HV4INFA068Wireless Module

User’s manual Bamboo (CTH-470, CTH-670) Bamboo Pen (CTL-470) Setting up Navigating with touch Customizing touch Using the ExpressKeys Using a pen Customizing a pen Going Wireless Troubleshooting ContentsIndex Contents 1 Index 1 ContentsIndex Contents 2 Index 2 Bamboo TM User’s Manual Version 1.0, Rev F2011 Copyright © Wacom Co., Ltd., 2011 All rights reserved. No part of this manual may be reproduced except for your express personal use. Wacom reserves the right to revise this publication without obligation to provide notification of such changes. Wacom does its best to provide current and accurate information in this manual. However, Wacom reserves the right to change any specifications and product configurations at its discretion, without prior notice and without obligation to include such changes in this manual. The above year indicates when this manual was prepared. However, the date of release to the users of the “manual” is simultaneous with the introduction into the market of the applicable Wacom product. Bamboo is a trademark and Wacom is a registered trademark of Wacom Co., Ltd. Adobe and Photoshop are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. Microsoft, Windows, and Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Apple, the Apple logo, and Mac are trademarks of Apple, Inc., registered in the U.S. and other countries. Any additional company and product names mentioned in this documentation may be trademarked and/or registered as trademarks. Mention of third-party products is for information purposes only and constitutes neither an endorsement nor a recommendation. Wacom assumes no responsibility with regard to the performance or use of these products. ExpressKey is a registered trademark of Ginsan Industries, Inc., and is used with permission. ContentsIndex Contents 3 Index 3 TABLE OF CONTENTS About the manual 5 YOUR BAMBOO 6 Identify your tablet model 6 Bamboo tablet 7 Bamboo Pen tablet 8 Pen 9 Pen holder 9 SETTING UP YOUR BAMBOO 10 Ergonomics 10 Configuring the tablet orientation 12 Understanding the tablet active area 13 Working with multiple monitors 15 Control panel basics 15 USING YOUR BAMBOO 16 The touch experience with Bamboo 16 Navigating with touch 17 Customizing touch 25 The pen experience with Bamboo 26 Holding the pen 26 Using the pen on the tablet 27 Positioning 27 Clicking 29 Dragging 29 Using the pen buttons 30 Writing and drawing with pressure sensitivity 31 Erasing 32 Eye-hand coordination exercise 33 Customizing pen input 33 Tablet controls 33 ExpressKey basics 34 Customizing the ExpressKeys 34 CUSTOMIZING YOUR BAMBOO 35 Opening the control panel 35 Control panel overview 36 Customize your touch experience 37 Setting the touch options 37 Setting the touch functions 38 Disabling touch 39 Customize your pen experience 40 Setting the tip and eraser feel, and double-click distance 41 Setting the pen button functions 42 Setting the tablet mapping 43 Portion of screen area 45 Portion of tablet area 45 Setting the pen speed in mouse mode 46 Customizing tablet and ExpressKey functions 47 Customizing the Pop-up Menu 48 Working with Display Toggle 49 Button functions 50 GOING WIRELESS WITH YOUR BAMBOO 55 Wireless accessory components 55 Wireless setup 56 Establishing a wireless connection 57 Optimizing the wireless connection 59 Battery and power management 60 Charging the battery 60 Battery and wireless connection status 61 Power saving features 62 Battery life information 63 Replacing the battery 64 Wireless module removal 65 Wireless receiver storage 65 ContentsIndex Contents 4 Index 4 PROBLEMS WITH YOUR BAMBOO? 66 Testing your tablet 67 Testing a pen 69 Troubleshooting tables 70 General problems 70 Touch input problems 71 Pen input problems 72 Wireless connection problems 74 Windows-specific problems 76 Mac-specific problems 77 Technical support options 79 Obtaining driver downloads 80 APPENDIX 81 Caring for Bamboo 81 Replacing the pen nib 82 Bamboo Dock 83 Uninstalling Bamboo 83 Managing preferences 84 Pen and digital ink capabilities in Windows 85 Product information 86 Ordering parts and accessories 87 Available parts and accessories 87 GLOSSARY 88 INDEX 91 ContentsIndex Contents 5 Index 5 ABOUT THE MANUAL This manual provides quick access to information about Bamboo. The information is common to Windows and Mac computers and Windows screen captures are shown, unless otherwise noted. •Go directly to table of contents or index topics by clicking on them. •Use the navigation controls to move through the manual. •You can use your .pdf viewer zoom-in tool to increase the size of the manual on your display screen. Most .pdf viewers include additional tools for using and printing the manual. See the viewer application help for more information. •S MALL CAPITAL LETTERS are used to identify the names of keyboard keys, dialog boxes, and control panel options. •Be sure to see also the Important Product Information guide for Bamboo, located on the Bamboo Installation CD. The guide includes product safety precautions, specifications, and your license agreement. •The following information is not included with this product: information about your specific computer hardware or operating system, or information about your application software. Your best source for this information is the set of manuals and discs that came with your hardware, operating system, or application. •Pen-equipped models: In addition to the built-in inking support found within Microsoft Windows 7 and Vista, many graphics applications also support pressure sensitivity and the pen eraser (when equipped). You can find a listing of applications that support these features on Wacom’s web site (see product information ). •For information on how best to use Bamboo features within a specific application, see the instructions in that application’s manuals. Note: Thi…

Text truncated - open the document above for the full version.

Important Product Information Informations importantes sur le produit Información importante sobre el producto Informações importantes sobre o produto 製品に関する重要なお知らせ 중요한 제품 정보 重要產品資訊 重要产品信息 (INF-A068, INF-A069, 1UF5550Z-WCM) Wacom wireless accessory kit-ASI1 12011/06/20 9:21:00  English PRECAUTIONS WARNINGS Keep this product and the battery out of reach of small children. They may accidently swallow the small pieces. Do not expose the tablet or any of the components of the wireless accessory kit to water or other liquids. Take care to never spill liquids on these products. Exposure to liquids may cause product malfunction or electrical shock. If the tablet and/or the wireless components get wet, remove the battery from the tablet, stop using it and contact your local distributor or the regional Wacom customer support center. Do not insert foreign materials into the USB port or any other opening of this tablet. It may cause the product to malfunction or burn out, and may cause electrical shock. CAUTION The use of wireless devices is regulated in most countries. If you travel with your wireless tablet, check with the appropriate regulatory authority for any restrictions that may apply to your product in the countries that you go to. Products using wireless signals may interfere with the equipment on commercial aircraft, and regulations require that all wireless devices be turned off when traveling in an airplane. Turn off the tablet wireless signal by pushing the power button on the side of the tablet wireless module (the battery status light will be off) and do not turn it on during takeoff, transit, or landing. Do not use wireless devices in a facility control system or any other environment that requires extremely high reliability, or where the use of a wireless device may cause interference. The wireless tablet may interfere with or cause other electronic devices to malfunction, or other wireless devices may interfere with or cause the tablet to malfunction. Where use of wireless products is prohibited, turn off the • • • • • • Wacom wireless accessory kit-ASI2 22011/06/20 9:21:00  tablet wireless signal by pushing the power button on the side of the tablet wireless module to prevent the possibility of it interfering with or causing other electronic devices to malfunction. Wacom does not accept any liability for direct or consequential damages. For details, please refer to your Warranty. SAFETY PRECAUTIONS FOR RECHARGEABLE BATTERY Do not abuse the battery in any manner. Puncturing, crushing, heating, exposure to water or fire, disassembly, shorting the terminals, or other types of abuse may cause the battery to explode or ignite, and potentially cause a fire or personal injury. Replace the battery immediately if dropped. Even though there is no visible damage, it can be damaged internally. If a dropped battery is installed in a tablet, it may leak or short, damaging the product. Do not use a battery that is visibly damaged. It could rupture, generate heat or catch on fire. Only use a Wacom battery specified for your product. If the product becomes excessively warm or emits an unusual smell while the battery is charging, immediately disconnect the USB cable, turn the power off by pushing the button on the side of the tablet and remove the battery. Contact your regional Wacom Technical Support for assistance. Properly recycle the battery in accordance with the battery manufacturer recommendations, and follow any applicable warnings. When transporting the battery, do not carry it loosely in your pocket or in any container that may contain metal objects. If transported improperly and metal objects come in contact with the battery terminals, the battery could short, causing personal injury or fire. It is recommended that you cover the terminals with adhesive tape to insulate them from possible contact with metal objects. If the battery should leak, do not touch, swallow, or get the fluid in your eye. Do not breathe in the dust or vapors. If skin contact occurs, wash the affected area immediately with soap and water. If swallowed, seek medical attention immediately. If battery fluid enters an eye, do not rub the eye. Immediately rinse the affected eye with copious amounts of water for at least 15 minutes and seek medical attention. • • • • • • • • Wacom wireless accessory kit-ASI3 32011/06/20 9:21:00  If inhalation occurs, move to fresh air and seek medical attention if necessary. If you travel with your product, check with the appropriate regulatory authority for any air or travel restrictions that may apply to Lithium-Ion batteries. If a battery fire should occur, extinguish using a dry chemical extinguisher or water. Please recycle batteries in accordance with the manufacturer recommendation, following all local laws and regulations. SPECIFICATIONS Wireless module (INF-A068) Physical size (W x H x D)7. x 5.5 x 6 mm (1.07 x 1.00 x 0. in) (approximate) Weight g (approximate) Frequency bandRF . GHz ISM Nominal communication distance 10 m (approximate, with no interference) Power requirement5 V, .5 V Operating temperature5 to 0 degrees C (1 to 10 degrees F) Storage temperature-0 to +60 degrees C (- to 10 degrees F) Operating relative humidity0 % to 80 % non-condensing Storage relative humidity0 % to 90 % non-condensing Wireless receiver (INF-A069) Physical size (W x H x D)19.9 x 15.0 x 6 mm (0.78 x 0.59 x 0. in) (approximate) Weight g (approximate) Frequency bandRF . GHz ISM ConnectorUSB Type A • • • Wacom wireless accessory kit-ASI4 42011/06/20 9:21:00 5 Nominal communication distance 10 m (approximate, with no interference) Power requirement5 V Operating temperature5 to 0 degrees C (1 to 10 degrees F) Storage temperature-0 to +60 degrees C (- to 10 degrees F) Operating relative humidity0 % to 80 % non-condensing Storage relative humidity0 % to 90 % non-condensing Rechargeable battery (1UF553450Z-WCM) Physical size (W x H x D).9 x 5.6 x 6.1 mm (1. x .1…

Text truncated - open the document above for the full version.

Wacom Co., Ltd. FCC ID: HV4INFA068 IC: 6888A-INFA068 Page 1 of 3 Wacom Co., Ltd. FCC ID: HV4INFA068 IC: 6888A-INFA068 Page 2 of 3 Wacom Co., Ltd. FCC ID: HV4INFA068 IC: 6888A-INFA068 Page 3 of 3

Wacom Co., Ltd. FCC ID: HV4INFA068 IC: 6888A-INFA068 Page 1 of 4 Wacom Co., Ltd. FCC ID: HV4INFA068 IC: 6888A-INFA068 Page 2 of 4 Wacom Co., Ltd. FCC ID: HV4INFA068 IC: 6888A-INFA068 Page 3 of 4 Wacom Co., Ltd. FCC ID: HV4INFA068 IC: 6888A-INFA068 Page 4 of 4

Report number: Z071C-11030 Page 2 of 34 ZACTA Technology Corp. FCC ID: HV4INF068 FCC 15C Rev.4.0 IC Certification Number: 6888A-INFA068 Table of contents Page 1. Summary of Test .................................................................................................................................................................. 4 1.1 Purpose of test .......................................................................................................................................................................... 4 1.2 Standards .................................................................................................................................................................................. 4 1.3 Summary of test results ........................................................................................................................................................... 4 1.4 Deviation from the standard .................................................................................................................................................... 4 1.5 Modification to the EUT by laboratory .................................................................................................................................. 4 2. Equipment description ......................................................................................................................................................... 5 2.1 General Description of equipment .......................................................................................................................................... 5 2.2 EUT information ...................................................................................................................................................................... 5 2.3 Operating channels and frequencies ....................................................................................................................................... 6 2.4 Description of Test modes ....................................................................................................................................................... 7 2.5 Operating mode ....................................................................................................................................................................... 7 3. Configuration information................................................................................................................................................... 8 3.1 Peripheral(s) used .................................................................................................................................................................... 8 3.2 Cable(s) information ................................................................................................................................................................ 8 3.3 System configuration ............................................................................................................................................................... 9 4. Test Type and Results ........................................................................................................................................................ 10 4.1 20dB Bandwidth / Occupied Bandwidth ............................................................................................................................. 10 4.1.1 Test Procedure [ RSS-Gen 4.6.1 ] ................................................................................................................................ 10 4.1.2 Measurement Setup ......................................................................................................................................................... 10 4.1.3 Limit of Bandwidth at 20 dB below ................................................................................................................................ 10 4.1.4 Measurement Result ........................................................................................................................................................ 10 4.1.5 Trace Data ........................................................................................................................................................................ 10 4.2 Restricted Band of Operation ............................................................................................................................................... 12 4.2.1 Test Procedure [ FCC 15.205, 15.209, 15.249(c),(d), IC RSS-210 A2.9(b) ] ............................................................. 12 4.2.2 Measurement Setup ......................................................................................................................................................... 12 4.2.3 Limit of Restricted Band of Operation ........................................................................................................................... 12 4.2.4 Measurement Result ........................................................................................................................................................ 12 4.2.5 Trace Data ........................................................................................................................................................................ 13 4.3 Spurious Emissions - Radiated - (9kHz - 25GHz) ......................................................................................................... 18 4.3.1 Test Procedure [ FCC 15.205/209/249(a), (b), (c), (d), (e), 15.35(b), IC RSS-210 A2.9(a), (b), RSS-Gen 4.9, 4.10 ] ......................................................................................................................................................................................... 18 4.3.2 Measurement Setup ....................................................................................................…

Text truncated - open the document above for the full version.

Wacom Co., Ltd. FCC ID: HV4INFA068 IC: 6888A-INFA068 System configuration (RF Conducted test) Transmitter Radiated Spurious Emissions (RF Radiated test) Wacom Co., Ltd. FCC ID: HV4INFA068 IC: 6888A-INFA068 X-axis Y-axis Z-axis Note: X-axis generates the maximum emission. Wacom Co., Ltd. FCC ID: HV4INFA068 IC: 6888A-INFA068 Conducted Emission at mains port The photographs show maximized emission configuration.
