/DC ConverterSPU10R-1NoneNone Model: WIT2411 Advanced Compliance Solutions FCC ID: HSW-2411M ACS Project: 01-08008 Page 6 6.0 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM M = Meters S = Shielded U = Unshielded Figure 6-1: EUT Test Setup 7.0 SUMMARY OF TESTS Along with the tabular data shown below, plots were taken of all signals deemed important enough to document. 7.1 Antenna Requirement - FCC Section 15.203 To ensure compliance with 15.203, we propose attaching a reverse-sex SMA connector to the 2dBi Stub, and a reverse N to the 9dBi omni and the 9dBi corner reflector. The 6dBi patch employs the specia…
