HZB-XB92WFR802.11a/n PCIe Module

Warning Statement FCC NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. RF Exposure warning The equipment complies with FCC RF exposure limits set forth for an uncontrolled environment. This device and its antenna(s) must not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. Refering to the multi-transmitter policy, multiple-transmitter(s) and module(s) can be operated simultaneously without C2P. This device is going to be operated in 5.15~5.25GHz frequency range, it is restricted in indoor environment only. Devices will not permit operations on channels 120-132 for 11a and 11n/a which overlap the 5600 - 5650 MHz band. IMPORTANT NOTE: This module is intended for OEM integrator. The OEM integrator is responsible for the compliance to all the rules that apply to the product into which this certified RF module is integrated. Additional testing and certification may be necessary when multiple modules are used. 20cm minimum distance has to be able to be maintained between the antenna and the users for the host this module is integrated into. Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied. Any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. USERS MANUAL OF THE END PRODUCT: In the users manual of the end product, the end user has to be informed to keep at least 20cm separation with the antenna while this end product is installed and operated. The end user has to be informed that the FCC radio-frequency exposure guidelines for an uncontrolled environment can be satisfied. The end user has to also be informed that any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. If the size of the end product is smaller than 8x10cm, then additional FCC part 15.19 statement is required to be available in the users manual: This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. LABEL OF THE END PRODUCT: The final end product must be labeled in a visible area with the following " Contains TX FCC ID: HZB-XB92WFR ". If the size of the end product is larger than 8x10cm, then the following FCC part 15.19 statement has to also be available on the label: This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. IC NOTICE This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This device and its antenna(s) must not be co-located with any other transmitters except in accordance with IC multi-transmitter product procedures. Refering to the multi-transmitter policy, multiple-transmitter(s) and module(s) can be operated simultaneously without reassessment permissive change. Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une autre antenne ou transmetteur. Dynamic Frequency Selection (DFS) for devices operating in the bands 5250- 5350 MHz, 5470-5600 MHz and 5650-5725 MHz Sélection dynamique de fréquences (DFS) pour les dispositifs fonctionnant dans les bandes 5250-5350 MHz, 5470-5600 MHz et 5650-5725 MHz The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel mobile satellite systems. les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux. The maximum antenna gain permitted (for devices in the bands 5250-53…

Text truncated - open the document above for the full version.

Page No. : 5 Proxim Wireless Corporation 1561 Buckeye Drive, Milpitas CA 95035 USA Tel: 408 383 7600 / Fax: 408 383 7680 Ad Hoc Mode Function Declaration Date: 2014/2/12 FCC ID：HZB-XB92WFR To Whom it may concern, We, the undersigned, declare that the EUT (Model Name: XB92HPW) doesn’t have Ad Hoc function on “non-US/Canada frequencies”. Regards, FCC Grantee contact person information. Applicant’s company name : Proxim Wireless Corporation Applicant’s company address : 1561 Buckeye Drive, Milpitas CA 95035 USA Signature : Name and Job Title : Cor van de Water / Sr. Regulatory and Compliance Manager E-Mail : [email protected] Tel. : 408 383 7600

Page No. : 3 Proxim Wireless Corporation 1561 Buckeye Drive, Milpitas CA 95035 USA Tel: 408 383 7600 / Fax: 408 383 7680 Confidential Letter Date: 2014/2/12 Federal Communications Commission Authorization and Evaluation Division FCC ID ：HZB-XB92WFR Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accomparting this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description 4. Tune-up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant’s company name : Proxim Wireless Corporation Applicant’s company address : 1561 Buckeye Drive, Milpitas CA 95035 USA Signature : Name and Job Title : Cor van de Water / Sr. Regulatory and Compliance Manager E-Mail : [email protected] Tel. : 408 383 7600

Page No. : 4 Proxim Wireless Corporation 1561 Buckeye Drive, Milpitas CA 95035 USA Tel: 408 383 7600 / Fax: 408 383 7680 DoC Attestation Letter Date: 2014/2/12 We Proxim Wireless Corporation, as the grantee of this project (FCC ID: HZB-XB92WFR / Brand Name: Proxim / Model No.: XB92HPW), would like to declare that the composite portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedures (Sporton report No.: FD342910-03, FCC Test Firm Registration No.: 187376). The final product shall consequently comply with the FCC rule applied for DoC Procedure. Regards, FCC Grantee contact person information. Applicant’s company name : Proxim Wireless Corporation Applicant’s company address : 1561 Buckeye Drive, Milpitas CA 95035 USA Signature : Name and Job Title : Cor van de Water / Sr. Regulatory and Compliance Manager E-Mail : [email protected] Tel. : 408 383 7600

Page No. : 22 Module Approval Request Letter Subject: Module Approval Date: 2014/3/12 FCC ID: HZB-XB92WFR Dear Reviewer, We, Sporton International Inc., are authorized by Proxim Wireless Corporation to have their state-of-the-art 802.11 a/n PCIe Module approved under module approval authorization. The application of this module is specified to mobile host equipment. The requirements regulated in Public Notice DA00-1407 have been fulfilled and clearly explained below. 1. The requirement of RF shielding: The shielding of the radio portion can be demonstrated in exhibition External Photo. 2. The requirement of buffered inputs: Buffered data inputs stage has been integrated in chip AR9280. 3. The requirement of power supply regulation: The part number of the power regulator is RT8010. 4. The requirements of section 15.203 and 15.204(C): The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition Test Report. 5. The requirement of stand-alone test configuration: Please reference exhibition Test Configuration Photo for the stand-alone test configuration. 6. The requirement of labeling: The instruction on the labeling rule of the end product has been stated in the users manual of this module. Please also see the exhibition Label Sample. 7. The requirement of compliance on specific rule or operating requirements: The required FCC rule has been fulfilled and all the instructions for maintaining compliance has been clearly stated in the Users Manual. 8. The requirement of RF exposure: Please refer exhibition RF Exposure for the compliance of MPE RF exposure rule. Please do not hesitate to contact me for any questions of this request letter. Thank you. Company name : Sporton International Inc. Company Address : No.8, Lane 724, Bo-ai St., Jhubei City, Hsinchu County 302, Taiwan, R.O.C. Signature : Name : Leo Huang Job Title : Manager

Page No. : 2 Proxim Wireless Corporation 1561 Buckeye Drive, Milpitas CA 95035 USA Tel: 408 383 7600 / Fax: 408 383 7680 Power of Attorney Date: 2014/2/12 Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Sporton International Inc. Address : No.8, Lane 724, Bo-ai St., Jhubei City, HsinChu County 302, Taiwan, R.O.C. Name : Leo Huang Job Title : Manager e-mail : [email protected] I am therefore responsible for the contents of the application. Brand name and model type of the specified radio equipment: Proxim / XB92HPW FCC ID: HZB-XB92WFR Product name: 802.11 a/n PCIe Module FCC Grantee contact person information. Applicant’s company name : Proxim Wireless Corporation Applicant’s company address : 1561 Buckeye Drive, Milpitas CA 95035 USA Signature : Name and Job Title : Cor van de Water / Sr. Regulatory and Compliance Manager E-Mail : [email protected] Tel. : 408 383 7600

Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 1 OF 9 TEL : 886-3-327-3456 ISSUED DATE : Feb. 27, 2014 FAX : 886-3-327-0973 Photographs of EUT Ant. 1 Model No. MA-WA55-30 Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 2 OF 9 TEL : 886-3-327-3456 ISSUED DATE : Feb. 27, 2014 FAX : 886-3-327-0973 Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 3 OF 9 TEL : 886-3-327-3456 ISSUED DATE : Feb. 27, 2014 FAX : 886-3-327-0973 Ant. 2 Model No. MA-WB55-20 Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 4 OF 9 TEL : 886-3-327-3456 ISSUED DATE : Feb. 27, 2014 FAX : 886-3-327-0973 Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 5 OF 9 TEL : 886-3-327-3456 ISSUED DATE : Feb. 27, 2014 FAX : 886-3-327-0973 Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 6 OF 9 TEL : 886-3-327-3456 ISSUED DATE : Feb. 27, 2014 FAX : 886-3-327-0973 Ant. 3 Model No. MA-WO55-10NH Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 7 OF 9 TEL : 886-3-327-3456 ISSUED DATE : Feb. 27, 2014 FAX : 886-3-327-0973 Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 8 OF 9 TEL : 886-3-327-3456 ISSUED DATE : Feb. 27, 2014 FAX : 886-3-327-0973 Ant. 4 Model No. GTT-AC-05-001 Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 9 OF 9 TEL : 886-3-327-3456 ISSUED DATE : Feb. 27, 2014 FAX : 886-3-327-0973

Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 1 OF 2 TEL : 886-3-327-3456 ISSUED DATE : Mar. 12, 2014 FAX : 886-3-327-0973 Photographs of EUT Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 2 OF 2 TEL : 886-3-327-3456 ISSUED DATE : Mar. 12, 2014 FAX : 886-3-327-0973

Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 1 OF 2 TEL : 886-3-327-3456 ISSUED DATE : Mar. 12, 2014 FAX : 886-3-327-0973 Photographs of EUT Report No.:342910-03 SPORTON International Inc. PAGE NUMBER : 2 OF 2 TEL : 886-3-327-3456 ISSUED DATE : Mar. 12, 2014 FAX : 886-3-327-0973

Report No.: FR342910-03 FCC ID: HZB-XB92WFR Page No. : B1 of B3 Appendix B. Maximum Permissible Exposure Report No.: FR342910-03 FCC ID: HZB-XB92WFR Page No. : B2 of B3 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Report No.: FR342910-03 FCC ID: HZB-XB92WFR Page No. : B3 of B3 1.3. Calculated Result and Limit For 5GHz UNII Band: Antenna Type : Ommi Antenna (Ant. 3) Max Conducted Power for 802.11n MCS0 20MHz: 14.97dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 8.00 6.3096 14.9698 31.4036 0.039439 1 Complies For 5GHz ISM Band: Antenna Type : Panel Antenna (Ant. 1) Max Conducted Power for 802.11n MCS0 20MHz: 15.63dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 16.00 39.8107 15.6301 36.5606 0.289710 1 Complies Antenna Type : Sector Antenna (Ant. 2) Max Conducted Power for 802.11n MCS0 40MHz: 22.18dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 8.00 6.3096 22.1787 165.1463 0.207405 1 Complies Antenna Type : Ommi Antenna (Ant. 3) Max Conducted Power for 802.11n MCS0 40MHz: 23.89dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 8.00 6.3096 23.8946 245.1668 0.307902 1 Complies

Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A1 of A12 Appendix A. Test Photos Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A2 of A12 1. Photographs of Conducted Emissions Test Configuration Mode. EUT + Ant. 1 FRONT VIEW REAR VIEW Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A3 of A12 SIDE VIEW Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A4 of A12 2. Photographs of Radiated Emissions Test Configuration Test Configuration: 9kHz ~30MHz FRONT VIEW REAR VIEW Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A5 of A12 Test Configuration: 30MHz~1GHz / Mode. EUT + Ant. 1 FRONT VIEW REAR VIEW Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A6 of A12 SIDE VIEW Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A7 of A12 Test Configuration: Above 1GHz / Mode 1. EUT + Ant. 1 FRONT VIEW REAR VIEW Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A8 of A12 SIDE VIEW Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A9 of A12 Mode 2. EUT + Ant. 2 FRONT VIEW REAR VIEW Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A10 of A12 SIDE VIEW Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A11 of A12 Mode 3. EUT + Ant. 3 FRONT VIEW REAR VIEW Report No.: FR342910-03AA FCC ID: HZB-XB92WFR Page No. : A12 of A12 SIDE VIEW
