HV4STU500LCD Signature Tablet

LCD Signature Tablet 2 INTRODUCTION AND OVERVIEW The Wacom® STU-500 LCD signature tablet combines the benefits of an LCD technology with the control, comfort, and productivity of Wacom’s cordless, battery- free pen technology. This gives you a direct pen-on-screen interface. The basic components of the LCD signature tablet include a Wacom pen tablet internally mounted behind a 5" diagonal TFT LCD display, and a cordless, battery-free Wacom pen. 3 PRECAUTIONS ON USE AND HANDLING Be sure to follow all instructions, cautions, and warnings found within this guide. Failure to do so could cause the loss of data or damage to your computer. Failure to do so could also void your warranty, in which case Wacom shall have no responsibility to repair or replace the product. Usage WARNING Do not use the STU-500 LCD signature tablet in a facility control system that requires extremely high reliability;it may cause other electronic devices to malfunction, or other devices may cause the LCD signature tablet to malfunction. Where use is prohibited, power off the STU-500 to prevent the possibility of it causing other electronic devices to malfunction. Wacom does not accept any liability for direct or consequential damages. Environment Temperature and humidity • Operating temperature and humidity: 5° to 35°C, 20 to 80% RH • Storage temperature and humidity: -10° to 60°C, 20 to 90% RH CAUTION Do not use or store the LCD signature tablet where: • Temperature changes are severe or exceed specifications (e.g., outdoors or inside a vehicle). • TheLCD signature tablet and pen are exposed to direct sunlight or heat from an appliance, or are exposed to water or any other kind of liquid. Do not use theLCD signature tablet in a dusty environment; this may damage the unit. Handling WARNING Be sure to use a specified AC adapter. If a different type of power adapter is used, theLCD signature tablet will not work properly or may be damaged. Using a different type of power adapter also has the potential to result in fire. Use of a different power adapter will void your warranty. When not using theLCD signature tablet for long periods of time, unplug the power adapter from the AC outlet. 4 Handling WARNING High Voltage. Do not open or disassemble the STU-500 LCD signature tablet. There is a risk of electrical shock when the casing is open. This will also void your warranty and Wacom shall have no responsibility to repair or replace the product. If the LCD screen has been damaged, DO NOT touch any liquid that may be leaking from it; this liquid is an irritant. In case of contact with skin, eyes, or mouth, rinse immediately with running water for at least 15 minutes or more. If contact is made with the eyes or mouth, also consult a physician. Prevent children from swallowing the pen tip. The pen tip may accidentally be pulled out if children are biting on them. CAUTION Do not disassemble the pen. This may cause the device to malfunction. In this case, Wacom shall have no responsibility to repair or replace the product. Do not scratch the display screen. Avoid placing sharp objects on the display screen surface. Avoid intensive shock or vibration to the STU-500 or the pen. Hitting or dropping theLCD signature tablet may damage the display screen or other components. Do not put heavy articles on theLCD signature tablet or push against it with a strong force; This may damage the display screen or bend the stand. Do not place heavy articles on the STU-500 cabling, repeatedly bend the cables sharply, or apply heavy stress to the cable connectors; this may damage the unit or cabling. If the pen tip becomes sharp or angular, it may damage the coating on the display screen. Please replace the pen tip if necessary. Do not use any organic solvent (e.g., alcohol) or even mild detergent to clean the display screen. Use of these cleaners can damage the coating on the screen. Please note that damage of this kind is not covered by the manufacturer's warranty. • To clean the display screen, use an anti-static cloth or a slightly damp cloth. When cleaning, apply only a light amount of pressure to the display screen and do not make the surface wet. • To clean theLCD signature tablet casing or pen, use a soft cloth with mild detergent (such as dish washing liquid) diluted with water. Do not expose the STU-500 to high voltage electrostatic discharges or to a build-up of an electrostatic charge on the LCD screen. This may result in a temporary discoloration and blotching of the LCD monitor. If discolorations occur, leave the STU-500’s display on and the discolorations should disappear within a few hours. 5 Reuse, recycling, and recovery. You are urged to recycle this product when replacing it with a newer product or when it has outlived its useful life by bringing it to an appropriate collection point for recyclable materials in your community or region. By doing this, you can help improve the environment of your community as well as minimize the potential negative effects created should any hazardous substance that may possibly be present within waste material reach the environment during the disposal process. Within the European Union, users are required not to dispose of Waste Electrical and Electronic Equipment (WEEE) as unsorted municipal waste, according to the Directive 2002/96/EC of the European Parliament and of the Council of 27 January 2003, or the corresponding local laws of the Member States. Products for which this is applicable will be marked with the WEEE symbol shown at the beginning of this note unless this is not feasible because of the size or the function of the product. Wacom products are subject to the Directive 2002/96/EC and therefore you should always collect them separately and bring them to the appropriate collection point in your community or region. Wacom LCD signature tablet products comply with the European Union RoHS Directive 2002/95/EC (RoHS Directive). Connecting the tablet The STU-500 can be connected to a ho…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 November 9, 2007 RE: Wacom Co Ltd FCC ID: HV4STU500 I have a few comments on this application. Depending on your responses, kindly understand there may be additional comments. 1. It seems this device is an intentional radiator according to the description “Intentionally Radiated frequencies CPU uses three kinds of clocks. Of each is 10MHz, 1.843MHz, and 32.7kHz” in the “(HV4STU500) OpDes”, which is required to be certified under part 15C. For these type devices, that the pen contains a battery and produces an electromagnetic field in the kHz range will generally be seen. This field is picked up by the tablet, which then produces a reference location for the pen. From looking at the internal photos of the tablet, we see that it is laced with a printed wire grid that appears to be for the above purpose. While the tablet itself may not produce this field, the pen does. The pen then is an intentional radiator by definition and must be certified. Please provide a full description of exactly how the pen talks to the tablet. In that description we will probably find out that the pen, as mentioned above, contains a coil which produces the low frequency field as stated. This application then would be both a part 15B computer peripheral (tablet) and an intentional radiator (pen). Both must be addressed. George Chen Chief Technical Officer - Asia mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 6 Wacom Co Ltd LCD SIGNATURE TABLET FCC ID:HV4STU500 Photographs Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT Page 7 Wacom Co Ltd LCD SIGNATURE TABLET FCC ID:HV4STU500 Figure 3 General Appearance of the EUT Figure 4 General Appearance of the EUT Label Location

Page 7 Wacom Co Ltd LCD SIGNATURE TABLET FCC ID:HV4STU500 Figure 3 General Appearance of the EUT Figure 4 General Appearance of the EUT Label Location

4-R2 99 79 OCT/29/2007 SLA-A201 * 7 G C P 0 1 0 3 2 * S T U - 5 0 0 / G

Page 8 Wacom Co Ltd LCD SIGNATURE TABLET FCC ID:HV4STU500 Figure 5 General Appearance of the EUT Figure 6 Inside Configuration of the EUT Page 9 Wacom Co Ltd LCD SIGNATURE TABLET FCC ID:HV4STU500 Figure 7 Inside Configuration of the EUT Figure 8 Inside Configuration of the EUT Page 10 Wacom Co Ltd LCD SIGNATURE TABLET FCC ID:HV4STU500 Figure 9 Inside Configuration of the EUT Figure 10 Inside Configuration of the EUT Page 11 Wacom Co Ltd LCD SIGNATURE TABLET FCC ID:HV4STU500 Figure 11 Inside Configuration of the EUT Figure 12 Inside Configuration of the EUT Page 12 Wacom Co Ltd LCD SIGNATURE TABLET FCC ID:HV4STU500 Figure 13 Inside Configuration of the EUT Figure 14 Inside Configuration of the EUT Page 13 Wacom Co Ltd LCD SIGNATURE TABLET FCC ID:HV4STU500 Figure 15 Inside Configuration of the EUT Figure 16 Inside Configuration of the EUT

FCC ID:HV4STU500 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07462 APPLICATION FOR CERTIFICATION On Behalf of Wacom Co Ltd LCD SIGNATURE TABLET Model Number: STU-500 Prepared for : Wacom Co Ltd 2-510-1 Toyonodai, Otone-cho, Kitasaitama-gun, Saitama 349-1148, Japan. Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755) 26639496 Report Number ： ACS-F07462 Date of Test ： Oct.23~27, 2007 Date of Report ： Oct.31, 2007 FCC ID:HV4STU500 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07462 TABLE OF CONTENTS Description Page Test Report Declaration 1. SUMMARY OF STANDARDS AND RESULTS .................................................................. 1-1 1.1. Description of Standards and Results.............................................................................................1-1 2. GENERAL INFORMATION .................................................................................................. 2-1 2.1. Description of Device (EUT) .........................................................................................................2-1 2.2. Tested Supporting System Details .................................................................................................2-2 2.3. Test Facility....................................................................................................................................2-4 2.4. Measurement Uncertainty ..............................................................................................................2-4 3. POWER LINE CONDUCTED EMISSION TEST................................................................ 3-1 3.1. Test Equipments.............................................................................................................................3-1 3.2. Block Diagram of Test Setup .........................................................................................................3-1 3.3. Power Line Conducted Emission Test Limits 15.207 ....................................................................3-1 3.4. Configuration of EUT on Test .......................................................................................................3-2 3.5. Operating Condition of EUT..........................................................................................................3-2 3.6. Test Procedure................................................................................................................................3-2 3.7. Conducted Disturbance at Mains Terminals Test Results..............................................................3-2 4. RADIATED EMISSION TEST ............................................................................................... 4-1 4.1. Test Equipment ..............................................................................................................................4-1 4.2. Block Diagram of Test Setup .........................................................................................................4-1 4.3. Radiated Emission Limit 15.209 ....................................................................................................4-2 4.4. EUT Configuration on Test............................................................................................................4-2 4.5. Operating Condition of EUT..........................................................................................................4-3 4.6. Test Procedure................................................................................................................................4-3 4.7. Radiated Disturbance Test Results.................................................................................................4-3 5. DEVIATION TO TEST SPECIFICATIONS ........................................................................ 5-1 6. PHOTOGRAPH........................................................................................................................ 6-1 6.1. Photos of Power Line Conducted Emission Test ...........................................................................6-1 6.2. Photos of Radiated Emission Test (In Anechoic Chamber) ...........................................................6-2 FCC ID:HV4STU500 Page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07462 1-1 1. SUMMARY OF STANDARDS AND RESULTS 1.1. Description of Standards and Results The EUT have been tested according to the applicable standards as referenced below. EMISSION Description of Test ItemStandard Limits Results Power Line Conducted Emission Test FCC Part 15: 2007 ANSI C63.4: 2003 Class B PASS Radiated Emission Test FCC Part 15: 2007 ANSI C63.4: 2003 Class B PASS FCC ID:HV4STU500 Page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07462 2-1 2. GENERAL INFORMATION 2.1. Description of Device (EUT) Description : LCD SIGNATURE TABLET Model Number : STU-500 Applicant : Wacom Co Ltd 2-510-1 Toyonodai, Otone-cho, Kitasaitama-gun, Saitama 349-1148, Japan. Manufacturer : Totton SANYO Electric (Guangzhou) Co., Ltd 3 Xingda Road, Huangpu, Guangzhou, Guangdong, P.R. China List Name : SUMITRONICS HONG KONG LTD. Unit 803A, East Ocean Centre, 98 Granville Road, Tsim Sha Tsui East, Kowloon, Hongkong Power Adaptor : Manufacturer: UNIFIUE, M/N: UI312-0520 Cable: Unshielded Detachable, 4.0m RS232 Cable : Unshielded, Detachable, 1.8m USB Cable : Unshielded, Detachable, 1.8m Date of Test : Oct.23~27, 2007 Date of Receipt : Oct.23, 2007 Sample Type : Series production FCC ID:HV4STU500 Page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07462 2-2 2.2. Tested Supporting System Details 2.2.1. PERSONAL COMPUTER 2.2.2.MONITOR 2.2.3.PS/2 KEYBOARD 2.2.4.HDD EMC CODE : Test PC E M/N : HP Pavilion W1000 S/N : THT504101L Manufacturer : HP Power Cord : Unshielded, Detachabled, 1.8m FCC ID : By DoC BSMI ID : R31001 EMC CODE : ACS-EMC-LM03R M/N : 1907FPt S/N : CN-0…

Text truncated - open the document above for the full version.

FCC ID:HV4STU500 Page 6-1 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07462 6. PHOTOGRAPH 6.1. Photos of Power Line Conducted Emission Test FCC ID:HV4STU500 Page 6-2 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07462 6.2. Photos of Radiated Emission Test (In Anechoic Chamber) Test Frequency: 30-1000MHz FCC ID:HV4STU500 Page 6-3 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07462 FCC ID:HV4STU500 Page 6-4 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07462 Test Frequency: 0.009-30MHz
