HZB-US58-B60U-NII/Spread spectrum radio

WESTERN MULTIPLEX CORPORATION Installation and Maintenance Manual Base Station Unit Multipoint MAN 40XX-001d1 SS TSUNAMI MULTIPOINT ii Revisions: September 2001 Draft October FCC submittal December Released for review WESTERN MULTIPLEX CORPORATION Tsunami Point-to-Multipoint  2001 Western Multiplex Corporation 1196 Borregas Avenue Sunnyvale, California 94089 USA Phone +1 408 542 5200 • Fax +1 408 542 5300 http://www.wmux.com ftp://ftp.wmux.com/products/ TSUNAMI MULTIPOINT ii NOTICE: CAREFULLY READ THE FOLLOWING LIMITED WARRANTY AND LIMITATION OF LIABILITY (THE “LIMITED WARRANTY”). BY USING THE WESTERN MULTIPLEX EQUIPMENT INCLUDED WITH THIS LIMITED WARRANTY, YOU AGREE TO THE TERMS AND CONDITIONS CONTAINED IN THIS LIMITED WARRANTY. IF YOU DO NOT AGREE TO THESE TERMS AND CONDITIONS, RETURN THE WESTERN MULTIPLEX EQUIPMENT TO WHERE IT WAS PURCHASED OR LEASED WITHIN THIRTY (30) DAYS OF RECEIPT FOR A FULL REFUND. 1. LIMITED EQUIPMENT WARRANTY 1.1 For the applicable Warranty Period (as defined in Paragraph 1.2 below) Western Multiplex warrants that the hardware manufactured by Western Multiplex and initially purchased or leased from one of Western Multiplex’s authorized resellers or distributors by the original end-user (“you”) for your personal use and not for resale (the “Equipment”) (a) substantially conforms to the specifications contained in the most recent version of the manual for the model of the Equipment purchased or leased by you (the “Equipment Specifications”) and (b) is free from defects in materials and workmanship. This Limited Warranty only applies to the Equipment and its preloaded firmware. This Limited Warranty does not apply to any software (or its associated documentation), whether preloaded with the Equipment, installed subsequently or otherwise (“Software”), nor does it apply to any firmware revision that is not originally preloaded on the Equipment at the time the Equipment is purchased or leased. The Software is licensed to you pursuant to the software license agreement that accompanied the Software and is subject to the terms, including the limited warranty and limitation of liability, contained in that license agreement. Western Multiplex has no obligation to repair or replace Software under this Limited Warranty. 1.2 This Limited Warranty shall start on the date that the Equipment is first shipped to you (the “Shipping Date”) and shall end: (a) for all unlicensed radio products which are point-to-multi-point products, one (1) year after the Shipping Date; (b) for all accessories, one (1) year after the Shipping Date; and (c) for all unlicensed radio products (except point-to-multi-point products) and for all licensed digital microwave radio products, two (2) years after the Shipping Date (in each case, the “Warranty Period”). 1.3 Nothing in this Limited Warranty affects any statutory rights of consumers that cannot be waived or limited by contract. 2. LIMITED WARRANTY EXCLUSIONS AND LIMITATIONS. 2.1 The Limited Warranty covers customary and intended usage only. 2.2 Western Multiplex does not warrant, and is not responsible for damage, defect or failure caused by any of the following: (a) Any part of the Equipment having been modified, adapted, repaired, or improperly installed, operated, maintained, stored, transported or relocated by any person other than Western Multiplex personnel or a Western Multiplex authorized service agent; (b) External causes, including electrical stress or lightning, interference caused by other radios or other sources, unsuitable physical or operating environment and use in conjunction with incompatible equipment or accessories; (c) Cosmetic damage, including all damage to the surface of the Equipment; iii (d) Acts of God, fires, floods, wars, terrorist acts, sabotage, civil unrest, labor disputes or similar events, actions or hazards; and (e) Accidents, negligence, neglect, mishandling, abuse or misuse, other than by Western Multiplex personnel or a Western Multiplex authorized service agent. 2.3 The Limited Warranty does not apply to the following parts of the Equipment, which are not manufactured by Western Multiplex, but which may be otherwise covered by an original manufacturer’s warranty: (a) antenna systems, including coaxial cable, wave guide, connectors, flex sections, mounts, and other parts of the antenna system and installation materials; (b) rack mounted equipment, which is not manufactured by Western Multiplex but which may be assembled, wired and tested at Western Multiplex’s factory or supplied as part of a system, including orderwire items, channel banks, multiplexers, fuse/alarm panels and remote alarm items; and (c) all equipment which is not included in Western Multiplex’s specifications. 2.4 Unless otherwise specified, equipment not manufactured by Western Multiplex is provided “AS IS” AND WITHOUT WARRANTIES OF ANY KIND. Please refer to the original manufacturer’s warranty, if any. 2.5 Any technical or other support provided for the Equipment by Western Multiplex, such as telephone assistance or assistance regarding installation, is provided “AS IS” AND WITHOUT WARRANTIES OF ANY KIND. 3. REPLACEMENT, REPAIR AND RETURN PROCESSES. 3.1 To request service under the Limited Warranty: (a) You must, within the applicable Warranty Period, promptly notify Western Multiplex of the problem with the Equipment, provide the serial number of the Equipment, and provide your contact information during business hours, by contacting Western Multiplex by telephone at 408-542-5390, by e-mail at [email protected], or by mail to Support, Western Multiplex Corporation, 1196 Borregas Avenue, Sunnyvale, California 94089, during the business hours of 8:00 a.m. to 5:00 p.m., Pacific Time, Monday through Friday, excluding holidays. This notice is effective when received by Western Multiplex during the business hours referenced above. (b) Western Multiplex shall, at its sole option, either resolve the problem over the telephone or provide you with …

Text truncated - open the document above for the full version.

Proxim Corporation Confidential 15.407(g) Compliance 3/19/2002 Compliance to 15.407(g) HZB-US58-B60 Emissions of the Tsunami Multipoint base station will be maintained within the band under all conditions of normal operation under the worst case of frequency shift. As described in the theory of operations document, the frequency of the RF signal is completely determined by a single reference oscillator of 20.75MHz frequency. Two vendors have been approved to supply the reference oscillator, part #690-00427-02, and the frequency-stability characteristics of each vendor’s part are shown in the following table. Data sheets are attached for reference. Frequency-Stability Characteristics of Reference Oscillator (p/n 690-00427-02) Characteristic Vectron [email protected] Type OCXO Initial Calibration ±0.1 ppm Stability vs.Temperature (-33°C to +70°C) ±0.01 Stability vs. Supply Voltage ±0.001 Aging (10 years) ±0.5 Total: ±0.611 ppm The worst-case stability is ±0.6 ppm, or ±3.5 kHz, over all operating conditions. This is sufficient to maintain the emissions within the allowable band; the supporting reasoning for this claim is as follows: a) The lowest channel center frequency is 5740.40MHz, with a maximum 26dBc bandwidth of 26MHz. The margin from the lower band edge of 5.725GHz to the lower 26dBc point is 2.4MHz. This margin is greater than the maximum oscillator error of 3.5kHz. b) The highest channel center frequency is 5809.57MHz, with a maximum 26dBc bandwidth of 26MHz. The margin from the upper band edge of 5.825GHz to the upper 26dBc point is 2.43MHz. This margin is also greater than the maximum oscillator error of 3.5kHz. Therefore, it is determined that the frequency-determining components offer superior stability to ensure compliance with 15.407(g). Caroline Yu Homologation Product Manager Proxim Corporation

TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD130 of TD137 Rev.No 1.1 (30 October 2001)

April 16, 2002 Federal Communications Commission Authorization and Evaluation Division Laboratory Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for withholding from public disclosure proprietary information FCC ID: HZB -US58-B60 Dear Sir or Madam: Western Multiplex Corporation requests that certain materials submitted with this application for certification of the Tsunami (UNII) radio be withheld from public disclosure. This request is made under the provision of Section 0.457 (d) of the Commission’s Rule and Section 552 (b) (4) of the Freedom of Information Act, Trade Secrets. The items marked “Confidential” contain detailed block diagrams, schematic diagrams, antenna design specifications, a parts list and a detailed theory of operation submitted to the FCC for review with this application. The information contains proprietary information (trade secrets) regarding the circuit operation and capabilities (specific values of components, circuit design details and system architecture), which are the result of our extensive investment in research and development. Without the disclosed information, competitive organizations would take considerable more time to assess and develop a workable competitive product. As a result, we believe that disclosure of these company guarded materials would compromise our leading position in this market. We therefore formally request that the materials marked “Confidential” be kept strictly confidential and not made available for inspection by any other party, except on a need to know basis for the sole purpose of the certification process. Caroline Yu Homologation Product Manager Proxim Corporation 1196 Borregas Ave., Sunnyvale, CA 94089-1302, USA Tel: +1 (408) 542-5200, Fax: +1 (408) 542-5300

April 16, 2002 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 We, the undersigned, hereby authorize Intertek Testing Services to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by Intertek Testing Services on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to the applications authorized hereunder is subject to a denial of benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853 (a). This agreement expires one year from the current date. Caroline Yu Homologation Product Manager Proxim Corporation 1196 Borregas Ave., Sunnyvale, CA 94089-1302, USA Tel: +1 (408) 542-5200, Fax: +1 (408) 542-5300

Exterior photos FCC ID: HZB-US58-B60

Label locat ionFCC ID: HZB-US58-B60

Internal photoFCC ID: HZB-US58-B60 Assembly Photos Top cover and antenna assembly removed (above). Underside of top cover and antenna assembly (above). Internal photoFCC ID: HZB-US58-B60 Base, partially populated (above). Base, fully depopulated (above). Internal photoFCC ID: HZB-US58-B60 Antenna assembly, cover removed (above). Ci rc uit Boa rds R F boa rd, co mpo ne nt si de (above ). Internal photoFCC ID: HZB-US58-B60 R F boa rd, sol de r si de (above ). R F boa rd, powe r a mpl ifie r de tail (a bove ). Internal photoFCC ID: HZB-US58-B60 RF board, oscillator detail (above). Digital board, component side (above). Internal photoFCC ID: HZB-US58-B60 Dig ital boa rd, sol de r si de (above ). GPS receiver board, side 1 (above). Internal photoFCC ID: HZB-US58-B60 GPS receiver board, side 2 (above). Co nne ctor boa rd, back a bove ). Internal photoFCC ID: HZB-US58-B60 Connector board, front (above).

Attention: Reviewing Engineer The HZB- US58- B60 radio is designed for fixed- mount point -to- multipoint applications. The device is integrated to an array antenna with maximum gain of 19 dBi. The maximum EIRP for the HZB- US58 - B60 as defined in FCC 15.407 is + 36 dBm. For the worst case EIRP of +36dBm, the power density at 1.5 meters from an antenna is: S = EIRP/4πR 2 =0.142 W/m 2 =0.014 mW/cm 2 < 1 mW/cm 2 Where: S = Power density R = distance to the center of radiation of the antenna Therefore, the power density is compliant with the limit for General Population/ Uncontrolled Exposure as specified in rule 1.1310. If you should have any questions regarding this submission, please feel free to contact the undersigned. Yours truly, Caroline Yu Homologation Product Manager Proxim Corporation 1196 Borregas Ave., Sunnyvale, CA 94089-1302, USA Tel: +1 (408) 542-5200, Fax: +1 (408) 542-5300

TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD110 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD111 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD112 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD113 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD114 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD115 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD116 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD117 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD118 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD119 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD120 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD121 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD122 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD123 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD124 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD125 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD126 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD127 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD128 of TD137 Rev.No 1.1 (30 October 2001) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page TD129 of TD137 Rev.No 1.1 (30 October 2001)

TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page 1 of 17 Rev.No 1.2 (22 March 2002) EMC EMISSION - TEST REPORT UNITED STATES STANDARD 47 CFR PART 15, SUBPART E Test Report File No. : SC106727-06 Date of Issue: Revision Date: 11 October 2001 22 March 2002 (Rev. 1.2) Model / Serial No. : 40400-XX 1 / ENGR UNIT #1 Product Type : UNII Radio FCC ID: HZB-US58-B60 2 Applicant : WESTERN MULTIPLEX CORPORATION Manufacturer : WESTERN MULTIPLEX CORPORATION License holder : WESTERN MULTIPLEX CORPORATION Address : 1196 Borregas Avenue : Sunnyvale, CA 94089 Test Result : nn Positive 3 oo Negative Test Project Number Reference(s) : SC106727-06 Total pages - Test Report : 176 (1) 40400-25 (20 megabytes) and 40400-65 (20 to 60 megabytes) (2) References to HZB-U58-B60 in the report should be HZB-US58-B60. (3) See General Remarks. NOTE: All test equipment used during testing is calibrated and traceable to NIST. TÜV Product Service reports apply only to the specific sample tested under stated test conditions. It is the manufacturer’s responsibility to assure the continued compliance of production units of this model. TÜV Product Service, Inc. shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV Product Service, Inc. issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. This report shall not be used by the client to claim product endorsement by NVLAP or any agency of the US government. TÜV Product Service, Inc. and its professional staff hold government and professional organization certifications and are members of AAMI, ACIL, AEA, ANSI, IEEE, NVLAP, and VCCI TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page 2 of 17 Rev.No 1.2 (22 March 2002) DIRECTORY - EMISSIONS Test Report Pages Test Report 1 - 17 Directory 2 Test Regulations 3 General Remarks and Summary 17 Equipment 15.407 (a) Output Power 5 15.407 (a) 26 dB Bandwidth 6 15.407 (a) (5) Power Density 7 15.407 (a) (6) The Ratio of the Peak Excursion of the Modulation Envelope to the Peak Transmit Power 8 15.407 (b) Out of Band Antenna Conducted Emission 9 15.407 (b) Band Edge Antenna Conducted Emission 10 15.205 Radiated Emission in Restricted Bands 11 15.207 AC Conducted Emission 12 15.209 Radiated Emission from Digital Part 13 15.209 Radiated Emission from Receiver L.O. 14 15.407 (c) Automatically Discontinue Transmission 15 Technical Documentation Test Data Sheets and Test Setup Drawing(s) TD1 Appendices Appendix A - Test Setups (Photographs) A1 Appendix B - Product Information Form(s) B1 Appendix C - Change History C1 Appendix D - Supplemental Information D1 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page 3 of 17 Rev.No 1.2 (22 March 2002) EMISSIONS TEST REGULATIONS : The emissions tests were performed according to the following regulations: o - EN 50081-1 / 1991 o - EN 55011 / 1998 o - Group 1 o - Group 2 o - Class A o - Class B o - EN 55014 / 1993 o - Household appliances and similar o - Portable tools o - Semiconductor devices o - EN 55022 / 1987 o - Class A o - Class B o - EN 55022 / 1998 o - Class A o - Class B o - VCCI o - Class A ITE o - Class B ITE n - 47 CFR Part 15, Subpart E n - 15.407 (a) n - 15.407 (a) (5) n - 15.407 (a) (6) n - 15.407 (b) n - 15.205 n - 15.207 n - 15.209 n - 15.407 (c) o - AS/NZS 3548: 1995 o - Class A o - Class B o - CISPR 11 (1997) o - Group 1 o - Group 2 o - Class A o - Class B o - CISPR 22 (1997) o - Class A o - Class B TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page 4 of 17 Rev.No 1.2 (22 March 2002) Environmental Conditions In The Laboratory: Actual Temperature: : 23 °C Relative Humidity: : 50 % Atmospheric Pressure: : 100.0 kPa Power Supply Utilized: Power supply system : 115 V / 60 Hz / 1φ Symbol Definitions: n - Applicable o - Not Applicable TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page 5 of 17 Rev.No 1.2 (22 March 2002) Emissions Test Conditions: Output Power The EMISSIONS measurements were performed at the following test location: o - Test not applicable n - SR-3, Shielded Room, 12’ x 20’ x 8’, Metal Chamber Test Equipment Used : Model No. Prop. No. Description Manufacturer Serial No. Cal Due Date HP8900D 802 Peak Power Meter Hewlett Packard 3607U00653 04/02 Result : n - Pass o - Fail Remarks: TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page 6 of 17 Rev.No 1.2 (22 March 2002) Emissions Test Conditions: 26 dB Bandwidth The EMISSIONS measurements were performed at the following test location: o - Test not applicable n - Western Multiplex Test Facility Test Equipment Used : Model No. Prop. No. Description Manufacturer Serial No. Cal Due Date E4404B -- Agilent Spectrum Analyzer ESA-E Series 9kHz-6.7GHz Agilent Technologies US41191299 06/02 Result : n - Pass o - Fail Remarks: Tested at customer’s test facility. For calculation purpose. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page 7 of 17 Rev.No 1.2 (22 March 2002) Emissions Test Conditions: Power Density The EMISSIONS measurements were performed at the following test location: o - Test not applicable n - Western Multiplex Test Facility Test Equipment Used : Model No. Prop. No. Description Manufacturer Serial No. Cal Due Date E4404B -- Agilent Spectrum Analyzer ESA-E Series 9kHz-6.7GHz Agilent Technologies US41191299 06/02 Result : n - Pass o - Fail Remarks: Tested at cust…

Text truncated - open the document above for the full version.

TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A1 of A14 Rev.No 1.1 (30 October 2001) Appendix A Test Setups (Photographs) NOTE: All photographs are representative of setup for maximum emissions. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A2 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: Output Power and The Ratio of the Peak Excursion of the Modulation Envelope to the Peak Transmit Power TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A3 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: 26 dB Bandwidth Photograph not available. SeeTechnical Documentation, page TD112 for test setup. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A4 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: Power Density Photograph not available. SeeTechnical Documentation, page TD112 for test setup. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A5 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: Out of Band Antenna Conducted Emissions TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A6 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: Out of Band Antenna Conducted Emissions TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A7 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: Band Edge Antenna Conducted Emissions Photograph not available. SeeTechnical Documentation, page TD112 for test setup. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A8 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: Radiated Emission in Restricted Bands and Radiated Emission from Receiver L.O. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A9 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: Radiated Emission in Restricted Bands and Radiated Emission from Receiver L.O. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A10 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: Radiated Emission in Restricted Bands TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A11 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: AC Conducted Emission TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A12 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: AC Conducted Emission TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A13 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: Radiated Emission from Digital Part TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page A14 of A14 Rev.No 1.1 (30 October 2001) Photograph of Test Setup: Radiated Emission from Digital Part TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page B1 of B5 Rev.No 1.1 (30 October 2001) Appendix B Product Information Form(s) TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page B2 of B5 Rev.No 1.1 (30 October 2001) General Equipment Description -- NOTE: This information will be input into your test report as shown below. EUT Description: Point -to-multipoint Base Station with integrated antenna of 18+/-1 dBi gain. EUT Name: UNII Radio FCC ID: HZB-US58-B60 Model No.: 40400-XX Serial No.: ENGR UNIT #1 Product Options: mdl 40400: 20, 30, 40, & 60Mbps; mdl 40400: 20Mbps only Configurations to be tested: mdl 40400: 20, 30, 40, & 60 Mbps Power Requirements Regulations require testing to be performed at typical power ratings in the countries of intended use. (i.e., European power is typically 230 VAC 50 Hz or 400 VAC 50 Hz, single and three phase, respectively) Voltage: 120 VAC (If battery powered, make sure battery life is sufficient to complete testing.) # of Phases: 1 Current (Amps/phase(max)): 2.5 Current (Amps/phase(nominal)): 1 Other: -- Other Special Requirements -- Typical Installation and/or Operating Environment (ie. Hospital, Small Business, Industrial/Factory, etc.) Small business EUT Power Cable Permanent OR n Removable Length (in meters): 1 to 100m Shielded OR n Unshielded Not Applicable TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. SC106727-06 Page B3 of B5 Rev.No 1.1 (30 October 2001) EUT Interface Ports and Cables Interface Shielding Type Type Termination Connector Type Port Termination EXAMPLE: RS232 o n 2 n o Foil over braid Coaxial Metallized 9- pin D-Sub Characteristic Impedance 6 n o Cat5 UTP n n 1 n -- Crimp RJ-45 Cat-5 0 n EUT Software. Revision Level: 4.6 Description: Software can be manually configured by an external computer to use the desired frequency channel and modulation mode (QPSK, 8QAM, or 16QAM). EUT Operating Modes to be Tested -- list the operating modes to be used during test. It is recommended the equipment be tested while operating in a typical operation mode. FCC testing of personal computers and/or peripherals requires that a simple program generate a complete line of upper case H’s. Provide a…

Text truncated - open the document above for the full version.
