HZB-S58-25

INSTALLATION AND MAINTENANCE MANUAL ETHERNET BRIDGE SPREAD SPRECTRUM RADIOS (2.4 AND 5.8 GHz) INSTALLATION AND MAINTENANCE MANUAL Tsunami FAMILY SPREAD SPECTRUM RADIOS SEPTEMBER 1999 i Installation and Maintenance Manual Copyright © 1999 by Glenayre Western Multiplex. All rights reserved. No part of this manual may be reproduced without prior written permission from Glenayre Western Multiplex. The information contained in this manual is subject to change without notice. Glenayre Western Multiplex shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this manual or equipment supplied with this manual. Glenayre Western Multiplex makes no warranty of any kind with regard to this manual or any equipment supplied with this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Heliax is a registered product of Andrews Corporation. Printed in the United States of America Notice: Y2K (Year 2000 Issue) All software supplied by and for Glenayre Western Multiplex products adheres to the four- (4) digit year nomenclature as required for Year 2000 compliance. Glenayre Western Multiplex 1196 Borregas Avenue Sunnyvale, California USA Tel:+1 408 542-5200 Fax::+1 408 542-5300 Our facility has been Registered to the International Organization for Standardization ISO 9000 Series Standards for quality. Issue:September 1999 INSTALLATION AND MAINTENANCE MANUAL Tsunami FAMILY SPREAD SPECTRUM RADIOS SEPTEMBER 1999 ii This page intentionally left blank INSTALLATION AND MAINTENANCE MANUAL Tsunami FAMILY SPREAD SPECTRUM RADIOS SEPTEMBER 1999 iii Regulatory Notice This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: *Reorient or relocate the receiving antenna. *Increase the separation between the equipment and receiver. *Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. *Consult the dealer or an experienced radio/TV technician for help. Shielded cables and I/O cords must be used for this equipment to comply with the relevant FCC regulations. Changes or modifications not expressly approved in writing by Glenayre Western Multiplex may void the user's authority to operate this equipment. This device complies with RSS-210 and/or RSS-139 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This device must be professionally installed. INSTALLATION AND MAINTENANCE MANUAL Tsunami FAMILY SPREAD SPECTRUM RADIOS SEPTEMBER 1999 iv This page intentionally left blank INSTALLATION AND MAINTENANCE MANUAL Tsunami FAMILY SPREAD SPECTRUM RADIOS SEPTEMBER 1999 vW/CS97-1 GENERAL TERMS 1.1 All Definitions contained in Glenayre Western Multiplex's Conditions of Sale (Glenayre Western Multiplex document number CS96-8), apply to the Warranty. 1.2 Subject to the provisions of the Warranty, Glenayre Western Multiplex warrants that the equipment described in Paragraph 1.3 shall conform to their specifications described in Paragraph 1.4 in all material respects and that the equipment shall be free from material defects in materials and workmanship. 1.3 This Warranty applies to all original purchases of Glenayre Western Multiplex manufactured equipment and accessories (collectively the "Equipment"). 1.4 This Warranty applies to the specifications contained in the most recent version of the manual for the model of the Equipment purchased (the "Specifications"). 1.5 This Warranty does not apply to the following items of Equipment which are covered by the Original Equipment Manufacturer's warranty: (a) antenna systems, including coax cable, waveguide, connectors flex-sections, mounts, other parts of the antenna system and installation materials; (b) non-Glenayre Western Multiplex manufactured rack mounted equipment that is assembled wired and tested at Glenayre Western Multiplex's factory or supplied as part of a system, including orderwire items, channel banks, multiplexers, fuse/alarm panels, remote alarm items; and (c) equipment which is not listed in Glenayre Western Multiplex's price book. 1.6 The effective period of this Warranty shall start on the date of shipment of the Equipment and shall end: (a) for all spread spectrum unlicensed radio products and for all licensed digital microwave radio products, two (2) years later; (b) for all analog microwave radio products, three (3) years later; or (c) for all baseband products, five (5) years later (in each case the "Warranty Period"). 1.7 The Customer acknowledges that Glenayre Western Multiplex does not represent or warrant that the services provided by Glenayre Western Multiplex under this Warranty will ensure uninterrupted or error-free operation of the Equipment. RETURN OF EQUIPMENT UNDER WARRANTY 2.1If an item of Equipment malfunctions or fails in normal intended usage and maintenance within the applicable Warranty Period: (a) the Customer shall promptly notify Glenayre Western Multiplex of the problem and the serial number of the defective item; (b) Glenayre Western Mult…

Text truncated - open the document above for the full version.

October 4, 1999 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 We, the undersigned, hereby authorize Intertek Testing Services to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by Intertek Testing Services on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to the applications authorized hereunder is subject to a denial of benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853 (a). This agreement expires one year from the current date. Caroline Yu International Product Manager Western Multiplex Corp.

October 4, 1999 Federal Communications Commission Authorization and Evaluation Division Laboratory Division 7435 Oakland Mills Road Columbia, MD 21046 Re:Western Multiplex, Tsunami (Model 27705) Radio Request for withholding from public disclosure proprietary information submitted pursuant to an application for certification of an ISM band radio. FCC ID: HZB-S58-25 Dear Sir or Madam: Western Multiplex Corporation requests certain materials submitted with this application for certification of the Tsunami (Model 27705) radio be withheld from public disclosure. This request is made under the provision of Section 0.457 (d) of the Commission’s Rule and Section 552 (b) (4) of the Freedom of Information Act, Trade Secrets. The items marked “Confidential” contain detailed block diagrams, schematic diagrams, and a detailed theory of operation submitted to the FCC for review with this application. The information contains proprietary information (trade secrets) regarding the circuit operation and capabilities (specific values of components, circuit design details and system architecture) which are the result of our extensive investment in research and development. Without the disclosed information, competitive organizations would take considerable more time to assess and develop a workable competitive product. As a result, we believe that disclosure of these company-guarded materials would compromise our leading position in this market. We therefore formally request that the materials marked “Confidential” be kept strictly confidential and not made available for inspection by any other party, except on a need to know basis for the sole purpose of the certification process. Caroline Yu International Product Manager Western Multiplex Corp.

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 February 17, 2000 RE:Re sponse to FCC Re que sts Correspondence Reference Numbe rs: 12038 FCC IDs: HZB-S58-25 Form 731 Confirmation Numbe rs: EA95966 Dear Mr. Dichoso 1. Please see attachment 1 for the latest version of section 3-10 of the Installation and Maintenance Manual. This warning was recommended by Greg Czumak on a similar product (HZB-S58-12) which just received FCC approval. The 5-meter distance is based on calculations in attachment 2. We are aware from a previous FCC request (#11532 regarding the HZB-S58-12) that the Commission is also looking at applying rule 1.1307 to our spread spectrum radios. Even though we still disagree with this approach of the Commission (please refer to my response to request 11532 on HZB-S58-12 in attachment 3), we are willing to lower the certified output power of HZB-S58-25 to 24.6dBm (290mW) to comply with the 1640W EIRP limit set in rule 1.1307. Please refer to attachment 3 for the supporting calculation. 2. Please see in attachment 4 for the confidentiality request letter. Please note that we only requested items listed in this letter to be held confidential. The other items were unintentionally marked as confidential while uploading the application. 3. Please find in attachment 5 the photo showing the component side of the RF board; the omission of this photo was unintentional. 4, 5Please find in attachment 6 a reply to your questions regarding processing gain. Greg Czumak raised a similar question recently when HZB-S58-12 was under review, which uses an identical spreading scheme. Grant for that product was awarded on Feb. 14, 2000. 6 For the flat panel antennas, we recommend only up to 2 foot in size. We did not mention this specifically because 2 foot is the biggest flat panel antenna available in the market. We will make modifications to the manual to be more specific about the antenna sizes to recommend only 1’, 2’ flat panel and 2’, 4’, 6’ and 8’ parabolic antennas for 5.8G spread spectrum radios. Please refer to Attachment 7 for a list of the antennas we recommend in the manual and the supporting technical specifications of the flat panel antennas from some typical manufacturers. As you can see, the maximum gain for the 2’ panel antenna is 28dBi, which is below the gain of the antenna used in testing. Therefore, at 5m distance and far field the radio will not introduce any RF exposure exceeding the level as calculated in attachment 2. As far as out-of-band emissions are concerned, the use of a 28dBi-panel antenna does not in anyway deteriorate the test results of the radio. Therefore, in addition to the 2’-8’ parabolic antennas, the 1’ and 2’ flat panel antennas should be allowed to be used with the HZB-S58-25 radios. I hope this response has addressed all your concerns and the grant for the HZB-S58-25 will be awarded soon. Yours tr ul y, Caroline Yu Inter natio nal Product Ma na ger Western Multiplex Corporation 1196 Borregas Ave., Sunnyvale, CA 94089-1302, USA Tel: +1 (408) 542-5200,Fax: +1 (408) 542-5300

Attachment 4 Letter of Request for Confidentiality October 4, 1999 Federal Communications Commission Authorization and Evaluation Division Laboratory Division 7435 Oakland Mills Road Columbia, MD 21046 Re:Western Multiplex, Tsunami (Model 27705) Radio Request for withholding from public disclosure proprietary information submitted pursuant to an application for certification of an ISM band radio. FCC ID: HZB-S58-25 Dear Sir or Madam: Western Multiplex Corporation requests certain materials submitted with this application for certification of the Tsunami (Model 27705) radio be withheld from public disclosure. This request is made under the provision of Section 0.457 (d) of the Commission’s Rule and Section 552 (b) (4) of the Freedom of Information Act, Trade Secrets. The items marked “Confidential” contain detailed block diagrams, schematic diagrams, and a detailed theory of operation submitted to the FCC for review with this application. The information contains proprietary information (trade secrets) regarding the circuit operation and capabilities (specific values of components, circuit design details and system architecture) which are the result of our extensive investment in research and development. Without the disclosed information, competitive organizations would take considerable more time to assess and develop a workable competitive product. As a result, we believe that disclosure of these company-guarded materials would compromise our leading position in this market. We therefore formally request that the materials marked “Confidential” be kept strictly confidential and not made available for inspection by any other party, except on a need to know basis for the sole purpose of the certification process. Caroline Yu International Product Manager Western Multiplex Corp.

Tsunami (Model 27705) Radio FCC/IC Label Design The “xx” is the channel number (A1, A2) The “XXXXXXXX” will be replaced by Industry Canada ID numbe r The “TX/RX” will be replaced by the specific transmit/receive fre quencies of each radio The device complies with Part 15 of the FCC Rules and IC. RSS-210. Operation is subject to the following three conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. (3) This device must be professionally installed. MADE IN USA

Processing Gain Measurement Data 10/1/1999 Gp (dB) 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 5800 5805 5810 5815 5820 5825 5830 5835 5840 Freq MHz Processing Gain

Attachment 2RF exposure statement Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attention: Reviewing Engineer The HZB-S58-25 radio is a full duty-cycle product exclusively designed for fixed-mount point-to-point applications (Please refer to Page 1-1 of the Installation and Maintenance Manual ). Each radio’s inputs are connected to external equipment through the radio’s interfaces. The RF output port is connected to a RF cable or a waveguide, which connects on the other side to an antenna usually installed on top of a building or a tower. It is impossible to use the radio in any mobile applications. The HZB-S58-25 radios need to be professionally installed outdoor either on top of a tower or a tall building. The installation sites are inaccessible to the general public. Only installation engineers may get close to the radio antenna during system installation. For the safety concern of the professional installers, we put a warning message on Page 3-20 (section 3.10) of the product manual recommending installers stay at least 5 meters away from the antenna during system operation. The maximum output power tested for the HZB-S58-25 is 420 mW (+26.2 dBm), and the biggest antenna to be used with our 5.8 GHz radios is of 8’ diameter (41dB gain). Due to the fact that the HZB-S58-25 radio is used for fix-mount point-to-point communication that requires line-of –sight clearance in the path and that the radio is single-unit in-door equipment, the antenna sites are always far away from the radio equipment room. The typical length of RF cable that runs from the output of the radio to the antenna input is over 100 feet. In situations w here an antenna site is extremely far from the equipment room, waveguide may be used as a means to reduce the loss from RF transmission. A typical distance between antenna and radio when waveguide is used is over 200 feet. To give a worst example, let’s assume 100 feet Andrew 5/8” foam coax cable or 200 feet Andrew waveguide is used. Given 0.5dB loss for the connectors on each end, the loss introduced by RF cabling is at least 3.5-5.5 dB (please refer to the table below for Loss/100’ data). As for the majority of cases, the transmission line loss is usually in the range of over 10dB. When the transmission line loss is taken into consideration, the maximum possible EIRP will be: Maximum Output power + Maximum Antenna Gain – Minimum Implementation Loss = 26.2 + 41 – 3.5 = 63.7 dBm. the power density at 5 meters from an antenna is: S = EIRP/4 π R 2 = 7.5 W/m 2 = 0.75 mW/cm 2 < 1 mW/cm 2 Where: S = Power density R = distance to the center of radiation of the antenna In the cases of using 2’, 4’, 6’ and 8’ parabolic antennas, The near field power density is : S nf = 16 η P/ π D 2 . The worst case of near-field power density is when the radio output at the certified power, η =1, and the antenna diameter D=2 ft. S nf max = 16x0.42/ π (2x0.3048) 2 = = 5.7 W/m 2 = 0.57 mW/cm 2 <1 mW/cm 2 Where: S nf = maximum near –field power density P = power fed to the antenna η = aperture efficiency D = antenna diameter So in all the above-mentioned situations, the power density is compliant with the limit for General Population/ Uncontrolled Exposure as specified in rule 1.1310. If you should have any questions regarding this submission, please feel free to contact the undersigned. Table 1:Feeder Loss Feeder Loss Type ManufacturerModel NumberLoss/100' 1/2" foam coaxAndrewLDF 4-506.6 dB 5/8" foam coaxAndrewLDF 4.5-504.7 dB WaveguideAndrewEW-521.2 dB Yours tr ul y, Caroline Yu Inter natio nal Product Ma na ger Western Multiplex Corporation

Attachment 3 1.FCC Request 11532 To: Ken Ruppel, Glenayre Western Multiplex From: Greg Czumak [email protected] FCC Application Processing Branch Re: FCC ID HZB-S58-12 Applicant: Glenayre Western Multiplex Correspondence Reference Number: 11532 731 Confirmation Number: EA95627 Date of Original E-Mail: 01/14/2000 1. We will need a list of all antennas to be used for this 5.8 GHz ss transmitter. 2. Your recent UNII filings had only 200 W EIRP output (due to 53 dBm limit for UNII). Even though the same type of antennas are proposed for the current filing, this device can have an output up to 2.7 kW EIRP when using a 41 dBi dish. This transmitter has an output nearly 10 times higher than the previous 2 UNII filings. Its output is also above the general categorical exclusion limits for routine RF exposure evaluation for licensed transmitters (see 1.1307 Table 1). Even through the rules do not specifically require a spread spectrum transmitter to perform routine RF exposure evaluation, because operations in the 5.8 GHz band do not have any EIRP restrictions for point-to-point operation, and there is a much higher potential for devices with high EIRP to exceed RF exposure requirements, we may need to apply 1.1307 (d), if there are no other effective solutions. The following are possible choices and/or issues which you may want to address or consider - (a) Tests for emission requirements have been based on a 29 dBi antenna. With RF exposure requirements in effect, we have concerns for approving antennas with gains higher than those tested, especially when the EIRP is substantially high. In this case, we may need to limit the maximum antenna gain to 29 dBi, as tested, in order to make it reasonable/acceptable for RF exposure compliance purposes. (b) Alternatively, you may choose to voluntarily limit the maximum EIRP (to similar levels used by your recent UNII filings) and we will indicated the maximum EIRP as a grant condition. This would allow you to consider antennas with higher than 29 dBi gain for this transmitter, with effective power reduction mechanisms. Again, a list of all antennas used by this transmitter must be submitted, including installation and power reduction procedures. (c) If both of the above options are not desirable, and you want to maintain the full 23.3 dBm output for antennas with higher than 29 dBi gain (the maximum EIRP is about 2700 W for the proposed 41 dBi gain antenna), we will need to consider the alternative in 1.1307(d), which may lead to an Environmental Assessment. This high EIRP is substantial, and is also above the general categorical exclusion limits of 1640 W EIRP for licensed transmitters, which typically have minimum antenna height requirements. This means that you may need to address environmental impact issues for RF exposure at all sites using this transmitter, including any antenna co-location issues for all sites (that generally also reduces the allowable limits for individual antennas since the total output of all antennas at the site is expected to be higher, see 1.1307(b)(3)). Please respond, informing us which of these options you select, or other alternatives you may propose, allowing us to complete the review of this application. Once an effective solution has been determined, we will determine the procedures for satisfying compliance and the type of antenna installation requirements, separation distances or any warnings etc.needed. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal pursuant to Section 2.917 (c) and forfeiture of the filing fee pursuant to section 1.1108. DO NOT reply to this e-mail by using the Reply button. In order for your response to be processed expeditiously, you must upload your response via the Internet at www.fcc.gov, Electronic Filing, OET Equipment Authorization Electronic Filing. If the response is submitted through Add Attachments, in order to expedite processing, a message which informs the processing staff that a new exhibit has been submitted must also be submitted via Submit Correspondence. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. 2.Response to FCC request 11532 RE:Re sponse to FCC Re que sts Correspondence Reference Numbe rs: 11532 FCC IDs: HZB-S58-12 Form 731 Confirmation Numbe rs: EA95627 Attn:Greg Czumak 1. Please find in the attached form a list of different types of antennas may be used with the HZB-S58-12 radios. For your reference, we have also included some typical antenna models made by different manufacturers. Antenna TypeManufacturerModel NumberMid-band Gain (dBi) 1 Foot Flat PanelGabrielDFPD1-5223.5 2 Foot Flat PanelGabrielDFPD2-5228 RSIA57A24-U26.5 2 Foot ParabolicGabrielSSP2-52B28.5 RSIP-57C2429 Radio WavesSP2-5.228.3 3 Foot ParabolicRadio WavesSP3-5.231.4 4 Foot ParabolicGabrielSSP4-52A34.2 RSIP-57B4834.7 Radio WavesSP4-5.234.6 6 Foot ParabolicGabrielSSP6-52A37.5 RSIP-57A7238.2 Radio WavesSP6-5.237.7 8 Foot ParabolicGabrielDRFB8-55ASE40.7 RSIP-57A9640.8 2. • As I have indicated in my previous response, our radios are fixed-mount equipment that are designed for point-to-point outdoor communications. The antennas must be highly directional, and the transmission path must have line-of-sight clearance. The radio antennas must be installed either on top of a tower or a very high building so that the line-of-sight condition can be met. Therefore, the antenna sites are not accessible to the general public. Installation of the radios and antennas must be performed by professional installation engineers. The transmission paths of the radios are well above ground level radiating in a beam point to point rather than omnidirectional to the gen…

Text truncated - open the document above for the full version.
