HZB-U5358-480U-NII Radio

Proxim Wireless Corporation

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Mar 28, 2001
Application Purpose: Original Equipment
Date of Application: Feb 14, 2001
Equipment Note: U-NII Radio
Frequency Range: 5775.00000000 - 5775.00000000
Company: Proxim Wireless Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

INSTALLATION AND MAINTENANCE MANUAL WIRELESS GIGABIT ETHERNET BRIDGE (5.3/5.8 GHz UNII/LE-LAN1000BaseF) MAN-27900 INSTALLATION AND MAINTENANCE MANUAL Tsunami FAMILY GIGABIT ETHERNET WIRELESS BRIDGES JANUARY 2001 i Installation and Maintenance Manual Copyright © 2000 by Western Multiplex. All rights reserved. No part of this manual may be reproduced without prior written permission from Western Multiplex. The information contained in this manual is subject to change without notice. Western Multiplex shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this manual or equipment supplied with this manual. Western Multiplex makes no warranty of any kind with regard to this manual or any equipment supplied with this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Heliax is a registered product of Andrews Corporation. OpenView is a registered product of Hewlett Packard Corporation. SmartBits is a registered product of NetCom Systems Inc. Windows is a registered product of Microsoft Inc. Chariot and Qcheck are a registered products of Ganymede Software Inc. Gabriel dual-band/dual polarized flat or parabolic antennas are products of Gabriel Electronics Inc. RadioWave dual-band/dual polarized, flat or parabolic antennas are products of Radio Wave Corp. Other names are trademarks of their owners Printed in the United States of America Notice: Y2K (Year 2000 Issue) All software supplied by and for Western Multiplex products adheres to the four-(4) digit year nomenclature as required for Year 2000 compliance. Western Multiplex 1196 Borregas Avenue Sunnyvale, California USA Tel:+1 408 542-5200 Fax::+1 408 542-5300 e-mail: [email protected] Our facility has been Registered to the International Organization for Standardization ISO 9000 Series Standards for quality. Issue:January 2001 INSTALLATION AND MAINTENANCE MANUAL Tsunami FAMILY GIGABIT ETHERNET WIRELESS BRIDGES JANUARY 2001 ii Revision history: November 2000:First version Draft version December 2000:Added updated drawings Front panel LED detail Update NMS screen captures January 2001Replaced Browser NMS graphics INSTALLATION AND MAINTENANCE MANUAL Tsunami FAMILY GIGABIT ETHERNET WIRELESS BRIDGES JANUARY 2001 iii Regulatory Notice This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. This equipment generates, uses and can radiate radio frequency energy and is to be installed and used in accordance with the instructions. Shielded cables and I/O cords must be used for this equipment to comply with the relevant FCC regulations. Changes or modifications not expressly approved in writing by Western Multiplex may void the user's authority to operate this equipment. This device must be professionally installed. INSTALLATION AND MAINTENANCE MANUAL Tsunami FAMILY GIGABIT ETHERNET WIRELESS BRIDGES JANUARY 2001 iv This page intentionally left blank INSTALLATION AND MAINTENANCE MANUAL Tsunami FAMILY GIGABIT ETHERNET WIRELESS BRIDGES JANUARY 2001 vW/CS97-1 GENERAL TERMS 1.1 All Definitions contained in Western Multiplex's Conditions of Sale (Western Multiplex document number CS96-8), apply to the Warranty. 1.2 Subject to the provisions of the Warranty, Western Multiplex warrants that the equipment described in Paragraph 1.3 shall conform to their specifications described in Paragraph 1.4 in all material respects and that the equipment shall be free from material defects in materials and workmanship. 1.3 This Warranty applies to all original purchases of Western Multiplex manufactured equipment and accessories (collectively the "Equipment"). 1.4 This Warranty applies to the specifications contained in the most recent version of the manual for the model of the Equipment purchased (the "Specifications"). 1.5 This Warranty does not apply to the following items of Equipment which are covered by the Original Equipment Manufacturer's warranty: (a) antenna systems, including coax cable, waveguide, connectors flex-sections, mounts, other parts of the antenna system and installation materials; (b) non-Western Multiplex manufactured rack mounted equipment that is assembled wired and tested at Western Multiplex's factory or supplied as part of a system, including orderwire items, channel banks, multiplexers, fuse/alarm panels, remote alarm items; and (c) equipment which is not listed in Western Multiplex's price book. 1.6 The effective period of this Warranty shall start on the date of shipment of the Equipment and shall end: (a) for all spread spectrum unlicensed radio products and for all licensed digital microwave radio products, two (2) years later; (b) for all analog microwave radio products, three (3) years later; or (c) for all baseband products, five (5) years later (in each case the "Warranty Period"). 1.7 The Customer acknowledges that Western Multiplex does not represent or warrant that the services provided by Western Multiplex under this Warranty will ensure uninterrupted or error- free operation of the Equipment. RETURN OF EQUIPMENT UNDER WARRANTY 2.1If an item of Equipment malfunctions or fails in normal intended usage and maintenance within the applicable Warranty Period: (a) the Customer shall promptly notify Western Multiplex of the problem and the serial number of the defective item; (b) Western Multiplex shall, at its sole option, either resolve the problem over the telephone or provide the Customer with a Returned Materials Authorization number (RMA #) and the address of the location to which the Customer may ship the defective item; (c) if the problem is not resolved over the telephone, the Customer shall attach a label to each Returned item describing the fault and the Customer's Return address. The Customer shall, at its cost, properly pack the item to be Returned, prepay the insurance and shipping charg…

Text truncated - open the document above for the full version.

Attestation Statements

November 13, 2000 Intertek Testing Services 1365 Adams Ct. Menlo Park, CA 94025 STATEMENT THAT TSUNAMI (UNII) RADIOS MUST BE PROFESSIONALLY INSTALLED AND SO IS EXEMPT FROM THE ANTENNA RESTRICTIONS OF FCC PART 15.203, INCLUDING INFORMATION ON ANTENNAS USED FOR TESTING This letter is submitted with regards to professional installation of the Tsunami (UNII) radio and the antennas used for testing. The Tsunami (UNII) radios must be professionally installed and so is exempt from the antenna restrictions of FCC Part 15.203. The Tsunami (UNII) radio is a product manufactured by Western Multiplex in Sunnyvale, California. The Tsunami (UNII) radio is to be certified for operation under Part 15.407 of the FCC Rules in the 5.25-5.35 GHz and 5.725-5.825 GHz band. This equipment is designed for point-to-point communications and will only carry data signals using a 1000BaseF(sx) interface. Due to the unique requirements of installation and integration of these systems, typical consumers or businesses will not have the proper training required for successful implementation of these systems. The Tsunami (UNII) is not designed for use by the general public, and will be sold as follows: • through the Western Multiplex sales force to professional communications users in the following categories : electric power utilities, cellular telephone operating companies, personal communication service operating companies, regional Bell operating companies, oil and gas exploration and transmission companies, railroad companies, federal, state and local government agencies, or • through designated and professionally trained Western Multiplex Value Added Resellers to business users under individual reseller agreements. These companies will either use their professional telecommunications engineering staff to carry out the installation or will subcontract to professional installation firms. On occasion, a professional installation firm will purchase the Tsunami (UNII) radios directly. The Tsunami (UNII) radio will be used for fixed, permanent or temporary, outdoor links requiring the use of directional antennas at 5.2-5.8 GHz which tend to be mounted on towers. These antennas will have narrow beamwidths and require professional installers to align them. In addition, the Tsunami (UNII) radio must be set up for the specific line interface required during installation. This procedure must be carried out by a qualified professional installer for the equipment to operate properly. 1196 Borregas Ave., Sunnyvale, CA 94089-1302, USA Tel: +1 (408) 542-5200,Fax: +1 (408) 542-5300 The output power of the Tsunami (UNII) radio will be adjusted to meet any applicable EIRP limits by the professional installer during installation. The method of adjusting the output power is described in the manual written for use by professional trained installers. The Tsunami (UNII) radio is a full duplex device with a common transmit and receive port. The addition of an external amplifier to boost the transmit power would disable the receive signal, thus rendering the Tsunami (UNII) radio inoperable. In addition, high power amplifiers (not generally available at 5.2-5.8 GHz) cannot be used without ensuring that signal saturation does not occur (because this would produce unrecoverable deterioration of the receive signal). Thus, the addition of an amplifier could not be accomplished by a non-professional installer. The Tsunami (UNII) radio is typically sold without an antenna, and the customer and/or installation engineer chooses from commercially available antennas. From time to time, Western Multiplex may sell a commercially available antenna along with the Tsunami (UNII) radio upon customer request. Western Multiplex has also included detailed instructions on how to determine the maximum output power based on EIRP limits for all professional installers to follow. Caroline Yu International Product Manager Western Multiplex Corporation

Attestation Statements

FCC ID: HZB-U5358-480 Compliance with 15.407( c ) frequency stability The following table shows the specifications of the determining oscillators and the total frequency stability of the equipment at both bands over the full operating temperature range. The data show on the table covers the worst frequency shift situation within the full operating temperature range of –30 to +65C specified for the equipment under application. The oscillators are crystal types. 5.775 GHz Transmitter5.3 GHz Transmitter Fundamental Oscillator (PN: 1900012-414000-000) 140MHz±10ppm or ±1.4 kHz 140MHz±10ppm or ±1.4 kHz Secondary Oscillator (PN: 1900017-610900-000) (109MHz±30ppm)x5 or ±16.4kHz (109MHz±30ppm) x5 or ±16.4kHz RF reference Oscillator (PN: 1900017-610900-000) (106.041666MHz±10ppm)x48 or ±50.89kHz (124.687500MHz±10ppm)x48 or 59.85kHz Total Frequency Stability ±11.89ppm or ±68.69kHz ±14.65ppm or ±77.65kHz Justification for the claim of compliance with 15.407( c ) is as follows: a) The lowest channel center frequency is 5300 MHz, with a 26dBc width of 86.3 MHz. The margin above and below the 26dBc points to the band edges is 6.85 MHz, both above and below the center frequency. b) The highest channel center frequency is 5775 MHz with a 26dBc width of 80.4 MHz. The margin above and below the 26dBc points to the band edges is 9.8 MHz, both above and below the center frequency. c) Therefore, the frequency stability of the frequency-determining element must be no worse than 0.129% (6.85 MHz/5300 MHz) over the normal operating range to maintain the emissions within the allowed band. From the above table, it can be seen that the frequency-determining components offer much super ior stability to ensure the compliance to 15.407(g).

Cover Letter(s)

P.O. Box 70, Scarborough, Maine 04070 U.S.A. Tel: 207-883-5161Fax: 207-883-4469 email: [email protected]: http://www.gabrielnet.com 59 5.250 - 5.850 GHz Parabolic Antennas 5.250 - 5.850 GHz Facts & Features • Gabriel Quality and Dependability. • Innovative Feed Design. • Feed input is Type N Female, 50 ohm. • Isolation is 35 dB on Dual Polarized models. • Optional radomes available. • 2 ft. (0.6) model feeds are installed from the front of the antenna. 4 ft. (1.2), 6 ft. (1.8) and 8 ft. (2.4) model feeds are installed from the rear of the antenna, and allow for inspection or replacement from the rear. These models allow for smooth polarization adjustment from the back of the antenna. • Gabriel’s Quick Align Mount comes standard on the SSP2, SSD2 and HSSP2 models. This mount allows for quick installation and easy alignment of the antenna with two hand tools. The Quick Align Mount will mount to a 1.9 - 4.5 in OD mast pipe. • New environmentally pleasing neutral colors. • Dual band models are available. Electrical Specifications 5.250 - 5.850 Standard & High Performance Plane - Dual Polarized Unlicensed "NII" and Spread Spectrum / "ISM" Bands (National Information Infrastructure) (Industrial, Scientific & Medical) NOTE: †Improved VSWR available. Product information subject to change without notice. Gabriel "UNII" and "ISM" Band 2-ft. (0.6 m) - Plane Polarized - Standard Parabolic Antenna 5.250 - 5.850 Associated Equipment InformationPages Point-to-Point Antenna Specifications................................. 14 - 111 Special Application Antennas............................................135 - 145 Antenna Mounts & Reference Dimensions.......................112 - 134 Radomes..............................................................................122 - 124 Tower Accessories............................................................146 - 154 Transmission Lines.............................................................155 - 243 Dry Air Pressurizers...........................................................244 - 253 Size ft (m) VSWR (R.L. max. dB) Gain at Low Mid High dBi F/B ratio dB Standard Frequency GHz Model Number Nominal Mid-Band Beamwidth degrees XPD dB See the Special Application section of this catalog for Gabriel’s Directional Flat Panel antennas for Spread Spectrum operation. Standard - Plane Polarized SSP2-52B2(0.6)-28.128.5 29.06.125381.50(14.0)† SSP4-52B4(1.2)-33.634.2 34.63.130461.50(14.0)† SSP6-52A6(1.8)-37.037.5 38.02.130491.50(14.0)† SSP8-528(2.4)-39.439.8 40.31.630521.50(14.0)† Standard - Dual Polarized SSD2-52A2(0.6)-28.028.4 28.96.130381.50(14.0)† SSD4-52A4(1.2)-33.534.1 34.53.130461.50(14.0)† SSD6-526(1.8)-36.937.4 37.92.130491.50(14.0)† SSD8-528(2.4)-39.339.7 40.21.630521.50(14.0)† High Performance - Plane Polarized HSSP2-522(0.6)-27.728.1 28.66.130431.50(14.0)† HSSP4-524(1.2)-33.333.9 34.33.130501.50(14.0)† HSSP6-526(1.8)-36.737.2 37.72.130581.50(14.0)† HSSP8-528(2.4)-39.239.6 40.11.630621.50(14.0)† SS-52 110800 5.250 - 5.850

Cover Letter(s)

FCC ID: HZB-U5358-480 Dear Mr. Dichoso: This is in response to your fax dated March 27, 2001. These responses follow the numbering of your questions. 1. Emissions of the HZB-U5358-100 equipment will be maintained wit hin the band under all conditions of normal operation under the worst case of frequency shift. A separate exhibit has been uploaded with the name “15407C Conformance” and the prior exhibit superceded. 2. Line conducted tests have been performed with an off-the-shelf power supply. Test setup photos and test results have been uploaded to the FCC database with the name “Conducted Emissions.” 3. The Center frequency of the transmit channels are 5775 MHz and 5300 MHz. The frequency band ranges on the Form 731 and Grant should be corrected to read 5300 MHz-5300 MHz and 5775 MHz – 5775 MHz. The Grant cannot be accessed; if available, it would be changed to read: a. Lower frequency (MHz) 5300Upper frequency (MHz) 5300 b. Lower frequency (MHz) 5775Upper frequency (MHz) 5775 4. A revised RF exposure attestation with the name “RF Exposure Statement” has been uploaded to the FCC database and the prior one has been superceded. The new statement demonstrates compliance with the MPE limits of 1.1310 at a separation distance of 1.5m. The Grant cannot be accessed; if available, the Grant note would be amended to include the 1.5 m distance to agree with TCB Section K procedures as follows: The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures with a separation distance of at least 1.5 meters from all persons during normal operation. Users and installers must be provided with antenna installation instructions and transmitter operating conditions, including antenna co-location requirements of 1.1307(b)(3), for satisfying RF exposure compliance. 5. The RF cable is used for connection between the outdoor unit and the antenna. As can be seen from the test setup photo, the cable is just slightly longer than the minimum distance between the antenna and the outdoor unit to allow easier installation. It is impossible to further reduce the length of the cable in any installation. The manufacturer maintains that there is no need to define a minimum length of cable in this case as any shorter length will make installation impossible. Specifically: the RF cable used during testing is of 16-inch long with N type connectors on both ends. The loss from the cable plus connectors is 0.5 dB. The manufacturer warrants that it will always ship the cables with the HZB- U5358-480 equipment, and t he cable will be no shorter than 16 inch. The Grant cannot be accessed; if available, Note Code 36 would be added as follows: 36 Certain antennas used with this equipment require a minimum cable length, or have power output limitations as documented in the application. 6. The equipment output power is adjustable by the professional installer. To ensure the worst- case situation is covered, the equipment was tested at the maximum output power. The Installation and Maintenance Manual of the product gives detailed instructions to professional installers on how to adjust the output power to maintain compliance to EIRP limits. The HZB- U5358-480 product is not a consumer product and must be installed and maintained by professionally trained personnel. No user manuals will be supplied. 7. The antenna used for testing was of Gabriel SSD2-52A with mid gain of 28.4dBi. The manufacturer wishes to allow higher gain antennas as listed in the manual, to benefit from better received signal gain w hile maintaining the EIRP limits. Due to the fact the equipment was tested at the maximum output power and full EIRP limit of +30dBm at 5.25-5.35GHz and +46.8dBm EIRP (18.4dBm output power with 28.4dBi antenna) at 5.725-5.825 GHz, as long as these two EIRP limits are not exceeded, any increase in antenna gain will mandate a decrease in equipment output power. Therefore the test results of the 2’ antenna cover the worst-case scenario. If the radio had been tested with a higher gain antenna with a reduced output power, the test results in all respects would be equal or better. An exhibit named “PSD Compliance with Antenna Gain” has been uploaded to the FCC database to support this reasoning. A Gabriel dual polarization antenna datasheet has also been uploaded to the FCC database, under the name “Antenna Datasheet”. Due to the fact the U-NII band is still relatively new, there are few U-NII antennas available, making it impossible to include examples of other brands. The Gabriel dual polarization antenna is the only brand the manufacturer has found so far. 8. The Professional Installation Letter has been edited to emphasize t hat all installers will have to follow instructions given in the Installation and Maintenance Manual. The edited Professional Installation Letter has been uploaded to the FCC database under the name “Professional Installation” and the prior one has been superceded. A list of antennas to be used with the HZB-U5358-480 product, with maximum output power calculated to each antenna gain, has also been uploaded to the FCC database under the name “List of antennas.” This list will be included in the I nstallation and Maintenance Manual. It also includes the formulas for calculating the maximum output power setting at the antenna input, as a function of antenna gain. Thank you, Roland G ubisch

External Photos

Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 External Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 External Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 External Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 External Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 External Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 External Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 External Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 External Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 External Photographs Report # 20293341 FCC Part 15.407 Certification

External Photos

Antennas to be used with HZB-U5358-480 Antenna Type Frequency RangeManufacturerModel NumberMid-band Gain (dBi)Max Tx (dBm) 2 Foot Parabolic Dual Polarized5.25-5.85 GHz GabrielSSD2-52A28.4 1.6 (5.25-5.35GHZ) 18.4 (5.725-5.825 GHz) 5.25-5.85 GHz AndrewP2F-5229.4 0.6 (5.25-5.35 GHz) 17.4 (5.725-5.825 GHz) 5.25-5.85 GHz AndrewPX2F-5229.4 0.6 (5.25-5.35 GHz) 17.4 (5.725-5.825 GHz) 3 Foot Parabolic Dual Polarized5.25-5.85 GHz Radio WavesSPD3-5.231.1 -1.1 (5.25-5.35 GHz) 15.7 (5.725-5.825 GHz) 5.25-5.85 GHz AndrewP3F-5233.4 -3.4 (5.25-5.35 GHz) 13.4 (5.725-5.825 GHz) 5.25-5.85 GHz AndrewPX3F-5233.4 -3.4 (5.25-5.35 GHz) 13.4 (5.725-5.825 GHz) 4 Foot Parabolic Dual Polarized5.25-5.85 GHz GabrielSSD4-5234.1 -4.1 (5.25-5.35 GHz) 12.7 (5.725-5.825 GHz) 5.25-5.85 GHz Radio WavesSPD4-5.234.4 -4.4 (5.25-5.35 GHz) 12.4 (5.725-5.825 GHz) 6 Foot Parabolic Dual Polarized5.25-5.85 GHz GabrielSSD6-5237.4 -7.4 (5.25-5.35 GHz) 9.4 (5.725-5.825 GHz) 5.25-5.85 GHz Radio WavesSPD6-5.237.5 -7.5 (5.25-5.35 GHz) 9.3 (5.725-5.825 GHz) 8 Foot Parabolic Dual Polarized5.25-5.85 GHz GabrielSSD8-5239.7 -9.7 (5.25-5.35 GHz) 7.1 (5.725-5.825 GHz) Formula for determining maximum output power setting at the antenna input for 5.25-5.35 GHz Transmitters (@ EIRP=30dBm) Max Tx (dBm) is the lesser of 2.3dBm (0.0017W) and 30 - G where:G = Antenna Gain Tx is the output power measured at the antenna input Formula for determining maximum output power setting at antenna input for 5.725-5.825 GHz Transmitters (@ EIRP=53dBm): Max Tx (dBm) is the lesser of the 18.4Bm (0.069W) and 46.8 - G where:G = Antenna Gain Tx is the output power measured at the antenna input Note: All Western Multiplex radios require professional installation. Antennas with gain less than 28.4dBi are not allowed Antennas of other make may be used with the HZB-U5358-480 device, but must be of the same type, dimensions and gain as those e listed

Internal Photos

Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification Intertek Testing Services 1365 Adams Court, Menlo Park, CA 94025 Western Multiplex, FCC ID: HZB-U5358-480Date of Test: October 23, 2000– November 15, 2000 Internal Photographs Report # 20293341 FCC Part 15.407 Certification

Internal Photos

RF Exposure Info

Attention: Reviewing Engineer The HZB-U5358-480 radio is a full duty-cycle product exclusively designed for fixed-mount point-to-point applications. Each radio’s inputs are connected to external equipment through the radio’s interfaces. The RF output port is connected to a RF cable or a waveguide, which connects on the other side to an antenna usually installed on top of a building or a tower. It is impossible to use the radio in any mobile applications. The HZB-U5358-480 radios need to be professionally installed outdoor either on top of a tower or a tall building. The installation sites are inaccessible to the general public. Only installation engineers may get close to the radio antenna during system installation. For the safety concern of the professional installers, we put a warning message on Page 3-18 of the product manual recommending ins…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Ken Lim(Accounting Manager)

[email protected]408 383 7600Fax: 408 383 7680

Technical Contact

Intertek Testing ServicesDavid Chernomordik

[email protected]650-463-2900

1365 Adams Court · Menlo Park, California · United States

Non-Technical Contact

Western MultiplexCaroline Yu

[email protected]408-542-5200

Test Firm

Intertek Testing Services NA Inc.John Quigley

[email protected]949-448-4100Fax: 650-463-2910

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Tolerance
2	15E	5.78 GHz - 5.78 GHz	69.00 mW	%

Confidentiality

Long Term

Grant Notes

This device must be professionally installed, and may only be used in point-to-point applications. The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures with a separation distance of at least 1.5 meters from all persons during normal operation. Users and installers must be provided with antenna installation instructions and transmitter operating conditions, including antenna co-location requirements of 1.1307(b) (3), for satisfying RF exposure compliance.
