HYQ14AEBSmart Card Key

Locking/Unlocking the doors of the vehicle INSTRUCTIONS When the engine switch is off and you push the lock button on the outside door handle while carrying Smart Card Key, all doors will be locked. Make sure all the doors are locked when you leave the vehicle. When you take hold the back side of the outside door handle on the driver’s door carrying Smart Card Key, the driver’s door will be unlocked. When you take hold the back side of the outside door handle except on the driver’s door, carrying Smart Card Key, all the doors will be unlocked. When you push the trunk button on the trunk lid while carrying Smart Card Key, the trunk lid will be unlocked. NOTE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

1-1,Showa-cho, Kariya-shi, Aichi-ken, 448-8661, Japan Tel : +81-566-25-5947 Fax : +81-566-25-4548 Date: March 7, 2008 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; 1-1,Showa-cho, Kariya-shi, Aichi-ken, 448-8661, Japan Tel : +81-566-25-5947 Fax : +81-566-25-4548 g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Kazuo Sakakibara, Senior Manager Engineering Administration Dept.

1-1,Showa-cho, Kariya-shi, Aichi-ken, 448-8661, Japan Tel : +81-566-25-5947 Fax : +81-566-25-4548 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: HYQ14AEB To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Technical description of the transmitter Block Diagram Circuit Diagram Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments in 45 days: External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Kazuo Sakakibara Senior Manager Engineering Administration Dept. March 11, 2008

1 Lucy Tsai From:Shizuka Kamakura Sent:Friday, March 14, 2008 4:24 AM To:Lucy Tsai Cc:Claire Hoque; Mika Kaneko Subject:RE: pls review DENSO CCS project#08J11637, AN08T7713 and AN08I2346, Notice#1 Attachments:04_Circuit_Diagram_14AEB_R.pdf Importance:High Hi Lucy, Q#1: Ant 1, Ant 2, Ant 3 are elements of one RX antenna. ANT 4 is TX antenna. Q#2: Please see the revised circuit diagram. Best regards, Shizuka -----Original Message----- From: Lucy Tsai Sent: Friday, March 14, 2008 8:29 PM To: Shizuka Kamakura; Claire Hoque Subject: RE: pls review DENSO CCS project#08J11637, AN08T7713 and AN08I2346, Notice#1 Hi Shizuka, Please address following issues for both TCB and IC. Q#1: According to schematics, there four antennas used in this device. This doesn’t agree with block diagram and the information shown inside the internal photo. Please clarify. Q#2: Please provide a schematics to include all parts value. Best Regards, Lucy

Marking location and layout Fig. Marking location and layout of Transmitter Note: Compliance statement of marking will not be changed. But marking layout, size and other indications maybe changed. FCC ID : HYQ14ABB IC : 1551A-14ABB DENSO FCC ID : HYQ14ABB IC : 1551A-14ABB DENSO Marking location

Model：14AEB Antenna location

FCC CFR47 PART 15 SUBPART C INDUSTRY CANADA RSS-210 ISSUE 7 INDUSTRY CANADA RSS-GEN ISSUE 2 CERTIFICATION TEST REPORT FOR SMART CARD KEY MODEL NUMBER: 14AEB FCC ID: HYQ14AEB IC: 1551A-14AEB REPORT NUMBER: 08J11637-1 ISSUE DATE: MARCH 11, 2008 Prepared for DENSO CORP. 1-1 SHOWA-CHO, KARIYA AICHI 448-8661, JAPAN Prepared by COMPLIANCE CERTIFICATION SERVICES 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 08J11637-1 DATE: MARCH 11, 2008 FCC ID: HYQ14AEB IC: 1551A-14AEB Page 2 of 30 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4031B 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issue Date Revisions Revised By -- 03/11/08 Initial Issue F. Ibrahim REPORT NO: 08J11637-1 DATE: MARCH 11, 2008 FCC ID: HYQ14AEB IC: 1551A-14AEB Page 3 of 30 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4031B 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................................ 4 2. TEST METHODOLOGY ..................................................................................................................... 5 3. FACILITIES AND ACCREDITATION .............................................................................................. 5 4. CALIBRATION AND UNCERTAINTY ............................................................................................ 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 5 4.2. MEASUREMENT UNCERTAINTY ............................................................................................... 5 5. EQUIPMENT UNDER TEST .............................................................................................................. 6 5.1. DESCRIPTION OF EUT ..............................................................................................................6 5.2. DESCRIPTION OF AVAILABLE ANTENNAS ............................................................................. 6 5.3. SOFTWARE AND FIRMWARE .................................................................................................... 6 5.4. WORST-CASE CONFIGURATION AND MODE......................................................................... 6 5.5. DETAILS OF TESTED SYSTEM .................................................................................................. 7 6. TEST AND MEASUREMENT EQUIPMENT .................................................................................... 9 7. ANTENNA PORT TEST RESULTS ................................................................................................. 10 7.1. 20 dB AND 99% BANDWIDTH.................................................................................................. 10 7.2. DUTY CYCLE ............................................................................................................................. 13 7.3. TRANSMISSION TIME ...............................................................................................................18 8. RADIATED EMISSION RESULTS .................................................................................................. 19 8.1. TRANSMITTER RADIATED SPURIOUS EMISSION ................................................................ 19 8.2. RECEIVER RADIATED SPURIOUS EMISSION ....................................................................... 24 9. SETUP PHOTOS................................................................................................................................ 27 REPORT NO: 08J11637-1 DATE: MARCH 11, 2008 FCC ID: HYQ14AEB IC: 1551A-14AEB Page 4 of 30 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4031B 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME : DENSO CORP. 1-1 SHOWA-CHO KARIYA, AICHI 448-8661, JAPAN EUT DESCRIPTION: SMART CARD KEY MODEL: 14AEB SERIAL NUMBER: 02099 DATE TESTED: FEBRUARY 29, 2008 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15 SUBPART C NO NON-COMPLIANCE NOTED INDUSTRY CANADA RSS-210 ISSUE 7 NO NON-COMPLIANCE NOTED INDUSTRY CANADA RSS-GEN ISSUE 2 NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: FRANK IBRAHIM TOM CHEN ENGINEERING SUPERVISOR TEST ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 08J11637-1 DATE: MARCH 11, 2008 FCC ID: HYQ14AEB IC: 1551A-14AEB Page 5 of 30 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4031B 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. 2. TEST METHODOLOGY The tests documented in …
